genata GNT- P4813V6 User manual

=
KEY FEATURE：
1、Using CAT.5 network patch cords support power for the wireless AP/CPE and IP camera/PTZ
2、Networking standard: IEEE802.3af/at/bt
3、POE power light blinks to determine the power status of the receiving end, and each blink is 2.7 watts.
4、PoE Watchdog AI Function: Detection front-end PoE cameras and PD, Automatic detection, Automatic restart
5、Upload port automatic flip (Auto MDI / MDIX)
6、6KV lightning protection,8KV surge protection, anti-reverse connection, over-current protection, over-voltage
protection, over-temperature protection, Short circuit protection
7、The Max output power of the port is 60W, which is convenient for hi-power equipment
8、Zero configuration feature power supply is automatically supplied to the adaptive equipment
WATCHDOG
Auto-detect and restart IP camera timely if the camera is halted.
6KV LIGHTNING 8KV ESD
Reaching 6KV lightning and 8KV Static electricity
protection, the PoE ports owns the capacity to keep the
PoE Switch from lightning strikes and other electrical
surges, offering reliable performance even in some harsh
environments.
SUPPLY 60W HIGH POWER
60W high-power port to meet the needs of more
and more high-power powered devices
EASY TO USE
The plug and play with no configuration makes the
maintaining as easy as ABC. With the indicator lights of
PWR and Link/Act, users can easily get the working
status of the connected devices. All those will have no
doubt to simply the use

SPECIFICATIONS：
Model GNT- P4813V6
Ports
14X10/100/100Mbps PoE ports (RJ45)
2X10/100/1000Mbps PoE ports (RJ45)
2X10/1000Mbps uplink port (RJ45)
1X10/1000Mbps SFP
Transmission Rate
2000Mbps Full Duplex; 10 or 100 or 1000Mbps Half Duplex
Transmission Distance
0-130m
Performance
Specification
Bandwidth: 12.80Gbps
Network Latency (10 to 1000Mbps): ≦16μs (use the 64byte package size)
MAC address table: 8K
The Frame Filter & Transmission Rate: 14800pps the most for 10M port, 148800pps the
most for 100M port,1488000pps the most for 1000M port
Networking
Standard
IEEE 802.3i 10BASE-T
IEEE 802.3u 100BASE-TX/ IEEE 802.3ab 1000BASE-T
IEEE 802.3xFlowControl
IEEE 802.3af/at/bt Power over Ethernet
Power Support
Power input: AC 110~220V Total≤300W
PoE Watchdog: Port 1~16
Power output: PoE1~14Port:1/2(+52V),3/6(GND)≤30W
PoE 15~16 Port:1245(+53V),3678(GND) compatible1/2(+52V),3/6(GND)≤60W
Protection Level
Lightning Protection:6KV, Per: IEC61000-4-5
ESD Protection:8KV, Per: IEC61000-4-2
Physical Specifications
Size(L*W*H)：430mm*180mm*45mm
Working
Environment
Operating Temperature: -30℃~60℃( -22°~140℉)
Storage Temperature: -40℃~70℃( -104°~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Electromagnetic
Compatibility
CE mark
FCCPart15，Class B
VCCI ClassBEN55022 (CISPR 22)
C-Tick
Warranty
Whole machine: 1 year
Package Content
Installation Manual

Port Description
Structure Diagrams
Product Installation
Typical Applications
