suprema FaceStation F2 User manual

FaceStation F2
INSTALLATION GUIDE
EN 101.00.FSF2_DB, FSF2_AB V1.01A
Version 1.01
English

Contents
Safety instructions .............................................................................. 3
Introduction ......................................................................................... 5
Components ...................................................................................................................................................5
Name and function of each part ...............................................................................................................6
Cables and connectors ......................................................................................................................................................8
Correct face registration and authentication method.............................................................................9
Cautions for registering a face .......................................................................................................................................9
Cautions for authenticating a face.................................................................................................................................9
Installation......................................................................................... 10
Fixing the bracket and the product........................................................................................................10
Power supply connection...........................................................................................................................13
Network connection....................................................................................................................................14
TCP/IP ..................................................................................................................................................................................14
TTL input connection .................................................................................................................................15
Relay connection.........................................................................................................................................16
Fail Safe Lock ....................................................................................................................................................................16
Fail Secure Lock ................................................................................................................................................................16
Automatic door connection............................................................................................................................................17
Connecting as a standalone......................................................................................................................18
Connecting to Secure I/O 2 ......................................................................................................................19
Wiegand connection ...................................................................................................................................20
Product specifications...................................................................... 21
Dimensions...................................................................................................................................................22
FCC compliance information .......................................................... 23
EU Declaration of Conformity (CE) ............................................... 23
Appendices ......................................................................................... 24
Disclaimers ...................................................................................................................................................24
Copyright notice..........................................................................................................................................24
Open Source License ....................................................................................................................................24
GNU General Public License ..............................................................................................................................................24
BoringSSL License ..............................................................................................................................................................31
OpenSSL License ................................................................................................................................................................31
Original SSLeay License.....................................................................................................................................................32
Apache License..................................................................................................................................................................35

Safety instructions
3
Safety instructions
Observe the following instructions to use the product safely and prevent any risk of injury or property damage.
Warning
Noncompliance of instructions could lead to serious injury or death.
Installation
Do not install the device under direct sunlight or UV light.
•Product damage, malfunction, discoloration, or deformation may occur.
Do not install the product in a place with direct sunlight, moisture, dust, or soot.
•A fire or electric shock may occur.
Do not install the product in a place with heat from an electric heater.
•A fire or electric shock may occur due to overheating.
Install the product in a dry place.
•Otherwise, a product damage or electric shock may occur due to moisture.
Install the product in a place with no electromagnetic interference.
•Otherwise, a product damage or electric shock may occur.
The user should not install or repair the product independently.
•A fire, electric shock, or personal injury may occur.
•If the product has been damaged due to independent installation or repair of the product by the user, free A/S service
will not be provided.
Operation
Do not allow liquids such as water, beverages, or chemicals get into the product.
•A fire, electric shock, or product damage may occur.
Caution
Noncompliance of instructions could lead to minor injury or product damage.
Installation
Do not install the power supply cable in a place where people pass by.
•Product damage or physical injury may occur.
Do not install the product near a highly magnetic object such as a magnet, TV, (especially CRT) monitor, or speaker.
•A product failure may occur.
Use only a power supply adapter of D.C 24 V and 12 V, 2.5 A or higher.
•If the proper power is not used, the product may not operate normally.
Use a separate power supply for Secure I/O 2, electric lock and FaceStation F2 respectively.
•If connecting and using the power supply to these devices together, the devices may malfunction.
Keep the minimum separation distances between the devices when install multiple devices.
•Otherwise, RF performance is affected to the other device, the devices may not operate normally.

Safety instructions
4
Operation
Do not drop the product or apply an impact to the product.
•A product failure may occur.
Manage the password with care not to disclose it to others and change the password periodically.
•Otherwise, illegal intrusion may occur.
Do not press the buttons on the product forcibly or using a sharp tool.
•A product failure may occur.
When cleaning the product, wipe the product with a soft and dry cloth and no water, benzene, or alcohol.
•Otherwise, a product failure may occur.
FaceStation F2 uses capacitive buttons. If the environment is moist from wet weather or the product surface is
smeared with a lot of water, wipe off the product with a dry towel before using it.
RTC battery
Replacing the battery with an incorrect type of battery may cause explosion.
Discard the battery according to the appropriate regional or international waste regulations.

Introduction
5
Introduction
Components
NOTE
•Components may vary according to the installation environment.
•When assembling the product with the bracket, you can use the included bracket fixing screw (Star Shaped) instead of the
product fixing screw for enhanced security.
FaceStation F2 Wall Bracket
Fixing Screw x6
PVC Anchor x6
Diode
Connection Cable
(1x2-pin, 1x3-pin, 3x4-pin)
Drilling Template
Quick Guide
120Ωresistor
Open Source Software
Guide
Bracket Fixing Screw
(Star Shaped)
Cable Cover

Introduction
6
Name and function of each part
Name Description
LED lamp Turned on when the user is detected in the dark.
Infrared camera Capture the infrared face image.
Visual camera Capture an actual face image.
LCD screen Provides UI for operation.
RF card & mobile access
card authentication unit
Part to scan the card for entrance.
Speaker Delivers sound.
Speaker
USB (Type-C) cable slot
Relay (3 pins)
Visual camera
SAM card slot*
Power Supply (2 pins)
RS-485 (4 pins)
TTL Input (4 pins)
Wiegand Input/Output
(4 pins)
Ethernet
RF card & mobile access card
authentication
unit
LCD screen
Infrared camera
LED lamp

Introduction
7
Ethernet Connect the Ethernet cable.
TTL input (4 pins) Connect the TTL input cable.
Relay (3 pins) Connect the relay cable.
Wiegand input/output
(4 pins)
Connect the Wiegand input/output cable.
Power supply (2 pins) Connect the power supply cable.
RS-485 (4 pins) Connect the RS-485 cable.
SAM card slot Insert the SAM card.
* SAM card slot is only supported in FSF2-DB.
USB (Type-C) cable slot Connect the USB cable.

Introduction
8
Cables and connectors
Power supply
Pin Name Color
1
PWR +VDC
Red (white stripe)
2
PWR GND
Black (white stripe)
Relay
Pin Name Color
1
RLY NO
White
2
RLY COM
Blue
3
RLY NC
Orange
RS-485
Pin Name Color
1
485 TRXP
Blue
2
485 TRXN
Yellow
3
485 GND
Black
4
SH GND
Gray
TTL input
Pin Name Color
1
TTL IN0
Red
2
TTL IN1
Yellow
3
TTL GND
Black
4
SH GND
Gray
Wiegand input and output
Pin Name Color
1
WG D0
Green
2
WG D1
White
3
WG GND
Black
4
SH GND
Gray

Introduction
9
Correct face registration and authentication method
Cautions for registering a face
•When registering a face, maintain a distance of 60 cm to 100 cm between the device and the face.
•Do not change your face expression.
•Do not wear masks, hats, or eye patches.
•Do not raise head up or lower head.
•Do not close your eyes.
•Do not wear thick makeup.
•Be careful not to display two faces on the screen. Register one person at a time.
•If you do not follow the instructions on the screen, the face registration may take longer or may fail.
Cautions for authenticating a face
•Ensure that the face appears in the center of the device's screen. When the guideline is displayed, follow the instructions
shown on the screen to authenticate the face.
•If a part of the face is covered with a hat, a mask, an eye patch, or sunglasses authentication may fail. Do not cover the
face; allow the device to recognize both the eyebrows and the face.

Installation
10
Installation
Fixing the bracket and the product
1 Determine the correct position to install the product using the provided drilling template.
NOTE
•The optimal height for installing device is 127 cm.
•Install the device where it does not reach the direct sunlight or UV light.
•
Adjust the installation position so that the face is not exposed to direct sunlight when a user tries to authenticate.
2 Fix the bracket firmly using fixing screws through the bracket to the position where FaceStation F2 will be installed.

Installation
11
NOTE
•If installing FaceStation F2 on a concrete wall, drill holes, insert PVC anchors, and fix them with fixing screws.
•To avoid RF interference, a minimum separation distance must be maintained.
Wall thickness Distance
100 mm
200 mm
120 mm
180 mm
150 mm
150 mm
•When using Suprema Mobile Access, install a minimum distance of 1 m between devices to avoid BLE interference.
3 Install FaceStation F2 onto the fixed bracket.
Wall
300 mm
Distance
Wall thickness
Wall
Wall

Installation
12
4 Connect FaceStation F2 to the bracket by rotating the product fixing screw of FaceStation F2.
Wall

Installation
13
Power supply connection
NOTE
•Use a power supply adapter of DC 24 V or DC 12 V (± 10%) with a minimum of 2,500 mA which has obtained the approval of
IEC/EN 60950-1. If you wish to connect and use another device to the power supply adapter, you should use an adapter with
a current capacity which is the same or larger than the total power consumption required for the terminal and another device.
•Use a separate power supply for Secure I/O 2, the electric lock, and the product respectively. If connecting and using the power
supply to these devices together, the devices may malfunction.
•When connecting the power supply, be aware of the distance between FaceStation F2 and the power supply. The FaceStation
F2 should be connected as close as possible to the power supply so that the length of the connecting cable is kept to a
minimum. If cable connections are made improperly it may cause the device to malfunction. It is recommended to use a 16
AWG or 18 AWG cable if the FaceStation F2 is far from the power supply. The connection distance may differ depending on the
standard of the cable used and the installation environment. FaceStation F2 supports both DC 24 V and DC 12 V power, so
check the maximum length according to the cable specification to ensure that the unit is properly powered.
Cable standard Max. extended length
DC 24 V DC 12 V
16 AWG
150 m
50 m
18 AWG
136 m
30 m
20 AWG
90 m
20 m
•DO NOT extend the length of power cable when using the power adapter (DC 24 V (± 10%), 2.5A).
•
DO NOT use the CAT5 UTP 2-Wire for power supply purpose.
UPS
(Optional)
DC power
FaceStation F2
1 - PWR +VDC Red (White stripe)
2 - PWR GND Black (White stripe)

Installation
14
Network connection
TCP/IP
LAN connection (connecting to a hub)
You can connect the product to a hub using a general type CAT-5e cable.
LAN connection (connecting to a PC directly)
FaceStation F2 has an automatic MDI/MDIX function so that it can be connected to a PC directly using a normal straight type
CAT-5e cable or a cross cable.
NOTE
•When you use a gigabit network switch, please see below information.
- Use a Cat5e UTP(Unshielded Twisted Pair) cable.
- Use all 4 pairs (8 lines) of cable for network connection.
- DO NOT use the pair of cable for other purpose.
Hub
FaceStation F2
PC
FaceStation F2
PC

Installation
15
TTL input connection
Door sensor
FaceStation F2
Door button
Cable shield (optional)
1 - TTL IN0 Red
2 - TTL IN1 Yellow
3 - TTL GND Black
4 - SH GND Gray

Installation
16
Relay connection
Fail Safe Lock
In order to use the Fail Safe Lock, connect N/C relay as shown in the figure below. There is normally a current flowing
through the relay for the Fail Safe Lock. When the relay is activated, blocking the current flow, the door will open. If the
power supply to the product is cut off due to a power failure or an external factor, the door will open.
NOTE
•Install a diode at both sides of the door lock wire as shown in the figure to protect the relay from the reverse current, which
occurs when the door lock operates.
•Take caution of the installation direction of the diode. Install the diode close to the door lock.
•Use a separate power supply for FaceStation F2 and the door lock.
•Suprema’ s standalone intelligent readers contain internal relays that can directly lock/unlock doors without external
controllers for added convenience. For access control applications in need of security, however, it is NOT recommended to use
the internal relay of a reader to prevent any tampering attacks which can potentially trigger the door unlock. For such
applications, it is highly recommended to use a separate relay unit for a lock control such as Suprema's Secure I/O 2, DM-20
or CoreStation installed at a secure side of a door.
Fail Secure Lock
In order to use the Fail Secure Lock, connect N/O relay as shown in the figure below There is normally no current flowing
through the relay for the Fail Secure Lock. When the current flow is activated by the relay, the door will open. If the power
supply to the product is cut off due to a power failure or an external factor, the door will lock.
Dead bolt /
Door strike DC power
2 - RLY COM Blue
3 - RLY NC Orange
Dead bolt /
Door strike
DC power
1 - RLY NO White
2 - RLY COM Blue
FaceStation F2
FaceStation F2

Installation
17
NOTE
•Install a diode at both sides of the door lock wire as shown in the figure to protect the relay from the reverse current, which
occurs when the door lock operates.
•Take caution of the installation direction of the diode. Install the diode close to the door lock.
•Use a separate power supply for FaceStation F2 and the door lock.
•Suprema’ s standalone intelligent readers contain internal relays that can directly lock/unlock doors without external
controllers for added convenience. For access control applications in need of security, however, it is NOT recommended to use
the internal relay of a reader to prevent any tampering attacks which can potentially trigger the door unlock. For such
applications, it is highly recommended to use a separate relay unit for a lock control such as Suprema's Secure I/O 2, DM-20
or CoreStation installed at a secure side of a door.
Automatic door connection
FaceStation F2
Automatic door
control device
Detection sensor
Door button
Door lock
1 - RLY NO White
2 - RLY COM Blue

Installation
18
Connecting as a standalone
FaceStation F2 can be connected to the door lock, door button, and door sensor directly without connecting a separate I/O
device.
NOTE
•FaceStation F2 can be used as a multi-door controller with the slave devices with the RS-485 cable. The slave devices are used
as dummy readers and authentication is performed in the master device.
•If a fingerprint authentication device is configured as a slave device in FaceStation F2, you cannot add another FaceStation F2
as a slave device.
•If the fingerprint authentication device is the master device, FaceStation F2 cannot be added as a slave device.
•When you connect FaceStation F2 as a slave device while FaceStation F2 is the master device, only one FaceStation F2 can be
added as a slave device.
•If FaceStation F2 is configured as a slave device for the face recognition terminal, you can connect one additional Secure I/O 1
and DM-20 each.
•If FaceStation F2 is configured as a slave device for the face recognition terminal, you cannot connect additional OM-120.
•The maximum number of slave devices available to connect varies according to the authentication method, number of users,
and number of devices. Also note that the number of slave devices affects the authentication speed.
•A master device can control 31 slave devices. The bandwidth of RS-485 allows for up to 7 fingerprint authentication devices to
be connected.
•Suprema’ s standalone intelligent readers contain internal relays that can directly lock/unlock doors without external
controllers for added convenience. For access control applications in need of security, however, it is NOT recommended to use
the internal relay of a reader to prevent any tampering attacks which can potentially trigger the door unlock. For such
applications, it is highly recommended to use a separate relay unit for a lock control such as Suprema's Secure I/O 2, DM-20
or CoreStation installed at a secure side of a door.
•
For more information, contact the Suprema technical support team (support.supremainc.com).
FaceStation F2
PC
Door button
Door sensor
or
Cable shield (optional)
TTL
Hub
Fail Secure Lock
Fail Safe Lock
DC power
DC power
Dead bolt /
Door strike
Relay
Power
Relay connection
1 - RLY NO White
2 - RLY COM Blue
3 - RLY NC Orange
TTL connection
1 - TTL IN0 Red
2 - TTL IN1 Yellow
3 - TTL GND Black
4 - SH GND Gray
Power supply connection
1 - PWR +VDC Red (white stripe)
2 - PWR GND Black (white stripe)

Installation
19
Connecting to Secure I/O 2
Secure I/O 2 is an I/O device, can be connected to FaceStation F2 with the RS-485 cable. Security can be maintained even if
the connection between FaceStation F2 and Secure I/O 2 has been lost or the power supply to FaceStation F2 has been shut
off due to external factors.
•Use an AWG24 twisted pair with a maximum length of 1.2 km for the RS-485 cable.
•If connecting with a RS-485 daisy chain, connect the termination resistor (120 Ω) to both ends of the daisy chain
connection. If connected to the middle line, the signal level becomes smaller and the communication performance will
deteriorate. Make sure to connect it to both ends of the daisy chain connection.
NOTE
•FaceStation F2 can be used as a multi-door controller with the slave devices with the RS-485 cable. The slave devices are used
as dummy readers and authentication is performed in the master device.
•If a fingerprint authentication device is configured as a slave device in FaceStation F2, you cannot add another FaceStation F2
as a slave device.
•If the fingerprint authentication device is the master device, FaceStation F2 cannot be added as a slave device.
•When you connect FaceStation F2 as a slave device while FaceStation F2 is the master device, only one FaceStation F2 can be
added as a slave device.
•If FaceStation F2 is configured as a slave device for the face recognition terminal, you can connect one additional Secure I/O 1
and DM-20 each.
•If FaceStation F2 is configured as a slave device for the face recognition terminal, you cannot connect additional OM-120.
•The maximum number of slave devices available to connect varies according to the authentication method, number of users,
and number of devices. Also note that the number of slave devices affects the authentication speed.
•A master device can control 31 slave devices. The bandwidth of RS-485 allows for up to 7 fingerprint authentication devices to
be connected.
•For more information, contact the Suprema technical support team (support.supremainc.com).
FaceStation F2
PC
Door lock
Secure I/O 2
Door sensor
RS-485 connection
1 - 485 TRXP Blue
2 - 485 TRXN Yellow
3 - 485 GND Black
4 - SH GND Gray
Cable shield (optional)
DC power
DC power
DC power
Hub
RS-485
Power
Power supply connection
1 - PWR +VDC Red (White stripe)
2 - PWR GND Black (White stripe)
Door button

Installation
20
Wiegand connection
RFID reader
or
Controller
Cable shield (optional)
FaceStation F2
Use as a Wiegand input or output device
1 - WG D0 Green
2 - WG D1 White
3 - WG GND Black
4 - SH GND Gray
