GE 18 Operating instructions

GEAppliances.com
N
©
©
Safety Instructions ........ 2-4
Operating Instrt_ons
Additional Features .......... 8
Automatic Icemaker ...... 9, 10
Care and Cleaning ....... 11, 12
Crispers and Pans ........... 7
Getting Started ............. 5
Replacing the Light Bulbs .... 12
Shelves, Bins and
Water Dispenser ............ 6
Installation Instructions
Preparing to Install
the Reli'igerator ............ 13
Reve_sing the Door Swing.. 14-17
Troubleshooting Tips ... 18-20
Normal Operating Sounds . . .18
Consumer Support
Consumer Support ......... 24
Warranty (Canadian) ....... 22
Warranty (U.S.) ............ 23
Writethemodelandserialnumbershere:
Model #
Serial#
Find these numbers on a label on tile
left side, near the top of the freezer
compartment. 162D9629PO05 49-60135-1
Model 18
WR6S1 08-02JR

IMPORTANTSAFETYINFORMATION.
READALLINSTRUCTIONSBEFOREUSING.
WARNING!
Use this appliance only for its intended purpose as described in this Owner's Manual.
SAFETYPRECAUTIONS
When using electrical appliances, basic safety precaufions should be followed, including the following."
NThis refrigerator must be properly installed
and located in accordance with tile Installation
Instructions before it is used.
@Do not allow children to climb, stand or hang
on the shelves in tile refrigerator. They could
damage the refrigerator and seriously injure
themselves.
NDo not touch tile cold surfaces in tile freezer
compartment when hands are damp or wet.
Skin may stick to these extremely cold surfaces.
@Do not store or use gasoline or otber flammable
vapors and liquids in the vicinity of tbis or any
otber appliance.
NDo not refreeze frozen foods which have
thawed completely.
NIn refrigerators witb automatic icemakers, avoid
contact with tbe moving parts of the ejector
mechanism, or witb the heating element located
on the bottom of the icemaker. Do not place
tingers or hands on tbe automatic icemaking
mechanism while the reti-igerator is plugged in.
NKeep fingers out of tbe "pinch point" areas;
clearances between tbe doors and between
the doors and cabinet are necessarily small.
Be careful closing doors when children are
in tbe area.
@Unplug the reti'igerator betore cleaning and
making repairs.
NOTE:Westronglyrecommendthatanyservicingbe
performedbyaqualifiedindividual
NBefore replacing a burned-out light bulb,
unplug tbe refrigerator or turn off power at tbe
circuit breaker or fuse box in order m avoid
contact witb a live wire tilament. (A burned-out
light bulb may break when being replaced.)
NTurning the control to tim 0FFposition does
not remove power to tbe ligbt circuit.
2

GEAppliances.com
ADANGER!RISKOFCHILDENTRAPMENT
PROPERDISPOSALOFTHEREFRIGERATOR
Child entrapment and suffocation are not problems
of the past. .Junked or abandoned refrigerators are
still dangerous...even if they will sit far 'just a few
days." If you are getting rid of your old refrigeratol;
please follow the instructions below to help prevent
accidents.
Before YouThrewAway YourOldRefrigerator
or Freezer:
N Take off the doors.
N Leave the shelves in place so that children
may not easily climb inside.
CFCDisposal
Your old refi'igerator has a cooling system that used
CFCs (chlorofluorocarbons). CFCs are believed to
harm sn'atospheric ozone.
If you are throwdng away your old refrigerator, make
sure the CFC refrigerant is removed far proper
disposal by a qualified servicen lfyou intentionally
release this CFC refrigerant you can be subject to
fines and imprisonment under provisions of
environmental legislation.
USEOFEXTENSIONCORDS
Because of potential safety hazards under certain conditions, we strongly recommend
against the use of an extension cord.
Howevm; ifyou must use an extension cord, it is absolutely necessary that it be a UL-listed (in the United
States) or a CNA certified (in Canada), 3-wire grounding type appliance extension cord having a grounding
type plug and outlet and that the elecnical rating of the cord be 15 amperes (minimum) and 120 volts.
3

IMPORTANTSAFETYINFORMATION.
READALLINSTRUCTIONSBEFOREUSING.
AWARNING!
HOWTOCONNECTELECTRICITY
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
Forpersonal safe_ this appliance must be properly grounded.
The power cord of this appliance is equipped
with a 3-prong (grounding) plug which mates
with a standard 3-prong (grounding) wall oudet
to minimize tile possibility of electric shock hazard
from this appliance.
Have the wall outlet and circuit checked by
a qualified electrician to make sure the outlet
is properly grounded.
Where a standard 2-prong wall oudet is
encountered, it is your personal responsibility
and obligation to have it replaced with a properly
grounded 3-prong wall outlet.
The refrigerator should always be plugged into
its own individual electrical outlet which has
a voltage rating that matches tile rating plate.
This provides tile best performance and also
prevents overloading house wiring circuits which
could cause a fire hazard from overheated wires.
Never unplug your refrigerator by pulling on
the power cord. Always grip plug firmly and pull
sn'aight out from the outlet.
Repair or replace immediately all power cords
that have become frayed or otherwise damaged.
Do not use a cord tllat shows cracks or abrasion
damage along its length or at either end.
When moving the refrigerator away from the
wall, be careful not to roll over or damage the
power cord.
USEOFADAPTERPLUGS(Adapterpl.gsnotpermittedinCanada)
Because of potential safety hazards under certain conditions, we strongly recommend against
the use of an adapter plug.
Howevm; if you must use an adapter, where local
codes permit, a temporaryconnectionmay be made
to a properly grounded 2-prong wall outlet by use
ofa UL-listed adapter a'_ailable at most local
hardware stores.
The larger slot in tlle adapter must be aligned with
the laNer slot in the wall oudet to provide proper
polarity in the connection of the power cord.
When disconnecting tlle power cord from the
adapter, al,a-ayshold tlle adapter in place with one
hand while pulling tlle power cord plug with the
other hand. If this is not done, tlle adapter ground
terminal is very likely to break with repeated use.
If the adapter ground terminal breaks, DO NOT USE
the refrigerator until a proper ground has been
established.
Attachingtheadaptergroundterminaltoa waftoutlet
coverscrewdoesnotgroundtheapplianceunlessthe
coverscrewismetalandnotinsulated,andthewaft
outletisgroundedthroughthehousewiring. Youshould
havethecircuitcheckedbyaquaddedelectricianto make
suretheoutlet isproperlygrounded.
READANDFOLLOWTHISSAFETYINFORMATIONCAREFULLY.
SAVETHESEINSTRUCTIONS
4

Gettingstarted. GEAppliances.com
Initially set the refrigerator and freezer controls at 5. If you want colder or warmer temperatures, adjust the
For refrigerator and freezer, 5 is normal, 9 is coldest, refrigerator temperature first. When satisfied with that
setting, adjust the freezer temperature.
TEMPERATURE CONTROL
0
Checklist
Freezer Control
Tile freezer control maintains the temperature in the freezer compartment.
)Refrigerator Control
Tile refiigerator control maintains the temperature throughout the refrigerator compartment.
Moving the refiigerator control to OFFstops cooling in both areas-refiigerator and freezer--but
does not shut off power to the refrigerator.
After changingthecontrols,allow24 hoursfortherefrigeratortoreachthetemperatureyouhaveset.
OInstall TopHinge Cover
I£not already installed, locate the pl&stichinge
cover inside the parts kit and carefully snap it over
the top hinge.
O) Adjust Rollers SoOoors/_rawer Automatically Close
The re_i_mmr should be elevated slightly at the front so
the doom/drawer will close autom_c_]y when parnally
open. See PreparingtoInstallthe Refrigerato_
TopHingeCoverPartNos.
WB2S56 Bisque
WB2S72 Black
WR2S8 White
5

Abouttherefrigeratorshelves,binsand water dispenser.
Not all features are on all models.
Rearranging the Shelves
Glass and wire shelves in tile refrigerator compartment are adjustable.
TORemove TOReplace
Slide-Out Spillproof Shelf
The slide-out spillproof shelf allows you
to reach items stored behind others. The
special edges are designed to help prevent
spills from dripping to lower shelves.
Makesureyoupushtheshelvesall thewayback
in beforeyouclosethedoor
Adjustable Door Bins
Adjustable bins can easily be carried from
refi-igerator to work area.
Toremove:Tih tile bin up and pull out
on tile molded supports until it comes
completely out of tile doo_:
TOreplace or relocate: Select desired height,
engage the bin in tile molded supports of
tile door and slide the bin in. The bin will
hook in place.
The snuggershelp prevent tipping, spilling
or sliding of small items stored on the door
shelf. Place a finger on either side of the
divider near tile front and move it hack
and forth to fit your needs.
Brita_Water Dispenser
TOinstall:Grasp the dispenser as shown.
Using a slight backv_rd tilt, align tile
mounting brackets on the dispenser with
the support brackets in tile refrigerator doon
Gently slide the dispenser back until it
touches tile door and lower it into the
support brackets.
TOremove:Tilt tile dispenser up at tile front
and pull it fbrv_-ard on the molded support
brackets until it comes completely out of
tile dool:
6

Aboutthecrispersandpans. GEAppliances.com
Fruit and Vegetable Crispers
Adjustable Humidity Crispers
_1' , ,,_ Slide tile control all tile way to the
HIGHsetting m provide high humidity
, , recommended for most vegetables.
Slide the control all the way to tile
LOWsetOng to proxdde lower humidity
levels recommended for most fruits.
Detachable Snack Pan
The slide-out snack pan can be
removed and taken to the sink or
food preparation area.
The pan and the adjustable shelf
to which it attaches can be relocated
at any level.
Crisper and Cover Removal
OToRemoveCrispers:
These drawers can be removed easily by lifting up slightly
while pulling the drawers past the stop location.
When the door cannot be opened enough to pull the drawer
straight out, slide the drawer toward the middle and remove it.
ToRemoveCover:
Remove the glass, then the fi'ame. When replacing the glass,
push the rear edge firmly into the frame.
@ @
iiilii i!iiii:iill i ii !! !iii!!iiiiiiili
i .......
}{ {

Someadditionalfeatures.
Not all features are on all models.
Beverage Rack (onsome models)
This slide-out lack provides storage for
a variety of beverages. The rack and tile adjustable shelf m which it attaches can be relocated to any level.
iiiiii !!i!i! !ii!il
Removable Wine Rack (onsomemodels)
This rock is designed to hold a bottle on
its side.
Freezer Shelves and Baskets
Onswingdoormodelswith threesliding
baskets:Boththe lower and upper baskets
slide out to pro_ilde easy access to foods
stored in the freezer. When the lower
basket is pulled out, the upper basket may
be pushed back to fiwther improve access
to the lower basket.
Onswingdoormodelswith onesliding
basketandtwosplitfixedshelves:
The lower basket slides out to provide
easy access to foods stored in this basket.
The top flfll width fixed shelf provides a
convenient location to store ice cube trays
and ice bucket as well as a variety of foods.
r
Ondrawermodels:The lower basket slides
out when the drawer is opened to provide
easy access to foods stored in this basket.
The upper basket may be pushed back to
fhrther improve access to the lower basket.
The baskets may he easily removed for
cleaning spills or crumbs off the fi-eezer
............................................................floor, or for installing an icemakeE
8

Abouttheautomaticicemaker. GEAppliances.com
A newly-installed refrigerator may take 12-24 hours to begin making ice.
Icemaker Accessory Kit
Kyour refrigerator did not come already
equipped with an automatic icemakm;
an icemaker accessory kit (IM-4 for U.S.
models, or IM4-1 for Canadian models) is
available at extra cost.
Icemaker Installation
A special icemaker mounting block must
be used when installing an icemaken
Directions on how to install tile icemaker
mounting block are included in the
lcemaker Accessory Kit Installation
Instructions.
For U.S. models, the mounting block
is included with the refrigeraton For
Canadian models, the mounting block
is included in the optional icemaker
accessory kit (IM4-1).
Automatic Icemaker (onsomemodels)
The icemaker will produce seven cubes
per cycle--approximately 100-130 cubes
in a 24-hour period, depending on
freezer compartment temperature,
room temperature, number of door
openings and other use conditions.
K the refiigerator is operated before the
water connection is made to the icemakm;
set the power swiwh to 0 (Off).
When the refrigerator has been connected
to the water supply, set the power switch to
I (on). Do not open the door/drawer fbr
approximately 4 hours. This will allow the
freezer to reach the correct operating
temperature for making ice, and will
prevent water from spilling out of the
icemaker mold.
Special Note about the Green Power Light
Even when the icemaker power switch is in
the I (on)position, power to the icemaker
will be interrupted when the freezer
door/drawer is open. This prevents ice
ejecting from the icemaker from missing
the ice bucket and dropping into the back
of the freezm: Because power to the
icemaker is interrupted while the
door/drawer is open, the green power light
on the icemaker will be off To make sure
the icemaker is working properly, press the
freezer light switch located on the upper
right side of the freezer compartment. Tim
power light on the icemaker will come on.
The icemaker will fill with water when it
cools to 15°F (-10°C). A newly-installed
refrigerator may take 12 to 24 hours to
begin making ice cubes.
Throw away the first few batches of ice to
allow the w-ater line to clean
Be sure nothing interferes with the sweep
of the feeler arm.
When the bin fills to the level of the fi?eler
arm, the icemaker will stop producing ice.
It is normal for several cubes to be joined
togethen
ff ice is not used frequently, old ice cubes
will become cloudy, 'taste stale and shrink.
ffice cubes get stuck in the icemake_; set
the power switch to 0 (Off)and remove the
cubes. Set the power switch to I(on)to
restart the icemake_:
After the icemaker has been turned on
again, there will be a delay of about
45 minutes befbre the icemaker resumes
operations.
NOTE:Inhomeswithlower-than-averagewater
pressure,youmayheartheicemakercyclemultiple
timeswhenmakingonebatchofice.
9

Abouttheautomaticicemaker.
A newly-installed refrigerator may take 12-24 hours to begin making ice.
Ice Cube Tray Shelf (on some models)
Some models have a small separate shelf"
for ice cube trays.
Ice Trays and Bucket (on some models)
To remove ice cubes from tile tray, place
tile tray upside down on tile bucket as shown. Press down on tile tray and tile cubes will pop out.
Large Ice Bucket (on some models)
This bucket is requiredwhen using an
aummadc icemaken When installing an
icemakel; the upper left basket must be
removed in order m make room for tile
large ice bucket. If an icemaker is not
installed, the bucket can be removed
to provide more capacity in tile freezer
compartment. For U.S. models, tile bucket
is included with tile reffigeraton For
Canadian models, the bucket is included
in the optional icemaker accessory
kit (IM4-1).
10

Careandcleaning oftherefrigerator. GEAppliances.com
Cleaning the Outside
Keep the outside clean. Wipe with a clean
cloth lightly dampened with mild liquid
dish detergent. Dry and polish with a clean,
soft cloth.
Donotwipetherefrigeratorwith a soileddish
clothor wet towel Thesemayleavea residue
thatcanerodethepaint.Donotusescouring
pads,powderedcleaners,bleachor cleaners
containingbleachbecausetheseproductscan
scratchandweakenthepaintfinish.
The stainless steel panels and door handles
(on some models) can be cleaned with
a commercially availal)le stainless steel
cleaner such as Stainless Steel Magic. TM
Stainless Steel Magic is a_ailable at Ace,
True Value, Servistal; HWI and other
leading stores. It is also availat)le through
GE Parts and Accessories, 800.626.2002, or
_dsit our Website, GEAppliances.com. In
Canada, call 1.888.261.3055 or _dsit our
Website, geappliances.ca. Order part
number WX10X15.
Donotuseappliancewaxorpolishonthe
stainlesssteel
Cleaning the Inside
TOhelp prevent odors,leave an open box of
baking soda in the fresh food and freezer
compamnents.
Unplug the refrigerator before cleaning. If this
is not practical, wring excess moisture out
of sponge or cloth when cleaning around
switches, lights or controls.
Use warm water and baking soda solution--
about a tablespoon (15 ml) of baking soda
to a quart {f 1) of water: This both cleans
and neutralizes odors. Rinse and wipe dry.
After cleaning the door gaskets, apply a
thin layer of paraffin wax to the door
gaskets at the hinge side. This helps keep
the gaskets from sticking and bending out
of shape.
Avoid cleaning cold glass shelves (on
some models) with hot water because
the extreme temperature difference
may cause them to break. Handle glass
shelves carefully. Bumping tempered
glass can cause it to shatter.
TheBrita_WaterDispenser[onsomemodels)
is dishwashersafe.
Donotwashanyotherplasticrefrigeratorparts
in thedishwasher
11

Careand cleaning ofthe refrigerator.
Behind the Refrigerator
Be careflfl when moving the refrigerator
away from tbe wall. All types of floor
coverings can be damaged, particularly
cushioned coverings and those with
embossed surfaces.
Pull the refiigerator straight out and return
it to position by pushing it sn'aight in.
Moving tbe refrigerator in a side direction
may result in damage to the floor covering
or refiigerator.
When pushing the refrigerator back,
make sure you don't roll over the
power cord.
Preparing for Vacation
For long vacations or absences, remove
food and unplug the refrigeratol: Move
the control to tile 0FFposition, and clean
the interior with a baking soda solution
of one tablespoon (15 ml) of baking soda
to one quart (1 1) ofwaten Leave the
doors open.
lfan icemaker is installed, move the
icemaker feeler arm to the STOP (up)
position and shut off the water supply
to the refiigeraton
Preparing to Move
Secure all loose items such as grille,
shelves and drawers by taping them
securely in place to prevent damage.
Besuretherefrigeratorstaysinan upright
positionduringmoving.
Replacing the Light Bulbs
To replace a burned-out bulb, unplug the
refrigerator from its electrical oudet.
In the refrigerator compartmen_ remove
tbe lens cover by gently applying pressure
to tbe back corners of the lens cover and
pulling the cover free from the control
housing. Undrew tbe bulb when cool
and replace it with an appliance bulb
of tbe same or lower wattage.
There is also a light in tbe refrigerator
control panel. To replace it, simply
unscrew the bulb when cool and
replace it with an appliance bulb of
tbe same or lower wattage.
IIIthe freezer compartment, simply undrew
and replace the bulb 'after ensuring tbe
refrigerator is unplugged.
TurningthecontroltotheOFFpositiondoesnot
removepowertothelightcircuit.
12

Installation
Instructions Refrigerat0
Model 18
IQuestions?Call 800.GE.CARES(800.432.2737)or VisitourWcbsiteat:GEAppliances.com
In Canada,call 1.800.361.3400or Visitour Websiteat:geappliances.ca I
BEFORE YOU BEGIN
Read these instructions completely and carefully.
• IMPORTANT - Savethese
instructions for local inspector's use.
•IMPORTANT -Ot,so ,,call
governing codes and ordinances.
• Note to Installer -Besure to leave these
instructions with the Consumes:
• Note to Consumer - Keepthese instructions
for future reference.
•Skill level - Installation of this appliance requires
basic mechanical skills.
•Completion time - Refrigerator Installation
15 minutes
• Proper installation is the responsibility of the
installer.
• Product failure due to improper installation is not
covered under the Warranty.
WATER SUPPLY TO THE ICEMAKER
(ON SOME MODELS)
If the refrigerator has an icemakm, it will have m be
connected m a cold water line. AGE water supply kit
(containing tubing, shutoff valve, fittings and
instructions) is available at extra cost from your dealm,
by visiting our Website at GEAppliances.com (in
Canada at geappliances.ca) or fi'om Parts and
Accessories, 800.626.2002 (in Canada 1.888.261.3055).
REFRIGERATOR LOCATION
•Do not install the refiigeramr where the temperature
will go below 60°F (16°C) because it will not run often
enough to maintain proper temperatures.
• Do not install the refrigerator where the temperature
will go above 100°F (37°C) because it will not perform
properly.
•lnstall the refrigerator on a floor strong enough to
support it when fhlly loaded.
13
PACKAGING TAPE
Remove all packaging tape and peel-off films. These
tapes were added to secure and protect your refi'igerator
during shipping.
CLEARANCES
Allow the following clearances 1or ease of installation,
proper air circulation and plumbing and electrical
connections:
• Sides 1/8" (3 mm)
•Top 1" (25 mm)
•Back 1" (25 mm)
If the refrigerator is against a wall on either side, allow
a minimum of 13/1" (45 mm) between the wall and the
side of the refrigerator to allow for door and handle
clearance.
ROLLERS
The rogers have 2 purposes:
• The rollers are used to level the refrigerator.
NOTE: It is recommended that the refrigerator be
elevated 1/2" (13 mm) in the front. When installing an
icemaker, make sure that the icemaker is completely
level while maintaining the refrigerator incline.
• Rollm_ allow you to move the refrigerator a_a_yfrom
the wall for cleaning.
To adjust the rollers:
O Remove the base grille by pulling it straight out.
Turn the two front roller
acljusting screws dockwlse
to raise the refrigerator,
counterclockwise to lower it.
Use a 3/8" socket wrench,
adjustable wrench or pliers. FrontFl011erAdiustingScrew
NOTE: The refrigerator must be supported by all four
rollel.-s.To test. move the refrigerator to make sure it
does not rock.

Installation Instructions
REVERSING THE DOOR SWING
Read these instructions completely and carefully.
IMPORTANT NOTES
When reversing tile door swing:
• Read the instructions all the w-aythrough before
starting.
• NOTE: Doors on stainless steel models are not
reversible.
• Handle parts carefully to avoid scratching paint.
• Set screws down by their related parts to avoid using
them in the wrong places.
• Provide a non-scratching work surface for the doors.
These instructions are for changing the hinges from
the right side to the left side--if you ever want to
change tile hinges back to the right side, follow these
same instructions and reverse all references to left
and right.
Unplug the refrigerator from its electrical outlet.
Empty all door shelves, induding the dairy compartment.
TOOLS YOU WILL NEED
Phillipsscrewdriver
Maskingtape
7/327 5/16" and3/8"
socketwreach(6-pointsockets
arerecommended)
1-20orT-25TorxDriver,
whicheveryourmodel
requires
Puttyknifeor
thie-Nadescrewdriver
[] REMOVE THE REFRIGERATOR
DOOR (TOP DOOR)
Tape the door shut with masking tape.
Remove the hinge coven With a 5/16" socket
wrench, remove the two screws that hold the top
hinge to the cabinet.
Lift the hinge straight up to free the hinge pin from
tile socket in the top of the done
Remove tape, tilt tile door a_a_yfrom the cabinet and
lift it to free its bottom socket from the hinge pin on
tile center hinge bracket.
Set the door on a non-scratching surface with the
outside tip.
[] REMOVE THE FREEZER DOOR
(BOTTOM DOOR) (For freezer
swing door models only)
Tape the door shut with masking tape.
Remove the hinge pin
with a 7/32" socket Plasticwasher-
wrench.
Remove tape and tilt the Centerhiege
door away from the cabinet, bracket
Remove and ,save the
washer on the hinge pin.
Lift the door sU_ight tip
to free its bottom socket
from the pin in the
bottom hinge bracket.
REMOVE CENTER HINGE PIN
(For models with a freezer drawer)
Remove the hinge pin with a 7/32" socket wrench.
14

Installation Instructions
[] TRANSFER BOTTOM HINGE
BRACKET TO THE LEFT (For
freezer swing door models only)
Pull tile base grille straigbt out to gain access to tile
hinge bracket screws.
Using a 5/16" socket wrench, remove tile hinge
bracket, screws, plastic washer and spacer shim from
tile bottom right side of"the cabinet.
Reinstall tile spacer shim, hinge bracket, screws and
plastic ,a_asherto the bottom left side of tile cabinet.
Remove the cap from tile left end of the base grille.
Install tile cap, supplied inside the kit, on tile right
end of the base grille. Reinstall the base grille and
push it firmly into place.
[] TRANSFER CENTER HINGE
BRACKET TO THE LEFT
Remove tbe center hinge bracket and shim by
removing tbe tbree screws. NOTE: Keep these screws
with tim hinge bracket. They are longer screws and will
be used when installing tim hinge on tbe other side.
f
Remove the tbree painted screws and take vcashers
from the center left side of tbe cabinet. Screw them
into tbe holes on the rigbt side, which were uncovered
above.
Place tbe center hinge bracket and shim over the holes
at tbe center left side of tbe cabinet. Insert the three
screws tbat were removed with the center hinge bracket
at tbe beginning of"Step 4 and tighten securely.
_'gr£
Do not install tbe hinge pin yet.
[] TRANSFER TOP HINGE
TO THE LEFT
Interchange hinge and shim at top right with two
plug buttons at top left of cabinet. Do not tighten
screws on hinge side at this time.
15

Installation Instructions
REVERSING THE DOOR SWING (CONT.)
[] TRANSFER DOOR STOPS
On each door, remove the metal door stop. Use tile
center hinge pin as a guMe to align tile door stop,
supplied inside tile kit, on tile opposite side, after
reversing tile handles.
On freezer drawer models, only dm refiigerator door
has a door stop.
[] PREPARE FREEZER HANDLE
FOR DOOR SWING CHANGE (For
freezer swing door models only)
One of the illustrations below will look like your
freezer door handle.
Remove the four handle mounting screws. Remove
the plug button and plug button retainer and transfer
them to the opposite side. Reinstall handle.
_ [..,._ Handle
Plugbutton _ screwsm°Unting
Plugbutton_
retainer
Remove tile plug button and transfer it to tim
opposite side.
Plugbutton __
NOTE: Make sure tile door stop on tile bottom oftbe
door has been transferred to tile left side of the door
as explained in step 6.
[] TRANSFER REFRIGERATOR
DOOR HANDLE TO THE RIGHT
Remove tbe four handle mounting screws. On some
models, you must first remove the screw covers.
Using a putty knife, remove tbe tour screw hole plug
buttons from the right side of tbe door.
Reinstall tbe plug buttons on dm left side of tbe door:
Align the handle over tbe holes in tbe right side of
tbe door and install the four mounting screws and
screw covers (on some models).
At tbe top of the door, remove the plug button using
a putty knife and reinstall it in tbe top right hand
side hole.
One of the illustrations bdow will look like your
refrigerator door handle.
Hondle :,--P,ogb tteo
Handle
mounting
SCreWS
Handle
door
e.dlt.r-Plug button
NOTE: Make sure the door stop on the bottom of
tbe door has been n'ansferred to tbe lett side of the
door as explained in step 6.
16

Installation Instructions
[] REHANG FREEZER DOOR (For
freezer swing door models only)
Lower bottom socket of freezer door onto pin Oil
bottom hinge bracket. Be sure washer is in place.
Tilt door toward cabinet and gently push door under
center hinge bracket and align with tile hole in tile
center hinge bracket.
Reinstall hinge pin with a 7/32" socket wrench so it
extends tbrougb the hole in tile center hinge bracket
and into socket on top of freezer door.
fil
Hingepie ........._ U
Centerhinge _ _ _'_l
bracket _5,_,_,---_P-_
Freezerd°°r_l I
REPLACE CENTER HINGE PIN
(For models with a freezer drawer)
Reinstall hinge pin with a 7/32" socket wrench
so it extends tbrough tile hole in the center hinge
bracket.
[] REHANG REFRIGERATOR DOOR
Lower bottom socket of the refi'igerator door onto
center hinge pin. Be sure washer is in place.
Tilt door toward cabinet, lifting tim mp hinge so the
pin fits into the socket on top oftbe door.
Tighten the top hinge screw,s after supporting the
door on the handle side and ensuring the gap
between the doors is even all across the front.
Replace tim hinge cover.
17

Normal operatingsounds.
Depending on the placement of the refrigerator in your kitchen,
you may want to place a piece of rubber backed carpet under
the refrigerator to reduce noise.
[]
[] Evaporator Fan.You may hear air being forced through the cabinet
by tile fan.
[] Evaporator.The flow of refrigerant through the e'_aporator may create a
boiling or gll@ing sound.
[]
[]
Defrost Heater. During defrost cycles, water dripping onto the heater may
cause a hissing or sizzling sound. After defrosting, a popping sound may
occur and the evaporator may create a boiling or gurgling sound.
ColdControl& Defrost T'emer.These parts can produce a snapping sound
when turning the refrigerator on or of[ The timer also produces a sound
similar to an electric clock.
[]
[]
WaterPan.Water may be heard running into the drain pan during the
defrost cycle.
Compressor.Modern, high efficiency compressors operate much fgster
than older models. The compressor may have a high pitched hum or
pulsating sound.
[] CondenserFan.You may hear air being forced over the condenser by the fan.
Before youcall forservice...
Troubleshooting tips
Save time and money! Review the charts on the following
pages first and you may not need to call for service.
Possible Causes What ToDo
Refrigerator in defrost cycle. * Wait about 45 minutes for defi'ost cycle to end.
Control in OFFposJltion. • Move the control to a temperature setting.
Refrigerator is unplugged. • Push the plug completely into the outlet.
The fuse is blown/circuit • Replace fuse or reset the breakm:
breaker is tripped.
Rollers need adjusting. •See Preparing to Install the Refrigerator:
18

GEAppliances.com
Possible Causes What To Do
Normal when refrigerator • Wait 24 hours for the refrigerator to completely
is f'n'st plugged in. cool down.
Often occurs when large • This is normal.
amotmts of food are
placed in refrigerator.
Door left open. • Check re see if"package is holding door open.
• Rollers must be properly adjusted so doors/drawers
will close automatically when partially open. See
Preparing to Install the Refrigerato_
Hot weather or frequent •This is normal.
door openings.
Temperature control • See Getting started.
set at the coldest setting.
Temperature controls not set • See Getting started.
cold enough.
Warm weather or frequent • Set the temperature control one step coldel:
door openings. See Getting started.
Door left open. • Check re see if package is holding door open.
• Rollers must be properly adjusted so doors/drawers
will close automatically when partially open. See
Preparing to Install the Refrigerato_
Door left open. • Check re see if package is holding door open.
• Rollers must be properly adjusted so doors/drawers
will close automatically when partially open. See
Preparing to Install the Refrigerato_
Too frequent or too long
door openings.
Food transmitting odor/taste • Wrap foods well.
to ice cubes.
Interior of refrigerator • See Care and cleaning.
needs cleaning.
Door left open. • Check ro see if package is holding door open.
• Rollers must be properly adjusted so doors/drawers
will close automatically when partially open. See
Preparing to Install the Refrigerato_
Freezer control not set • See Getting started.
cold enough.
Foods transmitting • Foods with sn'ong odors should he tightly wrapped.
odor to refrigerator. • Keep an open box of baking soda in the refrigerator;
replace every three months.
Interior needs cleaning. • See Care and cleaning.
19

Before youcall forservice...
Possible Causes What ToDo
Not unustml during • Wipe surface dry and reset the refrigerator control
periods of high humidity, one setting colden
Too frequent or too
long door openings.
Food too dose to air vent. • Move tile food away from the air vent (near the controls).
Refrigerator control is set • Move the refrigerator control re a ,a_armer temperature.
too cold.
Rollers need adjusting. • See Preparing to Install the Refrigerato_
No power at outlet. • Replace fuse or reset the breakel:
Light bulb burned out. • See Replacing the light bulbs.
Hinge and/or gasket needs
lubrication.
This is normal if, after popping • This indicates that there is a good seal on tile freezer
open, the freezer door/drawer door/drawel: If tile freezer door/drawer does not
dosed on its own. automatically close a£ter popping open, then see the
Problem: Door/drawer does not close byitself, above.
Freezer door/drawer is open. • This is normal. Power to the icemaker is interrupted
when the freezer door/drawer is open to prevent ice
from ejecdng and dropping into the back of the freezen
To check if icemaker is working properly, press the
freezer light switch located on tile tipper right side
of tile freezel: The green power light will come on.
Freezer door/drawer was • Clean up spill, then shut tile freezer door/drawer and
opened shortly after icemaker do not open for approximately 4hours. This will allow
was installed, tile freezer to reach the correct operating temperature
for making ice.
Freezer door left open for an • Because of"door openings, freezer could not maintain
extended period, then opened tile correct operating temperature for making ice. Clean
and closed frequently soon after, tip spill, then shut tile freezer door/drawer and do not
open for approximately 4 hours.
Not enough water pressure • Collar type self'piercing ,_ter valves are not
to icemaker water valve, recommended unless a 1/4" hole is predfilled in home
water line. See Installing the WaterLine instructions in
the Icemaker Accessory Kit Installation Instructions.
2O
