GE JGSS05DEMBB Manual

Dimensions and Installation Information (in inches)
Factory set for Natural gas. A set of LP
orifices is included with each range for
LP conversion.
Gas Self-Clean Range Anti-Tip Bracket
(Part No. 205C1714P001)
Electrical Rating: 120V, 60Hz, 5A
Installation Information: Before installing,
consult installation instructions packed with
product for current dimensional data.
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
330229
Specification Created 5/07
JGSS05DEM
GE® 30" Slide-In Gas Range
36
46-3/8
30
36 ±1/4
*Depth to front of closed oven door
29" depth including handle
25-1/4" depth to front top edge of cooktop
26-1/8 *
24
30" FS Gas Ranges-CL
30
8
4
9
2
2-1/2
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off valve
A
B
C
D
E
Installation Information (Dimensions in inches)
Recommended common
area for gas outlet and
electrical outlet
C
L

OVEN
LIGHT
OFF
LO
2
4
6
8
HI
LITE
OFF
LO
2
4
6
8
HI
LITE
OFF
LO
2
4
6
8
HI
LITE
OFF
LO
2
4
6
8
HI
LITE
FRONTFRONT
REAROVENTEMPREAR
500
BROIL
OFF
450
400
JGSS05BEM
Features and Benefits
• Extra-Large Oven Capacity - Provides a large oven interior ideal for cooking
more items at once
• Standard Burners - Provide reliable and consistent heat output that is
adjustable for precise temperature control
• Broiler Drawer - Supplies a concentrated heat for crisping and browning
• ClearView™Window - Features a convenient viewing area to check the
progress of food
• Lift-Up Cooktop - Cooktop lifts up for easy access to porcelain-
enameled subtop
• Interior Oven Light - Supplies light to make viewing the progress of cooking
easy and convenient
• Extra-Large Broiler Pan with Grid
• Two Oven Racks - Feature a durable construction to help accommodate
any size or type of cookware
• Porcelain Oven Door - Offers a scratch-resistant porcelain coating for
easy cleaning
• Standard Porcelain Steel Grates
• Designer-Style Handle - Exudes a clean style that adds to the modern
appearance of the range
• Model JGSS05DEMBB - Black (black door and control panel/black
patterned cooktop)
330229
Specification Created 5/07
JGSS05DEM
GE® 30" Slide-In Gas Range
