PD900DP
GE Profile™ 30" Drop-In Electric Range
Note: Cabinets installed adjacent to slide-in ranges must have an
adhesion spec of at least 194° temperature rating.
Note: To reduce possibility of scorching the side walls above the
countertop when no load is present on burners, it is recommended
that a minimum of 6" spacing from adjacent side wall be allowed for
possible extended, high-heat, element operation.
IMPORTANT: 30" DROP-IN RANGES ARE DESIGNED TO HANG
FROM THE COUNTERTOP. IT DOES NOT REST ON THE FLOOR.
FOR INSTALLATION ALTERNATIVES, REFER TO INSTALLATION
INSTRUCTIONS PACKED WITH PRODUCT.
Optional Kits For Drop-In Electric Ranges (Available At Additional Cost)
Installation information: Before installing, consult installation
instructions packed with product for current dimensional data.
Accessory Backguards
(Attaches to the back of range
as a backguard when unit is installed
in 30" free-standing cutout)
JXS32SS (Stainless) - 4" High
JXS32WW (White) - 4" High
JXS32BB (Black) - 4" High
JXS37WW (White) - 5-1/4" High
JXS37CC (Bisque) - 5-1/4" High
JXS37BB (Black) - 5-1/4" High
Rear Filler Strip
WB07T10680 - Black Filler Strip Assembly
WB07T10681 - White Filler Strip Assembly
WB07T10682 - Bisque Filler Strip Assembly
Specification Created 5/09 220804
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Listed by
Underwriters
Laboratories
Dimensions and Installation Information (in inches)
KW Rating
240V 11.6
208V 8.7
Breaker Size
240V 40 Amps
208V 40 Amps
Acceptable Electrical Outlet
Area Also In Adjacent
Cabinet Or Under Floor
Conduit is 40" long
30" Min.
30" Min.
15" Min.
6" Min.
from walls
7-1/2
2-7/8"
To Front Surface
of Countertop
30
36
27-1/2 25
23-3/16
If necessary,
build upsides
to 1-1/4" thick
to provide
countertop
support
27
20-5/8" Door
Clearance
From Front
Surface of
Countertop
24
31-1/4
30
A/B*
Accessory
Backguard
26-1/2** *JXS37 is 5-1/4" and JXS32 is 4"
(excluding handle)
**Total depth from wall to
front of closed oven door
including handle is 29-1/2.
Acceptable Electrical Outlet
Area Also In Adjacent
Cabinet Or Under Floor
Conduit is 40" long
30" Min.
30" Min.
15" Min.
6" Min.
from walls
7-1/2
2-7/8"
To Front Surface
of Countertop
30
36
27-1/2 25
23-3/16
If necessary,
build upsides
to 1-1/4" thick
to provide
countertop
support
27
20-5/8" Door
Clearance
From Front
Surface of
Countertop
24
31-1/4
30
A/B*
Accessory
Backguard
26-1/2** *JXS37 is 5-1/4" and JXS32 is 4"
(excluding handle)
**Total depth from wall to
front of closed oven door
including handle is 29-1/2.

PD900DP
GE Profile™ 30" Drop-In Electric Range
Features and Benefits
• Self-cleanOven-Self-cleanallowsyoutospareyourselffromthetroubleand
effort it takes to scrub the oven interior. The oven does all the work!
• ElectronicOvenControls-Electronicpadsonthecontrolpanelareeasyto
operate with just a touch
• PowerBoil™Element - Accommodates various-size pots or pans and 3,000 watts
of power speeds the broiling process
• Extra-largeOvenCapacity-Enoughroomtocookanentiremealatonce
•  T r u e T e m p ™Oven System - This feature helps ensure the temperature you set is
the temperature you get, with less variance, to give you the baking and broiling
performance you desire
• RibbonHeatingElements-Powerfulheatbeneaththesmoothsurfaceprovides
high-speed warm-up and even heating
• CeramicGlassCooktop-Asmoothcooktopsurfacemakescleaningquick
and easy
• Six-passBakeElement-Onecontinuousheatingelementdeliversevenheating,
unparalleled baking and evenly cooked food
• WarmMode-Helpskeepjust-cookedfoodswarmandattheideal
serving temperature
• ProofMode-Gentlycirculate100˚Fairallowsdoughtorisequicklyandefficiently
• ModelPD900DPWW-Whiteonwhite(whitedoorandpatternedblackcooktop)
• ModelPD900DPCC-Bisqueonbisque(bisquedoorandpatternedblackcooktop)
• ModelPD900DPBB-Blackonblack(blackdoorandblackpatternedcooktop)
Specification Created 5/09 220804
