GeeMo G12 User manual

Handheld Cordless Vacuum Cleaner
Instruction Manual
Instruction Manual
Model: G12
For any questions and malfunctions of the appliance during use, please
contact our customer service email:[email protected]

CONTENT
IMPORTANT SAFEGUARDS
OVERVIEW
WHAT'S IN THE PACKAGE
OPERATION INSTRUCTION
CLEANING AND MAINTENANCE
SPECIFICATIONS
TROUBLESHOOTING
WARRANTY
01
02
03
04
06
07
08
09

IMPORTANT SAFEGUARDS
Before using the product, please read this instruction manual carefully, so as to help you correctly operate
the product. In order to avoid the personnel hurt or property loss caused by improper operation, please pay
attention to the following events before operation:
1.The product is especially designed for the individual household environment, and can not be used for
commercial purpose.
2.After unpacking the product, please carefully check if the product, power adapter(charger) are in good
condition. In case of a damage, please do not use the product, and contact the franchiser or customer
service to solve it.
3.Please maintain the instruction manual, package and other objects of the product for the future usage,
storage and maintenance.
4.Before connecting to the power supply, please check if your local voltage corresponds the voltage
range indicated on the power adapter.
5.The power adapter should be placed on a dry surface in charging.
6.When unplug the power adapter, please hold the plug instead of the wire, thus avoiding damaging the
power cord. At the same time, please keep the power cord away from the heat source and do not touch
the power adapter with wet hands.
7.The product is not a toy. The operation and storage of the vacuum cleaner should be away from
children. When children play around, it should be very careful.
8.Please do not use the cleaner to suck any liquid, high-temperature object, refined object(such as the
wood dust, land plaster, lime, cement, ash, carbon powder and so on), sharp fragment(glass, clip, nail
and so on), dangerous object(such as solution, detergent and so on), chemical object(such as acid
object, cleaning agent and so on), flammable and explosive object(gasoline, ethanol and so on).
9.In cleaning the product, please disconnect the power source in the first, and then wipe with dry or
humid cloth. Please do not use alcohol, benzene or detergent or other solutions to clean the product
surface, so as to avoid damaging the product appearance.
10.The product can’t maintain upright when there is no fixed rest. In storage, please fix the machine on
the charging base to avoid falling or collision.
11.Do not place the cleaner in water, or place or operate it outdoor.
12.Please confirm that all filtering components have already been correctly installed. It is forbidden to
use the product when the filtration device is not installed.
13.Please do not try to remove the battery, place the machine on metal surface or near heat source.
Please do not throw the battery into fire.
14.Please do not try to disassemble, maintain the product or power adapter. The maintenance work
shall be worked by the manufacturer or its maintenance department or similar professionals. In addition,
the original accessories must be used.
15.Before discarding the cleaner, please ensure that it absolutely can not be used. Therefore, before
discarding, please disconnect the power supply, take out the battery, and the discarded battery should
be safely recycled.
01

OVERVIEW
16.The product is not intended for these persons(including children): persons with psychological, physical
or emotional sense, lacking experience and knowledge, unless they are supervised or guided by persons
who are responsible for their safety in operating the product.
The design of the cleaner is not provided with any professional or industrial application. Any fault caused
by industrial or professional operation, improper operation or operation going against the instruction
manual, shall not be responsible by the company, and is not within the warranty scope.
02
Handle
Ring
Charging port
Dust cup release button
Dust Cup
ON/OFF Switch
Indicator Light
HEPA Filter Frame
HEPA Filter

WHAT'S IN THE PACKAGE
03
Flocking Pet Brush
Bed Brush
Flat Suction
Main Body Two-in-one Brush Combination Brush
Base Charging Cable Instruction Manual

OPERATING INSTRUCTION
04
※When the battery is fully charged for the first time, it must be fully charged again to activate
the battery in the best condition.
Only use the adapter provided by this product to charge the product.
Charging
Main body using
Operating : White Light
Power Low: Red Light Flash
Charging: White Light Flash
Fully charged：White Light
The battery should be charged fully before the first use.
Press the power switch to
enter the low mode, press
again to enter the high
mode, press again to shut
down.
Push the release button of
the dust cup backward to
dump the dust into the
waste container.
Aim the running main
body suction inlet at the
spot needs to be cleaned.

05
Rotate the flat suction brush head in the direction of the arrow to switch to the flat suction
nozzle state, and then rotate upward to switch to the brush head state. According to the actual
use of objects in different conditions (such as the surface of the table, sofa) targeted cleaning
treatment.
Combination brush with soft teeth can be used on pets; Take out the soft tooth assembly
along the arrow direction can be used in sofa, bedding, bed sheets and other occasions.
Accessories using
Two-in-one Brush Using

CLEANING AND MAINTENANCE
06
1. When the power is off, aim at the dust
container and push the release button of the
dust cup backward to empty the dust.
2. Take out the filter assembly diagonally
by holding the convex ribs on both sides of
the external filter assembly or knock down
the filter as figure showed, and tap the
metal filter net gently to remove the dust .
3. Hold the center bar of the HEPA filter and take
out the HEPA filter along the arrow.
4. Wash the external
filter assembly with
clean water or detergent
and dry completely.
5. Gently wipe the inner
wall of the dust cup and
soft rubber scraper with a
wet towel to remove dust.
6. Reload the HEPA filter
assembly into the external filter
assembly and make sure the
assembly is in place.
2

SPECIFICATIONS
07
7. Install the filter parts back: insert the filter assembly into the
main card slot diagonally, press the location indicated by the arrow
and hear the click, indicating that the installation is in place.
Base storage Ring storage
Storage
Product description
Rated Power
Rated Voltage
Noise
Suction Power
Run Time
Adaptor Output
Dust Cup Capacity
Handheld cordless vacuum cleaner
120W (High level)/60W(Low level)
11.1V
≤ 80dB
14 kpa(High level)/10 kpa (Low Level)
10Min (High level)/19Min (Low level)
13.5V 500mA
0.22L

TROUBLESHOOTING
08
Problem Possible reason Potential solutions
The appliance does not work
Unit is abnormal working
Poor vacuuming effect
Noise and air leakage
Battery runs our;
No normal press the power switch;
The appliance is charging;
Dust container is poor position；
Suction inlet is blocked；
HEPA filter is blocking ；
Dust cup is full；
HEPA filter Frame is poor position；
Dust container is damaged
Dust cup is full;
Suction inlet is blocked；
The HEPA filter filter is not installed well
The filter components are dirty
Check whether the dust container
rotates in place;
Check the suction inlet and clean it ；
Clean the HEPA filter
Empty the dust cup；
Check if need to clean the HEPA filter
Check if the cleaner needs charging;
Reload the HEPA filter frame;
Empty and clean the dust cup;
Check and clean the suction inlet;
Install the HEPA filter well
Clean the HEPA filter and frame;
Charging again;
Press the power switch;
Unplug the USB charging cable;

WARRANTY
09
CUSTOMER CARE
WHAT IS NOT COVERED
WARRANTY SERVICE
The 1-year Limited Warranty is valid for products purchased from our GEEMO only, starting
from the date of the original retail purchased. We will provide customer service for any defects
in quality or materials under normal, non-commercial use.
1. According to the requirements outlined in this instruction manual, the warranty is subject to
the following conditions and exclusions.
2. This warranty provides, at no extra cost to you all labor and parts necessary to ensure your
machine is in proper operating condition during the warranty period.
3. We provide the repair or replacement of your GEEMO appliance if your GEEMO appliance
is found to be defective due to faulty materials, workmanship function within 1 year of
purchase or delivery. ( If any part is no longer available or out of manufacture, we will replace
it with a functional replacement part).
1.Under your GEEMO guarantee, GEEMO shall not be liable for costs of repair or replace-
ment of a product incurred as a result of: Accidental damage, faults caused by negligent use
or care, misuse, neglect, careless operation or handling of the GEEMO appliance which is not
in accordance with this GEEMO Instruction Manual.
2.Machines purchased from an unauthorized dealer.
3.Use of parts and accessories other than those produced or recommended by GEEMO.
4.Repairs or alterations carried out by unauthorized parties or agents.
5.Use of the machine other than for normal domestic purpose, e.g. for commercial or rental
purposes.
6.Reduction in battery run time due to battery age or use.
1. If you have a query about your GEEMO appliance, please contact the GEEMO customer
service email: [email protected]
2. Please inform us your model name/number, purchase date, order number, machine
problem and your requirement.
3. Your model number can be found on rating plate. For information on your rating plate see
the inside front cover.
4. Please keep your purchase receipt in a safe place to ensure you have this information.
5. Service under this warranty will not extend the available time of warranty.
