Owner’s Manual
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
Questions? Help is just a moment away!
Call: Generac Generator Helpline - 1-800-270-1408 M-F 8-5 CT
Web: www.generac-portables.com or www.briggsandstratton.com
Model No. 1658-0 (5,000 Watt AC Generator) Manual No. 189633GS Revision 1 (08/23/2001)
Safety Rules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Know Your Generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Product Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Schematic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Replacement Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Last Page
Table of Contents
• Generator
• Engine oil
• Owner's manual
• Engine manual
*If any parts are missing or damaged, call 1-800-270-1408.
Parts Included*

2
5,000 Watt Portable Generator
EQUIPMENT
DESCRIPTION
This generator is an engine-driven, revolving field, alternating
current (AC) generator. It was designed to supply electrical
power for operating compatible electrical lighting, appliance,
tool and motor loads.
This manual contains information for a generator that
operates 120 and/or 240Volt AC, single phase, 60Hz devices
that require up to 5,000 watts (5.0 kW) of power that pull
up to 41.7 Amps at 120Volts or 20.8 Amps at 240Volts.
CAUTION! Do Not exceed the generator’s
wattage/amperage capacity.Add up the rated watts of all
devices you will connect to generator receptacles at one
time.This total should not be greater than 5,000 watts for
this generator. Review “Don’t Overload the Generator” on
page 8.
The generator’s revolving field is driven at about 3,600 rpm
by a single-cylinder engine.
Every effort has been made to ensure that information in
this manual is accurate and current. However, Generac
reserves the right to change, alter or otherwise improve the
product and this document at any time without prior
notice.
CAUTION! Do Not tamper with engine
governed speed. High operating speeds are
dangerous and increase risk of personal injury or
damage to equipment.The generator supplies
correct rated frequency and voltage only when
running at proper governed speed. Incorrect
frequency and/or voltage can damage some
connected electrical loads. Operating at excessively
low speeds imposes a heavy load.When adequate
engine power is not available engine life may be
shortened.
The Emission Control System for this generator is
warranted for standards set by the Environmental
Protection Agency. For warranty information refer to the
engine owner’s manual.
SAFETY RULES
This generator set was designed and manufactured for
specific applications. Do Not attempt to modify the unit or
use it for any application it was not designed for. If you have
any questions about your generator’s application, ask your
dealer or consult the factory.
The manufacturer could not possibly anticipate every
circumstance that might involve a hazard. For that reason
warnings in the manual and warnings on tags or decals
affixed to the unit are not all–inclusive. If you intend to
handle, operate or service the unit by a procedure or
method not specifically recommended by the manufacturer,
first make sure that such a procedure or method will not
render this equipment unsafe or pose a threat to you and
others.
Read this manual carefully and become familiar
with your generator set. Know its applications, its
limitations and any hazards involved.
WARNING! You must isolate the generator
from the electric utility using approved transfer
equipment if this unit is used for backup power.
Failure to isolate the generator from the
power utility may result in injury or death to
electric utility workers and damage to the
generator due to a backfeed of electrical energy.
Whenever unit is providing backup power, the
electric utility must be notified.
DANGER! Generator exhaust gases contain
DEADLY carbon monoxide gas. If breathed in
sufficient concentrations, carbon monoxide
can cause unconsciousness or death. Operate
this equipment outdoors where adequate ventilation
is available.
The engine exhaust from this product contains
chemicals known to the State of California
to cause cancer, birth defects,
or other reproductive harm.
WARNING:

5,000 Watt Portable Generator
3
• The generator produces a very powerful voltage that can
cause serious injury or death by electrocution. Never
touch bare wires or receptacles. Never permit a child or
any unqualified person to operate the generator.
•Never handle any kind of electrical cord or device while
standing in water, while barefoot or while hands or feet
are wet. Death or serious injury from electrocution may
result.
• Use a ground fault circuit interrupter (GFCI) in any damp
or highly conductive area (such as metal decking or steel
work).
•Never use worn, bare, frayed or otherwise damaged
electrical cords with the generator. Death, serious injury
and property damage from electrical shock may result.
•Gasoline is highly FLAMMABLE and its vapors are
EXPLOSIVE. Never allow smoking, open flames,
sparks or heat in the vicinity while handling
gasoline. Avoid spilling gasoline on a hot engine. Comply
with all laws regulating storage and handling of gasoline.
•Do Not overfill the fuel tank.Always allow room for fuel
expansion. If tank is overfilled, fuel can overflow
onto a hot engine and cause a FIRE or an
EXPLOSION.
•Never store a generator with fuel in the tank where
gasoline vapors might reach an open flame, spark or pilot
light (as on a furnace, water heater, clothes dryer). FIRE
or an EXPLOSION may result.
• The unit requires an adequate flow of cooling air for its
continued proper operation. Never operate the unit
inside any room or enclosure where the free flow of
cooling air into and out of the unit might be obstructed.
Allow at least 2 feet of clearance on all sides of generator,
even while operating unit outdoors, or you could damage
the unit.
•Never start, or stop the unit with electrical loads
connected to receptacles with the connected devices
turned ON. Start the engine and let it stabilize before
connecting any electrical loads. Disconnect all electrical
loads before shutting down the generator.
•Do Not insert any object through cooling slots of the
engine.You could damage the unit or injure yourself.
•Never operate the generator:
in rain; in any enclosed compartment; when connected
electrical devices overheat; if electrical output is lost; if
engine or generator sparks; if flame or smoke is observed
while unit is running; if unit vibrates excessively.
GROUNDING THE
GENERATOR
The National Electrical Code requires that the frame and
external electrically conductive parts of this generator be
properly connected to an approved earth ground. Local
electrical codes may also require proper grounding of the
unit. For that purpose, a GROUNDING WING NUT is
provided on the generator end (Figure 1).
Generally, connecting a No. 12 AWG (American Wire
Gauge) stranded copper wire to the grounding wing nut
and to an earth–driven copper or brass grounding rod
(electrode) provides adequate protection against electrical
shock. Be careful to keep the grounding wire attached after
connecting the stranded copper wire. However, local codes
may vary widely. Consult with a local electrician for
grounding requirements in your area.
Properly grounding the generator helps prevent electrical
shock if a ground fault condition exists in the generator or
in connected electrical devices. Proper grounding also helps
dissipate static electricity, which often builds up in
ungrounded devices.
Figure 1 — Grounding Wing Nut
Grounding Wing Nut

4
5,000 Watt Portable Generator
Your generator is ready for use after it has been properly
serviced with the recommended oil and fuel.
If you have any problems with the generator, please
call the generator helpline at 1-800-270-1408.
IMPORTANT: Any attempt to run the unit before it has
been serviced with the recommended oil will result in an
engine failure.
REMOVE GENERATOR
FROM CARTON
• Set the carton on a rigid flat surface with “This Side Up”
arrows pointing upward.
• Carefully open the top flaps of the shipping carton.
• Cut down corners at one end of carton from top to
bottom and lay that side of carton down flat.
• Remove all packing material, carton fillers, etc.
• Remove the generator from the shipping carton.
CARTON CONTENTS
Check all contents. If any parts are missing or damaged, call
the generator helpline at 1-800-270-1408.
• The generator
• Generator and engine owner’s manuals
• Engine oil
BEFORE STARTING THE
ENGINE
Add Oil
CAUTION! Any attempt to crank or start the engine
before it has been properly filled with the recommended
oil may result in an engine failure.
To fill your engine with oil:
• Place generator on a level surface.
• Follow the oil grade recommendations and oil fill
instructions given in the engine owner’s manual.
NOTE: The generator’s revolving field rides on a
prelubricated and sealed ball bearing that requires no
additional lubrication for the life of the bearing.
Add Gasoline
WARNING! Never fill fuel tank indoors. Never
fill fuel tank when engine is running or hot.Allow
unit to cool for two minutes before refueling. Do
Not light a cigarette or smoke when filling the fuel
tank.
WARNING! Do Not overfill the fuel tank.
Always allow room for fuel expansion.
• Use regular UNLEADED gasoline with the generator
engine. Do Not use premium gasoline. Do Not mix oil
with gasoline.
• Clean area around fuel fill cap, remove cap.
• Slowly add unleaded regular gasoline to fuel tank. Be
careful not to overfill.Allow about 1.5" of tank space for
fuel expansion (Figure 2).
• Install fuel cap and wipe up any spilled gasoline.
IMPORTANT: It is important to prevent gum deposits
from forming in essential fuel system parts, such as the
carburetor, fuel filter, fuel hose or tank during storage.Also,
experience indicates that alcohol–blended fuels (called
gasohol, ethanol or methanol) can attract moisture, which
leads to separation and formation of acids during storage.
Acidic fuel can damage the fuel system of an engine while in
storage.
To avoid engine problems, the fuel system should be
emptied before storage of 30 days or longer. See “Storage”
on page 9. Never use engine or carburetor cleaner
products in the fuel tank or permanent damage may occur.
Figure 2 — Typical Fuel Expansion Space
Fuel
Tank
1.5” Air Space

5,000 Watt Portable Generator
5
120 Volt AC, 20 Amp, Duplex Receptacle — May be
used to supply electrical power for the operation of
120 Volt AC, 20 Amp, single phase, 60 Hz electrical lighting,
appliance, tool and motor loads.
120/240 Volt AC, 20 Amp Locking Receptacle — May
be used to supply electrical power for the operation of
120 and/or 240 Volt AC, 20 Amp, single phase, 60 Hz
electrical lighting, appliance, tool and motor loads.
Air Cleaner — Uses a dry type filter element and foam
pre–cleaner to limit the amount of dirt and dust sucked
into the engine.
Choke Lever — Used when starting a cold engine.
Circuit Breakers (AC) — Each receptacle is provided
with a "push to reset" circuit breaker to protect the
generator against electrical overload.
Fuel Tank — Capacity of five (5) U.S. gallons.
Grounding Wing Nut — Used for proper grounding of
unit.
Oil Fill Cap — Add oil to engine here.
Recoil starter — Used to start the engine.
Rocker Switch — Set this switch to "On" before using
recoil starter. Set switch to "Off" to switch off engine.
KNOWYOUR GENERATOR
Read this owner’s manual and safety rules before operating your generator.
Compare the illustrations with your generator, to familiarize yourself with the locations of various controls and
adjustments. Save this manual for future reference.
120 Volt AC, 20 Amp
Duplex Receptacle
Fuel Tank
Choke Lever
Recoil Starter
Rocker Switch
Circuit
Breakers
(AC)
120/240 Volt AC,
20 Amp Receptacle
Air Cleaner
Grounding
Wing Nut
(not shown)
Oil Fill Cap
(not shown)

6
5,000 Watt Portable Generator
OPERATING THE
GENERATOR
CAUTION! Never start or stop the engine with
electrical loads connected to the receptacles AND
with the connected devices turned ON.
Starting the Engine
Disconnect all electrical loads from the generator. Use the
following start instruction steps by numerical order:
1. Turn the fuel valve to the “On” position (Figure 3).
2. Place the choke lever in the “Choke” position
(Figure 4).
3. Set the rocker switch to “On” position (Figure 5).
4. Grasp the recoil handle and pull slowly until slight
resistance is felt.Then pull rapidly to start engine.
5. Move choke lever to “Run” position a short distance at
a time over several seconds in warm weather or
minutes in cold weather. Let engine run smoothly before
each change. Operate with choke in “Run” position.
NOTE: If engine still fails to start after 3 pulls, check for
proper oil level in crankcase.This unit is equipped with a
low oil device which prevents the engine from being
started. See engine manual.
Refer to the engine owner’s manual for complete
starting instructions.
Connecting Electrical Loads
• Let engine stabilize and warm up for a few minutes after
starting.
• Plug in and turn on the desired 120 and/or 240 Volt AC,
single phase, 60 Hz electrical loads.
•Do Not connect 240 Volt loads to the 120 Volt duplex
receptacles.
•Do Not connect 3–phase loads to the generator.
•Do Not connect 50 Hz loads to the generator.
•DO NOT OVERLOAD THE GENERATOR. See
“Don’t Overload the Generator” on page 8.
Stopping the Engine
• Unplug all electrical loads from generator panel
receptacles. Never start or stop engine with electrical
devices plugged in and turned ON.
• Let engine run at no-load for several minutes to stabilize
the internal temperatures of engine and generator.
• Move rocker switch to “Off” position.
• Move the fuel valve to the “Off” position.
Fuel Valve is shown
in the On position
Figure 3 — FuelValve
Figure 4 — Choke Lever
Figure 5 — Rocker Switch

5,000 Watt Portable Generator
7
RECEPTACLES
This generator is equipped with the following receptacles:
120 Volt AC, 20 Amp Receptacle
This outlet is protected against overload by 20 Amp push-
to-reset circuit breakers.
Use each socket to operate 120 Volt AC, single phase,
60 Hz electrical loads requiring up to 2,400 watts (2.4kW)
of power at 20 Amps (Figure 6). Use cord sets that are
rated 125 Volts at 20 Amps (or greater).
120/240 Volt AC, 20 Amp Locking
Receptacle
Use a NEMA L14-20 plug with this receptacle. Connect a
4-wire cord set rated for 250 Volts AC at 20 Amps (or
greater).You can use the same 4-wire cord if you plan only
to run a 120 Volt load (Figure 7).
This receptacle powers 120Volt AC, single phase, 60Hz
loads requiring up to 2,400 watts of power (2.4 kW). Or it
will operate 240 Volt AC, single phase, 60Hz loads up to
4,800 watts (4.8 kW).This outlet is protected by 20 Amp
push-to-reset circuit breakers.
Figure 6 — 120Volt, 20 Amp Duplex Receptacle Figure 7 — 120/240 Volt AC, 20 Amp Receptacle
4-Wire Cord Set
240V
120V 120V
W (Neutral)
X (Hot)
Y (Hot)
NEMA L14-20 Ground (Green)

8
5,000 Watt Portable Generator
DON'T OVERLOADYOUR
GENERATOR
Capacity
You must make sure your generator can supply enough
rated (running) and surge (starting) watts for the items you
will power at the same time. Follow these simple steps:
1. Select the items you will power at the same time.
2. Total the rated (running) watts of these items.This is
the amount of power your generator must produce to
keep your items running. See Figure 8.
3. Estimate how many surge (starting) watts you will
need. Surge wattage is the short burst of power
needed to start electric motor-driven tools or
appliances such as a circular saw or refrigerator.
Because not all motors start at the same time, total
surge watts can be estimated by adding only the
item(s) with the highest additional surge watts to the
total rated watts from step 2.
Example:
Total Rated (Running) Watts = 3075
Highest Additional Surge Watts = 1800
Total Generator Output Required = 4875
Power Management
To prolong the life of your generator and attached devices,
it is important to take care when adding electrical loads to
your generator.There should be nothing connected to the
generator outlets before starting it's engine.The correct
and safe way to manage generator power is to sequentially
add loads as follows:
1. With nothing connected to the generator, start the
engine as described in this manual.
2. Plug in and turn on the first load, preferably the largest
load you have.
3. Permit the generator output to stabilize (engine runs
smoothly and attached device operates properly.
4. Plug in and turn on the next load.
5. Again, permit the generator to stabilize.
6. Repeat steps 4 and 5 for each additional load.
Never add more loads than the generator capacity.Take
special care to consider surge loads in generator capacity,
as described above.
*Wattages listed are approximate only. Check tool or
appliance for actual wattage.
Tool or Appliance Rated (Running)
Watts Additional Surge (Starting) Watts
Window Air
Conditioner 1200 1800
Refrigerator 800 1600
Deep Freezer 500 500
Television 500 -
Light (75 Watts) 75 -
3075 Total
Running Watts 1800 Highest Surge Watts
Tool or Appliance Rated* (Running)
Watts
Additional
Surge
(Starting)
Watts
Essentials
Light Bulb - 75 watt 75 -
Deep Freezer 500 500
Sump Pump 800 1200
Refrigerator/Freezer - 18 Cu. Ft. 800 1600
Water Well Pump - 1/3 HP 1000 2000
Heating/Cooling
Window AC - 10,000 BTU 1200 1800
Window Fan 300 600
Furnace Fan Blower - 1/2 HP 800 1300
Kitchen
Microwave Oven - 1000 Watt 1000 -
Coffee Maker 1500 -
Electric Stove - Single Element 1500 -
Hot Plate 2500 -
Family Room
DVD/CD Player 100 -
VCR 100 -
Stereo Receiver 450 -
Color Television - 27” 500 -
Personal Computer w/17” monitor 800 -
Other
Security System 180 -
AM/FM Clock Radio 300 -
Garage Door Opener - 1/2 HP 480 520
Electric Water Heater - 40 Gallon 4000 -
DIY/Job Site
Quartz Halogen Work Light 1000 -
Airless Sprayer - 1/3 HP 600 1200
Reciprocating Saw 960 960
Electric Drill - 1/2 HP 1000 1000
Circular Saw - 7 1/4” 1500 1500
Miter Saw - 10” 1800 1800
Planer/Jointer - 6” 1800 1800
Table Saw/Radial Arm Saw - 10” 2000 2000
Air Compressor - 1-1/2 HP 2500 2500
Figure 8 - Wattage Reference Chart

5,000 Watt Portable Generator
9
SPECIFICATIONS
Maximum Surge Watts . . . . . . . . . . . . . . . . .6,250 watts
Continuous Wattage Capacity . . . . . . . . . . .5,000 watts
Power Factor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.0
Rated Maximum Continuous AC Load Current:
At 120 Volts . . . . . . . . . . . . . . . . . . . . . . .41.7 Amps
At 240 Volts . . . . . . . . . . . . . . . . . . . . . . .20.8 Amps
Phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1–phase
Rated Frequency . . . . . . . . . . . . . . . . . . . . . . .60 Hertz
Fuel Tank Capacity . . . . . . . . . . . . . . . . . . . 5 U.S. gallons
Shipping Weight . . . . . . . . . . . . . . . . . . . . . . . . . 158 lbs.
GENERAL MAINTENANCE
RECOMMENDATIONS
The Owner/Operator is responsible for making sure that
all periodic maintenance tasks are completed on a timely
basis; that all discrepancies are corrected; and that the unit
is kept clean and properly stored. Never operate a
damaged or defective generator.
Engine Maintenance
See engine owner’s manual for instructions.
CAUTION! Avoid prolonged or repeated skin
contact with used motor oil. Used motor oil has
been shown to cause skin cancer in certain
laboratory animals.Thoroughly wash exposed areas
with soap and water.
KEEP OUT OF REACH OF CHILDREN. DON'T
POLLUTE. CONSERVE RESOURCES. RETURN
USED OIL TO COLLECTION CENTERS.
Generator Maintenance
Generator maintenance consists of keeping the unit clean
and dry. Operate and store the unit in a clean dry
environment where it will not be exposed to excessive
dust, dirt, moisture or any corrosive vapors. Cooling air
slots in the generator must not become clogged with snow,
leaves or any other foreign material.
NOTE: Do Not use a garden hose to clean generator.
Water can enter engine fuel system and cause problems. In
addition, if water enters generator through cooling air slots,
some of the water will be retained in voids and cracks of
the rotor and stator winding insulation.Water and dirt
buildup on the generator internal windings will eventually
decrease the insulation resistance of these windings.
To Clean the Generator
• Use a damp cloth to wipe exterior surfaces clean.
• A soft bristle brush may be used to loosen caked on dirt
or oil.
• A vacuum cleaner may be used to pick up loose dirt and
debris.
• Low pressure air (not to exceed 25 psi) may be used to
blow away dirt. Inspect cooling air slots and opening on
generator.These openings must be kept clean and
unobstructed.
STORAGE
The generator should be started at least once every seven
days and allowed to run at least 30 minutes. If this cannot
be done and you must store the unit for more than
30 days, use the following guidelines to prepare it for
storage.
Generator Storage
• Clean the generator as outlined in “To Clean the
Generator.”
• Check that cooling air slots and openings on generator
are open and unobstructed.
CAUTION! Storage covers can be flammable. Do
Not place a storage cover over a hot generator. Let
the unit cool for a sufficient time before placing the
cover on the unit.
Engine Storage
See engine owner’s manual for instructions.
Other Storage Tips
•Do Not store gasoline from one season to another.
• Replace fuel container if it starts to rust. Rust and/or dirt
in fuel can cause problems if it's used with this unit.
• Store in clean and dry area.

10
5,000 Watt Portable Generator
TROUBLESHOOTING
Problem
Cause
Solution
Engine is running, but
no AC output is
available.
1. Circuit breaker is open.
2. Poor connection or defective cord set.
3. Connected device is bad.
4. Fault in generator.
1. Reset circuit breaker.
2. Check and repair.
3. Connect another device that is in good
condition.
4. Contact Generac service facility.
Engine runs good but
bogs down when
loads are connected.
1. Short circuit in a connected load.
2. Generator is overloaded.
3. Engine speed is too slow.
4. Shorted generator circuit.
1. Disconnect shorted electrical load.
2. See “Don’t Overload the Generator” on
page 8.
3. Contact Briggs and Stratton service
facility.
4. Contact Generac service facility.
Engine will not start;
or starts and runs
rough.
1. Rocker switch set to “Off”.
2. Dirty air cleaner.
3. Out of gasoline.
4. Stale gasoline.
5. Spark plug wire not connected to
spark plug.
6. Bad spark plug.
7. Water in gasoline.
8. Overchoking.
9. Low oil level.
10. Excessively rich fuel mixture.
11. Intake valve stuck open or closed.
12. Engine has lost compression.
1. Set switch to “On”.
2. Clean or replace air cleaner.
3. Fill fuel tank.
4. Drain gas tank and fill with fresh fuel.
5. Connect wire to spark plug.
6. Replace spark plug.
7. Drain gas tank; fill with fresh fuel.
8. Set choke to “Off” position.
9. Fill crankcase to proper level.
10. Contact Briggs and Stratton service
facility.
11. Contact Briggs and Stratton service
facility.
12. Contact Briggs and Stratton service
facility.
Engine shuts down
during operation.
1. Out of gasoline.
2. Fault in engine.
1. Fill fuel tank.
2. Contact Briggs and Stratton service
facility.
Engine lacks power.
1. Load is too high.
2. Dirty air filter.
3. Engine needs to be serviced.
1. See “Don’t Overload the Generator” on
page 8.
2. Replace air filter.
3. Contact Briggs and Stratton service
facility.
Engine “hunts” or
falters.
1. Choke is opened too soon.
2. Carburetor is running too rich or too
lean.
1. Move choke to halfway position until
engine runs smoothly.
2. Contact Briggs and Stratton service
facility.

5,000 Watt Portable Generator
11
NOTES

12
5,000 Watt Portable Generator
SCHEMATIC

5,000 Watt Portable Generator
13
WIRING DIAGRAM

14
5,000 Watt Portable Generator
EXPLODED VIEW – MAIN UNIT

Item Part # Qty Description
1 B189553GS 1 CRADLE
2 67989GS 8 NUT, M8 Flange Serrated
3 189626GS 2 SPACER
4 84346GS 2 PPHMS, M8 -1.25 x 35 mm
5 70642GS 2 MOUNT,Vibration 45 Deg.
6 96796GS 1 WASHER, 22.2 OD X 8.4 ID x 3
7 BB4260GS 1 DISK, Engine Air
8 86307GS 2 HHCS, 5/16 x 3/4, SEMS
9 189750GS 1 ADAPTER, Engine/Alt, Sincro
10 189749GS 1 FAN, Sincro
11 189825GS 1 HHCS, 5/16 - 24 x 7 1/2"
12 189757GS 1 BEARING, Ball
13 A1816GS 1 ASSEMBLY, Diode/Varistor
14 189751GS 1 ROTOR, Sincro
15 23762GS 1 WASHER, Shakeproof #10
16 39253GS 4 HHCS, M8 - 1.25 x 20
17 189752GS 1 STATOR, Sincro
18 189758GS 1 COVER, RBC Opening
19 189755GS 1 COVER, Stator
20 189754GS 1 CLIP, Capacitor
21 A1817AGS 1 CAPACITOR, 35, UF
22 189824GS 1 CAP, M8 THD
23 26850GS 4 WASHER, M6 Shakeproof
24 87680GS 1 WING NUT, M6 - 1.0
25 19553621GS 1 WIRE, Ground
26 85652GS 2 MOUNT,Vibration
27 42907GS 1 CAPSCREW, M8 - 1.25 x 16
28 27482GS 1 WASHER, 5/16" Shakeproof
29 49813GS 2 NUT, Hex M6 - 1.0
30 45757GS 1 HHCS, M6 - 1.0 x 25
31 70453GS 1 TAG, Oil Warning
32 48031CGS 2 CLAMP, Hose 1/2"
33 189867CGS 1 HOSE, 1/4" x 21" I.D. SAE-30R7
34 189878GS 1 DECAL,Air Cleaner
35 B2153GS 4 SCREW, Self Drill 12-14 x 7/8"
36 J189055GS 1 HEAT SHIELD, Muffler
37 80270GS 1 VALVE, Fuel
Item Part # Qty Description
38 56893GS 1 CRIMPTITE, #10-24 x 1/2"
39 55934GGS 1 CLAMP,Vinyl Coated
40 B4986GS 1 DECAL, Ground
41 189637GS 1 DECAL, Panel
42 20566GS 1 DECAL, 1-800
43 77395GS 4 NUT, M6 Flange Lock
44 73054GS 1 DECAL, Fuel Shut-Off
45 77816GS 1 DECAL, Caution Hot Muffler
46 189235GS 1 DECAL, Start Instruction
47 188973GS 4 GROMMET, Mounting Tank
48 189155GS 4 WASHER, Flat, 6.6 x 21.6 x 1.9
49 189286GS 4 HHCS, M6 -1.0 x 45
50 90878GS 1 CAP, Fuel
51 92982GS 1 DECAL, Danger
52 188797GS 1 TANK, Fuel, 5 Gallon (Includes
Items 37 & 53)
53 78299GS 1 BUSHING, Fuel Tank
54 75207GS 2 BREAKER, Circuit, 20 Amp
55 BB3061GS 1 OIL BOTTLE
56 189633GS 1 MANUAL, Generator
57 188826GS 1 MANUAL, Engine
58 188333GS 1 DECAL, Gas Tank Fill
59 189624GS 1 PANEL, Control, Sincro
60 75475GS 4 PPHMS, M4 - 0.7 x 10
61 B4911GS 1 CAP
62 91526GS 4 PPMS, M5 - .8 x 12
63 68867GS 1 OUTLET, 120/240V 20A Locking
64 22985GS 4 WASHER, M4 Flat
65 22264GS 4 WASHER, M4 Lock
66 51715GS 4 NUT, M4 - 0.7
67 68759GS 1 OUTLET, 120V/20A, Duplex
68 189625GS 1 HARNESS,Wire, Sincro
69 29745GS 4 HHCS, 3/8" - 16 x 1
70 49820GS 4 NUT, Nylok, M8 - 1.25
71 74908GS 1 TAPTITE, M5 - 0.8 x 10
900 NSP 1 ENGINE
5,000 Watt Portable Generator
15
PARTS LIST – MAIN UNIT

LIMITED WARRANTY
FOR PORTABLE GENERATORS
GENERAC PORTABLE PRODUCTS, L.L.C.
Jefferson,Wisconsin U.S.A.
GENERAC PORTABLE PRODUCTS, LLC (hereafter referred to as the COMPANY) warrants to the original purchaser that the
components in its portable generator will be free from defects in materials or workmanship for the items and period set forth
below from the date of original purchase.This warranty does not include the gasoline engine when furnished or attached because
such engine is covered solely by the engine manufacturer’s warranty. Starting batteries are not warranted by the COMPANY.The
term “original purchaser” means the person for whom the generator is originally purchased.This warranty is not transferable and
applies only to portable generators driven by an overhead valve engine.
Warranty Schedule:
Consumer* Commercial*
Engine Warranted solely by the engine manufacturer
All other parts 2 years (2nd year parts only) 1 Year
With the exception of European Community Countries, all units bound for export shall be warranted for One (1)Year in
Consumer applications, and 90 days in Commercial applications as defined below.
*NOTE: For the purpose of this warranty "consumer use" means personal residential household use by original
purchaser.This warranty does not apply to units used for prime power in place of utility. "Commercial Use" means
all other uses, including rental, construction, commercial and income producing purposes. Once a generator has
experienced commercial use, it shall thereafter be considered a commercial use generator for the purposes of this
warranty.
During the warranty period, the COMPANY will, at is option, repair or replace any part which, upon examination by the
COMPANY, is found to be defective under normal use and service**.All transportation costs under warranty, including return to
the factory if necessary, are to be borne by the purchaser and prepaid by the purchaser.This warranty does not cover normal
maintenance and service and does not apply to a generator set, alternator, or parts which have been subjected to improper or
unauthorized installation or alteration, misuse, negligence, accident, overloading, overspeeding, improper maintenance, repair or
storage so as, in the COMPANY’s judgement, to adversely affect its performance and reliability.
**NORMAL WEAR: As with all mechanical devices, the generator needs periodic parts service and replacement to
perform well.This warranty will not cover repair when normal wear has exhausted the life of a part or generator.
THERE IS NO OTHER EXPRESS WARRANTY.THE COMPANY HEREBY DISCLAIMS ANY AND ALL IMPLIED
WARRANTIES, INCLUDING BUT NOT LIMITED TO THOSE OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE TO THE EXTENT PERMITTED BY LAW.THE DURATION OF ANY IMPLIEDWARRANTIES
WHICH CANNOT BE DISCLAIMED IS LIMITED TO THE TIME PERIOD AS SPECIFIED IN THE EXPRESS
WARRANTY. LIABILITY FOR CONSEQUENTIAL, INCIDENTAL OR SPECIAL DAMAGES UNDER ANY AND ALL
WARRANTIES IS EXCLUDED. THE COMPANY ALSO DISCLAIMS ANY RESPONSIBILITY FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SUCH AS THE LOSS OF TIME OR THE USE OFTHE POWER EQUIPMENT, OR ANY
COMMERCIAL LOSS DUE TO THE FAILURE OF THE EQUIPMENT:AND ANY IMPLIED WARRANTIES ARE
LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or
consequential damages, so the above limitations or exclusions may not apply to you.This warranty gives you specific legal rights and
you may also have other rights, which vary from state to state.
For service, see your nearest COMPANY authorized warranty service facility or call 1-877-544-0982. Or look on the internet at
www.generac-portables.com.Warranty service can be performed only by a COMPANY authorized service facility.This warranty will
not apply to service at any other facility.At the time of requesting warranty service, evidence of original purchase date must be
presented.
