GE Profile CustomStyle PSW23PSTSS Manual

"94 SxS Refer
A
Front View
Top View
G
D
C
F
BE
H
Dimensions and Installation Information
*When cap is removed: 69 1/4"
**Width including top caps is 36-3/16".
†Water hook-up fits in back air clearance when calculating
installation depth.
If installed against a wall, allow clearance of 13-15/16" on freezer
side to remove bin.
Clearance required to remove fresh food full-size pan without
disassembling is 18-5/8".
Allow additional space for any necessary leveling adjustments.
Listed by
Underwriters
Laboratories
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Specification Revised 2/07 210342
Overall
Dimensions
Height to top of hinge (in.) A 70-3/4*
Height to top of case (in.) B 68-3/4
Case depth without door (in.) C†24-3/8
Case depth less door handle (in.) D†27-1/4
Case depth with door handle (in.) E†29-11/16
Depth with fresh food door open 90° (in.) F†46
Width (in.) G 36**
Width with door open 90° less door handle (in.) H 41-5/16
Air
Clearances
Each side (in.) 1/8
Top (in.) 1
Back (in.) 1/2
PSW23PST
GE Profile CustomStyle™ENERGY STAR® 23.2 Cu. Ft. Stainless-Wrapped Side-by-Side Refrigerator
with Integrated Dispenser

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
PSW23PST
GE Profile CustomStyle™ENERGY STAR® 23.2 Cu. Ft. Stainless-Wrapped Side-by-Side Refrigerator
with Integrated Dispenser
Listed by
Underwriters
Laboratories
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
Specification Revised 2/07 210342
To Remove Top Caps and Doors on PSW23PST
Step 1: the refrigerator. Remove two screws, one on each side at the rear of the top
cap. Lift off and remove top cap.
Step 2: Open both doors. Remove one screw on each side of the toekick. Pull forward
to remove toekick.
Step 3: On the freezer door, disconnect water line coupler by pushing against the collar
on the left side. Disconnect wire harness.
Step 4: Use a Torx T-20 screwdriver to remove 2 screws holding the top hinge. Carefully
remove hinge while supporting door. Lift door up and off bottom hinge. Remove fresh
food door in the same manner. Note: Do not remove bottom hinges! Door alignment
will be difficult if bottom hinges are removed.
Step 5: Place refrigerator onto a hand truck, upright and against one side.
Move refrigerator to the installation location.
Step 6: Carefully lower doors onto bottom hinges. Be sure to route the tubing and
electrical connector through the bottom hinge. Reinstall top hinges.
Step 7: Place cap over the top of the refrigerator. Reinstall the original screws in the top
and back of the cap.
Step 8: Reconnect the wiring harness and waterline.
Water Line Coupler
1.
366-15A
Hinge Screws
Wire Harness
Toekick Screw
4.
3.
2.

PSW23PST
GE Profile CustomStyle™ENERGY STAR® 23.2 Cu. Ft. Stainless-Wrapped Side-by-Side Refrigerator
with Integrated Dispenser
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
PSW23PSTSS
PSW26PSTSS
DOOR
ALARM
RESET
FILTER
Hold3seconds to Reset
LIGHT
WATER
OUNCE
MEASUREDFILL
OUNCES
LOCK
Hold3seconds
CUPS
CRUSHED CUBED QUICKICE
CUP
Specification Revised 2/07 210342
Features and Benefits
• CustomStyle™Configuration - Offers a built-in look without the built-in expense
• Stainless-Wrapped - Provides stainless steel doors, side panels and top for a truly dramatic look
• ClimateKeeper2™System - Keeps food garden fresh longer, while protecting ice from odor transfer,
with its unique dual-evaporator system
• PreciseFill Technology - Dispenses fresh, filtered water in accurate measurements
• Integrated Dispenser with LED Lighting - Beveled color-matched design gives the dispenser
an attractive, updated look; LED lighting provides long-lasting illumunation
• Electronic Beverage Center - Keeps beverages and treats icy cold and easily accessible
• CustomCool™Technology - Chills in minutes, thaws in hours and keeps foods fresher, longer
• Electronic Controls with Actual Temperature Display - Eliminates guesswork in setting
refrigerator temperatures
• Slide ‘n Store™Full-Extension Freezer Baskets - Extends 12” to 16” beyond the cabinet, providing easy
loading and unloading
• Quick Ice™Option - Makes ice up to 50% faster than normal settings-ideal for entertaining
• TurboCool™Setting - “Revs up” the refrigerator, cooling it quickly after frequent door openings
• Integrated Ice™System - Frees up valuable freezer space. It tilts down, providing easy access
to bulk ice
• Tilt-Out Freezer Door Bins - Move forward for convenient access
• Integrated Shelf Support System - Provides strong, yet flexible support
• Model PSW23PSTSS - Stainless steel
