GE UVP-C3-D27 User manual

UltraView
Series PTZ
integrated PTZ dome camera
Overview
The GE UltraView™ PTZ builds upon the legacy of the CyberDome™
II PTZ line with new, full-featured camera options that help you
choose the best PTZ for your application. The dome works with
multiple vendor systems and can easily be added to an existing
system. Available housings are among the most durable in the
industry and permit the installation of a dome in a wide range of
applications. Choose from two camera modules that feature day/
night, wide dynamic range and image stabilization.
Two camera options are available—a 27x optical zoom and 37x
optical zoom. Both cameras feature true day/night, WDR, 12X
digital zoom and EIS. The WDR feature is ideal for use in high-
contrast lighting conditions and intelligently adjusts the amount
of compensation that is required for an ideal image. Digital zoom
extends the range of the cameras beyond standard optical zoom
lenses. This EIS stabilization feature offers additional image
improvements when the camera is installed in areas subject
to vibration. The integrated shroud conceals camera position.
Cameras can be mounted into housings featuring alarms and
relays for direct wiring to nearby sensors. In addition, firmware
updates are capable through the same interface as the PTZ.
Indoor and outdoor housings are designed to hold up in a variety
of environmental conditions, with standard outdoor housings
achieving an IP66 environmental rating, and can operate
to –40 degrees F/C with the optional heater.
A special day/night light sensor in the dome controls day/night
mode and has multiple thresholds. With a choice to use either the
external sensor or the camera sensor, users can select the one that
provides best settings for a camera’s position. An auto slow shutter
feature on the day/night cameras slows down shutter speed for
better images in dark areas.
UltraView PTZ allows the user to preset up to 128 positions,
repeatable to within ±0.1 degree. Set areas, privacy masks,
and preset and Shadow Tours for maximum surveillance.
Variable-speed pan/tilt lets users move the camera through
surveillance areas at any of 32 speeds, with a maximum
pan/tilt of 340 degrees per second.
The Quick Spin feature lets the camera spin automatically when
the bottom of tilt travel is reached. It can track motion directly under
a camera without losing the picture.
Set specific operations when the camera is powered on or when
no external command is received in a defined period of time.
Operations include calling a preset position or initiating a preset
tour or a Shadow Tour.
Standard Features
• Comprehensive programming choices with advanced options
to meet almost any application
• UltraView PTZ Standard (UVP) models include 4 alarm inputs
and 2 relay outputs
• Shroud offers better concealment of camera position
• 128 preset positions, 4 preset tours, and 4 Shadow Tours
• Control day/night settings through the camera module
or a unit sensor to get best results
• Choose from many options in camera module, housing
and accessories
• Quick Spin feature spins camera 180 degrees automatically
when bottom of tilt travel is reached
• Variable-speed pan/tilt with smoother pan operation
• Site-tied memory allows camera replacement
without reprogramming
• Compatible with CyberDome II housings and accessories
Video Surveillance
UltraView™Series PTZ

GE UltraView™PTZ Options
Available Housings
• Flush-mount ceiling
• Pendant-mount
• Pendant-mount with heater
• Wall-mount
• Heavy-duty
• Heavy-duty with heater
• Rugged pendant
• Rugged pendant with heater
• Pressurized pendant mount
with heater
Available Cameras (NTSC or PAL)
• 27x day/night camera with WDR
and EIS
• 37x day/night camera with WDR
and EIS
Bubble Specifications
Choose from four different acrylic
bubbles or two polycarbonate bubbles,
based on how you wish to balance
discreet camera position and available
light. Polycarbonate bubbles work
with heavy-duty and rugged pendant
housings only.
Bubble
Clear acrylic
Smoke acrylic
Chrome mirrored acrylic
Gold mirrored acrylic
Clear polycarbonate
Smoke polycarbonate
Light loss
none
1/2 f-stop
2 f-stop
2 f-stop
none
1/2 f-stop
General Specifications
• Manual pan speed: 0.5 to 200°/sec
• Manual tilt speed: 0.5 to 120°/sec
• Max. pan/tilt speed: 340°/sec
• Presets: 128 with 24-character title
• Preset tours: 4 tours with
64 presets each
• Shadow tours: 4 with 5 min. each
• Protocols: Digiplex RS422, Impac
RS485, ASCII RS422, Pelco D,
Pelco P, Pelco Coaxitron, Ultrak,
AD 4800, AD Manchester, BBV,
Bosch Biphase, Bosch RS232, KD6,
Panasonic, VCL, Vicon
• Operating temperature, without
heater: 32 to 140°F (0 to 60°C)
• Operating temperature, with heater:
-40 to 140°F (-40 to 60°C)
• Regulatory: FCC, CE, C-Tick, UL, RoHS
Flush-mount ceiling
The indoor flush-mount housing is designed for in-ceiling
applications. A T-bar support kit is included.
Electrical
•Operatingvoltage:24VAC+/-4VAC
•Power:25Wstartup;20Wrunning
Mechanical
•Environmentalenclosure:RatedIP50
•Dimensions:9.5in.dia.x9.6in.high(241x243mm)
•Weight(housing,PTZ):6lb.,8.5oz.(2.96kg)
•Construction:GrayABSplastic
Pendant-mount and pendant-mount with heater
The weatherproof pendant-mount housing can be used for indoor
or outdoor applications. Both the pendant-mount and pendant-
mount with heater and fan are rated IP66. With the heater/fan
option, the housing can be used in temperatures to -40°F (-40°C).
Electrical
•Operatingvoltage:24VAC+/-4VAC
•Power:25Wstartup;20W running
•Power,withheater:93Wstartup;45W running
Mechanical
•Environmentalenclosure:RatedIP66
•Dimensions:9.5in.dia.x11.9in.high(241x303mm)
•Weight(housing,heater,PTZ):6lb.,8.5oz.(2.96kg)
•Construction:GrayABSplastic
Wall-mount and wall-mount with heater
The weatherproof wall-mount housing can be used for indoor
or outdoor applications. The wall arm is constructed of cast
aluminum. Both the wall-mount and wall-mount with heater
and fan are rated IP66. With the heater option, the housing
can be used in temperatures to -40°F (-40°C).
Electrical
•Operatingvoltage:24VAC+/-4VAC
•Power:25Wstartup;20Wrunning
•Power,withheater:93Wstartup;45Wrunning
Mechanical
•Environmentalenclosure:RatedIP66
•Dimensions:9.5in.dia.x9.6in.high(241x243mm)
•Weight(housing,heater,PTZ):8lb.,8.5oz.(3.87kg)
•Construction:GrayABSplastic
Heavy-duty and heavy-duty with heater
The weatherproof heavy-duty housing is designed to hold up under
tough outdoor use. Both the heavy-duty and heavy-duty with heater
and fan come with adjustable wall-mount brackets. With the heater
option, the housing can be used in temperatures to -13°F (-25°C).
Electrical
•Operatingvoltage:24VAC+/-4VAC
•Power:25Wstartup;20Wrunning
•Power,withheater:153Wstartup;66Wrunning
Mechanical
•Dimensions:10.56in.widex9.64in.high(268x236mm)
•Weight(housing,heater,PTZ):13lb.,8oz.(6.12kg)
•Construction:Castaluminum
Rugged pendant and rugged pendant with heater
The weatherproof rugged pendant housing is for outdoor applications
that require tamper resistance. Both the rugged pendant and
rugged pendant with heater and fan are rated IP66. With the heater
option, the housing can be used in temperatures to -40°F (-40°C).
Electrical
•Operatingvoltage:24VAC+/-4VAC
•Power:25Wstartup;20Wrunning
•Power,withheater:153Wstartup;66Wrunning
Mechanical
•Environmentalenclosure:RatedIP66
•Dimensions:9.5in.dia.x11.1in.high(241x283mm)
•Weight(housing,heater,andPTZ):12lb.,8.5oz.(5.68kg)
•Construction:Castaluminum
10.44 in. (265 mm)
7 in. (177.8 mm)
10 in. (254 mm)
10.56 in. (268 mm)
9.64 in. (244.9 mm)
6.85 in.
(174 mm)

Ordering Information
First, choose the housing, bubble, and camera that you want.
UV
Model
PS Select
P Standard
Housing
F Flush-mount
H Pendant-mount
HE Pendant-mount with heater and fan
C Wall-mount
CE Wall-mount with heater and fan
D Heavy-duty
DE Heavy-duty with heater and fan
P Wall-mount pendant pressurized
housing
PE Pendant pressurized housing
R Rugged pendant
RE Rugged pendant with heater and fan
Dome Bubble
2 Bronze acrylic
(pressurized only)
3 Clear acrylic
4 Smoke acrylic
Chrome mirrored
acrylic (a la carte only)
Gold mirrored
acrylic (a la carte only)
8 Clear polycarbonate†
9 Smoke polycarbonate†
†Available for F, D, DE, R,
and RE housing options
PTZ Camera Assembly
D27N 27x day/night camera, NTSC
D27P 27x day/night camera, PAL
D37N 37x day/night camera, NTSC
D37P 37x day/night camera, PAL
Please ask your Interlogix™
sales representative for all
available options.
Then, choose mounting accessories from the list below.
GEA-102
Cast-aluminum wall-mount arm
•Weight:2.0lb.(0.91kg)
•Material:Aluminum
•Finish:Gray
GEA-104
Parapet swing-arm mount
•Weight:7.75lb.(3.52kg)
•Material:Aluminum
•Finish:Graypowdercoat
GEA-105
Corner-mount adapter
•Weight:1.9lb.(0.86kg)
•Material:Aluminum
•Finish:Graypowdercoat
GEA-106
Pole-mount adapter
•Weight:14.4oz.(408g)
•Material:Aluminum
•Finish:Graypowdercoat
GEA-107
Roof-mount adapter
•Weight:1.2lb.(0.54kg)
•Material:Aluminum
•Finish:Graypowdercoat
IDH-5200
Sun-shield for standard and rugged housings
•Dimensions:10.75in.(273mm)x7.51in.(191mm)
•Material:ABSplastic
•Finish:Graypowdercoat
< GEA-102
GEA-104 >
< GEA-105
^ GEA-106
IDH-5200 >
< GEA-113
GEA-114 >
GEA-113
Ceiling panel
•Weight:3.2oz.(91g)
•Material:Steel
•Finish:Whiteenamel
GEA-114
T-bar support kit
•Weight:6.4oz.(181g)
•Material:Steel
•Finish:Galvanized
Parapet-capping brackets
•Material:0.25in.aluminum
•Finish:Graypowdercoat
GEA-108: Corner, narrow
•6to12in.(152to305mm)
•Weight:7lb.(3.18kg)
GEA-109: Corner, wide
•12to17in.(305to432mm)
•Weight:8lb.(3.63kg)
GEA-110: Straight, narrow
•6to12in.(152to305mm)
•Weight:14lb.(6.4kg)
GEA-111: Straight, wide
•12to17in.(305to432mm)
•Weight:15lb.(6.8kg)
< brackets
Camera specifications
Modules 27x day/night with WDR 37x day/night with WDR
Sensor 1/4 in. CCD 1/4 in. CCD
Zoom Optical27x;Digital12x Optical37x;Digital12x
Resolution 540 TVL 540 TVL
Synchronization Internal/line lock Internal/line lock
Lens 3.25mm(wide)to88mm(tele);F1.5-3.8 3.5mm(wide)to129mm(tele);F1.5-4.1
Sensitivity 0.6 lux at 1/60 sec NTSC or 1/50 sec PAL 0.6 lux at 1/60 sec NTSC or 1/50 sec PAL
Sensitivity, ICR-off 0.01 lux at 1/4 sec NTSC or 1/3 sec PAL 0.01 lux at 1/4 sec NTSC or 1/3 sec PAL
Electronic
Shutter Speed
1/60to1/90,000sec,NTSC;
1/50to1/90,000sec,PAL
1/60to1/90,000sec,NTSC;
1/50to1/90,000sec,PAL
Video Output 1.0 V p-p 1.0 V p-p
< GEA-107

010-3374 2010/11 (64003)
North America
T 888-437-3287
Asia
T852-2907-8108
F 852-2142-5063
Australia
T61-3-9239-1200
F61-3-9239-1299
Europe
T 32-2-725-11-20
T 32-2-721-40-47
Latin America
T561-998-6100
T561-994-6572
interlogix.com
utcfireandsecurity.com
Specifications subject to change without notice.
© 2010 Interlogix, A UTC Fire & Security Company
All rights reserved.
is a trademark of General Electric Company and
is used under license to UTC Fire & Security,
9FarmSpringsRoad,Farmington,CT06034-4065
