Gecko Aeware in.terface User manual







1
in.terface
Table of contents
overview .......................................................................................... 3
installation .......................................................................................6
connections
- audio/video in.terface .................................................... 8
- aux. keypad in.terface ..................................................... 9
powering the unit ...........................................................................11
specifications ..................................................................................12
table of contents

3
in.terface overview
in.terface
Versatile connecting box
In.terface is a waterproof universal box used to connect various
accessories to Aeware spa systems.
UL, CSA, CE approved, in.terface is available in 2 configurations:
• Audio/video in.terface is used to control Aeware's in.tune
receiver/cd player or in.pix dvd/cd player from in.k600 series of
menu-driven interface spa keypads.
• Auxiliary keypad in.terface is used to connect auxiliary keypads
(3 different versions available).

4
in.terfaceoverview
To spa pack
Fastening bracket
"CO" enclosure keyings
"AU" enclosure
keyings
Audio/video in.terface

5
in.terface overview
To spa pack
Fastening bracket
"C" enclosure keyings
Aux. keypad in.terface
"AC" enclosure keyings

6
in.terface
The unit must be installed under the spa skirt, in the upright
position to ensure watertightness.
We recommend that you install the unit with #8 PAN-head screws.
See the illustration above.
installation

7
in.terface
Blue "AU" enclosure keyings
are used to connect the audio/
video device (in.tune or in.pix)
and a wired remote (in.k455 or
in.k155) to the in.terface.
Optional purple "CO"
enclosure keyings are used to
connect DJS-1, SpaWatch or
Pocket-tek ADIR II cartridge
(in.pocket).
Connect the in.terface to the
Aeware spa pack (in.xm) purple
"CO" connector.
Audio/video in.terface
in.k455
in.k155
in.tune (or in.pix)
to DJS, SpaWatch, in.pocket
in.xm
(or any Aeware spa pack)
or
connections

8
in.terface
Connection of the in.terface to
the Aeware spa pack (in.xm) is
done through the orange "C"
connector for all three versions.
In.k100/in.k400/
Streamlined interface
version of in.k600
If you use the in.k100, in.k400
or streamlined interface version
of the in.k600, you need to
connect the keypads in the
orange "C" enclosure keyings of
the in.terface.
Note that only one type of
single-configuration keypad
can be used. Keypad on the
first connector (left) determines
keypad's type.
You can connect up to
5 keypads to the in.terface.
Auxiliary keypad in.terface
in.xm
(or any Aeware spa pack)
connections

9
in.terface
Single switch
If you use single switches, you
need to connect them in the
white "AC" enclosure keyings of
the in.terface.
Connector position determines
switch's functionality.
Customized functionality is
possible. Contact us for more
details.
You can connect up to 5 single
switches to the in.terface (k-29
keypads, etc.).
Auxiliary keypad in.terface (Con't)
P1
in.xm
(or any Aeware spa pack)
P2 P4P3
P5
connections

10
in.terface
Dry contact switch
If you use dry contact switches,
you need to connect them
in the white "AC" enclosure
keyings.
Up to 2 loads per connector is
possible for a maximum of
4 different loads.
Wires of cables determine
switch's functionality.
P1
Light
in.xm
(or any Aeware spa pack)
P1 P3P2
Light
Auxiliary keypad in.terface (Con't)
connections

11
in.terface
Audio/video in.terface connection shown above
powering the unit
Powering the in.terface
Simply connect the in.terface to the Aeware spa pack (in.xm).
See the illustration opposite.
You do not need to turn off the power before connecting the
in.terface to the Aeware spa pack (in.xm). But if you use the
auxiliary keypad in.terface, you will need to reset the Aeware spa
pack (in.xm) after completion of the installation.
Note:
Before powering the Aeware spa pack (in.xm), make sure all
accessories are linked to the bonding connector and connected to
the spa pack. Make sure also that the spa pack door is closed.
Then turn on the breaker.
For more details, please refer to the Aeware spa pack (in.xm)
techbook.

12
in.terface
Environmental ratings:
Humidity: Up to 85% non condensing
operating temp.: -25˚C to +60˚C
Storage temp.: -30˚C to +85˚C
Specifications and design are subject to change without prior notice.
specifications
Standards:
UL 1563 Fifth Ed.
CSA No. 22.2 - 218.1-M89
IEC: 60335-2-60-2.2002
EN: 60335-2-60: 2003

Advanced electronics! Water resistance!
