Geemarc AMPLIVOICE50 User manual

CONTENTS 2
INTRODUCTION
Important safety instructions 3
Unpacking the AmpliVOICE50 3
DESCRIPTION
General Description 4
LCD Screen Description 6
Menu Navigation 6
INSTALLATION
Setting Up 7
Wall Mounting 9
SETTINGS
Language Setting 10
Screen Contrast Setting 10
Time Setting 11
Voice Function Setting 12
Flash (Recall) Setting 12
Dialling Mode (Tone/Pulse)
Setting 12
Ringer Volume Setting 12
USING THE TELEPHONE
Making a Call 13
Pre-Dialling 13
Making a Call - hands free 14
Receiving a Call 15
Last Number Redial 15
Receiving a call – Hands Free 15
Mute Function 16
Handset Volume Setting 16
Speaker Volume Setting 16
Tone Control Setting 16
Call Timer 17
Hearing Aid Use 17
CALLER DISPLAY 18
View Caller Display List 19
Dial a Number from the
Caller Display List 19
Delete an Entry from the
Caller Display List 20
Delete all Entries from the
Caller Display List 20
Copying a Number to the
Phone Book 20
PHONE BOOK 21
Create a Phone Book Entry 21
Store/Change a Name
Recording 22
Delete a Name Recording 23
View Phone Book Entries 23
Dialling using a Phone Book
Entry 23
Modify a Phone Book Entry 24
Delete a Phone Book Entry 24
Delete all Phone Book Entries 25
QUICK DIAL
Storing a Quick Dial Number 26
Dialling a Quick Dial Number 26
TROUBLESHOOTING 27
SAFETY INFORMATION 28
REGULATORY COMPLIANCE 29
GUARANTEE 31
2
CONTENT

3
INTRODUCTION
IMPORTANT SAFETY INSTRUCTIONS
When using your telephone equipment, basic safety precautions should
always be followed to reduce the risk of fire, electric shock and injury to
persons, including the following:
1.
Do not use this product near water, for example, near a bath tub, wash
bowl,kitchen sink or laundry tub, in a wet basement or near a swimming pool.
2. Avoid using a telephone (other than a cordless type) during an electrical
storm. There may be a remote risk of electric shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of the leak.
4. Use only the power cord and batteries indicated in this manual. Do not
dispose of batteries in a fire. They may explode. Check with local codes for
possible special disposal instructions.
SAVE THESE INSTRUCTIONS!
Congratulations on purchasing your Geemarc AmpliVOICE50 telephone.
This is a multifunction telephone which offers features such as hands free
use, phone book, caller display* and voice announcing.
Its is important that you read the instructions below in order to use your
Geemarc telephone to its full potential. Keep this user guide in a safe place
for future reference.
This guide explains how to use the following telephone:
AmpliVOICE50
*To use the caller display facility, you must subscribe to your network
provider’s caller display service.
Unpacking the Telephone
When unpacking the telephone, you should find the following in the box:
• 1 AmpliVOICE50 unit
• 1 AmpliVOICE50 handset with curly cord
• 1 Mains power adaptor
• 1 Telephone line cord
• 1 User Guide

4
DESCRIPTION
123 456
8
9
10
11
12
13
14
15
161718
7
General Description

5
DESCRIPTION
1= Call back, confirm
2= Quick Dial M1 (emergency call number 1)
3= Delete
4= Quick Dial M2 (emergency call number 2)
5= Scroll upwards
6= Quick Dial M3 (emergency call number 3)
7= Scroll downwards
8= LED( flashes when a new call has been received)
9= Menu button
10= Phonebook, Exit, Caller ID
11= Recall
12= Mute
13= Redial, Insert a pause
14= Handsfree
15= LED, telephone is ringing
16= Earpiece amplifier button
17= LED, receiver volume
18= Control knob for receiver volume (hidden)
19= Ringer volume slide control
20= Tone slide control
21= Speakerphone volume slide control
21 20 19

6
DESCRIPTION
LCD Screen Description
This LCD display shows the total number of calls and the number of new
calls ready to be reviewed. In this example you have a total of 4 calls which
includes two new calls.
Menu Navigation
To access settings, press MENU.
To exit the menu, press CID.
To skip back a level within the menu, press DELETE
The telephone will automatically return to standby mode from any menu if
no button is pressed for 20 seconds.
Time and Date
Battery Icon
New Calls
Received
Calls Received
Caller’s Number
Caller’s Name

7
Setting Up
Connect the handset to one end of the curly cord. The connector at the
end of the curly cord plugs into the socket on the left hand side of the
AmpliVOICE50 unit.
Open the battery compartment (push the small clip backwards and then
upwards). Insert 4 good quality alkaline batteries (AA size, 1.5V type, not
supplied) into the battery compartment located on the base of the telephone.
Replace the battery cover. If the batteries are running low, the battery icon
will appear on the LCD display. Ensure that the telephone is not connected
to the telephone line socket and/or mains power connection when the bat-
teries are being inserted or replaced.
Note: Do not use rechargeable batteries. Do not put batteries into the
household rubbish, pay attention to battery regulations regarding battery
disposal.
Connect the line cord to the socket located at rear of telephone then con-
nect the plug into the wall socket *.
Connect the power supply to the socket located at rear of the telephone
then plug into a 13amp wall socket. Please choose a socket near your
telephone to enable you to unplug the mains power quickly in case of a
problem.
Mains power outlet Telephone line jac
k
Receiver connection
(*) Classified “hazardous voltage” according to EN60950 standard
(**) Classified TNV-3 according to EN60950 standard.
INSTALLATION

8
Note: Mains power is required to power the multifunction features
of the telephone. Fit 4 x AA sized batteries in order to save and
use stored numbers in case of mains power failure. Without mains
or battery power, the telephone can still be used to answer calls or
to manually dial out calls but all the multifunction features will not
be available. If no batteries are inserted, the battery icon will be
displayed on the LCD display.
INSTALLATION

9
Wall Mounting
Feed the guide tabs (1) on the wall-mounting bracket (2) in the slots (3)
on the underside of the telephone. Slide the wall-mounting bracket 10 mm
upwards until it audibly locks into place. Drill a hole and insert a screw leav-
ing about 5 mm of the screw projecting from the wall. Guide the mounting
hole (4) in the mounting bracket (2) over the screw and slide the telephone
downwards.
Caution: Ensure there are no electrical lines, water pipes etc. in the wall
where the hole is drilled.

2
33

Turn the hook (5) in the receiver cradle so that the receiver can be placed
on-hook.
5
5
5
5
INSTALLATION

10
Language Setting
You can choose between 4 different languages including English and French.
Each language has voice announcements available in that language.
Press MENU
Use ▲or ▼to select LANGUAGE
Press DIAL to select
Use ▲or ▼to select the desired language
Press DIAL to select
Press CID to exit
Screen Contrast Setting
Your screen has a backlight which automatically switches off after 15
seconds of inactivity. The contrast of the backlight against the text can be
increased or decreased.
Press MENU
Use ▲or ▼to select CONTRAST
Press DIAL to select
Use ▲or ▼to select the desired contrast setting (3=normal)
Press DIAL to select
Press CID to exit
SETTINGS

11
Time Setting
If you subscribe to a Caller Display service, the date and time will be set
whenever you receive a call. However, if you do not subscribe to this
service, you will need to set the date and time manually.
Press MENU
Use ▲or ▼to select TIME/DATE
Press DIAL to select
The HOUR digit will flash. Use ▲or ▼to select the correct hour
Press DIAL to confirm
The MINUTE digits will flash. Use ▲or ▼to select the correct minute
Press DIAL to confirm
The MONTH digit will flash. Use ▲or ▼to select the correct month
Press DIAL to confirm
The DAY digit will flash. Use ▲or ▼to select the correct day
Press DIAL to confirm
Press CID to exit
SETTINGS

12
Voice Function Setting
When the VOICE function is ON, in pre-dial mode numbers 0-9, numbers
held in the call log, numbers held in the phone book and a caller’s name
(if recorded, see Phonebook Chapter – Storing Name Recording) will be
announced in the loudspeaker.
Press MENU
Use ▲or ▼to select VOICE
Press DIAL to select
Use ▲or ▼to select ON/OFF
Press DIAL to select
Press CID to exit
Flash (Recall) Setting
Many special telephone services, such as Call Waiting, require a switch
hook signal. For example, if you have Call Waiting, you can put a call on
hold and take a second incoming call on the same line by pressing CALL
WAITING button. Press CALL WAITING again to alternate the between the
two call.
Note: If you do not have any special phone services requiring a switch hook
signal,pressing CALL WAITING might disconnect the current call.
Dialling Mode (Tone/Pulse) Settings
In the US, all telephone exchanges now use Tone dialing. If your phone
does not dial out, it is probably being used from an older private switchboard
(PBX). In this case, the Tone/Pulse setting must be changed to Pulse.
SETTINGS

13
Press MENU
Use ▲or ▼to select TONE/PULSE
Press DIAL to select
Use ▲or ▼to select the desired method, TONE or PULSE 40/60
Press DIAL to select
Press CID to exit
Ringer Volume Setting
A switch located on the right side of the AmpliVOICE50 unit allows the
ringer to be switched to LOW, MEDIUM or HIGH.
Making a Call
Pick up the handset.
When you hear the dialling tone, dial the number on the keypad.
The number will be displayed on the LCD display
To end the call simply replace the handset in the cradle
Pre-dialling
If VOICE is activated, once you press the number keys 0-9 you will hear the
number being dialled.
Key in the required number without lifting the handset..
Use DELETE if necessary to cancel and correct a wrong digit
Lift the handset OR press DIAL OR press and the number
will be automatically dialed
To end the call simply replace the handset in the cradle OR press
USING THE TELEPHONE

14
USING THE TELEPHONE
Making a Call – Hands Free
Dial the number on the keypad in the on-hook position
Use DELETE if necessary to cancel and correct a wrong digit
Press and the number will be dialled automatically. The handsfree
function (speaker) is now activated and the LED indicator next to the
button will be illuminated.
When the third party answers the call, you may speak with the
telephone in the hands free mode ( handset in the cradle). Speak
towards the microphone located on the front edge of the telephone.
To end the call, press
Note: To deactivate the Hands Free function during a call, lift the
handset. To activate the Hands Free function during the call, press
and replace the handset on the cradle at the same time.
Also, when in hands free mode, only one person may talk at a time.
The switch-over between speaker and microphone is automatic. This is
dependent on the sound level of the incoming call and the microphone
respectively. It is therefore essential that there are no loud noises, e.g.
music, in the immediate vicinity of the telephone, as this will disrupt the
hands free function.

15
USING THE TELEPHONE
Receiving a Call
When an incoming call is received, the telephone rings and the LCD display
backlight lights up. If the caller can be identified (due to subscription to a
Caller Display service), the caller’s telephone number will be displayed.
The caller’s name will also be displayed provided that the number and name
stored are in the phone book. If the VOICE setting is ON and the caller
can be identified and a voice recording is associated with the incoming
call, the voice recording will be heard three times, followed by the ringer as
standard. (Refer to Phonebook chapter, Create a Phonebook Entry to find
out more about voice recording)
Lift the handset and speak
To end the call simply replace the handset in the cradle
Last Number Redial
Lift the handset or press for hands free use
Press REDIAL to redial the last number dialled.
Receiving a call – Hands Free
Press to speak hands free
To end the call press

16
Mute Function
If you wish, you can speak privately to someone else in the room without
your caller overhearing. You will still be able to hear the caller but they
cannot hear you during the mute operation.
To switch on the mute mode during a call just press and hold MUTE button.
Your caller will not be able to hear you anymore. Release MUTE to resume
the conversation with your caller.
Handset Volume Setting
During a call, the handset volume can be adjusted to one of 10 levels using
the control knob located on the handset cradle of the AmpliVOICE50 unit.
The “+40dB” button should be pressed to allow extra amplification, when
pressed the handset volume LED will light up
Note: Setting the receiver volume to maximum may under certain
circumstances, cause ear damage. Therefore, it is recommend that
you reset the volume to “0” after each call.
Speaker Volume Setting
During a call in handsfree mode, you can adjust the speaker volume to
a desirable level. Simply use the slide control located on the right of the
AmpliVOICE50 unit
Tone Control Setting
During a call, in handsfree mode, you can adjust the tone to a desirable
level. Simply use the slide control located on the right of the AmpliVOICE50
unit.
Note: Tone adjustment is not possible when the receiver volume is
set to its minimum level.
USING THE TELEPHONE
Volume
Tone

17
Call Timer
Your handset automatically times the duration of every external call. The
time is shown during the call and for a few seconds after the call has
ended.
Hearing Aid Use
This telephone is hearing aid compatible. Select the T mode on your hear-
ing aid to enable this feature.
USING THE TELEPHONE

18
The features described in this section are only available if you subscribe to
a Caller Display service from your network provider.
Caller Display means you can see who is calling before you answer a call
or see who has called in your absence (provided the number is not with-
held, unavailable or is an international call). If the number is stored in the
phonebook, the caller’s name is also displayed
Whether you take a call or not, the caller’s details are stored in the Call log.
The call log stores the incoming calls. When the call log memory is full, a
new call will take the place of the oldest call. You can display, scroll through
and dial numbers in the log. The sequence number is shown in the top
right-hand side of the LCD display.
If the caller has exercised the option to prevent his number from being
displayed, PRIVATE will be shown on the LCD display. If someone is call-
ing from an area where the service provider is not offering the Caller display
services or an area which is not providing name and number delivery to
your area via the long distance network, OUT OF AREA will be displayed
on the LCD display. If a telephone number has not been seen previously,
NEW will be displayed on the LCD display. If several calls have been
received from a particular number, REPEAT will be displayed.
The red incoming call indicator located on the right of your LCD display will
flash when you have received a new call in your absence. The indicator will
continue to flash until you review all the new calls displayed on the screen.
A total of 64 numbers can be stored in the call log.
A call log entry consists of the following information:
CALLER DISPLAY
Time and Date New Calls
Received
Caller’s Number
Caller’s Name

19
Your telephone displays incoming call waiting Caller ID information while
you are on another call. Once you have received a Call Waiting call, the
CALL WAITING icon will light.
Note: The Call Waiting information will be disappear after 20 seconds.
View Caller Display List
Use ▲or ▼to scroll through the caller display list
Notes: At the end of the caller display list the LCD display will display END
OF LIST. If there are no caller display telephone numbers in the caller
display list, NO CALLS is displayed
Dial a Number from the Caller Display List
Lift the handset or press to get a dial tone
Use ▲or ▼to scroll through the caller display list until you find
the telephone number you wish to dial
Press DIAL to automatically dial the telephone number
Or
In the on-hook position use ▲or ▼to scroll through the caller
display list until you find the telephone number you wish to dial
Press DIAL to automatically dial the telephone number
CALLER DISPLAY

20
CALLER DISPLAY
Delete an Entry from the Caller Display List
Use ▲and ▼to scroll through the caller display list until you find the
telephone number you wish to delete
Press DELETE, DELETE? will be shown on the LCD display
Press and hold DELETE until the telephone number disappears
Press CID to exit
Delete All Entries from the Caller Display List
Use ▲and ▼to scroll through the caller display list until you find the
telephone number you wish to delete
Press and hold DELETE, DELETE ALL? will be shown on the
LCD display
Press and hold DELETE until the telephone number disappears,
the list is erased
All the entries can be deleted after new calls have be reviewed.
Copying a Number to the Phone Book
Use ▲and ▼to scroll through the caller display list until you
find the telephone number you wish to copy
Press and hold MENU until the display shows COPY TO MEMORY
Press DIAL
