GEAppliances WASE6280 User manual

GEAppliances.com
WASE6280
WCSE6270
WNSE6280
WSSE6280
WWSE6260
EWA3000
Owner’s Manual
Washers
175D1807P350 49-90088 06-01 JR
Safety Instructions . . . . . . . .2, 3
Operating Instructions
Control Panel . . . . . . . . . . . .4, 5
Control Settings . . . . . . . . . .6, 7
Features . . . . . . . . . . . . . . . . .8, 9
Loading and Using
the Washer . . . . . . . . . . . . 10, 11
Troubleshooting Tips . . . .12–14
Consumer Support
Consumer Support . .Back Cover
Product Registration . . . . .15, 16
Warranty . . . . . . . . . . . . . . . . .19
Write the model and serial
numbers here:
Model # ______________
Serial # ______________
You can find them in the
upper right corner on the
back of your washer.

■Install or store where it will not be exposed to
temperatures below freezing or exposed to
the weather.
■Properly ground washer to conform with all
governing codes and ordinances. Follow details
in Installation Instructions.
2
WATER HEATER SAFETY
Under certain conditions hydrogen gas may be produced in a water heater that has not been used for two
weeks or more. Hydrogen gas can be explosive under these circumstances.
If the hot water has not been used for two weeks or more, prevent the possibility of damage or injury
by turning on all hot water faucets and allowing them to run for several minutes. Do this before using
any electrical appliance which is connected to the hot water system. This simple procedure will allow
any built-up hydrogen gas to escape. Since the gas is flammable, do not smoke or use an open flame
or appliance during this process.
PROPER INSTALLATION
This washer must be properly installed and located in accordance with the Installation Instructions
before it is used. If you did not receive an Installation Instructions sheet, you can receive one by visiting
GEAppliances.com, or by calling 800.GE.CARES (800.432.2737).
■Keep the area underneath and around your
appliances free of combustible materials such
as lint, paper, rags, chemicals, etc.
■Close supervision is necessary if this appliance
is used by or near children. Do not allow
children to play on, with, or inside this or
any other appliance.
YOUR LAUNDRY AREA
IMPORTANT SAFETY INSTRUCTIONS.
READ ALL INSTRUCTIONS BEFORE USING.
For your safety, the information in this manual must be followed to minimize the risk of fire,
explosion, electric shock, or to prevent property damage, personal injury, or loss of life.
WARNING!
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips

Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
■Never reach into washer while it is moving.
Wait until the machine has completely
stopped before opening the lid.
■Do not mix chlorine bleach with ammonia
or acids such as vinegar and/or rust remover.
Mixing different chemicals can produce
a toxic gas which may cause death.
■Do not wash or dry articles that have been
cleaned in, washed in, soaked in, or spotted
with combustible or explosive substances
(such as wax, oil, paint, gasoline, degreasers,
dry-cleaning solvents, kerosene, etc.) which
may ignite or explode. Do not add these
substances to the wash water. Do not use or
place these substances around your washer
or dryer during operation.
■ The laundry process can reduce the flame
retardancy of fabrics. To avoid such a result,
carefully follow the garment manufacturer’s
wash and care instructions.
■To minimize the possibility of electric shock,
unplug this appliance from the power supply
or disconnect the washer at the household
distribution panel by removing the fuse or
switching off the circuit breaker before
attempting any maintenance or cleaning.
NOTE: Turning the Cycle Selector knob to
an off position, or pressing PAUSE does
NOT disconnect the appliance from the
power supply.
■Never attempt to operate this appliance if
it is damaged, malfunctioning, partially
disassembled, or has missing or broken parts,
including a damaged cord or plug.
WHEN USING THE WASHER
■Turn off water faucets to relieve pressure on
hoses and valves and to minimize leakage if
a break or rupture should occur. Check the
condition of the fill hoses; they should be
replaced every 5 years.
■Before discarding a washer, or removing
it from service, remove the washer lid to
prevent children from hiding inside.
■Do not attempt to repair or replace any
part of this appliance unless specifically
recommended in this Owner’s Manual, or
in published user-repair instructions that you
understand and have the skills to carry out.
■Do not tamper with controls.
WHEN NOT IN USE
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
3
Use this
appliance
only for its
intended
purpose as
described in
this Owner’s
Manual.
GEAppliances.com

Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
4
Model WASE6280
Quick Start Guide
• Add detergent
• Add diluted fabric
softener (on models
with a fabric
softener dispenser)
• Add clothes • Select load size and
other wash options
• Select wash cycle
• Close lid
• Push
START
NOTE: When making a selection with any knob, simply point the knob anywhere within the shaded range for that setting.
About the washer control panel.
Model WCSE6270
Model WSSE6280

5
GEAppliances.com
Model WWSE6260
Model WNSE6280
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
Model EWA3000

6
Color Logic
Select the correct TEMPERATURE setting. Match the particular color below the words
with the same color on the WASH/SPIN SPEED setting. Next, match the color again
with the same color on the Cycle Selector knob.
Example: Washing a load of medium soiled cotton towels and sheets.
Choose the LOAD SIZE.
Choose the TEMPERATURE setting— for this load it would be the HOT COLD
(which is a particular color) .
Choose the WASH/SPIN SPEED setting that matches that color—for this load it
would be the NORMAL FAST.
Turn the Cycle Selector knob to the area that has the same color as the
TEMPERATURE and WASH/SPIN SPEED settings you have chosen—for this load it
would be the COTTONS area. Turn the knob to the MEDIUM setting.
Load Size
Loosely load clothes no higher than the top row of holes in the washer tub.
The water level should just cover the clothes. Adjust the load size accordingly.
Custom Care Wash/Spin Speeds
The agitator moves clothes around for a cleaner wash; the basket spins later
in the cycle to release water from the load. The Wash/Spin Speed dial sets the
speed of both the agitator and the basket.
Wash Speeds
With Normal Speed, the agitator will move at a high speed for the first
few minutes, then it slows down to a moderate speed. This gets your clothes
clean while reducing wear on your clothing. Use for cottons, denims and
play clothes.
With Gentle Speed, the agitator moves slower. Use for delicate and
knit items.
With Handwash, the agitator will move slowly and will pause for periods to
allow the clothes to soak. Use for items labelsed handwash.
With Casuals, the agitator will agitate and then pause to soak your clothes.
It provides a gentler way to wash your wrinkle-free and permanent press items
and knits.
Spin Speeds
The Fast spin speed is for normal items. Use it to remove more water from
your clothes to allow them to dry faster in the dryer.
The Slow spin speed is for delicate items like sweaters and lingerie. When
using Slow spin speed, clothes will be less dry than when using Fast spin speed.
Temperature
Select the water temperature for the wash and rinse cycles. Always follow
fabric manufacturer’s care label or instructions when laundering.
4
3
2
1
About the washer control settings.
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips

Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
7
GEAppliances.com
Wash Cycle
The wash cycle controls the length of the washing process. The knob can be turned in either
direction. Turning the Cycle Selector knob after starting a cycle will stop the washer and reset
the cycle to the new selection. Press START to begin the new cycle selection.
The Cycle Indicator Lights show what stage the washer is in. The wash time is the length of the
wash agitation. The 6 MIN light will remain lit during drain and spin. When the Selector knob
is set to a new cycle the Indicator Lights will flash momentarily, showing what stages the cycle
will go through. On models without an AUTO SOAK option, the SOAK light will not light up.
The chart below will help you match the wash cycle setting with your clothing.
COTTONS For heavy to lightly soiled cottons, household linens, work and play clothes.
EASY CARE For wrinkle-free and permanent press items, and knits.
HANDWASH For items labeled handwashable with light soils. Provides period of agitation and soak during
wash and rinse.
CASUALS For wrinkle-free and permanent press items, and knits. The HEAVY cycle has three agitate/pause cycles to
clean your heavily soiled items. The MEDIUM cycle has two agitate/pause cycles.
DELICATES For lingerie and special-care fabrics with light to normal soil.
QUICK RINSE For quickly rinsing chlorine, perspiration, stains, etc., out of clothes.
15 MIN/30 MIN For heavily soiled clothes. Begins with a brief agitation, soaks for a specified period of time, then moves
AUTO SOAK through the rest of the cycle automatically.
START
Press START to begin the cycle. Pressing START again or raising the lid will PAUSE the cycle
and the Cycle indicator light will blink.
REMEMBER: When
choosing the cycle, the
Cycle Selector knob can
be pointed anywhere
within the shaded range
for the cycle setting.

PerfecTemp
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
8
About washer features.
PerfecTemp (on some models)
PerfecTemp senses the incoming water temperature and adjusts the fill water to obtain
a more precise temperature range for all three wash temperatures. You may select cold,
warm or hot. For example, in a Cold Wash selection, some warm water may be added
to reach a temperature needed to better dissolve detergents. Often, detergents are not
completely dissolved in very cold water, especially in cooler climates.
NOTE: PerfecTemp will not adjust the fill on WARM WASH unless the washer lid is
closed. Be sure to start the washer after the lid is closed.
(appearance and features may vary)
Spot Spray (on some models)
Provides a short spray of water to allow you to dampen clothing when you pretreat stains.
Open the washer lid.
Press the SPOT SPRAY button. (You will see a short stream of water.)
Dampen your soiled garment with the SPOT SPRAY option and rub your favorite
pretreatment product into soiled area.
NOTE: The SPOT SPRAY option will not work if
■ the washer lid is down
■ the washer tub is filling
■ the water has already reached the level you selected.
3
2
1
SPOT SPRAY
AutoTemp (on some models)
AutoTemp senses the incoming water temperature and adjusts the cold water
temperature to ensure that the incoming cold water is warm enough to dissolve
the detergent. Often, detergents are not completely dissolved in very cold water,
especially in cooler climates.
AutoTemp
Stain Assist (on some models)
This option adds a short agitation and a soaking period at the beginning of the
selected wash cycle.
2nd Rinse Option (on some models)
When you use extra detergent or bleach to clean heavily soiled clothes, you may want
to use the 2nd Rinse option. It provides a second deep cold rinse.
Extended Spin Option (on some models)
Use this option to extract more water from your clothes. Clothes will be drier when
this option is selected, and will dry more quickly in your dryer.
Signal Off Option (on some models)
Some models have a signal that will sound at the end of the cycle. Use this option to
turn off the signal.

Liquid Bleach Dispenser
The dispenser dilutes liquid chlorine bleach before it reaches into your wash load.
Check clothing care labels for special instructions.
Measure liquid bleach carefully, following instructions on the bottle.
■ Never pour undiluted liquid chlorine bleach directly onto clothes or into the wash basket.
■ Do not pour powdered bleach into bleach dispenser.
Before starting the washer, pour measured amount of bleach directly into
bleach dispenser. Avoid splashing or over-filling dispenser. If you prefer to
use powdered bleach, add it into the wash basket with your detergent.
■ Do not mix chlorine bleach with ammonia or acids such as vinegar and/or rust remover.
Mixing can produce a toxic gas which may cause death.
3
2
1
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
9
GEAppliances.com
Cleaning the Fabric Softener Dispenser
Remove the dispenser from the top of the agitator.
Separate the dispenser cup from the cover by grasping the top and pushing
down on the inside of the cup with your fingers. Dispenser cup will pop free
from the cover.
To clean the dispenser, soak both the dispenser cup and the dispenser cover
in the following solution:
■ 1 US gallon (3.8 liters) warm water
■ 1/4 cup (60 ml) heavy-duty liquid detergent
■ 1 cup (240 ml) bleach
If necessary, loosen build-up with a clean, soft cloth after soaking. Do not use
a stiff brush; you may roughen the surface of the dispenser.
Rinse and reassemble dispenser. Place dispenser back on the agitator.
5
4
3
2
1
Separate for cleaning.
The Agitator Cap or Fabric Softener Dispenser
The agitator cap fits into the top of the
agitator. If it accidentally comes off,
simply put it back on.
The fabric softener dispenser automatically
releases liquid fabric softener at the
proper time during the cycle.
Do not stop the washer during the first spin.
This will cause the dispenser to empty
too soon.
To use, follow these steps:
Make sure dispenser is securely
attached to agitator.
Use only liquid fabric softener.
Pour into dispenser, using amount
recommended on package.
Never pour fabric softener directly on
clothes. It may stain them.
Add water to dispenser until it
reaches the maximum fill line.
3
2
1
Do not pour anything into the agitator if
the agitator cap or dispenser is removed.

10
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
Loading and using the washer. Always follow fabric manufacturer’s care label when laundering.
Sort by color (whites, lights, colors), soil level,
fabric type (sturdy cottons, easy care, delicates),
and whether the fabric produces lint (terry
cloth, chenille), or collects lint (velveteen,
corduroy).
Sorting Wash Loads
Add detergent and start the washer before
adding clothes so that the detergent can
work effectively. Using too little or too much
detergent is a common cause of laundry
problems.
You can use less detergent if you have soft water,
a smaller load, or a lightly soiled load.
Proper Use of Detergent
Load dry items loosely, no higher than the top
row of holes in the washer basket. When loading
wet items make sure you set the load/water level
high enough to allow the items to move freely.
Water level should just cover the clothes. To add
items after washer has started, lift the lid and
submerge additional items next to the agitator.
■ Do not wrap long items like sheets or pants
around the agitator.
■ Do not wash fabrics containing flammable
materials (waxes, cleaning fluids, etc.).
■ Agitation will not start with the lid up.
Loading the Washer

11
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
Care and Cleaning of the Washer
Wash Basket: Leave the lid open after washing to
allow moisture to evaporate. If you want to clean the
basket use a clean soft cloth dampened with liquid
detergent, then rinse. (Do not use harsh or gritty
cleaners.)
Fill Hoses: Hoses connecting washer to faucet
should be replaced every 5 years.
Lint Filter: The lint filter is located under the
agitator. It is self-cleaning and requires no
maintenance.
Exterior: Immediately wipe off any spills.
Wipe with damp cloth. Try not to hit surface
with sharp objects.
Moving and Storage: Ask the service technician to
remove water from drain pump and hoses. See the
Installation Instructions packed with product for
information on how to reinstall the shipping rod to
keep the tub stationary when moving the washer.
For more information, visit GEAppliances.com , or
call 800.GE.CARES (800.432.2737). Do not store
the washer where it will be exposed to the weather.
Long Vacations: Be sure water supply is shut off at
faucets. Drain all water from hoses if weather will
be below freezing.
Fabric Care Labels
Machine
wash
cycle
Normal Permanent Press/
wrinkle resistant
Gentle/
delicate Hand wash Do not wash Do not wring
Water
temperature
Hot
(50°C/120°F)
Warm
(40°C/105°F)
Cold/cool
(30°C/85°F)
Tumble
dry
Dry Normal Permanent Press/
wrinkle resistant
Gentle/
delicate Do not tumble dry
Do not dry
(used with
do not wash)
Heat
setting
High Medium Low No heat/air
Special
instructions
Line dry/
hang to dry Drip dry Dry flat In the shade
Bleach
symbols
Any bleach
(when needed) Only non-chlorine bleach
(when needed)
Do not bleach
WASH LABELS
DRY LABELS
BLEACH LABELS
Below are fabric care label “symbols” that affect the clothing you will be laundering.
GEAppliances.com

WATER Possible Causes What To Do
Too many suds Type of detergent •Switch to a lower sudsing detergent brand and follow
instructions on package.
Very soft water •Try less detergent.
Too much detergent •Measure your detergent carefully. Use less soap if you
have soft water, a smaller load, or a lightly soiled load.
Water leaks Fill hoses or drain hose is •Make sure hose connections are tight at faucets and
improperly connected rubber washers are installed. Make sure end of drain
hose is correctly inserted in and secured to drain facility.
Household drain may •Check household plumbing. You may need to call
be clogged a plumber.
Constant water pressure •Tighten hoses at the faucets and turn the water off after
to the fill hoses at the each use.
water source •Check condition of the fill hoses; they should be
replaced every 5 years.
Using too much detergent •Use less detergent. Use less soap if you have soft water,
in washer a smaller load, or a lightly soiled load.
Water temperature Control is not set properly •Check water temperature control and adjust.
is incorrect
Water supply is turned off •Turn both hot and cold faucets fully on and make sure
or improperly connected hoses are connected to correct faucets.
Water valve screens are • Turn off the water source and remove the water
stopped up connection hoses from the upper back of the washer.
Use a brush or toothpick to clean the screens in the
machine. Reconnect the hoses and turn the water back on.
House water heater is •Make sure house water heater is delivering water
not set properly at 120°F–140°F(48°C–60°C).
Water pumped out before Lid lifted or cycle was put in •Reset cycle.
cycle is complete pause for over 24 hours
Water won’t drain Drain hose is kinked or •Straighten drain hose and make sure washer is not
improperly connected sitting on it.
•Top of drain outlet should be less than 8 ft (2.5 m)
above floor.
Washer pauses in cycle The HANDWASH or CASUALS •This is normal. The washer alternates between agitate
cycle was chosen and soak during the HANDWASH and CASUALS cycles to
get your clothes cleaner with less wear.
PERFECTEMP/AUTOTEMP Possible Causes What To Do
PerfecTemp or AutoTemp The washer is in a cold rinse cycle •This normal. The PerfecTemp and AutoTemp features
wash temperature are designed not to activate during a cold rinse cycle
is incorrect to improve the energy efficiency of your washer.
(Review PerfecTemp All the water in your household •Wait until the water in the water heater is heated to the
and AutoTemp in the water heater has been used correct temperature.
“About washer
features” section)
12
Before you call for service…
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
Troubleshooting Tips
Save time and money! Review the charts on the following pages, or
visit GEAppliances.com. You may not need to call for service.

OPERATION Possible Causes What To Do
Washer won’t operate Washer is unplugged •Make sure cord is plugged securely into a working outlet.
Water supply is turned off •Turn both hot and cold faucets fully on.
Controls are not set properly •Check controls.
Lid is open – safety feature •Close lid and reset cycle, to the beginning if necessary.
prevents agitation and spinning
when lid is up
Circuit breaker/fuse is •Check house circuit breakers/fuses. Replace fuses or
tripped/blown reset breaker. Washer should have separate outlet.
Electronics need to be reset •Unplug washer, wait 2 minutes, plug back in, and
press START.
START was not pressed •Press START.
PERFORMANCE Possible Causes What To Do
Clothes too wet Incorrect spin cycle •Make sure the spin cycle selected matches the load you
selected are washing. Some fabrics will feel wetter when rinsed
with cold water.
Colored spots Incorrect use of fabric •Check fabric softener package for instructions and follow
softener directions for using dispenser.
•Pretreat stain and rewash.
Dye transfer •Sort whites or lightly colored items from dark colors.
Grayed or yellowed Not enough detergent •Use more detergent (especially with larger loads).
clothes
Hard water •Use a water conditioner like Calgon brand or install
a water softener.
Water is not hot enough •Make sure water heater is delivering water at
120°F–140°F (48°C–60°C).
Washer is overloaded •Select load size to match clothes load.
Detergent is not •Add detergent as wash basket fills with water before
dissolving you load clothes.
Dye transfer •Sort clothes by color. If fabric label states wash separately,
unstable dyes may be indicated.
Lint or residue on Clothes are air or line dried •If you do not dry your clothes with a clothes dryer, your
clothes clothes may retain more lint.
Incorrect sorting •Separate lint producers from lint collectors.
Washing too long •Wash small loads for a shorter time than larger loads.
Detergent not dissolving •Add detergent as wash basket fills with water, before you
load clothes.
•Try a liquid detergent.
•Use warmer water temperature.
Overloading •Load clothes no higher than the top row of holes in the
washer tub.
•Make sure load size selector matches clothes load size.
Incorrect use of fabric softener •Check fabric softener package for instructions
and follow directions for using dispenser.
13
GEAppliances.com
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions

OTHER Possible Causes What To Do
Labels on the exterior Occasionally the adhesive •Use a hair dryer set at the lowest heat setting, directing
of the washer will not used on the labels does the air at the label for a short amount of time. This will
peel off cleanly not release cleanly release the adhesive easily, without damaging the surface
of the washer.
NOISE Possible Causes What To Do
Washer is noisy Washer is uneven •To level the front of the washer, adjust the front leveling
legs by rotating the individual leg in the proper direction
for up or down. To level back of washer, lift back of
machine 4″(11 cm) and set down.
Washer load is •Press PAUSE to stop the washer, open the lid
unbalanced and redistribute the load evenly. Close the lid and
press START.
Shipping rod is still assembled •To remove shipping rod from washer, pull yellow tag and
in unit attached rod from the bottom right-hand side of washer.
Washer is sitting too close •Pull washer away from the wall; about 4″(11 cm)
to wall (causes knocking is needed.
during cycle)
PERFORMANCE (cont.) Possible Causes What To Do
Pilling Result of normal wear on •While this is not caused by the washer, you can slow the
poly-cotton blends and pilling process by washing garments inside out.
fuzzy fabrics
Snags, holes, tears, rips Pins, snaps, hooks, sharp •Fasten snaps, hooks, buttons, and zippers.
or excessive wear buttons, belt buckles, •Remove loose items like pins, objects in pockets,
zippers, and sharp objects and sharp buttons.
left in pockets •Turn knits (which snag easily) inside out.
Undiluted chlorine bleach •Check bleach package instructions for proper amount.
•Never add undiluted bleach to wash or allow clothes
to come in contact with undiluted bleach.
Chemicals like hair bleach •Rinse items that may have chemicals on them
or dye, permanent wave before washing.
solution
Wrinkling Improper sorting •Avoid mixing heavy items (like work clothes) with
light items (like blouses).
•Try a fabric softener.
Overloading or •Load your washer so clothes have enough room
incorrect water level to move freely.
Incorrect wash and •Match Cycle selection to the type of fabric you are
dry cycles washing (especially for easy care loads).
Repeated washing in •Wash in warm or cold water.
water that is too hot
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
14
Before you call for service…
Troubleshooting Tips

General Electric Company
Warranty Registration Department
P.O. Box 32150
Louisville, KY 40232-2150
GE Service Protection Plus™
GE, a name recognized worldwide for quality and dependability, offers you
Service Protection Plus™—comprehensive protection on all your appliances—
No Matter What Brand!
Benefits Include:
•Backed by GE
•All brands covered
•Unlimited service calls
•All parts and labor costs included
•No out-of-pocket expenses
•No hidden deductibles
•One 800 number to call
You will be completely satisfied with our service protection or you may request your money back
on the remaining value of your contract. No questions asked. It’s that simple.
Protect your refrigerator, dishwasher, washer and dryer, range, TV, VCR and much more—any brand!
Plus there’s no extra charge for emergency service and low monthly financing is available. Even icemaker
coverage and food spoilage protection is offered. You can rest easy, knowing that all your valuable
household products are protected against expensive repairs.
Place your confidence in GE and call us in the U.S. toll-free at 800.626.2224
for more information.
*All brands covered, up to 20 years old, in the continental U.S.
We’ll Cover Any Appliance.
Anywhere. Anytime.*
Please place in envelope and mail to:
✁Cut here
15

Consumer Product Ownership Registration
Important
Mail
Today!
General Electric Company
Louisville, Kentucky
GEAppliances.com
First
Name
Mr. ■■Ms. ■■Mrs. ■■Miss ■■
Street
Address
City State
Date Placed
In Use
Month Day Year
Zip
Code
Apt. #
Last
Name
Phone
Number __
Consumer Product Ownership Registration
Dear Customer:
Thank you for purchasing our product and thank you for placing your confidence in us.
We are proud to have you as a customer!
Follow these three steps to protect your new appliance investment:
Important: If you did not get a registration card with your
product, detach and return the form below to
ensure that your product is registered, or register
online at GEAppliances.com.
123
Model Number Serial Number
✁Cut here
Complete and mail
your Consumer
Product Ownership
Registration today.
Have the peace of
mind of knowing we
can contact you in
the unlikely event of
a safety modification.
After mailing the
registration below,
store this document
in a safe place. It
contains information
you will need should
you require service.
Our service number is
800.GE.CARES
(800.432.2737).
Read your Owner’s
Manual carefully.
It will help you
operate your new
appliance properly.
Model Number Serial Number
E-mail Address*
* Please provide your e-mail address to receive, via e-mail, discounts, special offers and other important
communications from GE Appliances (GEA).
■■Check here if you do not want to receive communications from GEA’s carefully selected partners.
16

17
Notes.
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions

18
Notes.
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips

■Service trips to your home to teach you how to use
the product.
■Improper installation.
■Failure of the product if it is abused, misused, or used for
other than the intended purpose or used commercially.
■Replacement of house fuses or resetting of circuit
breakers.
■Damage to the product caused by accident, fire, floods or
acts of God.
■Incidental or consequential damage caused by possible
defects with this appliance.
For The Period Of: We Will Replace:
What Is Not Covered:
One Year Any part of the washer which fails due to a defect in materials or workmanship. During this full
From the date of the one-year warranty, GE will also provide, free of charge, all labor and in-home service to replace the
original purchase defective part.
Five Years The transmission, suspension rod and spring assembly, if any of these parts should fail due to a defect
From the date of the in materials or workmanship. GE will also replace the washer lid or cover, if they should rust under
original purchase operating conditions. During this additional four-year limited warranty, you will
be responsible for any labor or in-home service costs.
Ten Years The washer tub, if it should fail due to a defect in materials or workmanship. During this
From the date of the additional nine-year limited warranty, you will be responsible for any labor or in-home service
original purchase costs.
Twenty Years The washer basket, if it should fail due to a defect in materials or workmanship. During this
From the date of the additional nineteen-year limited warranty, you will be responsible for any labor or in-home service
original purchase costs.
19
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
GE Washer Warranty.
This warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within the USA. In Alaska, the
warranty excludes the cost of shipping or service calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal rights, and you
may also have other rights which vary from state to state. To know what your legal rights are, consult your local or state consumer affairs office or
your state’s Attorney General.
Warrantor: General Electric Company. Louisville, KY 40225
All warranty service provided by our Factory Service Centers,
or an authorized Customer Care
®
technician. To schedule service,
on-line, 24 hours a day, visit us at GEAppliances.com, or call
800.GE.CARES (800.432.2737).
Staple your receipt here.
Proof of the original purchase
date is needed to obtain service
under the warranty.

Printed in Louisville, KY
Consumer Support.
GE Appliances Website
GEAppliances.com
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day,
any day of the year! For greater convenience and faster service, you can now download Owner’s Manuals,
order parts, catalogs, or even schedule service on-line. You can also “Ask Our Team of Experts™”
your questions, and so much more...
Schedule Service GEAppliances.com
Expert GE repair service is only one step away from your door. Get on-line and schedule your service at
your convenience 24 hours any day of the year! Or call 800.GE.CARES (800.432.2737) during normal
business hours.
Real Life Design Studio GEAppliances.com
GE supports the Universal Design concept—products, services and environments that can be used by
people of all ages, sizes and capabilities. We recognize the need to design for a wide range of physical and
mental abilities and impairments. For details of GE’s Universal Design applications, including kitchen
design ideas for people with disabilities, check out our Website today. For the hearing impaired, please call
800.TDD.GEAC (800.833.4322).
Extended Warranties GEAppliances.com
Purchase a GE extended warranty and learn about special discounts that are available while your warranty
is still in effect. You can purchase it on-line anytime, or call 800.626.2224 during normal business hours.
GE Consumer Home Services will still be there after your warranty expires.
Parts and Accessories GEAppliances.com
Individuals qualified to service their own appliances can have parts or accessories sent directly to their
homes (VISA, MasterCard and Discover cards are accepted). Order on-line today, 24 hours every day or
by phone at 800.626.2002 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing generally
should be referred to qualified service personnel. Caution must be exercised, since improper servicing may cause
unsafe operation.
Contact Us GEAppliances.com
If you are not satisfied with the service you receive from GE, contact us on our Website with all the details
including your phone number, or write to: General Manager, Customer Relations
GE Appliances, Appliance Park
Louisville, KY 40225
Register Your Appliance GEAppliances.com
Register your new appliance on-line—at your convenience! Timely product registration will allow for
enhanced communication and prompt service under the terms of your warranty, should the need arise.
You may also mail in the pre-printed registration card included in the packing material, or detach and
use the form in this Owner’s Manual.
