GE JGSP28CEK Manual

All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
R
Listed by
Underwriters
Laboratories
Dimension and installation information are shown in inches.
JGSP28WEK/CEK/BEK
GE® 30" Slide-In Gas Range
Dimensions and Installation Information
Specification Created 11/04
330228
Models are shipped with color-
matched Rear Filler Strip Kit.
Optional Kits For Slide-In
Electric Ranges
(Available at additional cost)
Lower/Side Trim Kits Accessory Backguards
JXS56 - Lower Trim Kit JXS37 - Backguard
JXS86 - Vertical Side Trim Kit JXS77 - Body Sides
Note: To reduce possiblity of scorching of the side wall
adjacent to the heating elements, it is
recommended a minimum of 6” spacing from
adjacent side walls be allowed for possible extended,
high-heat, no-load operation of heating elements.
Receptacle Location: For all 30” Slide-In Ranges locally
approved flexible service cord or conduit must be
used because terminals are not accessible after range
installation. See shaded area in drawing for location of
electrical outlet box. Recommended outlet locations
allow range to be installed directly against rear wall.
Note: Cabinets installed adjacent to slide-in ranges
must have an adhesion spec of at least 194°.
Installation Information: Before installing, consult
installation instructions packed with product for
current dimensional data.
KW Rating
240V 10.8
208V 8.1
For answers to your Monogram,® GE Profile™ or
GE® appliance questions, visit our website at
ge.com or call GE Answer Center® service,
800.626.2000.
If you are NOT using the
optional Filler or Backguard:
23-3/16
30
If you are using the optional
Filler or Backguard:
25
30

JGSP28WK/CK/BK
HI
LITE
REAR
9
8
7
654
3
2
1
LO
HI
LITE
FRONT
9
8
7
654
3
2
1
LO
HI
LITE
FRONT
9
8
7
654
3
2
1
LO
HI
LITE
OVEN
LIGHT
DELAY
START
ON
OFF
REAR
9
8
7
654
3
2
1
LO
Features and Benefits
• Self clean oven - Conveniently cleans the oven cavity without need of scrubbing
• Precise simmer burner - Offers a low setting of 600 BTUs, ensuring more
temperature control for simmering
• High output burner - Provides a powerful burner output for efficient heat-up
and boiling
• Electronic oven controls - One-touch electronic pads are easy-to-use and allow
for simple oven operation
• Continuous grates - Interlocking grates provide a flat, sturdy surface allowing
easy movement of pans between burners
• Two oven racks - Features a durable construction to help accommodate any size
or type of cookware
• Certifed Sabbath mode - Prepared foods can stay warm in accordance with
kosher law
• Big ClearViewTM window - An extra large clear window makes monitoring the
progress of food easy
• Frameless glass oven door- Offers an easy-to-clean and stylish design that blends
seamlessly into existing cabinetry
• Medium cast grates - Constructed from a durable cast iron material for long-lasting
performance and reliability
• Model JGSP28WEKWW - White on white
• Model JGSP28CEKCC - Bisque on bisque
• Model JGSP28BEKBB - Black on black
JGSP28WEK/CEK/BEK
GE® 30" Slide-In Gas Range
Specification Created 11/04
330228
