Gefen EXT-DVI-2-VGAN User manual

www.gefen.com
DVI to VGA
Converter
EXT-DVI-2-VGAN
User Manual

ASKING FOR ASSISTANCE
Rev A2
Technical Support:
Telephone [phone]
[phone]
Fax [phone]
Technical Support Hours:
8:00 AM to 5:00 PM Monday thru Friday, Pacific Time
Write To:
Gefen LLC
c/o Customer Service
20600 Nordhoff St
Chatsworth, CA 91311
www.gefen.com
[email protected]
Notice
Gefen LLC reserves the right to make changes in the hardware, packaging and
any accompanying documentation without prior written notice.
DVI to VGA Converter is a trademark of Gefen, LLC
© 2010 Gefen LLC, All Rights Reserved.
All trademarks are the property of their respective owners.

CONTENTS
1 Introduction
2 Operation Notes
3 Features
4 Panel Layout
5 Panel Descriptions
6 Connecting and Operating the DVI to VGA Converter
6 Wiring Diagram
7 EDID Management
7 EDID Mode Selection
8 Internal EDID Specifications
9 Specifications
10 Warranty

1
INTRODUCTION
Congratulations on your purchase of the DVI to VGA Converter. Your complete
satisfaction is very important to us.
Gefen
We specialize in total integration for your home theater, while also focusing on
going above and beyond customer expectations to ensure you get the most from
your hardware. We invite you to explore our distinct product line. Please visit
http://www.gefen.com for the latest offerings in High-Definition signal solutions
or call us between the hours of 8:00 am and 5:00 pm Monday-Friday, Pacific
Standard Time for assistance with your A/V needs. We’ll be happy to assist you.
The Gefen DVI to VGA Converter
The Gefen DVI to VGA Converter is a small box solution that converts DVI-D to
VGAAnalog PC/RGB, enabling digital sources to connect with any display, pro-
jector or TV using VGA. Output resolutions up to 1920x1200 are supported. The
Gefen DVI to VGA Converter features advanced EDID management which uses
the EDID of the connected monitor if it is available. Otherwise, the internal EDID
is sent to the source for compatibility.
How It Works
Connect a DVI cable from the DVI source to the DVI input. Connect a monitor to
the VGA output connector. Connect the supplied 5V DC power supply to the unit
and connect the included AC power cord to an available electrical outlet.

2
OPERATION NOTES
READ THESE NOTES BEFORE INSTALLING OR
OPERATING THE GEFEN DVI TO VGA CONVERTER
• The DVI to VGA Converter supports a DVI-D signal using a DVI-I connector.
• The DVI to VGA Converter detect the presence of a connected monitor to
determine which EDID will be used.
NOTE: Once the DVI to VGA Converter is connected to a monitor, the EDID
from the monitor will be used. This feature cannot be disabled. See page 7
for details on the Internal and External EDID.
• The DVI to VGA Converter does not have scaling capabilities. The VGA
monitor must be able to support the DVI input resolution.
• This product does not support HDCP content.

3
FEATURES
Features
• Enables a DVI source to be displayed on VGA monitors or projectors
• Supports VESA resolutions up to 1920x1200 @ 60 Hz.
• EDID Management for rapid integration of sources and display devices.
Package Includes
(1) Gefen DVI to VGA Converter
(1) 6 ft DVI cable (M-M)
(1) 5V DC Power Supply
(1) User Manual

4
PANEL LAYOUT
Front
Back
12
3
4

5
PANEL DESCRIPTIONS
1 DVI In
Connect a digital DVI (DVI-D) source to this port.
2 Power Indicator
This LED will turn bright red once the included 5V DC power supply has
been properly connected to the unit and the locking power supply has been
connected to an available electrical outlet.
3 5V DC Power Connector
Connect the included 5V DC power supply to this connector.
4 VGA Out
Connect a VGAmonitor to this port.

6
CONNECTINGAND OPERATING THE DVI TO VGACONVERTER
How to Connect the DVI to VGA Converter
1. Connect a DVI source to the DVI In connector using the provided DVI cable.
NOTE: The DVI to VGA Converter only supports DVI-D sources.
2. Connect a VGA cable between the VGA monitor and the DVI to VGA
Converter.
3. Connect the 5V DC power supply to the DVI to VGA Converter and connect
the included AC power cord to an available electrical outlet. The LED on the
DVI to VGA Converter will turn bright red indicating that the unit is powered.
4. Power on the VGA monitor and the DVI source.
Wiring Diagram for the DVI to VGA Converter

7
EDID MANAGEMENT
EDID Modes
1. EXTERNAL MODE:
In order to use the external (display) EDID, the DVI to VGA Converter must
be powered after it has been connected to the display. If the Converter is
powered before it is connected to the display, then the internal EDID will be
used.
2. INTERNAL MODE:
The internal EDID is a preset EDID that is stored in the DVI to VGA
Converter. This pre-programmed standard EDID data structure is compatible
with most A/V displays. All resolutions and audio formats specified in
the internal EDID will be passed to the source device. See page 8 for a
complete listing of the resolutions and audio formats listed in the internal
EDID.

8
EDID MANAGEMENT
Internal EDID Specifications
The table below lists the resolutions and timings within the Internal EDID:
Video Data Block Video Data Block
1920x1080p @ 59.94/60 Hz (native)
1920 x 1080i @ 59.94/60 Hz (native)
1920 x 1080i @ 50 Hz
1920 x 1080p @ 50 Hz
1280 x 720p @ 59.94/60 Hz
1280 x 720p @ 50 Hz
720 x 480p @ 59.94/60 Hz
720 x 480i @ 59.94/60 Hz
720 x 576i @ 50 Hz
720 x 576p @ 50 Hz
1920 x 1200 @ 60 Hz
1600 x 1200
1280 x 1024 @ 60/75 Hz
1280 x 960 @ 60 Hz
1280 x 800 @ 60 Hz
1280 x 768 @ 60 Hz
1152 x 870 @ 75 Hz
1024 x 768 @ 60/70/75 Hz
800 x 600 @ 60/72/85 Hz
640 x 480 @ 60 Hz

9
SPECIFICATIONS
Video Bandwidth........................................................................................165 MHz
Input Video Signal................................................................................1.2 Volts p-p
Input DDC Signal...........................................................................5 Volts p-p (TTL)
DVI Connector.....................................................DVI-I 29-pin, female (digital only)
VGA Connector.................................................................................HD-15, female
Power Supply.................................................................................................5V DC
Power Consumption.......................................................................2.5 Watts (max.)
Operating Temperature..............................................................................0 ~ 40 °C
Dimensions.............................................................................3” W x 3.75” H x 1” D
Shipping Weight..............................................................................................2 lbs.

10
WARRANTY
Gefen warrants the equipment it manufactures to be free from defects in material
and workmanship.
If equipment fails because of such defects and Gefen is notified within two (2)
years from the date of shipment, Gefen will, at its option, repair or replace the
equipment, provided that the equipment has not been subjected to mechanical,
electrical, or other abuse or modifications. Equipment that fails under conditions
other than those covered will be repaired at the current price of parts and labor in
effect at the time of repair. Such repairs are warranted for ninety (90) days from
the day of reshipment to the Buyer.
This warranty is in lieu of all other warranties expressed or implied, including
without limitation, any implied warranty or merchantability or fitness for any
particular purpose, all of which are expressly disclaimed.
1. Proof of sale may be required in order to claim warranty.
2. Customers outside the US are responsible for shipping charges to and from
Gefen.
3. Copper cables are limited to a 30 day warranty and cables must be in their
original condition.
The information in this manual has been carefully checked and is believed to
be accurate. However, Gefen assumes no responsibility for any inaccuracies
that may be contained in this manual. In no event will Gefen be liable for
direct, indirect, special, incidental, or consequential damages resulting from
any defect or omission in this manual, even if advised of the possibility of such
damages. The technical information contained herein regarding the features and
specifications is subject to change without notice.
For the latest warranty coverage information, please visit Gefen’s Warranty web
page at http://www.gefen.com/kvm/aboutus/warranty.jsp
PRODUCT REGISTRATION
Please register your product online by visiting Gefen’s web site at
http://www.gefen.com/kvm/Registry/Registration.jsp

Pb
20600 Nordhoff St., Chatsworth CA 91311
1-800-545-6900 818-772-9100 fax: [phone]
www.gefen.com [email protected]
Rev A2
