GE Profile WPGT9350 Operating instructions

Safety Instructions . . . . . . . . . . 2, 3
Operating Instructions
Controls . . . . . . . . . . . . . . . . . . . . . .4
Cycle Options . . . . . . . . . . . . . . . . .6
Help Feature . . . . . . . . . . . . . .13, 14
Troubleshooter . . . . . . . . . . . . . .13
Loading and Using
the Washer . . . . . . . . . . . . . . . .17, 18
“My Cycles” Feature . . . . . . . . .11, 12
Other Features . . . . . . . . . . . . .15, 16
Quick Start Feature . . . . . . . . . . . . .5
Stain Inspector . . . . . . . . . . . . . .7, 8
Summary Screen . . . . . . . . . . . .9, 10
Installation Instructions
Before You Begin . . . . . . . . . . .19–21
Step-by-Step Instructions . . . . .21–24
Switching the Washer and
Dryer Backsplashes . . . . . . . . .25–28
Troubleshooting Tips . . . . . .29, 30
Consumer Support
Consumer Support . . . . . Back Cover
Warranty . . . . . . . . . . . . . . . . . . . . 31
www.GEAppliances.com
Washers
3828EA3023 175D1807P415 49-90151 03-03 JR
Profile
Write the model and serial
numbers here:
Model # ______________
Serial # ______________
You can find them on the
rear cover of the washer
backsplash.
WPGT9350
Owner’s Manual
and Installation
Instructions

2
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING.
WATER HEATER SAFETY
Under certain conditions, hydrogen gas may be produced in a water heater that has not been used for two
weeks or more. Hydrogen gas can be explosive under these circumstances.
If the hot water has not been used for two weeks or more, prevent the possibility of damage or
injury by turning on all hot water faucets and allowing them to run for several minutes. Do this
before using any electrical appliance which is connected to the hot water system. This simple
procedure will allow any built-up hydrogen gas to escape. Since the gas is flammable, do not
smoke or use an open flame or appliance during this process.
WARNING! For your safety, the information in this manual must be followed to minimize the risk of fire or
explosion, electric shock, or to prevent property damage, personal injury, or loss of life.
PROPER INSTALLATION
•Install or store where it will not be exposed
to temperatures below freezing or exposed
to the weather.
•Properly ground washer to conform with all
governing codes and ordinances. Follow
details in Installation Instructions.
YOUR LAUNDRY AREA
•Keep the area underneath and around your
appliances free of combustible materials such
as lint, paper, rags, chemicals, etc.
•Close supervision is necessary if this
appliance is used by or near children. Do not
allow children to play on, with or inside this
or any other appliance.
This washer must be properly installed and located in accordance with the Installation Instructions before it
is used. Installation Instructions are included in the back of this manual.

3
READ AND FOLLOW THIS SAFETY
INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS.
WHEN USING THE WASHER
•Use this appliance only for its intended
purpose as described in this Owner’s Manual.
•Never reach into washer while it is moving.
Wait until the machine has completely
stopped before opening the lid.
•Do not mix chlorine bleach with ammonia
or acids such as vinegar and/or rust remover.
Mixing different chemicals can produce a
toxic gas which may cause death.
•Do not wash or dry articles that have been
cleaned in, washed in, soaked in, or spotted
with combustible or explosive substances
(such as wax, oil, paint, gasoline, degreasers,
dry-cleaning solvents, kerosene) which may
ignite or explode. Do not add these
substances to the wash water. Do not use or
place these substances around your washer or
dryer during operation.
•The laundry process can reduce the flame
retardancy of fabrics. To avoid such a result,
carefully follow the garment manufacturer’s
wash and care instructions.
•To minimize the possibility of electric shock,
unplug this appliance from the power supply
or disconnect the washer at the household
distribution panel by removing the fuse or
switching off the circuit breaker before
attempting any maintenance or cleaning.
NOTE: Pressing START/STOP or POWER
does NOT disconnect the appliance from
the power supply.
•Never attempt to operate this appliance
if it is damaged, malfunctioning, partially
disassembled, or has missing or broken
parts, including a damaged cord or plug.
WHEN NOT IN USE
•Turn off water faucets to relieve pressure on
hoses and valves and to minimize leakage if a
break or rupture should occur. Check the
condition of the fill hoses; they should be
replaced every 5 years.
•Before discarding a washer, or removing it
from service, remove the washer lid to prevent
children from hiding inside.
•Do not attempt to repair or replace any
part of this appliance unless specifically
recommended in this Owner’s Manual, or
in published user-repair instructions that you
understand and have the skills to carry out.
•Do not tamper with controls.
WARNING! For your safety, the information in this manual must be followed to minimize the risk of fire or
explosion, electric shock, or to prevent property damage, personal injury, or loss of life.
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING.

P
O
W
E
R
M
Y
C
Y
C
L
E
S
B
A
C
K
H
E
L
P
START
STOP
H
O
M
E
Washer Control Panel
www.GEAppliances.com
Features of
the washer
control
panel
1 POWER. Press to “wake up” the display. If
the display is active, press to put the washer
into standby mode. You may also press the
Touch Screen or any button to “wake up”
the display.
NOTE: Pressing POWER does not
disconnect the appliance from the power
supply.
2 MY CYCLES. Press to use, create, rename,
modify or delete custom wash cycles.
3 BACK. Press to return to the previous
screen.
4 TOUCH SCREEN. Press the graphics on
the interactive display to use the washer
features.
Do not use sharp objects to press the Touch
Screen.
NOTE: If the washer is inactive for 5
minutes, the Touch Screen will go into
standby mode, and the display will be dark.
Press the Touch Screen or any button to
“wake up” the display.
5 HOME. Press to return to the “TOUCH TO
SELECT WASH CYCLE” screen (Home
Screen).
6 START/STOP. Press to start a wash cycle.
If the washer is running, pressing once will
pause the washer. Press again to restart the
wash cycle.
NOTE: If the washer is paused and the
cycle is not restarted within five minutes,
the washer will enter standby mode and the
current wash cycle will be canceled.
7 HELP. Press to set machine preferences, to
find help using the Touch Screen or to find
troubleshooting tips for common washer
problems.
Throughout this manual, features and appearance may vary from your model.
4
WARNING – To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY
INSTRUCTIONS before operating this appliance.

5
Quick Start
www.GEAppliances.com
Getting
Started
If the Touch
Screen is
dark, press
POWER or
the Touch
Screen to
access the
wash cycles
menu.
Loosely load clothes no higher than the top
row of holes in the washer tub. Overloading
may reduce washer efficiency and possibly
increase wrinkling.
Add a low-sudsing, high-efficiency detergent.
Add diluted fabric softener, bleach or wash
boost additives as desired.
Select one of the five wash methods from the
Home Screen:
• Press BY COLOR to wash according to fabric
color.
• Press BY GARMENT to wash according to
clothing type.
• Press BY FABRIC to wash according to fabric
type.
• Press SPECIAL CYCLES to wash non-garment
items, or to select a rinse and spin or spin-
only cycle.
• Press STAIN INSPECTOR to wash items with
specific types of stains.
After selecting a wash method, use the Touch
Screen to select a specific wash cycle to match
your load.
Change any of the automatic settings, if
desired, by pressing the Touch Screen
and following the on-screen instructions.
By changing the settings you can:
• Remove heavier soil.
• Change the water temperature.
• Change the wash action to Vigorous, Normal,
Delicate or Hand Wash.
• Set a Delay Start, Extended Spin, Presoak or
Extra Rinse, or change the End-of-Cycle
Signal volume.
• Adjust time settings.
Close the lid and press START.
The washer will not fill unless the lid is closed.
After you press START, a Cycle Status screen
will appear to indicate what stage of the cycle
the washer is in and the time remaining in
the cycle.
BY COLOR BY GARMENT
TOUCH TO SELECT WASH CYCLE
BY
FABRIC SPECIAL
CYCLES STAIN INSPECTOR
SUMMARY SCREEN
0:54
TIME
TEMP
OPTIONS
SOIL
NORMAL
WASH ACTION
CYCLE
COTTONS
START
STOP
Home Screen

6
Wash Cycles
www.GEAppliances.com
Washing by
Color
If the Touch Screen is dark, press POWER or the Touch Screen to access the wash cycles menu.
The default cycle settings are based on standard load types. Always follow the fabric manufacturer’s
care label when laundering.
• Bright/Dark
Colors
• Light Colors
• Mixed Colors
• New Colors
• Whites
BY COLOR
Washing by
Garment
Type
• Athletic Wear
• Blouses
• Delicates
• Dress Shirts
• Easy Care
• Everyday
Wear/Casual
• Jackets/Coats
• Jeans
• Khakis
• Knits
• Lingerie
• Mixed Garments
• Play Clothes
• Sweaters
• Swimwear
• Underwear
• Silks (Washable)
BY GARMENT
Select By Color to wash loads sorted by color.
COLOR CYCLES include:
Select By Garment to wash loads sorted by garment type.
GARMENT CYCLES include:
Washing by
Fabric Type
• Blends
• Cottons
• Delicates
• Knits
• Polyester
• Silks (Washable)
BY
FABRIC
Select By Fabric to wash loads sorted by fabric type.
FABRIC CYCLES include:
Washing
Using the
Special
Cycles
• Blankets (Cotton)
• Blankets (Other)
• Comforter
• Super Clean
• Pet Bedding
(Washable)
• Handwash
Woolite®HE
• Rinse and Spin
• Sheets
• Sneakers
• Spin Only
• Throw Rugs
(Washable)
• Towels
• Quick Wash
SPECIAL
CYCLES
Select SPECIAL CYCLES to wash loads of nongarment items or to
select a rinse and spin or spin-only cycle.
SPECIAL CYCLES include:

7
Washing
Using the
Stain Inspector
The Stain Inspector provides pretreatment
tips and optimum washing for specific types
of stains.
You select the specific stain, fabric type and
color, and the washer creates the wash cycle
for treating the stain.
Stain Inspector
www.GEAppliances.com
1 Press STAIN INSPECTOR.
2 Read and follow the instructions on the
Touch Screen before treating the fabric.
3 Select FOOD/DAIRY/COOKING from
the list of stain categories and select
CHOCOLATE from the list of stains.
You can find additional stain categories and
stains by pressing MORE in the lower right
corner of the Touch Screen.
4 Press the HELP button to find pretreatment
information for the specific type of stain.
5 Select COTTONS from the list of fabric
types, and select WHITES from the list
of colors.
6 Fill the detergent tray with a low-sudsing,
high-efficiency liquid detergent such as
Tide®HE. Fill the Wash Boost tray with
the proper pre-treatment additive.
7 Place the stained garment(s) in the washer
first; then add the rest of the load. For best
stain removal, only wash items with stains
matching your selection.
8 Press START.
The washer will run a Wash Boost presoak cycle
prior to the main wash cycle.
NOTE: For some stain cycles, the water
temperature for the presoak cycle may not be
the same as the water temperature for the main
wash cycle.
IMPORTANT: Check to make sure the stain
is completely removed before placing the
garment in the dryer.
STAIN
INSPECTOR
Example: Washing a chocolate-stained, white cotton shirt
OK
1) REFER TO FABRIC CARE LABEL FOR
INSTRUCTIONS. USE HELP FUNCTION
FOR ADDITIONAL STAIN TIPS
2) TEST STAIN REMOVAL TIPS ON HIDDEN
AREA OF FABRIC
3) DO NOT PUT STAINED ITEM INTO DRYER
(STAIN MAY BE SET INTO FABRIC)
BEFORE
TREATING
FABRIC
CHOCOLATE
- ADD AN ENZYME CONTAINING
DETERGENT, LIKE LIQUID TIDE(R) TO THE
'WASH BOOST' DISPENSER AND USE A
HIGH EFFICIENCY DETERGENT IN THE
DETERGENT DISPENSER.
MORE
CHOCOLATE
BUTTER
MARGARINE
MAYONNAISE
SALAD
DRESSING
TOMATO-BASED
FOOD/DAIRY/COOKING
Detergent Tray
Wash
Boost Tray

8
Stain Selections
Stain Inspector
www.GEAppliances.com
Below is a listing of the stain selections
available on the washer Touch Screen. For
additional information on handling these types
of stains, visit the Tide®Stain Detective at
www.tide.com/staindetective.
Beverages
• Alcoholic beverages
• Coffee
• Fruit juice
• Kool-Aid®
• Milk
• Soda
• Tea
• Water
• Wine
School/Office/Home
• Adhesive tape
• Crayon
• Glue (synthetic)
• Glue
(white/common)
• Ink
• Mildew
• Paint (water-based)
• Paint (oil-based)
• Pencil mark
• Rubber cement
• Wite-out®
Food/Dairy/Cooking
• Animal fat
• Baby formula
• Butter/margarine
• Chocolate
• Cooking oil
• Cream/cheese sauce
• Egg
• Gravy
• Grease
• Mayonnaise
• Milk
• Mustard
• Pudding
• Salad dressing
• Tomato-based
• Vegetable oil
Heavy Oils
• Motor oil
• Ointment/salve
Outdoor
• Dingy white socks
• Grass
• Mud/dirt
• Clay
• Rust/iron
Personal
• Baby stains
• Blood
• Feces
• Perspiration
• Urine
• Vomit
Cosmetics
• Chap Stick®
• Deodorant/
antiperspirant
• Lipstick
• Lotions
• Makeup (oil-based)
• Makeup (water-
based)
Specialty Stains
• Adhesive tape
• Asphalt/tar
• Glue (synthetic)
• Ink
• Pine sap
• Rubber cement
• Silly Putty®
Waxes
• Candle wax
• Chap Stick®
• Crayon
Stain Selections

9
Summary Screen
www.GEAppliances.com
SUMMARY SCREEN
0:54
TIME
TEMP
OPTIONS
SOIL
NORMAL
WASH ACTION
CYCLE
COTTONS
About the
Summary
Screen
After selecting a wash cycle, the Summary
Screen displays the automatic settings for the
cycle you have chosen. You can adjust these by
touching the screen location for any of the
settings shown.
If you change any of the automatic settings,
you can save the new settings as a custom
“ My Cycle” by pressing the MY CYCLES button
and choosing SAVE CURRENT SETTINGS.
SOIL LEVEL
MORE SOIL
LESS SOIL
HEAVY
LIGHT
OK
Changing
the Soil
Level
Changing the soil level increases or decreases
the wash time to remove different amounts of
soil.
To change the soil level, touch SOIL on the
Touch Screen; then use the arrows to select
more or less soil. Press OK when you have
reached the desired setting.
TEMPERATURE
HIGHER
LOWER
COOL
OK
Changing
the Wash
Temperature
Changing the temperature changes the wash
and presoak temperatures only. The final rinse
will always be a cold rinse.
Follow the fabric manufacturer’s care label
when selecting the wash temperature.
To change the wash temperature, touch the
TEMP pad on the Touch Screen; then use the
arrows to select a higher or lower temperature.
Press OK when you have reached the desired
setting.
WASH ACTION
NORMAL
VIGOROUS DELICATE
HAND
WASH
Changing
the Wash
Action
Changing the wash action changes the wash and
spin speeds of the cycle.
Always follow the fabric manufacturer’s care
label when changing the wash action.
To change the wash action, touch WASH
ACTION on the Touch Screen; then select the
desired setting.
Typically, slower spin speeds result in less water
removed from clothes.
Wash Action Wash Speed Spin Speed
Normal Medium Fast
Vigorous Fast Fast
Delicate Slow Slow
Hand Wash* Extra Slow Extra Slow
*Use a low-sudsing, high-efficiency, gentle liquid detergent
such as Woolite®HE.

10
Summary Screen
www.GEAppliances.com
OPTIONS
ADDITIVES
MIN15
PRE
SOAK
DELAY
START HR
1
EXTENDED
SPIN
SIGNAL
EXTRA
RINSE
OK
About
the Wash
Options
The Wash Options allow you to set options
for the current wash cycle only. After you have
made all desired changes, press OK.
Delay Start – Use to delay the start of your
washer. Press DELAY START to change the
delay time.
Presoak – Soaks the clothes before beginning
the wash cycle. Press PRESOAK to change the
soaking time.
Additives – Appears ONLY AFTER a presoak
has been selected. Uses the contents of the
Wash Boost dispenser tray for a presoak.
When selected, the washer will drain after the
presoak and fill again for the wash cycle. Press
ADDITIVES to specify if you will NOT be using
a Wash Boost additive or if you do not want the
washer to drain after presoak.
Extra Rinse – Adds an additional cold rinse to
the end of the wash cycle.
Signal – Alerts you that the cycle is complete.
The clothes should be removed when the
beeper goes off so wrinkles won’t set in. Touch
SIGNAL to select the volume or to turn the
beeper off. The new volume will be saved as
the default setting.
Extended Spin – Increases the length of the
spin time to extract more water from your
clothes.
NOTE: The water level will vary depending
on the load size and type. The washer uses
adaptive filling and load sensing to provide
the appropriate water level for effective and
efficient wash performance and energy usage.
ADJUST TIME SETTINGS
EXTENDED SPIN
CYCLE TIME DELAY TIME
Adjusting
the Time
Settings
You can adjust the length of the wash cycle by
changing the cycle time, adding a Delay Start
or adding an Extending Spin.
Cycle Time – Press CYCLE TIME; then use the
arrows to select more or less time.
Delay Time – Use to add a Delay Start to the
beginning of the wash cycle. Press DELAY
START; then set the DELAY START time in
the OPTIONS menu.
Extended Spin – Increases the length of the
spin time to extract more water from your
clothes. Press EXTENDED SPIN; then select
EXTENDED SPIN from the OPTIONS menu.
NOTE: After the wash cycle begins, you will
not be able to change the Cycle Time or Delay
Time. The washer will beep twice if you try to
change the times after the cycle begins.
YES NO
ARE YOU USING
PRESOAK ADDITIVES ?

11
“My Cycles”
www.GEAppliances.com
About the
“My Cycles”
Feature
The “My Cycles” feature allows you to create,
store and reuse up to 6 custom cycles. Create
your own cycles from scratch, or adjust the
settings of a predefined wash cycle, then save
for one-touch recall.
Creating
and Using a
“My Cycle”
You can create “My Cycles” two ways, by either
modifying a predefined wash cycle or creating a
cycle from your own combination of settings
and options.
To build your own “My Cycle” from the
Home Screen:
1Press the MY CYCLES button.
2Select CREATE from the Touch Screen
menu.
3Choose whether you want to modify a
predefined cycle or create a new cycle.
4If you are modifying a predefined cycle,
select the wash cycle you wish to modify.
5Change any of the automatic settings and
select any options.
6Press SAVE on the Touch Screen.
7Using the keypad on the Touch Screen, type
the name of your “My Cycle” and press OK.
To begin using your new “My Cycle” right away,
select it from the Touch Screen menu and press
START.
To save a current cycle as a “My Cycle” from the
Summary Screen:
1After setting a wash cycle, or after a wash
cycle has just completed, press the MY
CYCLES button.
2Select SAVE CURRENT SETTINGS from the
Touch Screen menu.
3Using the keypad on the Touch Screen, type
the name of your “My Cycle” and press OK.
To begin using your new “My Cycle” right away,
select it from the Touch Screen menu and press
START.
To use a “My Cycle” from the Home Screen:
1Press the MY CYCLES button.
2Select USE from the Touch Screen menu.
3Select the cycle name from the Touch Screen
menu.
4Change any of the automatic settings and
select any options.
5Press START.
MY CYCLES
CREATE RENAME
USE MODIFY
DELETE SAVE CURRENT
SETTINGS
M
Y
C
Y
C
L
E
S

12
“My Cycles”
www.GEAppliances.com
Modifying,
Renaming
or Deleting
a “My
Cycle”
To modify the settings of a “My Cycle” from the
Home Screen:
1Press the MY CYCLES button.
2Select MODIFY from the Touch Screen
menu.
3Select the cycle name from the Touch Screen
menu.
4Change any of the automatic settings and
select any options.
5Press SAVE on the Touch Screen.
To rename a “My Cycle” from the Home Screen:
1Press the MY CYCLES button.
2Select RENAME from the Touch Screen
menu.
3Select the cycle name from the Touch Screen
menu.
4Using the keypad on the Touch Screen, type
the name of your “My Cycle” and press OK.
To delete a “My Cycle” from the Home Screen:
1Press the MY CYCLES button.
2Select DELETE from the Touch Screen
menu.
3Select the cycle name from the Touch Screen
menu.
4Choose YES to delete the cycle or CANCEL
to return to the list of “My Cycles.”

13
Help
www.GEAppliances.com
TROUBLE SHOOTER
MACHINE
PREFERENCES
HOME SCREEN
HELP
About
the Help
Feature
Pressing the HELP button from the Home
Screen allows you to locate troubleshooting tips
for common washer problems, to find help with
using the Home Screen or to set machine
preferences.
Pressing the HELP button while on any other
screen allows you to find additional information
on features found on that screen. Press HELP;
then touch any pad on the Touch Screen for an
explanation of that feature. To exit the feature,
press HELP once to return to the previous
screen or twice to exit Help.
TROUBLE SHOOTER
PRESS DESCRIPTION FOR POSSIBLE CAUSES
NO INFUSOR OR BASKET MOTION
MACHINE MOVES BEFORE WATER FILL
FILLING AND DRAINING AT THE SAME
TIME
SPORADIC FILL
NO FILL OR SLOW FILL
Using the
Troubleshooter
To locate Troubleshooting Tips for common
washer problems:
1Press the HELP button.
2On the Touch Screen, select TROUBLE
SHOOTER.
3On the Touch Screen, select the problem
description from the list. You can use the
arrows at the right of the screen to scroll
up and down through the list of additional
problems.
4On the Touch Screen, select a possible cause
for the problem and follow the on-screen
instructions to find a solution.
Finding Help
Using the
Home Screen
Pressing the HELP button, then selecting
HOME SCREEN HELP allows you to find
additional information on features found on
the Home Screen. Touch any pad on the Touch
Screen for an explanation of that feature. To
exit the feature, press the BACK button.

14
The machine settings on the Help feature
allow you to control the volume of the button
beep and end-of-cycle signal, and turn the
washer/dryer communication feature on or off.
Button Beep
The button beep controls the volume of the
beep that is made when you press any of the
buttons or the Touch Screen.
To change the volume of the button beep:
1From the Home Screen, press the HELP
button.
2Select MACHINE PREFERENCES from the
Touch Screen.
3Select BUTTON BEEP from the Touch
Screen.
4Use the arrows to make the volume louder
or softer, or to turn the beep off.
5Select OK from the Touch Screen.
The new volume is now saved as the default
setting.
Washer/Dryer Communication
Washer/Dryer communication allows your
washer to send cycle information to your dryer
to create a dry cycle that matches your wash
load.
After the wash cycle is complete,
communication begins once either the washer
or dryer Touch Screen is activated.
Once the information is sent, your dryer will
create the optimal dry cycle for your load.
To turn the Washer/Dryer Communication
feature on or off:
1From the Home Screen, press the HELP
button.
2Select MACHINE PREFERENCES from the
Touch Screen.
3Select WASHER/DRYER
COMMUNICATION from the Touch
Screen.
4Touch the pad at the bottom of the Touch
Screen to select ON or OFF.
5Select OK from the Touch Screen.
End-of-Cycle Signal
The End-of-Cycle signal alerts you when the
cycle is complete.
To change the volume of the end-of-cycle
signal:
1From the Home Screen, press the HELP
button.
2Select MACHINE PREFERENCES from the
Touch Screen.
3Select END OF CYCLE SIGNAL from the
Touch Screen.
4Use the arrows to make the volume louder
or softer, or to turn the signal off.
5Select OK from the Touch Screen.
The new volume is now saved as the default
setting.
Help
www.GEAppliances.com
MACHINE PREFERENCES
END OF CYCLE
SIGNAL BUTTON BEEP
WASHER/DRYER
COMMUNICATION
Setting the
Machine
Preferences

15
Washer Features
www.GEAppliances.com
Using the
Liquid Bleach
Dispenser
The bleach dispenser automatically dilutes and
dispenses liquid chlorine bleach at the proper
time in the wash cycle.
1Check clothing care labels for special
instructions.
2Measure liquid bleach carefully, following
instructions on the bottle.
•Never pour undiluted liquid chlorine bleach
directly onto clothes or into the wash basket.
• Do not pour powdered bleach into bleach
dispenser.
• Avoid overfilling or splashing when adding
bleach to the dispenser. The maximum capacity
of the bleach dispenser is one cup of bleach per
wash cycle. Overfilling could result in early
dispensing of bleach.
3Before starting the washer, pour measured
amount of bleach directly into bleach
dispenser. If you prefer to use powdered
bleach, add it into the wash basket directly
before adding clothes.
Do not mix chlorine bleach with ammonia or acids
such as vinegar and/or rust remover. Mixing can
produce a toxic gas which may cause death.
Using the
Dispenser
Drawer
The dispenser drawer contains three
compartments:
•Liquid Fabric Softener
• Liquid or Powder Low-Sudsing, High-
Efficiency Detergent
• Liquid Wash Boost Additives
The dispenser automatically dispenses additives
at the proper time in the wash cycle.
1Slowly open the dispenser drawer by pulling
the drawer out until it stops.
2After adding laundry products, slowly close
the dispenser drawer. Closing the drawer too
quickly could result in early dispensing of
additives.
• Avoid overfilling or splashing when adding
laundry products to the dispenser. Doing so
could result in early dispensing of laundry
products.
At the end of the cycle, you may see water
in the compartments. This is part of the normal
operation of the washer.
NOTE: Do not use bleach in the dispenser
drawer.

16
Washer Features
www.GEAppliances.com
Adding
Detergent
NOTE: Use only low-sudsing, high-efficiency
detergent such as Tide®HE.
Add measured detergent to the detergent
compartment of the dispenser drawer.
•Do not exceed the maximum fill line.
Detergent is flushed through the dispenser
at the beginning of the wash phase. Either
powdered or liquid detergent can be used.
When using liquid detergent, make sure
the detergent box and insert are in place.
For powdered detergent, remove both the
detergent box and insert. Powdered detergent
will not dispense with the detergent box and
insert in place.
Detergent usage may need to be adjusted for
water temperature, water hardness, size and
soil level of the load. Avoid using too much
detergent in your washer, as it can lead to
oversudsing and detergent residue being
left on the clothes.
Adding Fabric
Softener
If desired, pour the recommended amount
of liquid fabric softener into the left-hand
compartment. Use only liquid fabric softener.
Dilute with water to the maximum fill line.
•Do not exceed the maximum fill line.
Overfilling can cause early dispensing of the
fabric softener, which could stain clothes.
NOTE: Do not pour fabric softener directly on
the wash load. It may stain the clothes.
ADDITIVES
Adding
Wash Boost
Additives
The Wash Boost dispenser may be used to
clean heavily soiled or stained garments more
efficiently. Selecting ADDITIVES when setting a
presoak sets a special “Wash Boost” that soaks,
drains and spins, then refills the washer for the
main wash cycle. If ADDITIVES is not selected,
the washer will not drain and refill after the
presoak.
Place the additives for the Wash Boost setting
in the right-hand compartment. Select an Extra
Rinse to make sure all remaining detergent is
removed from the wash load.
You may add low-sudsing, high-efficiency liquid
detergent to this compartment when selecting
a Stain Inspector cycle or when choosing a
Presoak requiring special additives.
•Do not exceed the maximum fill line to avoid
oversudsing.
Overfilling can cause early dispensing of
presoak additives, which could result in
damaged clothes.
Insert
Detergent box

17
Loading and Using the Washer
www.GEAppliances.com
Sorting Wash
Loads
Sort by color (whites, lights, colors), soil level,
fabric type (sturdy cottons, easy care, delicates)
and whether the fabric produces lint (terry cloth,
chenille) or collects lint (velveteen, corduroy).
Loading the
Washer
Load dry items loosely, no higher than the top
row of holes in the washer basket. Overloading
may reduce washer efficiency and possibly
increase wrinkling.
Bulky items should be placed as far down in the
wash basket as possible for optimal results.
Always place buoyant items at the bottom of the
wash basket.
The washer will automatically detect the load
size. Because of the high-efficiency wash system,
the water level may not completely cover the
load. To add items after washer has started, lift
the lid, add items, close the lid and press
START.
•Do not wash fabrics containing flammable
materials (waxes, cleaning fluids, etc.)
•The washer will not fill or operate with the
lid open.
Always follow fabric manufacturer’s care label when laundering.
Fabric Care
Labels
Below are fabric care label “symbols” that affect
the clothing you will be laundering.
Machine
wash
cycle Normal Permanent Press/
wrinkle resistant
Gentle/
delicate Hand wash Do not wash Do not wring
Water
temperature Hot
(50°C/120°F)
Warm
(40°C/105°F)
Cold/cool
(30°C/85°F)
Tumble
dry
Dry Normal Permanent Press/
wrinkle resistant
Gentle/
delicate Do not tumble dry
Do not dry
(used with
do not wash)
Heat
setting
High Medium Low No heat/air
Special
instructions Line dry/
hang to dry Drip dry Dry flat In the shade
Bleach
symbols Any bleach
(when needed) Only non-chlorine bleach
(when needed)
Do not bleach
Wash Labels
Dry Labels
Bleach Labels

Wash Basket: Leave the lid open after washing
to allow moisture to evaporate. If you want to
clean the basket, use a clean soft cloth
dampened with liquid detergent; then rinse.
(Do not use harsh or gritty cleaners.)
Fill Hoses: Hoses connecting washer to faucet
should be replaced every 5 years.
Exterior: Immediately wipe off any spills. Wipe
with damp cloth. Do not touch the surface or
the Touch Screen with sharp objects.
Moving and Storage: Ask the service
technician to remove water from drain
pump and hoses. For more information, visit
www. GEAppliances.com or call 800.GE.CARES
(800.432.2737). Do not store the washer where
it will be exposed to the weather.
Long Vacations: Be sure water supply is shut off
at faucets. Drain all water from hoses if weather
will be below freezing.
Dispenser Drawers: Detergent and fabric
softener may build up in the dispenser drawer.
Residue should be removed once or twice a
month.
1Remove the drawer by pulling it straight out
until it stops. Lift up on the front of the
drawer and pull it out.
2Remove the inserts from the three
compartments; rinse the inserts and the
drawer with warm water to remove traces
of accumulated laundry products.
3To clean the drawer opening, use a small,
non-metal brush to clean the recess. Remove
all residue from the upper and lower parts
of the recess.
4Return the inserts to the proper
compartments and replace the drawer.
Loading and Using the Washer
www.GEAppliances.com
Care and
Cleaning of
the Washer
Proper Use of
Detergent
Using too much detergent is a common cause
of laundry problems. Today’s detergents are
formulated to be effective without highly visible
sudsing. Be sure to carefully read and follow
manufacturer’s recommendations for how
much detergent to use in your wash.
You can use less detergent if you have soft
water, a smaller load or a lightly soiled load.
NOTE: Use only low-sudsing, high-efficiency
detergent such as Tide®HE.
18

BEFORE YOU BEGIN
Read these instructions completely and
carefully.
•IMPORTANT – Save these
instructions for local electrical inspector’s
use.
•IMPORTANT – Observe all
governing codes and ordinances.
•Note to Installer – Be sure to leave these
instructions with the Consumer.
•Note to Consumer – Keep these instructions
for future reference.
•Skill level – Installation of this appliance
requires basic mechanical skills.
•Proper installation is the responsibility of
the installer.
•Product failure due to improper installation
is not covered under the Warranty.
Installation Washer
Instructions WPGT9350
19
Questions? Call 800.GE.CARES (800.432.2737) or visit our Web site at: www.GEAppliances.com
PLUMBING REQUIREMENTS
FOR YOUR SAFETY:
ELECTRICAL REQUIREMENTS
CAUTION – For personal safety,
do not use an extension cord or adapter plug
with this appliance. Do not, under any
circumstances, cut or remove the third
grounding prong from the power cord. Follow
national electrical codes and ordinances. This
appliance must be supplied with the voltage
and frequency indicated on the rating plate
(located on the rear cover of the backsplash),
and connected to an individual, properly
grounded branch circuit, protected by a 15-
or 20-amp circuit breaker or time-delay fuse.
If the electric supply provided does not meet
the above requirements, call a licensed
electrician.
WATER PRESSURE – Must be 10 psi minimum
to 120 psi maximum.
WATER TEMPERATURE – Household water
heater should be set to deliver water at 120°
to 150°F (50° to 66°C) TO THE WASHER.
SHUTOFF VALVES – Both hot and cold shutoff
valves (faucets) should be supplied.
DRAIN – Water may be drained into
standpipe or set tub. Discharge height MUST
NOT BE LESS THAN 30 INCHES and no more
than 8 feet above the base of the washer.
Standpipe must be 11⁄2inches minimum
inside diameter and must be open to
atmosphere.
GROUNDING INSTRUCTIONS
This appliance must be grounded. In
the event of malfunction or breakdown,
grounding will reduce the risk of electric
shock by providing a path of least resistance
for electric current. This appliance is equipped
with a cord having an equipment-grounding
conductor and a grounding plug. The plug
must be plugged into an appropriate outlet
that is properly installed and grounded in
accordance with all local codes and
ordinances.
WARNING – Improper connection
of the equipment-grounding conductor can
result in a risk of electric shock. Check with a
qualified electrician or serviceman if you are
in doubt as to whether the appliance is
properly grounded. Do not modify the plug
provided with the appliance—if it will not fit
the outlet, have a proper outlet installed by a
qualified electrician.

Installation Instructions
20
WASHER LOCATION
The washer must be installed on firm flooring
to minimize vibration during the spin cycle.
Concrete flooring is best, but a wood floor is
sufficient, provided floor support meets FHA
standards. The washer should not be installed
on rugs or exposed to weather.
Minimum clearance between washer and
adjacent walls or other surfaces:
•0” either side
•2” front
•3” rear
Minimum vertical space from floor to
overhead shelves, cabinets, ceilings, etc.,
is 52”.
WASHER DIMENSIONS
27”
(68.6 cm)
431⁄8”
(109.4 cm)
523⁄4”
(133.7 cm)
(with lid
open)
281⁄4”
(71.6 cm)
Side View
Front View
REQUIREMENTS FOR ALCOVE OR
CLOSET INSTALLATION
Your washer is approved for installation in
an alcove or closet, as stated on a label on
the back of the machine.
Minimum clearance between washer and
adjacent walls or other surfaces:
•0” either side
•2” front
•3” rear
Minimum vertical space from floor to
overhead shelves, cabinets, ceilings, etc.,
is 52”.
Closet doors must be louvered or otherwise
ventilated and have at least 60 square inches
of open area for washer only, or if the closet
contains both a washer and a dryer, door
must contain at least 120 square inches of
open area equally distributed. Air openings
are required to be unobstructed when a door
is installed. A louvered door with equivalent
air openings for the full length of the door is
acceptable.
NOTE: The clearances stated on this label are
minimums. Consideration must be given to
providing adequate clearances for installing
and servicing.
