GEAppliances GTW680 series Original instructions

WASHERS
SAFETY INSTRUCTIONS..........3
USING THE WASHER
Getting Started ...................... 5
Loading ............................. 11
CARE AND CLEANING ............12
INSTALLATION
INSTRUCTIONS .....................13
TROUBLESHOOTING TIPS......18
CONSUMER SUPPORT
Warranty ........................... 23
Consumer Support ................... 24
OWNER’S MANUAL &
INSTALLATION
INSTRUCTIONS
Write the model and serial
numbers here:
Model #_________________
Serial # _________________
You can find them under the
lid of the washer.
49-90565 11-16 GEA
G010
GE is a trademark of the General Electric Company. Manufactured under trademark license.
GTW680
ENGLISH/ESPAÑOL

249-90565
THANK YOU FOR MAKING GE APPLIANCES A PART OF YOUR HOME.
Whether you grew up with GE Appliances, or this is your first, we’re happy to have you in the family.
We take pride in the craftsmanship, innovation and design that goes into every GEAppliances
product, and we think you will too. Among other things, registration of your appliance ensures that we
can deliver important product information and warranty details when you need them.
Register your GE appliance now online. Helpful websites and phone numbers are available in the
Consumer Support section of this Owner’s Manual. You may also mail in the pre-printed registration
card included in the packing material.

49-90565 3
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
To reduce the risk of death, fire, explosion, electric shock, or injury to persons when using
your appliance, follow basic precautions, including the following:
ŶRead all instructions before using the appliance.
ŶDO NOT wash or dry articles that have been previously cleaned in, washed in, soaked in or spotted with
gasoline, dry-cleaning solvents, or other flammable or explosive substances, as they give off vapors that could
ignite or explode.
ŶDO NOT add gasoline, dry-cleaning solvents, or other flammable or explosive substances to the wash water.
These substances give off vapors that could ignite or explode.
ŶUnder certain conditions, hydrogen gas may be produced in a hot-water system that has not been used for
2 weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water system has not been used for such a
period, before using a washing machine, turn on all hot-water faucets and let the water flow from each for
several minutes. This will release any accumulated hydrogen gas. As the gas is flammable, DO NOT smoke
or use an open flame during this time.
ŶDO NOT allow children to play on or in this appliance. Close supervision of children is necessary when this
appliance is used near children. Before the washer is removed from service or discarded, remove the door or
lid. Failure to follow these instructions may result in death or injury to persons.
ŶDO NOT reach into the appliance if the tub or agitator is moving to prevent accidental entanglement.
ŶDO NOT install or store this appliance where it will be exposed to the weather.
ŶDO NOT tamper with controls, repair or replace any part of this appliance or attempt any servicing unless
specifically recommended in the user maintenance instructions or in published user repair instructions that you
understand and have the skills to carry out.
ŶDO NOT operate this appliance if it is damaged, malfunctioning, partially disassembled, or has missing or
broken parts including a damaged cord or plug.
ŶUnplug the appliance or turn off the circuit breaker before servicing. Pressing the Power button DOES NOT
disconnect power.
ŶSee “ELECTRICAL REQUIREMENTS” located in the Installation Instructions for grounding instructions.
WARNING
SAFETY INFORMATION

449-90565
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
PROPER INSTALLATION
This washer must be properly installed and located in accordance with the Installation Instructions before it is used.
ŶEnsure that the hot water hose is connected to the “H” valve and the cold water hose is connected to the “C”
valve.
ŶInstall or store where it will not be exposed to temperatures below freezing or exposed to the weather, which
could cause permanent damage and invalidate the warranty.
ŶProperly ground washer to conform with all governing codes and ordinances. Follow details in the Installation
Instructions.
ŶEnsure washer is properly leveled and washer legs are adjusted such that unit is stable.
ŶOptional drain hose extension recommended for discharging heights from 60” - 96”.
ŶGE Appliances strongly recommends the use of factory specified parts. A list of factory hoses available for
purchase are listed. These hoses are manufactured and tested to meet GE Appliances specifications.
ŶGE Appliances strongly recommends the use of new water supply hoses. Hoses degrade over time and need
to be replaced every 5 years to reduce the risk of hose failures and water damage.
PARTS AND ACCESSORIES
Order on-line at GEApplianceparts.com today,
24 hours a day or by phone at 800.626.2002 during
normal business hours. In Canada, visit your local
GE Appliances parts distributor or call 800.661.1616.
Part Number Accessory
PM14X10002 4 ft rubber water supply hoses
Or
PM14X10005 4 ft braided water supply hoses
WH49X301 Drain hose extension
PM7X1 Washer Floor Tray
WHEN NOT IN USE
ŶTurn off water faucets to minimize leakage if a break or rupture should occur. Check the condition of the fill
hoses; GE Appliances recommends changing the hoses every 5 years.
Plug into a grounded 3 prong outlet.
DO NOT remove ground prong.
DO NOT use an adapter.
DO NOT use an extension cord.
Failure to follow these instructions can result in death, fire or electrical shock.
- Electrical Shock Hazard
WARNING
SAFETY INFORMATION
START-UP SEQUENCE
ŶAny time the washer is being started or restarts after the washer lid has been opened and closed, the washer
will turn on the cold water valve for two short periods followed by a 10 second pause before continuing. If the
lid is opened during this period, the washer will pause. You will have to push the Start button again to restart
the cycle.
ŶMachine will automatically drain any time the lid is left open for more than 15 minutes and water is present.

49-90565 5
USING THE WASHER
Getting started
Throughout this manual, features and appearance may vary from your model.
To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY
INSTRUCTIONS before operating this appliance.
WARNING
A
B
Power
Press to “wake up” the display. If the display is active, press to put the washer into idle mode.
NOTE: Pressing Power does not disconnect the appliance from the power supply.
Start/Pause
Press Start to begin the cycle. NOTE: Unless Bulky Items cycle is selected, the lid must be closed for the washer to start cycle.
If the lid is open, “Lid” will scroll across the display. During the load sensing portion of the cycle, the lid will lock and “SEnSing” will
scroll across the display. When load sensing is complete, the lid will unlock.
Pressing Pause will unlock the lid (if locked at that time), pause the cycle and the Start indicator light will blink.
To continue the cycle, press Start again. If water remains in the machine, select the Drain & Spin cycle to drain basket and spin
water out of the washer basket.
NOTE: Machine will automatically cancel and drain when water is present and the lid is left open
for 15 minutes or the unit is left in a paused state for 24 hours with the lid closed. Select cycle and press Start to begin new cycle.
• Loosely add items around Infusor.
Overloading may negatively
impact wash performance. See
page 11 for suggested loading
examples.
• Close lid.
NOTE: Unless using Bulky Items
cycle washer will not start with
lid open.
Step 2 Step 3 Step 4
Step 1
• Select wash cycle.
• Select wash options,
including Deep Rinse
option when using fabric
softener.
• Select options.
• Press
Start.
• Add fabric softener to the fabric
softener dispenser; see page 10.
• Add the manufacturer’s
recommended amount of detergent.
GE Appliances recommends the
use of High Efficiency detergents
such as in your energy
efficient washer. Place detergent
pods in the bottom of the wash
basket before adding clothes.
Display and Status Lights
Display: The display shows the approximate time remaining until the end of the cycle. NOTE: The cycle time is affected by
how long it takes the washer to fill. This depends on the water pressure in your home. The size of the load being washed also
significantly impacts cycle time, with larger loads taking longer.
In addition, this display will, “scroll” the washer status:
• bALAnCINgStart of rebalancing cycle to redistribute clothes. Stops after rebalancing is complete.
• dELAY When Delay Wash is initiated. Replaced with estimated time when cycle starts.
• End End of current cycle.
• FILL “FILL” will scroll across display for the first 45 seconds of fill, afterwards the estimated end of cycle time is
displayed.
• H2O SUPPLYCan not sense water level (valves possibly turned off).
• LId Cycle stopped because lid is open. Close the lid.
• SEnSIng Sensing load size and type before and during fill (normal).
• PAUSE Cycle paused because the Start/Pause button was pressed and the washer was set to Pause. Press Start
button again to restart the cycle.
Cycle status lights: Shows whether the washer is in the Delay,Fill,Soak,Wash, Rinse or Spin portion of the cycle.
If an out-of-balance condition is detected by the washer, the Spin light will blink during the remaining portion of the cycle and
will stay illuminated for a short time after cycle completion. When this occurs, the washer is taking actions to correct the out-of-
balance condition and complete the cycle normally. In some cases, the washer may not be able to balance the load and
spin up to full speed. If you notice the load is more wet than normal at the end of the cycle, redistribute the load evenly in the
wash basket and run a Drain & Spin cycle.
C
Lid Lock
Spin Stop
DC
A
BFGH
H
G
GH
E

649-90565
Getting started
USING THE WASHER
D
Items to Wash Cycle Wash Temp Soil Level Spin
Selection Options Available Cycle Details
Cycle for normal,
regular, or typical
use for washing
up to a full load
of normally soiled
cotton clothing.
Colors Hot
Warm
Colors
Cool
Cold
Tap Cold
Ex. Heavy
Heavy
Normal
Light
Max
More
Normal
No Spin
Stain Removal Guide
Warm Rinse
Auto Soak
Deep Rinse
Delay Wash
Extra Rinse
Cycle for normal, regular, or typical
use for washing up to a full load
of normally soiled cotton clothing.
Choose the Heavy or Extra Heavy soil
level selection and Warm or Hot water
temperature selection as appropriate
for your clothes load for a higher
degree of cleaning. Incorporates multi-
stage fills and wash periods to provide
optimal fabric care.
Casual clothes,
lightly soiled
office wear.
Casuals Hot
Warm
Colors
Cool
Cold
Tap Cold
Ex. Heavy
Heavy
Normal
Light
Max
More
Normal
No Spin
Stain Removal Guide
Deep Fill
Warm Rinse
Auto Soak
Deep Rinse
Delay Wash
Extra Rinse
Wash cycle tailored to care for
casual clothes and office wear
items.
Lingerie and
special care
fabrics with light
soil.
Delicates Hot
Warm
Colors
Cool
Cold
Tap Cold
Ex. Heavy
Heavy
Normal
Light
Max
More
Normal
No Spin
Stain Removal Guide
Deep Fill
Warm Rinse
Auto Soak
Deep Rinse
Delay Wash
Extra Rinse
Utilizes a unique "tri-pulse" extra
gentle agitate profile to provide
special care to delicate fabrics. It
is recommended to place small or
ultra delicate items in mesh bags
before washing.
Medium to lightly
soiled athletic
wear items of
technical or
synthetic fabrics.
Active
Wear Hot Warm
Colors
Cool
Cold
Tap Cold
Ex. Heavy
Heavy
Normal
Light
Max
More
Normal
No Spin
Stain Removal Guide
Deep Fill
Warm Rinse
Auto Soak
Deep Rinse
Delay Wash
Extra Rinse
Cycle designed for care of medium
to lightly soiled active wear,
athletic wear, and technical fabrics.
Incorporates a dual stage wash
period with soak to effectively treat
body soils and odors. Use the Heavy
Duty cycle for heavily soiled sports
clothing constructed of sturdy fabric.
Dark colored
fabrics and mixed
loads.
Cold
Wash Hot Warm
Colors
Cool
Cold
Tap Cold
Ex. Heavy
Heavy
Normal
Light
Max
More
Normal
No Spin
Stain Removal Guide
Deep Fill
Auto Soak
Deep Rinse
Delay Wash
Extra Rinse
Cycle combines multiple wash
agitation periods with soak periods
to provide enhanced cleaning
performance and energy efficiency
with colder water temperatures.
Small loads of
lightly soiled
items that are
needed in a hurry.
Examples include
one casual wear
outfit or 3 soccer
uniforms.
Speed
Wash Hot Warm
Colors
Cool
Cold
Tap Cold
Ex. Heavy
Heavy
Normal
Light
Max
More
Normal
No Spin
Stain Removal Guide
Deep Fill
Warm Rinse
Auto Soak
Deep Rinse
Delay Wash
Extra Rinse
Utilizes more intense agitation
profile, expedited wash period, and
time saving continuous spray rinse
to clean small lightly soiled loads in
the fastest time possible.
Wet load of items.
For items that
need only to be
rinsed, use this
cycle with Deep
Rinse option.
Drain &
Spin Max More
Normal
No Spin
Deep Rinse
Extra Rinse
Utilizes a high speed spin to extract
water from wet items. For items that
need to be rinsed, select the Deep
Rinse option when using this cycle.
Wash Cycles-Cycle Selector Knob
The wash cycle controls the type of washing process. The cycle selector knob can be turned in either direction. Turning the
knob after starting a cycle will stop the washer and change the cycle/options to the new selection. Press Start to begin the
new cycle selection.
The chart below will help you match the items to be washed with the best wash cycle settings. For optimal performance,
select the cycle that most closely matches the items being washed.
Selections and options shown in bold are the recommended settings for that cycle.
Some cycles and options may not be available on some models.
Feature status lights indicate (see sections F and Gfor more details):
Pause - Will display when washer is paused between cycles.
Controls - The washer is locked - will blink once if you press any button or turn the cycle knob.
Lid Lock - The lid is locked. See the Control Lock description.
Spin Stop - Indicates wash basket is coasting to a stop following spin. Lid will not unlock until basket has fully come to a stop.

49-90565 7
USING THE WASHER
Getting started
Items to Wash Cycle Wash Temp Soil Level Spin
Selection Options Available Cycle Details
Cleaning the
basket of residue
and odor. No
clothes to be
washed using this
cycle.
Basket
Clean Hot Ex. Heavy Normal Deep Fill Deep Rinse Recommended use of at least once per month. Never load
laundry when using this cycle;
laundry may become damaged or
contaminated. Cycle incorporates
a hot deep wash, intense agitation
action, a dispenser purge (on
some models), and a deep rinse.
Heavily soiled
colorfast items. Sanitize with Oxi*Hot Ex. Heavy Max More Warm Rinse Auto Soak
Deep Rinse
Delay Wash
Extra Rinse
Cycle uses an initial lower water
fill for super concentrated,
high temperature sanitization
followed by a heavy wash
step.Apump purge and deep
rinse is incorporated to remove
contaminants. See additional details
and certifications below.
Jeans with
medium to light
soil. For heavily
soiled work jeans,
use the Heavy
Duty Cycle.
Jeans Hot
Warm
Colors
Cool
Cold
Tap Cold
Ex. Heavy
Heavy
Normal
Light
Max
More
Normal
No Spin
Stain Removal Guide
Deep Fill
Warm Rinse
Auto Soak
Deep Rinse
Delay Wash
Extra Rinse
Combines higher water levels,
a specially designed agitation
profile, and multi-step wash and
soak periods to care for jeans with
medium to light soil. Use the Heavy
Duty cycle for heavily soiled work
jeans.
Sturdy fabrics with
heavy to medium
soil.
Heavy
Duty Hot Warm
Colors
Cool
Cold
Tap Cold
Ex. Heavy
Heavy
Normal
Light
Max
More
Normal
No Spin
Stain Removal Guide
Deep Fill
Warm Rinse
Auto Soak
Deep Rinse
Delay Wash
Extra Rinse
Incorporates multi-step wash
and
soak periods combined
with extended
wash periods
to effectively clean heavily to
medium soiled sturdy fabrics.
Large coats, bed
spreads, mattress
covers, sleeping
bags, and similar
large bulky items.
Bulky
Items Hot Warm
Colors
Cool
Cold
Tap Cold
Ex. Heavy
Heavy
Normal
Light
Max
More
Normal
No Spin
Stain Removal Guide
Deep Fill
Warm Rinse
Auto Soak
Deep Rinse
Delay Wash
Extra Rinse
Provides a Deep Fill/max fill
wash water level with a specially
designed agitation profile to wash
bulky items.Also incorporates a
Deep Fill rinse to effectively rinse
bulky items.
Towels
Sheets Towels / Sheets Hot Warm
Colors
Cool
Cold
Tap Cold
Ex. Heavy
Heavy
Normal
Light
Max
More
Normal
No Spin
Stain Removal Guide
Deep Fill
Warm Rinse
Auto Soak
Deep Rinse
Delay Wash
Extra Rinse
Cycle designed washing towels
or sheets, using a higher
water level and a soak period to
effectively clean these items. It
is recommended that towels and
sheets be washed separately
for best care and washing
performance.
Whites and
household linens Whites Hot Warm
Colors
Cool
Cold
Tap Cold
Ex. Heavy
Heavy
Normal
Light
Max
More
Normal
No Spin
Stain Removal Guide
Deep Fill
Warm Rinse
Auto Soak
Deep Rinse
Delay Wash
Extra Rinse
Cycle tailored to clean and brighten
your whites.
The Sanitize with Oxi cycle, when using an Oxi additive along with your detergent, is designed to remove 99.9% of bacteria found in
home laundry.
Measure the detergent and the Oxi products carefully. Using the amounts appropriate for a large heavily soiled load, follow the
detergent and the Oxi product label instructions. The detergent should be added using the dispenser instructions as shown on
page 11 of this guide. Place the Oxi product directly in the bottom of the wash basket, before adding the clothes. The washer hot
water supply connection must provide a minimum of 120°F to ensure the effectiveness of this cycle.
NOTE: The default Sanitize With Oxi cycle water temperature can NOT be changed.
The Sanitize With Oxi cycle is certified by NSF International, an independent third party testing and certification organization.
The certification verified that the cycle reduced 99.9% of bacteria typically found in residential laundry and that no significant
contamination is transferred to subsequent washer loads. Only the Sanitize With Oxi cycle has been designed to meet the
requirements of NSF Protocol P172 for sanitizing effectiveness. NSF Protocol P172
Sanitization Performance of Residential and
Commercial, Family-Sized Clothes Washers
Sanitize with Oxi

849-90565
Getting started
USING THE WASHER
EStain Removal Guide
The Stain Removal Guide feature allows you to indicate what stains are on the garments in your load. This feature
incorporates a patent pending treatment method. An initial water fill is performed at a temperature tailored to the stain type
selected and to an amount which enables a concentrated cleaning step. A stain scrubbing period, followed by an active
soak, is conducted to effectively treat the stain. Then additional water is added to the selected temperature and the wash
phase is conducted for the cycle selected.
This feature can be applied to most wash cycles as described in the cycle guide.
To use Stain Removal Guide:
1. Select the desired wash cycle.
2. Press the Stain Removal Guide button.
Continue to press to select Tomato stain, Wine stain, Blood stain, Grass stain or Dirt stain. The indicator light will show
the selected stain.
To select a different stain, press the Stain Removal Guide button until desired stain to be removed is lit.
To turn off Stain Removal Guide, press until no indicator lights are illuminated.
NOTE: The Soil and Temperature levels will be changed to match the recommended default setting for each stain type.
Turning off Stain Removal Guide will return the settings to default.
Stain Removal Guide
Category Recommended Temperatures
Treatment/Wash Stain For best results,
before placing in washer:
Blood Cold/Cool Blood
Sweat
Body Fluids
Urine
Rinse in cold water; pretreat
stain with liquid detergent or
stain remover product.
Grass Cold/Warm Grass
Lipstick
Chocolate
Gravy
Mayonnaise
BBQ Sauce
Pretreat with liquid
detergent or stain remover
product. Brush lightly; rinse
with cold water.
Dirt Cool/Warm Dirt
Clay
Mud
Allow dirt to dry; remove
loose dirt using a brush.
Rinse with cool water.
Tomato Cool/Warm Sauce
Catsup
Salsa
Pretreat with liquid
detergent or stain remover
product; rinse with cool
water.
Wine Cool/Warm Wine
Soda
Kool-Aid
Tea
Coffee
Juice
Beer
Pretreat with mixture of Oxi
product and cool water.
Add Oxi product along with
detergent in the washer.
• Recommended temperatures are optimal for stain removal performance; adjust temperature selection to suit load being
washed.
• Ensure stain is completely removed after wash cycle and before placing in dryer; very tough stains may require a second
treatment.

49-90565 9
USING THE WASHER
Getting started
Cycle Options
Deep Fill
Select the Deep Fill feature for loads where extra water is needed. The Deep Fill feature is recommended for special case
loads only, not for typical use.
Press the Deep Fill button once before starting the cycle to add an incremental amount of water to the wash load. Holding the
Deep Fill button for 3 seconds will provide the deepest fill level possible; this will increase cycle time due to the additional time it
takes to fill the washer.
To cancel the option if desired, press the Deep Fill button again.
NOTE: The Deep Fill button can also be pressed after the washer has completed filling and is in the wash phase if additional
water is desired. To stop the extra fill, press the Deep Fill button again and the water will stop.
Warm Rinse
Provides a warm rinse to your wash load. Note that rinsing operations may be different with this operation selected in order to
effectively apply the warm rinse water to your load.
Auto Soak
This option begins with a brief agitation, soaks for a specified period of time, then moves through the rest of the cycle
automatically. Repeated pressing of the Soak button will scroll through 15 minute, 30 minute, 1 hour and 2 hour selections and
then return back to 0 soak minutes.
Deep Rinse
Set this option to provide a deep rinse or when using fabric softener. It may change other settings (e.g. Spin may go to a higher
setting) to maximize performance.
Delay Wash
When the Delay Wash button is repeatedly pressed, the delay time is set from 1 (01H) to 9 (09H) hours and back to clear (00H)
hours. If you
press and hold the Delay Wash button for 3 seconds, it will immediately reset.
Extra Rinse
When you use extra detergent or bleach to clean heavily soiled clothes, use the Extra Rinse option to better remove additional
residues. NOTE: This option is not allowed for some cycles.
Additional Options
My Cycle Settings
As the cycle selector knob is turned, the Temp, Soil and Spin settings change to automatic pre-set default settings for each
cycle. If you desire different default settings, select the desired options or changes to the cycle settings, then press and hold
the My Cycle button for 3 seconds to store them. The My Cycle button will light when active. In the future, when you
turn the selector knob to that cycle, your settings will be automatically recalled. To restore the factory defaults temporarily
(i.e. for this load), press the My Cycle button for 1/2 second. The My Cycle light will turn off and the factory defaults will
load. However, the next time you select this cycle, your My Cycle settings will load. If you wish to permanently restore the
factory default settings for the cycle; when the My Cycle is active (button light on) press and hold the My Cycle button for 3
seconds. The factory defaults will load for the selected cycle and the My Cycle light will turn off. The default settings will load
when this cycle is selected in the future and the My Cycle light will remain off. NOTE: My Cycle saves the following options:
Temp, Soil, Spin, Extra Rinse, Deep Fill, Warm Rinse, Auto Soak, Deep Rinse and Stain Removal Guide.
Volume
Use the Volume button to change the volume of the end of cycle signal and other system tones. Press the button until you reach
the desired volume (high, medium, low) or off.
Control Lock
Use the control lock before or during a cycle to prevent any selections from being made.
To lock/unlock the washer controls, press and hold the Warm Rinse and Auto Soak buttons for 3 seconds. The control lock
icon will light up when it is on. NOTE: The Power button can still be used when the machine is locked.
G
H
Settings
Individual settings for agitation (Soil), water temperature (Temp), and spin (Spin) can be set from the minimum (lowest in
column) to maximum (highest in column). In general, the higher up the column, the more washer energy will be used.
NOTE: Longer Spin times typically reduce dryer time/energy usage (i.e. reduces total energy when using both a washer and
a dryer).
F

10 49-90565
Automatic Load Sensing
This determines the correct agitate profile, agitate duration and amount of water suited to the size and type of load placed in the
washer. The washer will not start the wash cycle or fill with water if the lid is open. When the lid is closed the machine is able to
begin filling with water in order to sense the load size.
NOTE: Automatic Load Sensing initiates a spin at the beginning of the cycle and will take as much as 3 minutes to complete
(significantly shorter for smaller loads); this is normal operation.
NOTE: This is a high efficiency washing machine with Infusor wash action. This system requires less water while providing effective
cleaning action. You may notice that the water level is lower than on your previous washer. This is normal for an Infusor-equipped
washer.
Getting started
USING THE WASHER
Liquid chlorine bleach should be added through the
bleach dispenser in the front left corner. Follow bleach
manufacturer’s recommendations for the correct amount of
liquid chlorine bleach based on load size, taking care to not
apply or spill it directly on clothing.
NOTE: Do not use liquid chlorine bleach and laundry
pretreatments such as an Oxi product in the same wash load.
Liquid Bleach
Place laundry pretreatments, such as an Oxi product, directly
in the bottom of the wash basket before loading clothes.
NOTE: Do not use liquid chlorine bleach and laundry
pretreatments such as an Oxi product in the same wash load.
Pretreatment
Liquid or powdered HE detergent should be added to the
right side of the dispenser drawer. Follow the detergent
manufacturer’s recommendations for the correct amount of
detergent, based on load size, taking care to add detergent
to the right compartment. Do not overfill or dilute detergent
as this can result in additive being dispensed prematurely in
the wash cycle. Your option selections will determine when
detergent is automatically dispensed at its optimal time in the
wash cycle.
NOTE: Single-dose laundry packets should not be added to
the dispenser drawer, as they will not dispense properly. Put
packets in bottom of wash basket.
Detergent Dispenser
Liquid fabric softener should be added to the left side
of the dispenser drawer. Follow the liquid fabric softener
manufacturer’s recommendations for the correct amount of
softener, based on load size, taking care to add softener to
the left compartment. Do not overfill or dilute softener as this
can result in additive being dispensed prematurely in the wash
cycle. Your option selections will determine when liquid fabric
softener is automatically dispensed at its optimal time in the
rinse cycle.
NOTE: Fabric softener crystals should not be added to the
dispenser drawer, as they will not dispense properly.
Liquid Fabric Softener Dispenser
