Genelec 1032A User manual

Genelec 1032A
Monitoring Speaker
Operating
Manual

1. General description1. General description
1. General description1. General description
1. General description
SystemSystem
SystemSystem
System
The bi-amplified GENELEC 1032A is a
two way active monitoring speaker
designed for high output, low coloration
and broad bandwidth. It is based on the
famous 1031A near field monitor but
offers extended low frequency output
with an increased maximum SPL.
Due to compact size, integrated
construction, excellent dispersion and
precise stereo imaging this speaker
system is ideal for Near Field monitoring,
mobile vans, broadcast and TV control
rooms and home studios. Designed as
an active speaker, this unit contains
drivers, power amplifiers, active
crossover filtering and protection
circuitry. The DCW Technology used
provides excellent frequency balance
even in difficult acoustic environments.
DriversDrivers
DriversDrivers
Drivers
The bass frequencies are reproduced
by a 10" (250 mm) bass driver loaded in
a 24 liters vented cabinet. The -3dB point
lies at 40 Hz and the low frequency
response extends down to 36 Hz (-6dB).
The high frequency driver is a 1" (25 mm)
metal dome with pure piston behavior up
to 23 kHz. The uniform dispersion control
is achieved with the revolutionary DCW
Technology pioneered by Genelec. This
has also resulted in perfect phase and
delay uniformity at the crossover
frequency.
Both drivers are magnetically shielded.
CrossoverCrossover
CrossoverCrossover
Crossover
The active crossover network consists of
two parallel bandpass filters. Acoustically
the filters are complementary and the
slopes are 24 dB/octave. The crossover
frequency is set to 1,8 kHz. By use of
active crossover controls ('treble tilt',
'bass tilt' and 'bass roll-off') this speaker
may be exactly matched to any
application.
AmplifiersAmplifiers
AmplifiersAmplifiers
Amplifiers
The amplifier unit is mounted to the rear
of the speaker enclosure on quick release
vibration isolators, to ensure rattle free
operation and long term reliability. The
bass and treble amplifier produce 180 W
and 120 W, respectively, of short term
power. The fast, low distortion amplifiers
are capable of driving the stereo system
to peak output levels in excess of 124 dB
SPL at 1 m. The unit incorporates a
special protection circuitry for driver
overload protection and amplifier thermal
overload protection. Variable input
sensitivity allows for accurate level
matching to the mixing console.
2. Installation2. Installation
2. Installation2. Installation
2. Installation
Each 1032A monitor is supplied with an
integrated amplifier unit, a mains cable
and an operating manual. Once
unpacked, place the loudspeaker in its
required listening position, taking note of
the line of the listening axis (see figure
2).
Before connecting up, ensure that the
mains switch is off (see figure 4). Check
that the mains voltage selector is correctly
set. Audio input is made via a 10k Ohm
Figure 2. Speaker acoustic axis and
dimensions in horizontal and vertical
mounting positions.
Figure 1. Suggested tone control setting for differing acoustic environments
Figure 3 . XLR connection if unbalanced
input is required.
Setting the input sensitivitySetting the input sensitivity
Setting the input sensitivitySetting the input sensitivity
Setting the input sensitivity
Adjustment of the input sensitivity of each
speaker can be made to match that of
the mixing desk or other source, by use
of the input sensitivity control on the rear
panel (see figure 4). A small screw driver
is needed for the adjustment. The
manufacturer default setting for this
control is -6 dBu (fully CW) which gives
SPL of 100 dB @1m at -6 dBu input level.
Note that to get the full output level of 113
dB SPL, an input level of +7 dBu is
needed at this setting.
Setting tone controlsSetting tone controls
Setting tone controlsSetting tone controls
Setting tone controls
The acoustic response of the system
may also have to be adjusted to match
the acoustic environment. The
adjustment is done by setting the three
tone control switches 'treble tilt', 'bass
tilt' and 'bass roll-off' on the rear panel of
the amplifier. The manufacturers default
settings for these controls are 'All Off' to
give a flat anechoic response. See Figure
1 for suggested tone control settings in
differing acoustic environments. Figure
5 shows the effect of the controls on the
anechoic response. Always start
balanced (XLR), but unbalanced leads
may be used as long as pin 3 is grounded
to pin 1 of the XLR (see figure 3).
Once connection has been made, the
speakers are ready to be powered-up.
noitisoPgnitnuoMrekaepS elberT
tliT
ssaB
tliT
ssaB
ffo-lloR
esnopserciohcenatalFenoNenoNenoN
moordepmadanignidnatseerFenoNBd2-enoN
moortnarebreveranignidnatseerFenoNBd4-Bd2-
egdirbelosnocnodleifraeNenoNBd4-enoN
renrocanIenoNBd4-Bd4-

Figure 4. Rear panel layout.
adjustment by setting all switches to
'OFF' position. Then set only one switch
to ON position to select response curve
needed. If more than one switch is set to
'ON' (within one switch group) the
attenuation value is not accurate.
Vertical / horizontal mountingVertical / horizontal mounting
Vertical / horizontal mountingVertical / horizontal mounting
Vertical / horizontal mounting
The speakers are delivered normally for
vertical mounting. If horizontal mounting
is needed the DCW plate can be rotated
so that the GENELEC logo is located at
the bottom left corner of the DCW.
Remove the four corner screws of the
DCW (use a Torx 20 screw driver) and
pull the plate carefully out without
stressing the wires and the gasket. Rotate
the plate 90 degrees to the appropriate
direction and remount the screws. Note
that to get mirror image pair the DCW
must be rotated to different direction in
left and right speaker. In horizontal
mounting position the bass drivers should
point inwards to get better low frequency
summing.
Console top mountingConsole top mounting
Console top mountingConsole top mounting
Console top mounting
If the 1032A's are used for console top
monitoring it is recommended not to
mount the speakers directly on the
console. Instead position the speakers
slightly behind the console by using
floor stand or wall mount at the console
back side. This prevents the reflection
from the console surface from coloring
the sound.
Overload indicatorsOverload indicators
Overload indicatorsOverload indicators
Overload indicators
The speaker is provided with two warning
LED's marked 'OVL' and 'ON'. The green
ON-LED when lit indicates that the
speaker is ready for use. The red OVL-
LED indicates that the amplifier is
overloaded or the driver protection circuit
is activated. In both cases reduce the
signal level so that the LED stops blinking.
If the OVL-LED stays on constantly it
indicates that the amplifier thermal
protection is activated. Let the amplifier
cool down and check that the ventilation
at the rear side of the speaker is not
blocked. There should be a clearance of
more than 4" (10cm) between speaker
rear and any solid surface at the back.
3. Maintenance3. Maintenance
3. Maintenance3. Maintenance
3. Maintenance
No user serviceable parts are to be found
within the amplifier unit. Any maintenance
or repair of the 1032A unit should only be
undertaken by qualified service
personnel.
4. Safety Considerations4. Safety Considerations
4. Safety Considerations4. Safety Considerations
4. Safety Considerations
Although the 1032A has been designed
in accordance with international safety
standards, to ensure safe operation and
to maintain the instrument under safe
operating conditions, the following
warnings and cautions should be
observed.
- Servicing and adjustment should
only be performed by qualified
service personnel.
- Opening the amplifier's rear panel
is strictly prohibited except by
qualified service personnel who
are aware of the hazards involved.
- It is forbidden to use this product
with an unearthed mains cable,
which may lead to personal injury.
WARNING!WARNING!
WARNING!WARNING!
WARNING! This equipment is capable
of delivering Sound Pressure Levels in
excess of 90 dB, which may cause
permanent hearing damage.
5. Accessories5. Accessories
5. Accessories5. Accessories
5. Accessories
Several additional options are available
for the 1032A:
Flightcase 1032-401
Handles 1032-406
Grille 1032-409
Wall mount 1032-404 V/H*
Floor stand 1032-405 V/H*
*State the desired speaker orientation
V=vertical or H=horizontal when ordering
these accessories
6. Guarantee6. Guarantee
6. Guarantee6. Guarantee
6. Guarantee
This product is supplied with a ONE
YEAR guarantee against manufacturing
faults or defects that might alter the
performance of the 1032A unit. Refer to
supplier for full sales and guarantee
terms.

Genelec Oy, Olvitie 5Genelec Oy, Olvitie 5
Genelec Oy, Olvitie 5Genelec Oy, Olvitie 5
Genelec Oy, Olvitie 5
FIN - 74100 IISALMI, FINLANDFIN - 74100 IISALMI, FINLAND
FIN - 74100 IISALMI, FINLANDFIN - 74100 IISALMI, FINLAND
FIN - 74100 IISALMI, FINLAND
Phone:Phone:
Phone:Phone:
Phone: +358 - 17 - 83 881+358 - 17 - 83 881
+358 - 17 - 83 881+358 - 17 - 83 881
+358 - 17 - 83 881
FF
FF
Fax:ax:
ax:ax:
ax: +358 - 17 - 812 267+358 - 17 - 812 267
+358 - 17 - 812 267+358 - 17 - 812 267
+358 - 17 - 812 267
E-mail:E-mail:
E-mail:E-mail:
E-mail: [email protected][email protected]
[email protected][email protected]
[email protected]
Web:Web:
Web:Web:
Web: http://www.genelec.comhttp://www.genelec.com
http://www.genelec.comhttp://www.genelec.com
http://www.genelec.com
Note! All frequency response curves were measured in aNote! All frequency response curves were measured in a
Note! All frequency response curves were measured in aNote! All frequency response curves were measured in a
Note! All frequency response curves were measured in a
calibrated, 12 m cube, anechoic chamber at 1 m using grade 1calibrated, 12 m cube, anechoic chamber at 1 m using grade 1
calibrated, 12 m cube, anechoic chamber at 1 m using grade 1calibrated, 12 m cube, anechoic chamber at 1 m using grade 1
calibrated, 12 m cube, anechoic chamber at 1 m using grade 1
measuring equipment. Input signal levels were set at -20 dBu.measuring equipment. Input signal levels were set at -20 dBu.
measuring equipment. Input signal levels were set at -20 dBu.measuring equipment. Input signal levels were set at -20 dBu.
measuring equipment. Input signal levels were set at -20 dBu.
The anechoic chamber error in the free field response is lessThe anechoic chamber error in the free field response is less
The anechoic chamber error in the free field response is lessThe anechoic chamber error in the free field response is less
The anechoic chamber error in the free field response is less
than 0.5 dB down to 60 Hz.than 0.5 dB down to 60 Hz.
than 0.5 dB down to 60 Hz.than 0.5 dB down to 60 Hz.
than 0.5 dB down to 60 Hz.
Figure 5. The curves above left show the effect of the 'bass tilt',
'bass level' and 'bass roll-off' controls on the free field response. The
curves to the right show the effect of the treble and midrange 'level'
controls.
Figure 6. The upper curve group shows the horizontal directivity
characteristics of 1032A in its vertical configuration measured at 1m.
The lower curve is a 1/3 octave band power response, measured in
an IEC approved reverberation chamber.
SYSTEMSYSTEM
SYSTEMSYSTEM
SYSTEM
SPECIFICATIONSSPECIFICATIONS
SPECIFICATIONSSPECIFICATIONS
SPECIFICATIONS
AMPLIFIERAMPLIFIER
AMPLIFIERAMPLIFIER
AMPLIFIER
SECTIONSECTION
SECTIONSECTION
SECTION
CROSSOVERCROSSOVER
CROSSOVERCROSSOVER
CROSSOVER
SECTIONSECTION
SECTIONSECTION
SECTION
Genelec document DR32001
COPYRIGHT GENELEC OY 6/1999
All data subject to change without prior notice
Lower cut-off frequency, -3 dB: <40 Hz
Upper cut-off frequency, -3 dB: >22 kHz
Free field frequency response
of system: 42 Hz - 21 kHz (±2.5 dB)
Maximum short term sine wave acoustic
output on axis in half space, averaged from
100 Hz to 3 kHz: @1m >113 dB SPL
@0.5m >119 dB SPL
Maximum long term RMS acoustic output in
same conditions with IEC-weighted noise
(limited by driver unit protection circuit):
@1m >103 dB SPL
@0.5m >109 dB SPL
Maximum peak acoustic output per pair on
top of console, @ 1m from the engineer
with music material: >124 dB SPL
Self generated noise level in free field @ 1m
on axis: <10 dB
(A-weighted)
Harmonic distortion at 95 dB SPL at 1m on
axis:
50Hz...100 Hz <1%
freq. >100 Hz <0.5%
Drivers: Bass 10" (250 mm)
Treble 1" (25 mm) metal dome
Both drivers are magnetically shielded.
Weight: 21,7 kg (48 Ib.)
Dimensions: Height 495 mm (19 1/2")
Width 320 mm (12 5/8")
Depth 290 mm (11 7/16")
Bass amplifier output power with a 4 Ohm
load: Short term 180 W
Treble amplifier output power with a 8
Ohm load: Short term 120 W
Long term output power is limited by
driver unit protection circuitry.
Slew rate : 80V/µs
Amplifier system distortion at
nominal output: THD <0.05%
SMPTE-IM <0.05%
CCIF-IM <0.05%
DIM 100 <0.05%
Signal to Noise ratio, referred to full output:
Bass >100 dB
Treble >100 dB
Mains voltage: 100/200V or 115/230V
Voltage operating range at 115V setting:
104 - 126V (±10%)
Power consumption:
Idle 50W
Full output 200W
Genelec Inc, 7 Tech CircleGenelec Inc, 7 Tech Circle
Genelec Inc, 7 Tech CircleGenelec Inc, 7 Tech Circle
Genelec Inc, 7 Tech Circle
Natick, MA 01760, USANatick, MA 01760, USA
Natick, MA 01760, USANatick, MA 01760, USA
Natick, MA 01760, USA
Phone:Phone:
Phone:Phone:
Phone: +1+1
+1+1
+1 --
--
-508/652-0900508/652-0900
508/652-0900508/652-0900
508/652-0900
Fax:Fax:
Fax:Fax:
Fax: +1+1
+1+1
+1 --
--
-508/652-0909508/652-0909
508/652-0909508/652-0909
508/652-0909
E-mail:E-mail:
E-mail:E-mail:
E-mail: [email protected][email protected]
[email protected][email protected]
[email protected]
Input connector: XLR female pin1 gnd
pin2 +
pin3 -
Input impedance: 10 kOhm
Input level for 100 dB SPL output @1m:
variable from +6 to -6 dBu
Input level for maximum short term output
of 113 dB SPL @1m:
variable from +19 to +7 dBu
Subsonic filter below 40 Hz :
18 dB/octave
Ultrasonic filter above 25 kHz:
12 dB/octave
Crossover frequency: 1.8 kHz
Crossover acoustical slopes:
24 - 32 dB/octave
Treble tilt control operating range in 2dB
steps: from+2 to -4dB & MUTE
Bass roll-off control in 2 dB steps:
from 0 to -8 dB @40 Hz
Bass tilt control in 2 dB steps:
from 0 to -8 dB @80 Hz
The 'CAL' position is with all tone controls
set to 'off' and input sensitivity control to
maximum.
