GE WWSE5240GWW User manual

ge.com
Owner’s Manual
Washers
175D1807P563 49-90295-1 09-06 JR
Safety Instruct ons . . . . . . . . . .2, 3
Operat ng Instruct ons
Care and Cleaning
of the Washer . . . . . . . . . . . . . . . . . . . . 9
Control Panels . . . . . . . . . . . . . . . . . .4, 6
Control Settings . . . . . . . . . . . . . . . .4–7
Features . . . . . . . . . . . . . . . . . . . . . . . . . .8
Loading and sing
the Washer . . . . . . . . . . . . . . . . . . . . . . . 9
Troubleshoot ng T ps . . . . .10–12
Consumer Support
Consumer Support . . . . . . . . . . . . . . .16
Warranty . . . . . . . . . . . . . . . . . . . . . . . .15
Wr te the model and ser al
number here:
Model # ______________
Ser al # ______________
You can find them
under the lid of
the washer.

2
■Install or store where it will not be exposed to
temperatures below freezing or exposed to the
weather, which could cause permanent damage
and invalidate the warranty.
■Properly ground washer to conform with all
governing codes and ordinances. Follow details
in Installation Instructions.
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING! For your safety, the information in this manual must be followed to minimize the ris
of fire or explosion, electric shoc , or to prevent property damage, personal injury,
or loss of life.
WATER HEATER SAFETY
Under certain conditions, hydrogen gas may be produced in a water heater that has not been
used for two wee s or more. Hydrogen gas can be explosive under these circumstances.
If the hot water has not been used for two weeks or more, prevent the possibility of damage or injury by
turning on all hot water faucets and allowing them to run for several minutes. Do this before using any
electrical appliance which is connected to the hot water system. This simple procedure will allow any
built-up hydrogen gas to escape. Since the gas is flammable, do not smoke or use an open flame or
appliance during this process.
PROPER INSTALLATION
This washer must be properly installed and located in accordance with the Installation
Instructions before it is used. If you did not receive an Installation Instructions sheet, you can
receive one by visiting ge.com or by calling 800.GE.CARES (800.432.2737).
YOUR LAUNDRY AREA
■Keep the area underneath and around your
appliances free of combustible materials such as
lint, paper, rags, chemicals, etc.
■Close supervision is necessary if this appliance is
used by or near children. Do not allow children to
play on, with or inside this or any other appliance.
Operat ng Instruct ons Safety Instruct ons
Consumer Support Troubleshoot ng T ps

Consumer SupportTroubleshoot ng T psOperat ng Instruct onsSafety Instruct ons
3
Use this
appliance
only for its
intended
purpose as
described in
this Owner’s
Manual.
ge.com
WHEN USING THE WASHER
■Never reach into washer while it is moving.
Wait until the machine has completely stopped
before opening the lid.
■Do not mix chlorine bleach with ammonia or acids
such as vinegar and/or rust remover. Mixing
different chemicals can produce a
toxic gas which may cause death.
■Do not wash or dry articles that have been
cleaned in, washed in, soaked in or spotted with
combustible or explosive substances (such as
wax, oil, paint, gasoline, degreasers, dry-cleaning
solvents, kerosene, etc.). These substances give off
vapors that may ignite or explode. Do not add
these substances to the wash water. Do not use or
place these substances around your washer or
dryer during operation.
■The laundry process can reduce the flame
retardancy of fabrics. To avoid such a result,
carefully follow the garment manufacturer’s
wash and care instructions.
■To minimize the possibility of electric shock,
unplug this appliance from the power supply
or disconnect the washer at the building’s
distribution panel by removing the fuse or
switching off the circuit breaker before attempting
any maintenance or cleaning.
NOTE: Turning the Cycle Selector Knob to an off
position, or pressing PAUSE does NOT disconnect
the appliance from the power supply.
■Never attempt to operate this appliance if it is
damaged, malfunctioning, partially disassembled,
or has missing or broken parts, including a
damaged cord or plug.
WHEN NOT IN USE
■Turn off water faucets to relieve pressure on hoses
and valves and to minimize leakage if a break or
rupture should occur. Check the condition of the fill
hoses; GE recommends changing the hoses every
5 years.
■Before discarding a washer, or removing it
from service, remove the washer lid to prevent
children from hiding inside.
■Do not attempt to repair or replace any part of this
appliance unless specifically recommended in this
Owner’s Manual, or in published user-repair
instructions that you understand and have the
skills to carry out.
■Do not tamper with controls.
READ AND FOLLOW THIS SAFETY INFORMATION
CAREFULLY.
SAVE THESE INSTRUCTIONS

4
• Add detergent
• Add diluted fabric
softener (on models
with a fabric
softener dispenser)
• Add clothes
• Select load size and
other wash options
• Select wash cycle • Close lid
• Pull knob
uick Start Guide
About the control panel—for models w th “pull knob” start.
Load S ze
Loosely load clothes no higher than the top row of holes in the washer basket. The water level should just cover
the clothes. Adjust the load size accordingly.
Temperature (on some models)
Select the water temperature for the wash and rinse cycles. Always follow fabric manufacturer’s care label or
instructions when laundering.
Opt ons (on some models)
2nd R nse Opt on
When you use extra detergent or bleach to clean heavily soiled clothes, you may want to use the 2nd Rinse
option. It provides a second deep cold rinse.
A
A
B
B
C
C
D
Step 1 Step 2 Step 3
Step 4
Controls

ge.com
Consumer SupportTroubleshoot ng T psOperat ng Instruct onsSafety Instruct ons
Wash Cycle—Cycle Selector Knob
The chart below will help you match the wash cycle setting with your clothing. The chart is ranked from longest to
shortest cycle time and wash intensity.
Your washer may not have all these cycles. (Cycles vary by model.)
PREWASH For removing surface dirt from heavily soiled clothes. Make sure to follow with a
regular wash cycle.
CASUALS For wrinkle-free and permanent press items, and knits.
COTTONS For heavy to lightly soiled cottons, household linens, work and play clothes.
or WHITES
EASY CARE For wrinkle-free and permanent press items, and knits.
DELICATES For lingerie and special-care fabrics with light to normal soil.
HAND WASH For items labeled handwashable with light soils. Provides periods of agitation and soak
during wash and rinse.
SPEED WASH For lightly soiled items that are needed in a hurry.
SPIN For draining the tub and spinning water out of the clothes.
DARK COLORS For non-colorfast cottons and blends and items that are labeled cold wash by the fabric
manufacturer.
COLORS For wrinkle-free and permanent press items, knits and cottons.
RINSE SPIN For quickly rinsing chlorine, perspiration, stains, etc., out of clothes.
15 MIN/30 MIN For very soiled clothes. Begins with agitation, soaks for a specified period of time, then moves
AUTO SOAK through the rest of the cycle automatically.
2nd RINSE Provides an automatic, second deep rinse to thoroughly remove detergent or bleach from
your clothes.
D
5

6
• Add detergent
• Add diluted fabric
softener (on models
with a fabric
softener dispenser)
• Add clothes
• Select load size and
other wash options
• Select wash cycle • Close lid
• Push START
uick Start Guide
About the control panel—for models w th START button.
Load S ze
Loosely load clothes no higher than the top row of holes in the washer basket. The water level should just cover
the clothes. Adjust the load size accordingly.
Temperature
Select the water temperature for the wash and rinse cycles. Always follow fabric manufacturer’s care label or
instructions when laundering.
PerfecTemp senses the incoming water temperature and adjusts the fill water to obtain a more precise
temperature range for all wash temperatures. For example, in a COLD wash selection, some warm water
may be added to reach a temperature needed to better dissolve detergents. Often, detergents are not
completely dissolved in very cold water, especially in cooler climates.
During winter months, when the water entering your home is colder, or for locations with very cold water year
round, use the PerfecTemp plus COLD to help dissolve powdered detergents and to improve the cleaning of
your clothes.
The TAP COLD feature turns the PerfecTemp feature on your washer off, and uses your household tap water
temperature for a COLD wash. This can provide energy savings by reducing the amount of hot water used in
your wash.
Opt ons
Autosoak Opt on (on some models)
This option begins with a brief agitation, soaks for a specified period of time, then moves through the rest of the
cycle automatically. On some models, this option is located on the Cycle Selector knob.
2nd R nse Opt on (on some models)
When you use extra detergent or bleach to clean heavily soiled clothes, you may want to use the 2nd Rinse
option. It provides a second deep cold rinse.
Extended Sp n Opt on (on some models)
se this option to extract more water from your clothes. Clothes will be drier when this option is selected and will
dry more quickly in your dryer.
A
A
B
B
C
C
D
EF
Step 1 Step 2 Step 3
Step 4
Controls

7
Consumer SupportTroubleshoot ng T psOperat ng Instruct onsSafety Instruct ons
ge.com
Status Ind cator L ghts
The Cycle Indicator Lights show what stage the washer is in. When the Selector knob is set to a new cycle, the Indicator
Lights will flash momentarily, showing what stages the cycle will go through. On models without an AUTO SOAK option,
the SOAK light will not light up.
Wash Cycle—Cycle Selector Knob
The wash cycle controls the length and intensity of the washing process. The knob can be turned in either direction.
Turning the Cycle Selector knob after starting a cycle will stop the washer and reset the cycle to the new selection.
Press START to begin the new cycle selection.
The chart below will help you match the wash cycle setting with your clothing. The chart is ranked from longest to
shortest cycle time and wash intensity. (Cycles vary by model.)
PREWASH For removing surface dirt from heavily soiled clothes. Make sure to follow with a
regular wash cycle.
CASUALS For wrinkle-free and permanent press items, and knits.
COTTONS For heavy to lightly soiled cottons, household linens, work and play clothes.
EASY CARE For wrinkle-free and permanent press items, and knits.
DELICATES For lingerie and special-care fabrics with light to normal soil.
HAND WASH For items labeled handwashable with light soils. Provides periods of agitation and soak
during wash and rinse.
SPEED WASH For lightly soiled items that are needed in a hurry.
DRAIN & SPIN For draining the tub and spinning water out of the clothes.
OR
SPIN ONLY
AUTO SOAK For very soiled clothes. Begins with a brief agitation, soaks for a specified period of time,
then moves through the rest of the cycle automatically.
START
Press START to begin the cycle. Pressing START again or raising the lid will PAUSE the cycle and the Cycle indicator light
will blink.
To continue the cycle, press START again or close the lid. If machine is paused more than 24 hours, the cycle will be
cancelled. To stop the cycle, hold the button for 3 seconds. If water remains in the machine, select the DRAIN & SPIN
OR SPIN ONLY cycle to drain tub and spin water out of the washer tub.
Raising the lid will stop agitation or spin action, but does not pause the cycle.
D
E
F

Separate for cleaning
Operat ng Instruct ons Safety Instruct ons
Consumer Support Troubleshoot ng T ps
8
About washer features.
Clean ng the Fabr c Softener D spenser (on some models)
Remove the dispenser from the top of the agitator.
Separate the dispenser cup from the cover by grasping the top and pushing down on the
inside of the cup with your fingers. Dispenser cup will pop free from the cover.
To clean the dispenser, soak both the dispenser cup and the dispenser cover in the
following solution:
■ 1 US gallon (3.8 liters) warm water
■ 1/4 cup (60 ml) heavy-duty liquid detergent
■ 1 cup (240 ml) bleach
If necessary, loosen buildup with a clean, soft cloth after soaking. Do not use a stiff brush;
you may roughen the surface of the dispenser.
Rinse and reassemble dispenser. Place dispenser back on the agitator.
5
4
3
2
1
The Ag tator Cap or Fabr c Softener D spenser (depending on model)
The ag tator cap fits into the top of the
agitator. If it accidentally comes off,
simply put it back on.
The fabr c softener d spenser automatically
releases liquid fabric softener at the proper
time during the cycle.
Do not stop the washer dur ng the f rst sp n.
Th s w ll cause the d spenser to empty
too soon.
To use, follow these steps:
Make sure dispenser is securely attached
to agitator.
se only liquid fabric softener.
Pour into dispenser, using amount
recommended on package.
Never pour fabr c softener d rectly on
clothes. It may sta n them.
Add water to dispenser until it reaches
the maximum fill line.
3
2
1
Do not pour anything into the
agitator if the agitator cap or
dispenser is removed.
L qu d Bleach Funnel
The water fill dilutes liquid chlorine bleach as the washer fills for the wash cycle.
Check clothing care labels for special instructions.
Measure liquid bleach carefully, following instructions on the bottle.
■ Never pour undiluted liquid chlorine bleach directly onto clothes or into the wash bas et.
■ Do not pour powdered bleach into bleach funnel.
Before starting the washer, pour measured amount of bleach directly into bleach funnel.
Avoid splashing or over-filling dispenser. If you prefer to use powdered bleach, add it into
the wash basket with your detergent.
■ Do not mix chlorine bleach with ammonia or acids such as vinegar and/or rust remover.
Mixing can produce a toxic gas which may cause death.
3
2
1

Consumer SupportTroubleshoot ng T psOperat ng Instruct onsSafety Instruct ons
9
Load ng and us ng the washer.
Always follow fabric manufacturer’s care label when laundering. ge.com
Sorting Wash Loads
Sort by color (whites, lights, colors), soil level,
fabric type (sturdy cottons, easy care, delicates)
and whether the fabric produces lint (terry cloth,
chenille) or collects lint (velveteen, corduroy).
Proper Use of Detergent
Add detergent and start the washer before adding
clothes so that the detergent can work effectively.
sing too little or too much detergent is a common
cause of laundry problems.
You can use less detergent if you have soft water,
a smaller load or a lightly soiled load.
Loading the Washer
Load dry items loosely, no higher than the top row of
holes in the washer basket. When loading wet items,
make sure you set the load/water level high enough
to allow the items to move freely. Water level should
just cover the clothes. To add items after washer has
started, lift the lid and submerge additional items next
to the agitator.
■Do not wrap long items li e sheets or pants
around the agitator.
■Do not wash fabrics containing flammable
materials (waxes, cleaning fluids, etc.).
■Agitation will not start with the lid up.
Wash Basket: Leave the lid open after washing to
allow moisture to evaporate. If you want to clean
the basket, use a clean soft cloth dampened with
liquid detergent; then rinse. (Do not use harsh or
gritty cleaners.)
F ll Hoses: GE recommends changing the hoses
every 5 years.
Exter or: Immediately wipe off any spills. Wipe
with damp cloth. Try not to hit surface with
sharp objects.
Mov ng and Storage: Ask the service technician to
remove water from drain pump and hoses. See the
Installation Instructions packed with product for
information on how to reinstall the shipping rod
to keep the tub stationary when moving the washer.
For more information, visit ge.com or call
800.GE.CARES (800.432.2737). Do not store
the washer where it will be exposed to the weather.
Long Vacat ons: Be sure water supply is shut off at
faucets. Drain all water from hoses if weather will
be below freezing.
Care and clean ng of the washer.

WATER Poss ble Causes What To Do
Too many suds Too much detergent • Measure your detergent carefully. se less soap if you have
soft water, a smaller load or a lightly soiled load.
Type of detergent • Switch to a lower sudsing detergent brand and follow
instructions on package.
Soft water • Try less detergent.
Water leaks Using too much detergent • se less detergent. se less soap if you have soft water,
in washer a smaller load or a lightly soiled load.
Fill hoses or drain hose is • Make sure hose connections are tight at faucets and
improperly connected rubber washers are installed. Make sure end of drain hose
is correctly inserted in and secured to drain facility.
Household drain may • Check household plumbing. You may need to call
be clogged a plumber.
Constant water pressure • Tighten hoses at the faucets and turn the water off after
to the fill hoses at the each use.
water source •Check condition of the fill hoses; they should be replaced
every 5 years.
Water temperature Cooler water temperatures • New laundry detergents have been formulated to work
seems ncorrect provide improved energy with cooler water temperatures without affecting wash
efficiency performance.
Water supply is turned off • Turn both hot and cold faucets fully on and make sure
or improperly connected hoses are connected to correct faucets.
Water valve screens are • Turn off the water source and remove the water connection
stopped up hoses from the upper back of the washer. se a brush or
toothpick to clean the screens in the machine. Reconnect
the hoses and turn the water back on.
House water heater is • Make sure house water heater is delivering water at
not set properly 120°F–140°F (48°C–60°C).
Water pumped out before Lid lifted or cycle was put in • Reset cycle.
cycle s complete pause for over 24 hours
Water won’t dra n Drain hose is kinked or • Straighten drain hose and make sure washer is not
improperly connected sitting on it.
•Top of drain outlet should be less than 8 ft (2.5 m)
above floor.
Washer pauses dur ng The PREWASH Cycle or • This is normal. The washer alternates between agitate and
wash cycle AUTO SOAK Option was soak during these cycles to get your clothes cleaner with
chosen less wear.
Washer pauses dur ng This is normal • The washer may pause during the spin cycle to remove
sp n cycle soapy water more efficiently.
Troubleshooting Tips
Save time and money! Review the charts on the following pages,
or visit ge.com. You may not need to call for service.
Before you call for serv ce…
10
Operat ng Instruct ons Safety Instruct ons
Consumer Support Troubleshoot ng T ps

Consumer SupportTroubleshoot ng T psOperat ng Instruct onsSafety Instruct ons
OPERATION Poss ble Causes What To Do
Washer won’t operate Washer is unplugged • Make sure cord is plugged securely into a working outlet.
Water supply is turned off • Turn both hot and cold faucets fully on.
Controls are not set properly • Check controls.
Lid is open—safety feature • Close lid and reset cycle, to the beginning if necessary.
prevents agitation and
spinning when lid is up
Circuit breaker/fuse is • Check house circuit breakers/fuses. Replace fuses or
tripped/blown reset breaker. Washer should have separate outlet.
Electronics need to be reset • nplug washer, wait 2 minutes, plug back in and press START.
START was not pressed • Press START.
Lid magnet missing • Call for service.
T me not shown Unit filling • This is normal. Estimated time remaining is updated during
on d splay fill time.
Movement ns de mach ne Shifting mechanism is • When the machine is manually turned off, the shifter will
when shut off disengaging the motor disengage the motor before completely shutting down.
If lid is raised before the motor is disengaged, it will resume
when lid is closed.
PERFORMANCE Poss ble Causes What To Do
Clothes too wet Incorrect spin cycle • Make sure the spin cycle selected matches the load you are
selected washing. Some fabrics will feel wetter when rinsed with cold water.
Colored spots Incorrect use of fabric • Check fabric softener package for instructions and follow
softener directions for using dispenser.
•Pretreat stain and rewash.
Dye transfer • Sort whites or lightly colored items from dark colors.
Grayed or yellowed Not enough detergent • se more detergent (especially with larger loads).
clothes Be sure to follow detergent manufacturer’s directions.
Hard water • se a water conditioner like Calgon brand or install
a water softener.
Water is not hot enough • Make sure water heater is delivering water at
120°F–140°F (48°C–60°C).
Washer is overloaded • Select load size to match clothes load.
Detergent is not • Add detergent as wash basket fills with water before
dissolving you load clothes.
Dye transfer • Sort clothes by color. If fabric label states wash separately,
unstable dyes may be indicated.
L nt or res due on Clothes are air or line dried • If you do not dry your clothes with a clothes dryer, your
clothes clothes may retain more lint.
Incorrect sorting • Separate lint producers from lint collectors.
Washing too long • Wash small loads for a shorter time than larger loads.
Detergent not dissolving • Add detergent as wash basket fills with water, before you
load clothes.
•Try a liquid detergent.
•se warmer water temperature.
Overloading • Load clothes no higher than the top row of holes in the
washer basket.
•Make sure load size selected matches clothes load size.
Incorrect use of fabric • Check fabric softener package for instructions
softener and follow directions for using dispenser.
ge.com
11

Operating Instructions Safety Instructions
Consumer Support Troubleshooting Tips
Before you call for service…
PERFOR ANCE (cont.) Possible Causes What To Do
Pilling Result of normal wear on • While this is not caused by the washer, you can slow the
poly-cotton blends and pilling process by washing garments inside out.
fuzzy fabrics
Snags, holes, tears, rips Pins, snaps, hooks, sharp • Fasten snaps, hooks, buttons and zippers.
or excessive wear buttons, belt buckles, •Remove loose items like pins, objects in pockets and
zippers and sharp objects sharp buttons.
left in pockets •Turn knits (which snag easily inside out.
Undiluted chlorine bleach • Check bleach package instructions for proper amount.
•Never add undiluted bleach to wash or allow clothes to
come in contact with undiluted bleach.
Chemicals like hair bleach or • Rinse items that may have chemicals on them before
dye, permanent wave solution washing.
Wrinkling mproper sorting • Avoid mixing heavy items (like work clothes with light items
(like blouses .
•Try a fabric softener.
Overloading or incorrect • Load your washer so clothes have enough room to move
water level freely with water covering all of the clothes.
ncorrect wash and • Match Cycle selection to the type of fabric you are washing
dry cycles (especially for easy care loads .
Repeated washing in • Wash in warm or cold water.
water that is too hot
SOUNDS Possible Causes What To Do
“ etallic clicking” Shifter mechanism is • The drive system will engage at the start of agitate and
engaging or disengaging disengage when agitate is complete. This occurs multiple
times during the wash.
Back and forth “swoosh” Electric motor reversing • This machine has a drive system that doesn’t use gears.
or light “clicking” sound direction This sound is the motor rotating back and forth to agitate
during agitate your laundry.
Quick short agitation Clothing redistribution • At the end of agitate, the motor makes short agitation strokes
sounds at end of agitate to redistribute the load.
“Click” when water Relay switch • The relay makes a click sound when activated. The water
stops filling level activates the relay and stops filling.
“Clicking” behind Control Automatic Temperature • This valve mixes in cold and hot water. The “clicking” is the
Panel during fill Control Valve valve turning on and off.
Water volume changes Automatic Temperature • This valve mixes in cold and hot water. The sound changes
during fill Control Valve when the valves are turned on and off.
otor “whining up” or Motor ramping up/down • The motor will speed up incrementally during the spin cycle.
“coasting down” in spin during spin cycle When spin is complete, it will coast until it stops.
“Humming” Water drain pump • The drain pump will make a humming sound when pumping
out water after agitation stops and continue until spin is
complete.
“Gurgling” Water drain pump • When the pump starts drawing in air, It starts to gurgle.
The washer should then begin spinning and the sound will
continue until it is done spinning.
12
Troubleshooting Tips

Consumer SupportTroubleshoot ng T psOperat ng Instruct onsSafety Instruct ons
13
Notes. ge.com

Operat ng Instruct ons Safety Instruct ons
Consumer Support Troubleshoot ng T ps
14
Notes.

Consumer SupportTroubleshoot ng T psOperat ng Instruct onsSafety Instruct ons
15
For The Per od Of: We W ll Replace:
One Year Any part of the washer which fails due to a defect in materials or workmanship. During this
From the date of the l m ted one-year warranty,we will also provide, free of charge,all labor and related service to
original purchase replace the defective part.
What Is Not Covered:
All warranty service provided by our Factory Service Centers,
or an authorized Customer Care®technician. To schedule service,
on-line, 24 hours a day, visit us at ge.com, or call 800.GE.CARES
(800.432.2737). Please have serial number and model number
available when calling for service.
This warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within the
USA. If the product is located in an area where service by a GE Authorized Servicer is not available, you may be responsible for a
trip charge or you may be required to bring the product to an Authorized GE Service location. In Alas a, the warranty excludes the
cost of shipping or service calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal
rights, and you may also have other rights which vary from state to state. To now what your legal rights are, consult your local
or state consumer affairs office or your state’s Attorney General.
Warrantor: General Electr c Company. Lou sv lle, KY 40225
■Service trips to your home to teach you how to use
the product.
■Improper installation, delivery or maintenance.
■Failure of the product if it is abused, misused, or
used for other than the intended purpose or used
commercially.
■Replacement of house fuses or resetting of circuit
breakers.
■Products which are not defective or broken, or which are
working as described in the Owner’s Manual.
■Damage to the product caused by accident, fire, floods
or acts of God.
■Incidental or consequential damage caused by possible
defects with this appliance.
■Defects or damage due to operation in freezing
temperatures.
■Damage caused after delivery.
■Product not accessible to provide required service.
Staple your receipt here.
Proof of the original purchase
date is needed to obtain service
under the warranty.
GE Washer Warranty.
EXCLUSION OF IMPLIED WARRANTIES—Your sole and exclus ve remedy s product repa r as prov ded n th s L m ted
Warranty. Any mpl ed warrant es, nclud ng the mpl ed warrant es of merchantab l ty or f tness for a part cular
purpose, are l m ted to one year or the shortest per od allowed by law.

Printed in the United States
Consumer Support.
GE Appliances Website ge.com
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day,
any day of the year! For greater convenience and faster service, you can now download Owner’s Manuals,
order parts or even schedule service on-line.
Schedule Service ge.com
Expert GE repair service is only one step away from your door. Get on-line and schedule your service at
your convenience 24 hours any day of the year! Or call 800.GE.CARES (800.432.2737) during normal business
hours.
Real Life Design Studio ge.com
GE supports the niversal Design concept—products, services and environments that can be used by
people of all ages, sizes and capabilities. We recognize the need to design for a wide range of physical and
mental abilities and impairments. For details of GE’s niversal Design applications, including kitchen design ideas
for people with disabilities, check out our Website today. For the hearing impaired, please call 800.TDD.GEAC
(800.833.4322).
Extended Warranties ge.com
Purchase a GE extended warranty and learn about special discounts that are available while your warranty
is still in effect. You can purchase it on-line anytime, or call 800.626.2224 during normal business hours.
GE Consumer Home Services will still be there after your warranty expires.
Parts and Accessories ge.com
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
(VISA, MasterCard and Discover cards are accepted). Order on-line today, 24 hours every day or by phone
at 800.626.2002 during normal business hours.
Instruct ons conta ned n th s manual cover procedures to be performed by any user. Other serv c ng
generally should be referred to qual f ed serv ce personnel. Caut on must be exerc sed, s nce mproper
serv c ng may cause unsafe operat on.
Contact Us ge.com
If you are not satisfied with the service you receive from GE, contact us on our Website with all the details
including your phone number, or write to: General Manager, Customer Relations
GE Appliances, Appliance Park
Louisville, KY 40225
Register Your Appliance ge.com
Register your new appliance on-line—at your convenience! Timely product registration will allow for
enhanced communication and prompt service under the terms of your warranty, should the need arise.
You may also mail in the pre-printed registration card included in the packing material.

ge.com
Manual del
propietario
Lavadoras
175D1807P563 49-90295-1 09-06 JR
Instrucciones
de seguridad . . . . . . . . . . . . . . . . .2, 3
Instrucciones de operación
Ajustes de control . . . . . . . . . . . . . .4–7
Cómo cargar y usar
la lavadora . . . . . . . . . . . . . . . . . . . . . . . 9
Cuidado y limpieza
de la lavadora . . . . . . . . . . . . . . . . . . . . 9
unciones . . . . . . . . . . . . . . . . . . . . . . . . .8
Panel de control . . . . . . . . . . . . . . . . .4, 6
Consejos para la solución
de pro lemas . . . . . . . . . . . . .10–12
Soporte al consumidor
Garantía . . . . . . . . . . . . . . . . . . . . . . . . .15
Soporte al consumidor . . . . . . . . . . .16
Escri a el número de modelo
y de serie aquí:
No. de modelo______________
No. de serie ________________
Puede encontrarlos
bajo la puerta
de la lavadora.

2
■ Instale o almacene la lavadora en un lugar donde
no esté expuesta a temperaturas bajo cero ni a las
inclemencias climáticas, ya que esto puede provocar
daños irreversibles e invalidar la garantía.
■ Conecte correctamente a tierra la lavadora de
conformidad con todos los códigos y ordenanzas
regulatorias. Siga la información de Instrucciones
de instalación.
INFORMACIÓN DE SEGURIDAD IMPORTANTE.
LEA TODAS LAS INSTRUCCIONES ANTES DE USAR.
¡ADVERTENCIA! Por su seguridad, debe seguir las indicaciones de este manual para
minimizar el riesgo de incendio o explosi n, descarga eléctrica, o para
evitar daños a la propiedad, lesiones personales, o muerte.
SEGURIDAD DEL CALENTADOR DE AGUA
En determinadas condiciones, en un calentador de agua que no se haya utilizado durante un mínimo
de dos semanas se puede producir gas hidr geno. El gas hidr geno puede resultar explosivo en
determinadas circunstancias.
Si el agua caliente no se ha utilizado por dos semanas o más, prevenga la posibilidad de sufrir daños o lesiones
abriendo todos los grifos de agua caliente y dejándola correr durante varios minutos. Realice este proceso antes
de utilizar cualquier electrodoméstico que se conecte al sistema de agua caliente. Este sencillo procedimiento le
permitirá liberar todo el gas hidrógeno acumulado. Debido a que el gas es inflamable, no fume ni utilice ninguna
llama o electrodoméstico durante el proceso.
INSTALACIÓN CORRECTA
La lavadora se debe instalar y colocar correctamente de acuerdo con las instrucciones de instalaci n,
antes de utilizarla.
Si no recibi la hoja con instrucciones de instalaci n, puede obtener una
visitando ge.com o llamando al 800.GE.CARES (800.432.2737).
ZONA DE LAVADERO
■Mantenga la zona por debajo y alrededor
de sus electrodomésticos libres de materiales
combustibles como pelusa, papel, trapos,
productos químicos, etc.
■Es necesario vigilar con atención a los niños
si utilizan la lavadora o se encuentran en las
proximidades. No deje que los niños jueguen sobre
éste u otro electrodoméstico, con él o en su interior.
Operación SeguridadSoporte al consumidor Solucionar pro lemas

Soporte al consumidor
Solucionar pro lemasOperaciónSeguridad
3
Utilice este
electrodoméstico
s lo para el uso
que se describe
en este manual
del propietario.
ge.com
AL UTILIZAR LA LAVADORA
■No abra la lavadora mientras esté en movimiento.
Espere a que se haya detenido por completo antes
de abrir la puerta.
■No mezcle blanqueadores clorados con amoníaco
o ácidos como vinagre o desoxidantes. La mezcla
de distintos productos químicos puede producir
gases tóxicos que pueden causar la muerte.
■No lave ni seque prendas que se hayan limpiado,
lavado, empapado o manchado con sustancias
inflamables o explosivas (como cera, aceite,
pintura, gasolina, desengrasantes, disolventes
de limpieza en seco, queroseno, etc.) que puedan
prenderse o explosionar. No añada ninguna de
estas sustancias al agua de lavado. No utilice
ni coloque ninguna de estas sustancias en torno
a la lavadora o la secadora durante el
funcionamiento.
■El proceso de lavado puede reducir el tiempo
previo a la inflamación de los tejidos. Para evitar
este efecto, siga con atención las instrucciones de
lavado y cuidado del fabricante de la prenda.
■Para minimizar la posibilidad de descarga eléctrica,
desenchufe el electrodoméstico de la corriente o
desconecte la lavadora en el panel de distribución
de la vivienda quitando el fusible o apagando el
interruptor antes de realizar cualquier tarea de
mantenimiento o limpieza.
NOTA: El llevar la perilla selectora de ciclo a la
posici n OFF u oprimir PAUSE NO desconecta
el electrodoméstico de la alimentaci n.
■No intente en ningún caso utilizar la lavadora
si está dañada, funciona incorrectamente, está
parcialmente desmontada, le faltan piezas o
algunas están rotas, incluidos el cable o el enchufe.
CUANDO NO ESTÉ EN USO
■Cierre las llaves de paso para reducir la presión
de las tuberías y las válvulas, y minimizar las fugas
en caso de que se produzca una rotura o grieta.
Compruebe el estado de las mangueras de llenado;
GE recomienda el cambio de las mangueras cada
5 años.
■Antes de deshacerse de una lavadora o de
desecharla, quite la puerta de la lavadora para
evitar que los niños se escondan en su interior.
■No intente reparar ni sustituir ninguna pieza de
este electrodoméstico, a menos que se recomiende
de manera explícita en el manual del propietario
o en instrucciones publicadas de uso y reparación
que sean comprensibles y que pueda realizar usted.
■No manipule los controles.
LEA Y SIGA ESTA INFORMACIÓN
DE SEGURIDAD CUIDADOSAMENTE.
CONSERVE ESTAS INSTRUCCIONES

4
• Agregue el detergente
• Agregue el suavizante
diluido (en modelos
con dosificador para
suavizante)
• Agregue ropa
• Seleccione el tamaño de carga y
otras opciones de lavado
• Seleccione el ciclo de lavado • Cierre la puerta
• Tire la perilla
Guía r pida
Panel de control—para modelos que empieza con una perilla.
Tamaño de carga
Cargue la ropa sin apretarla; no sobrepase la fila superior de orificios del cesto de la lavadora. El nivel de agua
apenas debe cubrir la ropa. Ajuste el tamaño de la carga como corresponda.
Temperatura (en algunos modelos)
Seleccione la temperatura del agua para los ciclos de lavado y enjuague. Cuando realice el lavado, observe
siempre las instrucciones o rótulos de cuidados del fabricante del tejido.
Opciones (en algunos modelos)
Opción de 2do enjuague
Cuando utiliza más detergente o blanqueador para limpiar ropa muy sucia, puede que desee utilizar la opción
de 2do enjuague. Esto le proporciona un segundo enjuague profundo en frío.
A
A
B
B
C
C
D
Paso 1 Paso 2 Paso 3
Paso 4
Controles
