GECMA CHALLENGER 15 Inch User manual

GECMA COMPONENTS GMBH WWW.GECMA.COM TEL. [phone] FAX. -99
MANUAL CHALL 15_18 EN REV.1.3.NEX.DOC 31.01.07 A.J 1
Operating and Installation Instructions
Remote PC Terminals
CHALLENGER 15”
CHALLENGER 18”

GECMA COMPONENTS GMBH WWW.GECMA.COM TEL. [phone] FAX. -99
MANUAL CHALL 15_18 EN REV.1.3.NEX.DOC 31.01.07 A.J 2
General reference
Please read these instructions carefully before installing this device.
The CHALLENGER 15/18 and the associated power supply units 15-PSU and 18-PSU for the
CHALLENGER 15 and CHALLENGER 18 respectively may only be installed or deinstalled by
qualified personnel.
The information in the Certificate of Conformity should be fully adhered to.
If you have any questions or suggestions please contact your local representative or us
directly:
 Gecma Components GmbH Gecma International Ltd
Heisenbergstraße 26 – 40 Meridian House, Roe Street
D-50169 Kerpen Congleton, CW12 1PG
Germany United Kingdom
Tel.: [phone] / 69960 [phone]
Fax: [phone] / 69 96 99 [phone]
mailto:[email protected]
 http://www.gecma.com
Technical Developments
The manufacturer reserves the right to modify technical data without notice.
Version-/Revisiondata:
OSD Version: R1 und R2
This manual is valid for CHALLENGER 15-2 and CHALLENGER 18.
(CHALLENGER 15-2 corresponds to the second Generation of CHALLENGER 15.
In the following text it will be referred to as the CHALLENGER 15.)
Warning!

GECMA COMPONENTS GMBH WWW.GECMA.COM TEL. [phone] FAX. -99
MANUAL CHALL 15_18 EN REV.1.3.NEX.DOC 31.01.07 A.J 3
Repairs, Dangerous chemicals
A note detailing the fault must always accompany equipment sent to
GeCmaComponentsGmbH or any of their agents for repair.
The following procedures must be carried out before a unit is sent back for repair:
 Remove all residues that may be present. Pay special attention to the gasket grooves and
crevices where residue may collect. Please ensure that precautions have been taken to
remove all traces of substances that may represent a health risk before returning the
device.
 Costs of disposal of materials or injury of personnel (acid burns etc.) arising due to the
equipment not being cleaned properly will be charged to the owner of the equipment.
Trademarks:
AT, IBM and PS/2, are registered trademarks of the International Business Machines
Corporation.
Microsoft, Windows and Windows NT are registered trademarks of the Microsoft Corporation.
If any other trademarks are used in the text and pictures of this manual they are herewith
acknowledged as the trademarks of the owner.

GECMA COMPONENTS GMBH WWW.GECMA.COM TEL. [phone] FAX. -99
MANUAL CHALL 15_18 EN REV.1.3.NEX.DOC 31.01.07 A.J 4
Contents
General reference...........................................................................................................................................2
Contents ..........................................................................................................................................................4
Introduction......................................................................................................................................................5
Application ......................................................................................................................................................6
Operating principle.......................................................................................................................................... 6
Design of the 15-PSU/18-PSU ............................................................................................................................7
Design of the CHALLENGER 15 - FMO display module....................................................................................8
Design of the CHALLENGER 18 - FMO display module..................................................................................10
Design of the CHALLENGER KB keyboard ......................................................................................................12
Design of the CHALLENGER M mouse module..............................................................................................14
Design of the CHALLENGER TB trackball module ...........................................................................................15
Design of the CHALLENGER MTD....................................................................................................................16
Design of the TCV2 data transmission card...................................................................................................17
Design of the PSU2 power supply unit ............................................................................................................19
Design of the 19” rack (optional) ...................................................................................................................20
Software for the TCV2 and KB ........................................................................................................................21
Installation ......................................................................................................................................................22
General installation requirements ............................................................................................................ 22
Installing the terminal................................................................................................................................ 22
Installing the 15-PSU or 18-PSU.................................................................................................................. 22
Installation of CHALLENGER PC Terminals Supplied in Pre-wired Enclosures........................................... 23
Earthing between the STF or EBF Stands and the FH or FHP Enclosure.................................................... 24
Complete Wiring Details ................................................................................................................................25
Operation and adjustment of the display ....................................................................................................32
Options ..........................................................................................................................................................33
Technical data ..............................................................................................................................................34

GECMA COMPONENTS GMBH WWW.GECMA.COM TEL. [phone] FAX. -99
MANUAL CHALL 15_18 EN REV.1.3.NEX.DOC 31.01.07 A.J 5
Introduction
The CHALLENGER 15/18 is an Visualisation and Operator Terminal. It consists of the following
main components: the CHALLENGER 15/18-FMO display module, the CHALLENGER KB
keyboard and CHALLENGER TB Trackball, plus the 15-PSU or 18-PSU power supply unit and the
associated CHALLENGER TCV2 data transmission card. The transmission card transmits data
from the PC to the CHALLENGER Terminal. Distances of up to 600m and 400 m can be
covered by the 15 and 18 respectively.
The TCV2 transmission card is connected directly to the PC. It is connected to the VGA
graphics card for the RGB signal and the PS2 connectors for the keyboard and mouse signals.
IBM compatible PC’s must be used for trouble free operation. No special driver software is
required nor do any system specific graphics cards need to be installed in the PC.
The transmission of the display, keyboard and mouse data is made by the TCV2 card via a
screened twisted pair cable with 4 pairs to the CHALLENGER 15/18-FMO display module.
Built into the CHALLENGER 15/18-FMO display module is the receiver electronics as well as the
connector blocks for the keyboard and mouse/tracker ball. Power for the CHALLENGER 15/18-
FMO display module is supplied by the 15-PSU or 18-PSU power supply unit.
The following variants are available:
Device Version
CHALLENGER 15-FMO Panel-mounted monitor
CHALLENGER 18-FMO Panel-mounted monitor
CHALLENGER KB Panel-mounted keyboard
CHALLENGER-KMU Panel-mounted keyboard and mouse
CHALLENGER TB Trackball
CHALLENGER M Mouse
CHALLENGER MTD Mouse / trackball decoder
CHALLENGER 15-FH-DMK Field housing with display, mouse and keyboard
CHALLENGER 15-FH-DTK Field housing with display, trackball and keyboard
CHALLENGER 15-FH-D Field housing with display
CHALLENGER 15-FH-DT Field housing with display and trackball
CHALLENGER 15-FH-DK Field housing with display and keyboard
CHALLENGER 15-FH-DM Field housing with display and mouse
CHALLENGER 18-FH-DMK Field housing with display, mouse and keyboard
CHALLENGER 18-FH-DTK Field housing with display, trackball and keyboard
CHALLENGER 18-FH-D Field housing with display
CHALLENGER 18-FH-DT Field Housing with display and trackball
CHALLENGER 18-FH-DK Field housing with display and keyboard
CHALLENGER 18-FH-DM Field housing with display and mouse
CHALLENGER TCV2 19“ Euro card cartridge consisting of:
Data transmission card with optional connections for local
monitor, keyboard and mouse
PSU2 Power supply unit for the TCV2 19” rack
15-PSU Power supply for the CHALLENGER 15-FMO
18-PSU Power supply for the CHALLENGER 18-FMO

GECMA COMPONENTS GMBH WWW.GECMA.COM TEL. [phone] FAX. -99
MANUAL CHALL 15_18 EN REV.1.3.NEX.DOC 31.01.07 A.J 6
Application
The CHALLENGER 15 and 18 can be employed in all areas of industry where PC functionality is
required in the plant in harsh environments.
CHALLENGER 15:
It can be connected to any IBM compatible PC running software with an XGA resolution
(768 x 1024 pixels, True Colour 32 bit)
CHALLENGER 18:
It can be connected to any IBM compatible PC running software with an SXGA resolution
(1280 x 1024 pixels, True Colour 32 bit)
Operating principle
The VGA screen data and keyboard and mouse/tracker ball data are fed into the TCV2,
where they are combined and converted into conditioned signals. The PSU2 (for 100V…240V
AC) is required to supply the TCV2.
No special graphics card is needed, although we recommend that only good quality cards
are used otherwise picture quality may suffer. The data cable connection should not be wired
via junction boxes.
The electronics in the TCV2 cassette and the CHALLENGER 15/18 FMO allow the PC terminal to
be mounted 600m or more (400m in the case of the 18) from the actual PC CPU (at
distances of 400m or more the resolution and the display refresh rate must be reduced).

GECMA COMPONENTS GMBH WWW.GECMA.COM TEL. [phone] FAX. -99
MANUAL CHALL 15_18 EN REV.1.3.NEX.DOC 31.01.07 A.J 7
Design of the 15-PSU/18-PSU
The power supply unit 15-PSU or 18-PSU provides two electrically isolated power supply circuits
for the CHALLENGER 15 or CHALLENGER 18. The 15-PSU or 18-PSU has a voltage output of 12V
and a factory pre-set power limitation.
Please refer to the drawing of the 15-PSU or 18-PSU in the appendix for details.
POWER SUPPLIES 12V:
Input Voltage: 100-240V AC (optional 24VDC)
OutputVoltage: 10,8–13,2VDC
Power: 2x30W
InputFrequency: 50-60Hz
Operation Temperature: 0°C – 50°C
The Input-Voltage is connected as the following table to the Terminals labelled “INPUT“. The
supply with Input-Voltage for several modules is achieved by connecting them in parallel.
Input-Voltage: Connection:
INPUT L (L) 100-240V AC (optional +24VDC)
INPUT N (N) 100-240V AC (optional 0VDC)
For 15/18-PSU will be used two modules.
The Power for the CHALLENGER 15/18 is connected as the following table to the Terminals
labelled “OUTPUT”:
Preferred
cable-No.
Output Circuit
Terminals:
Terminal block
K1: Connection:
Cable1 2 OUTPUT 1 V- K1(11) & K3(2) Supply circuit
PS 3 & PS 8 (0 V)
Cable1 1 OUTPUT 1 V+ K1(12) & K3(1) Supply circuit
PS 3 & PS 8 (+12 V)
Cable2 2 OUTPUT 2 V- K1(3+15) & K2(2) Supply circuit
PS 1 & PS 6 & PS 7 (0 V)
Cable2 1 OUTPUT 2 V+ K1(4+16) & K2(1) Supply circuit
PS 1 & PS 6 & PS 7 (+12 V)
Warning!

GECMA COMPONENTS GMBH WWW.GECMA.COM TEL. [phone] FAX. -99
MANUAL CHALL 15_18 EN REV.1.3.NEX.DOC 31.01.07 A.J 8
Design of the CHALLENGER 15 - FMO display module
For mechanical details of the CHALLENGER 15-FMO please refer to the drawings in the
appendix.
Technical Data:
Component : CHALLENGER-15-FMO
Resolution : XGA (1024 x 768 pixels)
Lower resolutions are interpolated.
Screen size : 15.1“
Display type : TFT with 16 million colours
Ingress protection : IP66 (NEMA 4x) from front
Front plate : Anodised aluminium
Dimensions : 417 x 340.5 x 70 mm (w x h x d)
Weight : 12 kg
Power supply : 15-PSU
The connections are detailed in the following table.
Preferred
cable-No. Terminal block K1: Connection:
1 Not used
2 Not used
Cable2 2 3 Supply PS6- (0 V)
Cable2 1 4 Supply PS6+ (+12V)
5 Not used
6 Not used
7 Not used
8 Not used
9 Not used
10 Not used
Cable1 2 11 Supply PS3- (0 V)
Cable1 1 12 Supply PS3+ (+12)
13 Not used
14 Not used
Cable2 2 15 Supply PS1- (0 V)
Cable2 1 16 Supply PS1+ (+12)
Preferred
cable-No. Terminal block K2: Connection:
Cable2 1 1 Supply PS7+ (+12)
Cable2 2 2 Supply PS7- (0 V)
3 Not used
Preferred
cable-No. Terminal block K3: Connection:
Cable1 1 1 Supply PS8+ (+12)
Cable1 2 2 Supply PS8- (0 V)
3 Not used

GECMA COMPONENTS GMBH WWW.GECMA.COM TEL. [phone] FAX. -99
MANUAL CHALL 15_18 EN REV.1.3.NEX.DOC 31.01.07 A.J 9
The data signal is connected to terminal block K5. Only use recommended cable.
Preferred
cable-color Terminal block K5: Connection:
white 1 1. Twisted pair (a)
brown 2 1. Twisted pair (b)
white 3 2. Twisted pair (a)
green 4 2. Twisted pair (b)
white 5 3. Twisted pair (a)
orange 6 3. Twisted pair (b)
Screen 7 Screen
Screen 8 Screen
white 9 4. Twisted pair (a)
blue 10 4. Twisted pair (b)
Preferred
cable-No. Terminal block K4: Connection:
1 1 Keyboard/pointing device data (a)
2 2 Keyboard/pointing device data (b)
3 3 GND
4 4 Backlight-control
5 5 GND
6 6 GND
7 7 Keyboard power supply +5V
8 8 Keyboard power supply 0V
9 9 Pointing device power supply +5V
10 10 Pointing device power supply 0V
Preferred
cable-No. Terminal block K9: Connection:
17 1 Barcode Scanner Power Supply
16 2 Barcode Scanner Power Supply
13 3 OSD keyboard SUB menu
15 4 OSD keyboard UP
14 5 OSD keyboard Down
12 6 OSD keyboard menu
11 7 OSD keyboard GND
The adjustment potentiometers and the four-key keypad are described in “Commissioning“.

GECMA COMPONENTS GMBH WWW.GECMA.COM TEL. [phone] FAX. -99
MANUAL CHALL 15_18 EN REV.1.3.NEX.DOC 31.01.07 A.J 10
Design of the CHALLENGER 18 - FMO display module
For mechanical details of the CHALLENGER 18 display module please refer to the drawings in
the appendix.
Technical Data:
Component : CHALLENGER-18-FMO
Resolution : SXGA (1280 x 1024 pixels)
Lower resolutions are interpolated.
Screen size : 19 “
Display type : TFT with 16 million colours
Ingress protection : IP66 (NEMA 4X) from front
Front plate : Anodised aluminium
Dimensions : 505.9 x 427.7 x 80 mm (w x h x d)
Weight : 16 kg
Power supply : 18-PSU
The connections are detailed in the following table.
Preferred
cable-No. Terminal block K1: Connection:
1 Not used
2 Not used
Cable2 2 3 Supply PS6- (0 V)
Cable2 1 4 Supply PS6+ (+12V)
5 Not used
6 Not used
7 Not used
8 Not used
9 Not used
10 Not used
Cable1 2 11 Supply PS3- (0 V)
Cable1 1 12 Supply PS3+ (+12)
13 Not used
14 Not used
Cable2 2 15 Supply PS1- (0 V)
Cable2 1 16 Supply PS1+ (+12)
Preferred
cable-No. Terminal block K2: Connection:
Cable2 1 1 Supply PS7+ (+12)
Cable2 2 2 Supply PS7- (0 V)
3 Not used
Preferred
cable-No. Terminal block K3: Connection:
Cable1 1 1 Supply PS8+ (+12)
Cable1 2 2 Supply PS8- (0 V)
3 Not used

GECMA COMPONENTS GMBH WWW.GECMA.COM TEL. [phone] FAX. -99
MANUAL CHALL 15_18 EN REV.1.3.NEX.DOC 31.01.07 A.J 11
The data signal is connected to Terminal Block K5. Only use recommended cable.
Preferred
cable-color Terminal block K5: Connection:
white 1 1. Twisted pair (a)
brown 2 1. Twisted pair (b)
white 3 2. Twisted pair (a)
green 4 2. Twisted pair (b)
white 5 3. Twisted pair (a)
orange 6 3. Twisted pair (b)
Screen 7 Screen
Screen 8 Screen
white 9 4. Twisted pair (a)
blue 10 4. Twisted pair (b)
Preferred
cable-No. Terminal block K4: Connection:
1 1 Keyboard/pointing device data (a)
2 2 Keyboard/pointing device data (b)
3 3 GND
4 4 Backlight-control
5 5 GND
6 6 GND
7 7 Keyboard power supply +5V
8 8 Keyboard power supply 0V
9 9 Pointing device power supply +5V
10 10 Pointing device power supply 0V
Preferred
cable-No. Terminal block K9: Connection:
17 1 Barcode Scanner Power Supply
16 2 Barcode Scanner Power Supply
13 3 OSD keyboard SUB menu
15 4 OSD keyboard UP
14 5 OSD keyboard Down
12 6 OSD keyboard menu
11 7 OSD keyboard GND
The adjustment potentiometers and the four-key keypad are described in “Commissioning“

GECMA COMPONENTS GMBH WWW.GECMA.COM TEL. [phone] FAX. -99
MANUAL CHALL 15_18 EN REV.1.3.NEX.DOC 31.01.07 A.J 12
Design of the CHALLENGER KB keyboard
The CHALLENGER KB is a 105 key keyboard and is the same as a standard Windows 95
keyboard. In the KMU version of the keyboard there is a integrated mouse pointer (pressure
sensitive).
The two keyboards KB / KMU it is possible to connect the follow components.
- CHALLENGER M (Mouse)
- CHALLENGER TB (Trackball)
- CHALLENGER Barcode scanner
- Or further on request
The following variants are possible:
CHALLENGER KB (Trackball or Mouse)
CHALLENGER KMU -
CHALLENGER KB-2D (Trackball or Mouse) and (Trackball or Mouse) and Scanner
CHALLENGER KMU-2D (Trackball or Mouse) and Scanner
For mechanical details of the CHALLENGER KB / KMU module please refer to the drawings in
the appendix.
Technical data:
Tastatur & Pointing Device
Component : CHALLENGER-KB
Power supply : from display unit
Keyboard type : 105 QWERTZ, QWERTY, AZERTY keyboard lay out,
IBM compatible
Keys : Membrane protected short travel pushbuttons
included integrated industrial mouse
Ingress protection : IP66 (NEMA 4X) from front
Dimensions : 429 x 165 x 60 mm (w x h x d)
Weight : 2.0 kg
Membrane material : Technoplast – resistant to most solvents

GECMA COMPONENTS GMBH WWW.GECMA.COM TEL. [phone] FAX. -99
MANUAL CHALL 15_18 EN REV.1.3.NEX.DOC 31.01.07 A.J 13
The connections are detailed in the following table.
Preferred
cable-No. Terminal block K11: Connection:
1 1 Keyboard/pointing device data (a)
2 2 Keyboard/pointing device data (b)
3 3 GND
4 4 Back light control
5 5 GND
6 6 GND
7 7 Keyboard power supply +5V
8 8 Keyboard power supply 0V
9 9 Pointing device power supply +5V
10 10 Pointing device power supply 0V
11 Ext. pointing device +5V
12 Ext. pointing device 0V
13 Ext. pointing device data
14 Ext. pointing device clock
15 Not used
16 Not used
11 17 Deactivate keyboard/mouse (OPTION)
13 18
Deactivate keyboard/mouse (OPTION)
/ OSD keyboard SUB-menu
Preferred
cable-No. Terminal block K12: Connection:
12 1 OSD menu
14 2 OSD keyboard down
15 3 OSD keyboard up
Preferred
cable-No. Terminal block K14: Connection:
Scannerc. (1) 1 +5V for RS232 peripheral
16 2 connected to K9 (2)
17 3 connected to K9 (1)
Scannerc. (2) 4 RS232-RxD
Scannerc. (3) 5 0V for RS232 peripheral
6 RS232-DSR
7 RS232-CTS
8 RS232-TxD
9 RS232-DTR
Scannerc. (4) 10 RS232-GND
11 RS232-RTS
12 GND

GECMA COMPONENTS GMBH WWW.GECMA.COM TEL. [phone] FAX. -99
MANUAL CHALL 15_18 EN REV.1.3.NEX.DOC 31.01.07 A.J 14
Design of the CHALLENGER M mouse module
The CHALLENGER M is a Microsoft compatible industrial mouse that can be connected to the
CHALLENGER KB.
The principle of operation is based on pressure sensitive resistors much like those used in
Notebook PCs.
For mechanical details of the CHALLENGER M module please refer to the drawings in the
appendix.
Technical data:
Component : CHALLENGER M
Description : Panel mounted industrial mouse
based on PSR technology
Power supply : from display unit
Ingress protection : IP66 (NEMA 4X) from front
Front plate : Anodised aluminium
Dimensions : 98 x 165 x 40.5 mm (w x h x d)
Weight : 0.45 kg
The connections are detailed in the following table.
Connection cable Connection
Brown +5V
White 0V
Yellow Data
Green Clock

GECMA COMPONENTS GMBH WWW.GECMA.COM TEL. [phone] FAX. -99
MANUAL CHALL 15_18 EN REV.1.3.NEX.DOC 31.01.07 A.J 15
Design of the CHALLENGER TB trackball module
The CHALLENGER TB is a Microsoft compatible industrial trackball that can be connected to
the CHALLENGER KB .
For mechanical details of the CHALLENGER TB module please refer to the drawings in the
appendix.
Technical data:
Component : CHALLENGER TB
Description : Trackball with 55mm ball
Power supply : from display unit
Ingress protection : IP65 from front
Front Plate : Anodised aluminium
Dimensions : 98 x 165 x 40.5 mm (w x h x d)
Weight : 0.45 kg
The connections are detailed in the following table.
Connection cable Connection
Red +5V
Blue 0V
Green Data
White Clock

GECMA COMPONENTS GMBH WWW.GECMA.COM TEL. [phone] FAX. -99
MANUAL CHALL 15_18 EN REV.1.3.NEX.DOC 31.01.07 A.J 16
Design of the CHALLENGER MTD
The CHALLENGER MTD module is an interface to connect a mouse or trackball module. It is
used when no keyboard is required and only a display and pointing device are needed for
the application at hand.
For mechanical details of the CHALLENGER MTD module please refer to the drawings in the
appendix.
Technical data:
Component : CHALLENGER MTD
Housing : Anodised aluminium
Ingress protection : IP30
Power supply : from display unit
Anschlüsse : K11/ 18pole Phoenix socket
K12/ 3pole Phoenix socket
Dimensions : 160 x 37 x 144 mm (w x h x d)
Weight : 0.62 kg
The connections are detailed in the following table.
CHALLENGER
MTD
CHALLENGER
-FMO CHALLENGER M CHALLENGER TB
Preferred
cable-No. Terminal-
Block K11
Terminal-
Block K12
Terminal-
Block K4
Terminal-
Block K9 cable cable
1 1 - 1 - 1 1
2 2 - 2 - 2 2
3 3 - 3 - 3 3
4 4 - 4 - 4 4
5 5 - 5 - 5 5
6 6 - 6 - 6 6
7 7 - 7 - 7 7
8 8 - 8 - 8 8
9 9 - 9 - 9 9
10 10 - 10 - 10 10
11 - - - 11
12 - - - 12
13 - - - 13
14 - - - 14
15 - - - 15
16 - - - 16
11 17 - - 7 11 17
13 18 - - 3 13 18
12 - 1 - 6 12 -
14 - 2 - 5 14 -
15 - 3 - 4 15 -

GECMA COMPONENTS GMBH WWW.GECMA.COM TEL. [phone] FAX. -99
MANUAL CHALL 15_18 EN REV.1.3.NEX.DOC 31.01.07 A.J 17
Design of the TCV2 data transmission card
The TCV2 data transmission card has been designed as a 19“ cassette with 14 HP wide and
by 3 U high. Connections to the PC for the VGA cable, PS/2 keyboard and PS/2 mouse are
located on the front panel. The optional connections for connecting a local monitor,
keyboard and mouse are located to the right of these connections. The display, keyboard
and mouse data is transmitted to the CHALLENGER Terminal in the remote area using a four
pair data cable. The option to enable/disable the terminal and also the local keyboard and
mouse is possible using the digital inputs 14D and 14Z.
14Z 14D Status
H H Automatic operation
L H Terminal locked
H L Desktop locked
The TCV2 consists of the circuit board DC7, TRV2 and the TME2 and is supplied with power by
the 19“ PSU2 module.
On the rear of the TCV2 is a 48 pin connector to DIN 41612 type F for the connections.
The TCV2 data transmission card is compatible with PS2 pointing devices but not Microsoft
“intelli-mouse” or “wheel mouse”
Settings:
If cable runs are longer than 275m, the following jumpers on the TRV 2 must be closed:
JP1 to JP12
JP12
JP11
JP8
JP4
JP7
JP3
JP10
JP9
JP6JP5
JP2
JP1
Circuit board TRV2

GECMA COMPONENTS GMBH WWW.GECMA.COM TEL. [phone] FAX. -99
MANUAL CHALL 15_18 EN REV.1.3.NEX.DOC 31.01.07 A.J 18
Transmission card
Technical data:
Component : CHALLENGER-TCV2
Housing : 19” cassette 3 U, 14 HP
Power supply : from CHALLENGER PSU2
Connections : VGA, PS2 keyboard and mouse
Weight : 0.65 kg
Software version : >1.16
Connector pins ST10 Connection
2D Power supply+12V 2D
2Z Power supply+12V 2Z
4D Power supply 0V 4D
4Z Power supply 0V 4Z
6D Power supply –12V 6D
6Z Power supply –12V 6Z
8D Power supply +5V 8D
8Z Power supply +5V 8Z
10D Power supply 0V 10D
10Z Power supply 0V 10Z
12D Power supply –5V 12D
12Z Power supply –5V 12Z
14D keyboard/mouse lock function (Option)
14Z keyboard/mouse lock function (Option)
16D DATA_DE
16Z DATA_R
18D GND
18Z DATA_D
20D GND
20Z GND
22D GND
22Z GND
24D GND
24Z GND
26D 4. Twisted pair (a)
26Z 4. Twisted pair (b)
28D 1. Twisted pair (a)
28Z 1. Twisted pair (b)
30D 2. Twisted pair (a)
30Z 2. Twisted pair (b)
32D 3. Twisted pair (a)
32Z 3. Twisted pair (b)

GECMA COMPONENTS GMBH WWW.GECMA.COM TEL. [phone] FAX. -99
MANUAL CHALL 15_18 EN REV.1.3.NEX.DOC 31.01.07 A.J 19
Design of the PSU2 power supply unit
The PSU2 with wide range input (100-240VAC) is a 19“ Euro card. It provides all the power
required by up to 4 TCV2 and up to 4 TCS1 data transmission cards. On the rear of the PSU2 is
a 48 pin connector to DIN 41612 type F for the connections.
Technical data:
Power supply for TCV2 and TCS1
Component : CHALLENGER PSU2
Housing : 19” Euro card 3U, 8HP
Power supply : 100-240VAC 3,15 AT
Weight : 0.65 kg
Connector pins ST1 Connection
2D +5V
2Z +5V
4D GND
4Z GND
6D -5V
6Z -5V
8D GND
8Z GND
10D +12V
10Z +12V
12D GND
12Z GND
14D -12V
14Z -12V
16D GND
16Z GND
18D Do not use
18Z Do not use
20D GND
20Z GND
22D Do not use
22Z Do not use
24D GND
24Z GND
26D GND
26Z GND
28D Earth
28Z Earth
30D 100-240VAC (N)
30Z 100-240VAC (N)
32D 100-240VAC (L)
32Z 100-240VAC (L)
The mains power supply should not be connected directly to the connector pins. It should be
connected via a normal mains power supply filter.

GECMA COMPONENTS GMBH WWW.GECMA.COM TEL. [phone] FAX. -99
MANUAL CHALL 15_18 EN REV.1.3.NEX.DOC 31.01.07 A.J 20
Design of the 19” rack (optional)
If required, we can also supply the TCV2, PSU2 and TCS1 complete in a 19“ rack. The
components are installed in a desktop housing, type Rack 42-2, or a type Rack 84-2 full width
19“ rack.
All you need do is provide the power and plug in the data cable (10 pole Phoenix socket).
When installing more than one 19“ rack into a 19“ rack cabinet a minimum of 1U space must
be left between each rack for ventilation purposes.
Preferred
cable-color
10 pole Phoenix socket on 19”
rack Connection:
white 1 Twisted pair 1 a
brown 2 Twisted pair 1 b
white 3 Twisted pair 2 a
green 4 Twisted pair 2 b
white 5 Twisted pair 3 a
orange 6 Twisted pair 3 b
white 9 Twisted pair 4 a
blue 10 Twisted pair 4 b
Screen 7 Screen
Screen 8 Screen
