GEHEIT ABAC SG 2500 User manual

Geheit GmbH
Benzstraße 2
D – 72636 Frickenhausen
Germany
Phone: + 49 (0) 7022 78969021
Fax: [phone]
www.shop.geheit.de
Motor Blower SG 2500
Operating Manual

Stand. 01.04.2018
EG-Konformitätserklärung/ EC Declaration of conformity/ CE Déclaration de conformité/
EG Conformiteitsverklaring/ EF Overensstemmelseserklæring/ EG Konformitetsförklaring/
EF Samsvarserklæring/ EY Vaatimustenmukaisuusvakuutus/ EC Dichiarazione di
Conformità/ CE Declaración de Conformidad/ EC Declaração de Conformidade/ ЕО
Декларация за съответствие/ EK Δήλωση συμμόρφωσης/ CE Declara
ţie de conformitate/
WE Deklaracja zgodności/ EC Заявление осоответствии/ EK Atbilstības deklarācija/ EÜ
Vastavusdeklaratsioon/ EB Atitikties deklaracija/ ES Prohlášení o shodě/ ES Prehlásenie o
zhode/ ES Izjava o skladnosti/
EK Megfelelőségi nyilatkozat
GEHEIT GmbH
Benzstr. 2
D-72636 Frickenhausen
Angewendete harmonisierte Normen/ Applied harmonized standards/ Normes harmonisées appliquées/ Gebruikte geharmoniseerde normen/
Anvendte harmoniserede normer/ Harmoniserade standarder som använts/ Anvendte harmoniserte normer/ Sovellettavat harmonisoidut
standardit/ Norme armonizzate applicate/ Normas armonizadas aplicadas/ Normas harmonizadas aplicadas/ Приложени хармонизирани
стандарти / Εφαρμοσμένα εναρμονισμένα πρότυπα/ Norme armonizate aplicate/ Zastosowane normy zharmonizowane/ Применимые
гармонизированные нормы/ Pielietotie harmonizētie standarti/ Kohaldatud harmoniseeritud normid/ Taikyti darnieji standartai/ Použité
harmonizované normy/ Použité harmonizované normy/ Uporabljeni harmonizirani standardi/ Alkalmazott harmonizált szabványok:
Name und Anschrift der Person, die bevollmächtigt ist, die technischen Unterlagen zusammenzustellen.
Name and address of the person authorised to compile the technical documents.
Nr. / No. / No. / Nr./ Nr. / Nr. / Nr. / Nro./ N. / Nº / Nº/ №/
Αρ. / No. / Nr./ №/ Nr. / No. / Nr / Č. / Č. / Št. / Sz.:
Typ / Type / Type / Type/ Type / Type / Type / Tyyppi/ Tipo / Tipo / Tipo /
Тип / Τύπος / Tip / Typ/ Тип / Modelis / Tüüp / Tipas/ Typ / Typ / Tip / Típus:
Jahr / Year / Année / Jaar/ År / År / År / Vuosi / Anno / Año / Ano /
Година / Έτος / An / Rok/ Год / Gads / Aasta / Metai/ Rok / Leto / Év:
EN 292/2 pr EN1953b / EN60335/1.788 / EN55014/12.93 / EN60555/2.87 / EN614-1 / EN60204-1 /
EN50050-1-2 prEN501176 / pr EN50177 / EN6100-4-2 / 4-4 /4-5 / 4-11 / 3-22 /DIN-VDE0740 TEIL 21/4.81
Hauptabschnitt G VBG 23
EU-Richtlinie: EMV-Richtlinie 89/336 i.d.F. 93/68 EWG / Niederspannungsrichtlinie 73/23 EWG
Eugen Friesen (Managing Director)
000001-001000
Niederdruck Spritzgerät SG 2500
2018

1
Table of Contents
1 Intended Use 2
2 Brief Description 3
3 Technical Data 4
4 Safety Notes 5
4.1 Principles; Correct Operation 5
4.2 Safe Operation 6
5 Transportation and Storage 8
6 Start-Up and Operation 8
6.1 Setting Up the Motor Blower 8
6.2 Switching On and Adjusting the Blower 8
7 Switching Off the Motor Blower 9
8 Care, Maintenance and Repair 9
8.1 Replacing Intake Filter 9
9 Faults, Possible Causes and Remedies 10
10 Operating Instructions 11
11 Spare Parts 11
© 2019 by Geheit GmbH
Printed in Germany
All rights reserved, but particularly the right of duplication, distribution and translation.
No part of this publication may be reproduced in any form (printed, photocopying,
microfilming or by any other method) without the previous written consent of
Geheit GmbH, or be stored, processed, duplicated or distributed by means of electronic
systems.

2
1 Intended Use
The ABAC Motor Blower SG 2500 – named in this manual also as Motor Blower or
simply Blower – is intended to be used together with the ABAC low pressure spray
guns PN 1, PN 2 or PN 5 to spray and apply paints and lacquers. For spraying you may
use materials approved by paint manufacturers for High Volume Low Pressure (HVLP)
air-spraying technique application. These are for instance:
·Patina paints, two-component-paints, synthetic resin alkyd paints, acrylic and
dispersion paints, colour effect paints, insulation / inflammation protection, sprayable
wax materials.
Identification number of SG 2500 Motor Blower is BJ 380 502 0000 (100 V),
BJ3805030000 (115 V), BJ 380 501 0000 (230 V).
Always observe and comply with all processing instructions and safety notes provided
by material manufacturers as well the prescriptions of this operating manual.
In any case, only paints and solvents with a flash point above 21°C = 70°F may be used
for spraying!
The ABAC Motor Blower SG 2500 is designed to be operated in connection with PN 1 /
PN 1A, PN 2 / PN 2A and PN 5 ABAC Spray Guns, which operate in the low-pressure
range up to 0,45 bar.
It is forbidden to connect the ABAC Motor Blower SG 2500 to
devices, which are not intended for paint spraying and application,
as well to technically incompatible spray guns.
Any use of the Motor Blower different from described in this manual
is prohibited.
Ambient temperature range for equipment operation is from 0°Сto +45°С, relative
humidity must not exceed 80%. Conditions of transportation and storage see Section 5.

3
2 Brief Description
The ABAC SG 2500 Motor Blower generates an adjustable flow of high-volume-low-
pressure working air, which is fed to the ABAC spray gun via the air hose. The main
operating device is motor mounted together with air blower, which has four stages. The
cooling air, required for the motor, flows through an air channel separately from the
working air. To protect the motor, two separate intake filters are installed.
Figure 1
N
OTE:
Enter the serial number marked on the rating plate of your Blower in figure 1.
Keep your operating manual and its attached CE declaration of conformity in
a safe place.
GEHEIT GmbH
D – 72636 Frickenhausen
Made in Germany
Typ SG 2500
Fab. No.
AC 100 / 115 V 1/N 50-60 Hz
1500 W 16,0 A 21000 / min
Volumenstrom max. 2,7 m3/ min
Betriebsdruck max 0,35 bar
GEHEIT GmbH
D – 72636 Frickenhausen
Made in Germany
Typ SG 2500
Fab. No.
AC 230 V 1/N 50-60 Hz
1500 W 7,0 A 21000 / min
Volumenstrom max. 2,7 m3/ min
Betriebsdruck max. 0,35 bar

4
3 Technical Data
oSound Pressure Level, average, DIN 45635
(for spraying operation) 74 dB(A)
oOnly for paints and solvents with a flash point above 21°C / 70°F
oOperating Voltage………………………….. AC 100 V 1/N, 50 / 60 Hz
AC 115 V 1/N, 50 / 60 Hz
AC 230 V 1/N, 50 / 60 Hz
oInsulation (Protection Class)…………….. 3
oPower…………………………………............. 1500 W
oPower consumption…………………………. approx. 16 A (100 V)
approx. 16 A (115 V)
approx. 7 A (230 V)
oSpeed………………………………………….. 21 000 min-1 (max.)
oProtection Type……………………………….. IP 20
oQuantity of Air, adjustable, max. …................ 2,7 m³ / min
oOperating Pressure, approx. ………............... 0,35 bar (max.)
oLength………………………………………….. 230 mm
oWidth……………………………………………. 240 mm
oHeight…………………………………………… 435 mm
oWeight…………………………………………… 9,7 kg

5
4 Safety Notes
Besides this Operating Manual and the statutory safety regulations for accident prevention
applicable in the country and place of use, operators must also abide by the recognized codes
of practice for safe and workmanlike operation.
4.1 Principles; Correct Operation
●The Motor Blower is state of the art equipment complying with recognized safety
regulations. However, if used improperly there is a risk of death or injury to the user or
other persons, or of damage to the machine or other property.
●The Motor Blower should only be used for its intended purpose and when it is in a perfect
working order. The user must be safety conscious, fully aware of the risk, and follow the
operating instructions. Faults that could impair the operating safety of the unit must be
immediately remedied by an authorized person.
●The SG 2500 Motor Blower is intended for use with our own ABAC low-pressure spray
guns, which operate in the low-pressure range up to 0,45 bar. You must also follow the
instructions given in the relevant operating manuals for these ABAC low-pressure spray
guns.
It must not be used for any other purpose. The manufacturer or supplier is not
responsible and will not be liable for damage or injury resulting from improper use, which
shall be entirely at the user’s risk.
●Warranty obligations are valid only if the user observes the instructions and
recommendations described in this operating manual. Unauthorized changes and repair,
use for maintenance of spare parts other than original parts supplied with the product and
approved by the manufacturer or included in the spare parts list, as well operation of the
equipment under conditions other than those permitted in this manual, will void the
manufacturer’s guarantee for the ABAC SG 2500 Motor Blower.

6
4.2 Safe Operation
●Comply with the requirements of accident prevention regulation “Processing of Coating
Materials” (e.g. in Germany VBG 23).
●All persons using the ABAC Motor Blower must have read and understood this Operating
Manual, particularly the section entitled “Safety Notes”.
●The ABAC SG 2500 Motor Blower is not of flame-proof design. Take care to ensure that
there are no ignition sources in the vicinity, such as naked flames, sparks, glowing wires,
hot surfaces, lighted cigarettes etc. The distance between spray jet exit and a possible
source of ignition (even the Blower itself) must be at least 5 m (fire and explosion hazard
from ignitable spray mist).
●It must not be used in works locations subject to the provisions of explosion prevention
regulation, or on premises and in areas where there is a risk of fire.
●Use only paints and solvents with a flash point of 21°C/70°F or higher without additional
heating (see details on paint tin).
●When working in confined spaces, these must be properly ventilated using effective
technical ventilation systems.
●The sprayed paint emerges from the nozzle at high pressure. Never direct the spray jet at
people or animals. If the skin is injured by paint, lacquer or solvent there is a risk of
infection. Seek medical treatment immediately and tell the doctor which paint, lacquer or
solvent was used.
●Poisonous fumes may be given off during spraying (see paint tin for details). Use a
breathing mask as directed by paint manufacturer’s instructions. Keep children and other
people away from the working area.
●The ABAC SG 2500 Motor Blower is not splash-proof. It must not be used out of doors,
when it is raining or splashed or washed with water or immersed in liquid.
●Keep the ABAC SG 2500 Motor Blower in a safe place that is inaccessible to children
and unauthorized personnel. Make sure that no unauthorized personnel (particularly
children) can put the ABAC SG 2500 Motor Blower into operation.
●Store your Motor Blower in a dry ventilated room.
●For safety reasons you should only use ABAC original accessories and ABAC original
spare parts.

7
●Always switch off your SG 2500 Motor Blower before refilling paint into your spray gun
paint container.
●Never pull the connecting cable over sharp-edged objects and make sure the cable is in
perfect condition each time before using it.
●Repairs and maintenance works, or the replacement of the power cable, should
only be carried out by authorized specialists or by us. Addresses of authorized
firms can be obtained from us or from your dealer upon request.
●When spraying, take care not to spray in the direction of your Motor Blower.
●Dispose of your cleaning and spraying material wastes according to the instructions
given by the relevant lacquer, paint and solvent manufacturers.
●Provide the replacement of blower filters in time and on regular basis. The use of
worn-out filter will lead to blower overheating. Always check the filter state when
detect overheating of the Blower.

8
5 Transportation and Storage
The ABAC SG 2500 Motor Blower is supplied in a branded packaging. To avoid damage during
transportation and storage, we recommend to use this original packaging. Store your equipment
in a dry ventilated room.
Ambient temperature range for equipment storage is from 0°Сto +45°С, relative humidity must
not exceed 80%.
Attention!!!
Use for transport only the handle of the Motor Blower. Never attempt
to move the Blower by pulling on its air hose or electric cable!
Furthermore, it is forbidden to take non-explosion proof Blower to an
inflammable area.
6 Start-Up and Operation
6.1 Setting up the Motor Blower
●Check that the mains voltage corresponds to the operating voltage indicated on the rating
plate or in this Operating Manual.
●Connect the air hose to the Blower by turning the air hose connector clockwise in the
blower opening.
6.2 Switching on and Adjusting the Blower
●Plug the Blower into the mains and press the green button of the ON-OFF – switch with
the thumb.
●Use the rotary knob of the speed governor to adjust air quantity and pressure
continuously and match air quantity and pressure generated by motor blower operation to
the paint being used. The Blower can thus be adapted to material to be sprayed. The
spray consistency of the material must be determined beforehand in order to select the
best possible settings for the Blower and spray gun. A dipping cup is supplied with the
spray unit for this purpose; see operating instructions for PN 1, PN 2 or PN 5 spray guns,
depending on which one you’ll choose, for further details. It is recommended to spray
samples before work is started (e.g. onto cardboard or wood). Do not start work on the
actual object to be sprayed until the desired result is obtained with the samples.
●Ensure that the edges or borders of the object to be sprayed are properly masked.

9
7 Switching off the Motor Blower
After you have finished spraying, turn off the Blower by pressing the red button of ON-OFF-
switch with your thumb. Only then should the Blower be disconnected from the mains. When
work has finished, coil connection cable round the handle of motor blower.
8 Care, Maintenance and Repair
Attention!!!
Always switch off your Motor Blower and disconnect from mains,
before carrying out any repair and maintenance work.
Do not use any solvents or aggressive fluids to clean the fan cage.
Repair and maintenance work, or the replacement of the power
cable should only be carried out by authorized specialist firms or by
us. Addresses of authorized firms can be obtained from us or from
your dealer.
Excepting filter maintenance (see item 8.1), your SG 2500 Blower Motor does not require any
customer servicing to be carried out.
8.1 Replacing Intake Filter
Attention!!!
Switch off the Motor Blower, disconnect from mains and wait until
motor is stationary before opening intake vents. Please take notice,
that the closure is a screw joint. To unlock the device cover you may
need the screwdriver.
Always replace both intake filters when they are dirty. Do not
attempt to clean them.
Both intake filters should always be checked before spraying and replaced when dirty. This
ensures that the air flowing through the gun is always clean.
On the back side of blower housing you will find two intake vents: one at the top is provided to
cool the motor, another at the bottom is the suction of working air. Open each closure with a
crosshead screwdriver or similar object. Each closure has only one screw joint. Open the cover
and change intake filter. After replacing the filter, set the cover back and screw it with the
screwdriver carefully and without overtension.

10
9 Faults, Possible Causes and Remedies
Attention! Never use hard or sharp-edged tools for cleaning!
Fault Possible causes Remedy
Motor Blower delivers
insufficient air flow
·Intake filter is dirty ·Replace intake filter
Motor Blower delivers
too much or too little
air
·Rotary knob incorrectly set ·Reset rotary knob such that
required air quantity is
delivered
Motor Blower is not
running
·No mains voltage ·Check mains connection
·Motor protection has tripped ·Wait a while and press the
green button on the device
switch
·Carbon brushes worn ·Repair only by approved
workshop (ABAC)
·Motor Blower defective ·Repair only by approved
workshop (ABAC)
Air quantity cannot be
regulated
·Electronics defective ·Repair only by approved
workshop (ABAC)

11
10 Operating Instructions
Depending on actual use and location of the equipment, users must issue an operating
instruction, based on this manual and in the language of their employees, to define further
details for the safe operation of SG 2500 Motor Blower. This operating instruction is to be
displayed in a suitable public place at the workplace and to be read and observed by all
employees.
11 Spare Parts
For safety reasons you should only use ABAC original accessories
and ABAC original spare parts.
Spare parts are available from your ABAC specialist dealer or directly from our company.
For speedy and efficient ordering of spare parts we require the following details:
·Equipment type, serial number
·Designation of the part, identification number
·Quantity of parts required
·Address
Spare Parts List for ABAC SG 2500 Motor Blower
Fig. No. Quantity Designation Ident. Number
- 1 Intake filter H5 805 614 0000
(pack of 5 pcs.)
