Gecko Passion MP 830S Installation instructions

GECKO® PASSION MP 830S
www.geckomusic.net
www.geckomusic.net
OWNER S MANUAL
OWNER S MANUAL

GECKO® SAFETY INSTRUCTIONS & SYMBOLS GUIDE
GECKO® SAFETY INSTRUCTIONS & SYMBOLS GUIDE
For your own safety and to avoid invalidation of the warranty, all text marked with these symbols should be
read carefully.
SYMBOLS:
SYMBOLS:
SAFETY INSTRUCTIONS:
SAFETY INSTRUCTIONS:
•To reduce the risk of electrical shock, do not remove covers. No user serviceable parts inside. Please
refer servicing to qualified personnel.
•To reduce the risk of electrical shock or fire, do not expose the equipment to rain or moisture.
•o not impose unnecessary stress on your equipment (i.e. placing heavy objects on it, overscrewing its
mounting etc).
•Read and keep the instruction manuals in a safe place for future references.
•o not attempt to clean the equipment with chemical solvents as this may damage the finish. Clean only
with dry cloth.
•o not block any ventilation openings.
•o not install near any heat sources such as radiators, heat registers, stoves, or other apparatus that
produce heat.
•o not defeat the purpose of the polarized or grounding type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the grounding prong is provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician for the replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
•Unplug the apparatus during lightning storms or when it is not in use for a long period of time.
NOTES
NOTES
Contain important information and useful tips on the operation of your equipment.
WARNING
WARNING
The lightning flash with arrowhead symbol within an equilateral triangle, is intended to
alert the user to the presence of uninsulated dangerous voltage within the product’s
enclosure that may be of sufficient magnitude to constitute a risk of electric shock.
CAUTIONS
CAUTIONS
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in thee
literature accompanying the appliance. Please read the manual carefully.
H
HEADPHONES EADPHONES SAFETY SAFETY WARNIN WARNING G
Contain important information and use useful tips on headphones outputs and monitoring
levels.
!

•Use only attachments / accessories specified by the manufacturer.
•Always shut down power supply when not in use to save energy and for prolonged lifespan.
•Exposure to extremely high noise levels may cause permanent hearing loss. Individuals vary
considerably in susceptibility to noise-induced hearing loss, but nearly everyone will lose some hearing if
exposed to sufficiently intense noise for a period of time. The U.S. Government’s Occupational Safety
and Health Administration (OSHA) has specified the permissible noise level exposures shown in the
following chart. According to OSHA, any exposure in excess of these permissible limits could result in
some hearing loss. To ensure against potentially dangerous exposure to high sound pressure levels, it is
recommended that all persons exposed to equipment capable of producing high sound pressure levels
use hearing protectors while the equipment is in operation. Ear plugs or protectors in the ear canals or
over the ears must be worn when operating the equipment in order to prevent permanent hearing loss if
exposure is in excess of the limits set forth here:
Duratio /Day (Hours) dB, Sou d Pressure Level (SPL) Descriptio s
Below 90 dB Safe zone
8.00 90 Hearing damage
6.00 92
4.00 95
3.00 97
2.00 100 Serious hearing damage
1.50 102
1.00 105
0.50 110
0.25 or less 115 Human pain threshold
Headquarters
Headquarters
GECKO MUSIC GROUP
GECKO MUSIC GROUP
No. 59, 59-1, 61, 61-1, 63, 63-1, Jalan PE 3, Taman Paya Emas,
Paya Rumput, 76450 Melaka, Malaysia.
Mobile: [phone]
Email: [email protected]t • Website: www.geckomusic.net

FOREWORD
FOREWORD
ear Friends,
Thank you very much for purchasing quality products by GECKO MUSIC GROUP. I am indeed very
delighted that we have journeyed this far, setting new standards in the audio and music industry while
touching and changing lives along the way!
At GECKO MUSIC GROUP we focus on developing nothing but the best professional audio equipment and
premium grade musical instruments you ever need! It has been our philosophy all this while that good sound
reproductions can be achieved at a fraction of a premium. Our engineering team is constantly doing research
and development to meet this objective. We thank God that by HIS grace, we have succeeded in developing
the revolutionary C.R.I.S.T.A.L.® Audiophile technology that is changing the way how sound is being
encoded, reproduced and managed!
On behalf of GECKO MUSIC GROUP, I would like to pledge our continuing commitment to uphold our
traditions in serving music and audio communities around the world with more value-added highest possible
quality GECKO® professional audio equipment and premium grade musical instruments!
Once again, thank you very much for your support.
Yours truly,
aniel Foo
Founder / Chairman
GECKO MUSIC GROUP

TABLE OF CONTENTS
TABLE OF CONTENTS
INTRODUCTION 1
MICROPHONE ELEMENTS 2
CONNECTING AND DISCONNECTING THE MICROPHONE 3
MICROPHONE USE 4
SPECIFICATIONS 5
WARRANTY 6
NOTES: Congratulations on purchasing the GECKO® PASSION MP
830S C.R.I.S.T.A.L.® Audiophile supercardioid dynamic
microphone! We recommend that you take a moment and read
through the manual as it provides information that will assist you in
using your unit to its fullest potential.
______________________________________________________________________________________
© GECKO MUSIC GROUP. All Rights Reserved.

INTRODUCTION
INTRODUCTION
The GECKO® PASSION MP 830S C.R.I.S.T.A.L.® Audiophile supercardioid dynamic microphone has
almost all the characteristics of a premium grade studio condenser. It offers the most natural reproductions
for both vocal and instrument miking applications beyond what a conventional dynamic microphone can offer,
setting new standards of dynamic microphones.
* designed for smooth, natural vocal and instrumental reproductions;
* antistatic, all-metal design and construction for years of trouble-free use;
* GECKO® Secured Connection™ provides secured cable joint connection;
* off-axis rejection for minimum feedback;
* integral pop filter for minimum plosive effects;
* anti-roll metal mesh grille design;
* excellent choice for both professional live and studio applications.
______________________________________________________________________________________
1
1
© GECKO MUSIC GROUP. All Rights Reserved.

MICROPHONE ELEMENTS
MICROPHONE ELEMENTS
______________________________________________________________________________________
2
2
© GECKO MUSIC GROUP. All Rights Reserved.
1
4
3
5
FRONT BACK
2
6
7

______________________________________________________________________________________
3
3
© GECKO MUSIC GROUP. All Rights Reserved.
POLAR PATTERN - SUPERCAR IOI
FREQUENCY RESPONSE

1. ANTI-ROLL METAL MESH GRILLE
To prevent the microphone from accidental rolling off from hard surface and to protect the microphone
capsule from possible damage caused by external factors. It is also pop-filtered from the inside to reduce the
plosive effects.
2. MODEL NAME AND NUMBER
This is the microphone's laser-engraved model name and number “PASSION MP 830S”.
3. ANTISTATIC METAL BODY
This chromed anti-static metal body is designed to prevent unwanted static charges (that could cause noise
to the operation of the microphone) from building up, and to withstand on-the-road abuses for years of
trouble-free use.
4. NOISELESS ON / OFF SWITCH
To power ON / power OFF the microphone.
5. GECKO® LOGO
This is the laser-engraved GECKO® logo.
6. GECKO® Secured Co ectio ™
The GECKO® PASSION MP 830S has an integral XLR (male) output with GECKO® Secured Connection™
system ensuring secured cable joint connection. Positive pressure on diaphragm produces positive voltage
on Pin 2 with regards to Pin 3. See the next section “CONNECTING AND DISCONNECTING THE
MICROPHONE”.
7. SERIAL NUMBER
Every unit of the PASSION MP 830S is assigned with a unique laser-engraved serial number.
______________________________________________________________________________________
4
4
© GECKO MUSIC GROUP. All Rights Reserved.

CONNECTING AND DISCONNECTING THE MICROPHONE
CONNECTING AND DISCONNECTING THE MICROPHONE
1. Insert the provided microphone cable with GECKO® Secured Connection™ XLR (female) connector
end into the microphone as shown above. If necessary, rotate the connector to align the key on the
connector and the groove in the microphone. Push the connector into the microphone and secure
the connection by turning the bezel clockwise until it is tight.
NOTES: The integral XLR (male) output connector on the microphone takes in
standard size XLR (female) connector. If you need a longer cable length other than
the one provided, you may use either a third party longer cable (without GECKO®
Secured Connection™) or connect the XLR (female) end of the provided cable to
another GECKO® TRUTH T3 audiophile microphone cable of your desired length for
best performance.
2. If you are connecting to a balanced audio device, be sure to use balanced configuration on the XLR
and TRS type connectors. Pin 1 (Shield) = Ground, Pin 2 (Tip) = Positive (Hot), Pin 3 (Ring) =
Negative (Cold). If you are connecting to an unbalanced audio device, make sure you bridge Pin 1
and Pin 3 on the connectors.
3. To unplug the connector from the microphone, turn the bezel anti-clockwise all the way until it is off
from the microphone before pulling the connector out.
______________________________________________________________________________________
5
5
© GECKO MUSIC GROUP. All Rights Reserved.
Groove
Key
Bezel

MICROPHONE USE
MICROPHONE USE
1. Turn ON the microphone by sliding the switch to “ON”. Turn OFF the microphone by sliding the
switch to “OFF”. Keep the switch in the “OFF” position while connecting or disconnecting the
microphone from your audio device.
2. For vocal use, hold the microphone by its handle. Avoid holding the microphone grille. See pictures
above.
3. Position the microphone grille one to two inches (2cm - 5cm) away from the mouth. Move farther
away from the microphone to produce a more balanced, natural sound. Move closer to the
microphone to enhance low frequency (bass) response.
4. To minimize the chance of feedback (a loud howling or squealing noise), position the microphone
beside or behind loudspeakers.
5. Apart from vocal, the GECKO® PASSION MP 830S can also be used for instrument miking, i.e.
strings, woodwinds, brasses, percussions, and also backline amplifiers miking.
CAUTIONS: O NOT APPLY +48V C PHANTOM POWER ON THE PASSION MP
830S! Using +48V C phantom will affect the performance of the PASSION MP 830S
and may cause serious damage to the microphone.
CORRECT HAN LING WRONG HAN LING
______________________________________________________________________________________
6
6
© GECKO MUSIC GROUP. All Rights Reserved.

SPECIFICATIONS
SPECIFICATIONS
Eleme t:
C.R.I.S.T.A.L.® Audiophile Anti-Shock Hum-Compensating ynamic
Polar Patter :
Supercardioid
Freque cy Respo se:
38Hz ~ 20kHz
Se sitivity:
-49±3dB at 1kHz (0dB = 1mV/Pa)
Output Impeda ce:
600Ω (±15%)
Switch:
Noiseless 2-Position ON / OFF
Output Co ector:
Integral XLR Male with GECKO® Secured Connection™
I cluded Accessories:
GECKO® PASSION Microphone Case, GECKO® TRUTH T3 Audiophile Microphone Cable with GECKO®
Secured Connection™ (3m)
Physical Properties:
Finish: Anti-Static Metal Body, Anti-Roll Steel Mesh Grille (Pop-Filtered)
Color: Chrome (Body), Black (Steel Mesh Grille)
Net Weight: 350g
imension: (L) 215mm x (∅) 53.50mm
Specifications subject to change without prior notice. Manufactured under ISO9000 certified management
system.
______________________________________________________________________________________
© GECKO MUSIC GROUP. All Rights Reserved.

GECKO
GECKO® ® TERMS OF WARRANTY TERMS OF WARRANTY
WARRANTY:
GECKO MUSIC GROUP warrants its GECKO® products for a period of three (3) years from the original date
of purchase, in accordance to the warranty regulations described below.
WHAT IS COVERED:
uring the applicable warranty period, GECKO MUSIC GROUP warrants the product against defects in
materials and workmanship and against malfunctions. GECKO MUSIC GROUP will remedy all such defects
and malfunctions without charge for parts or labour if the warranty applies. In the case that other parts are
used which constitutes an improvement, GECKO MUSIC GROUP may, at its discretion, charge the customer
for the additional cost of these parts. Final determination of warranty coverage lies solely with GECKO
MUSIC GROUP.
WHAT IS NOT COVERED:
1. If the product needs to be modified or adapted in order to comply with applicable technical or safety
standards on a national or local level, in any country which is not the country where the product was
originally developed and manufactured, this modification/adaptation shall not be considered a defect in
material or workmanship.
2. Normal wear and tear, in particular, of faders, cross faders, potentiometers, keys/buttons, valves,
guitar/bass strings, machine heads, pick-up covers, vinyl covers, illuminants, and similar parts are not
covered by this warranty.
3. Improper handling, neglect or failure to operate the unit in compliance with the instructions given in the
user or service manuals.
4. Connection or operation of the unit in any way that does not comply with the technical or safety
regulations applicable in the country where the product is used.
5. amages/defects caused by force of nature or any other condition that is beyond the control of GECKO
MUSIC GROUP.
6. Any repair or opening of the unit carried out by unauthorized personnel (user included) will void the
warranty.
7. Modification or removal of serial numbers.
OBTAINING WARRANTY SERVICE:
To return a GECKO® product for warranty service, first fill out the O li e Tech ical Report on
www.geckomusic. et and submit for an authorization/service number. Write the authorization/service
number so that it is prominently displayed on the outside of the shipping carton. Any products received
without an authorization/service number that is clearly visible upon arrival at the factory will be refused.
Enclose proof of the original delivery date or a copy of the original sales receipt/invoice. Enclose a
description of the suspected defect or malfunction and the condition, if any, which caused the problem.
Return the product to GECKO MUSIC GROUP.
WARRANTY SHIPPING:
You are responsible for prepaying shipping costs F.O.B. GECKO MUSIC GROUP, Melaka, Malaysia.
Shipped product(s) must be properly packaged. Use original shipping cartons and packing materials where
possible. GECKO MUSIC GROUP is not responsible for damages resulting from inadequate and or improper
packing. Products received with damages due to improper packaging will be deemed out of warranty.

Products which do not meet the terms of this warranty will be repaired exclusively at the buyer’s expense.
GECKO MUSIC GROUP will inform the buyer of such circumstance. If the buyer fails to submit a written
repair order within six (6) weeks after notification, GECKO MUSIC GROUP will return the unit C.O. . with a
separate invoice for freight and packing. Such costs will also be invoiced separately when the buyer has sent
in a written repair order.
WARRANTY RIGHTS:
This warranty is exclusive and extended to the original buyer and is not transferable to anyone who may
subsequently purchase this product. No other person (apart from authorized GECKO® Stores) shall be
entitled to give any warranty promise on behalf of GECKO MUSIC GROUP.
