Owner’s Manual
For
Stationary Diesel Generators
Residential and Commercial
Protector™Series
This manual should remain with the unit.
This manual must be used in conjunction
with the appropriate installation manual.
*NOT INTENDED FOR USE IN CRITICAL
LIFE SUPPORT APPLICATIONS.
*ONLY QUALIFIED ELECTRICIANS OR
CONTRACTORS SHOULD ATTEMPT
INSTALLATION!
*DEADLY EXHAUST FUMES! OUTDOOR
INSTALLATION ONLY!
Model
RD015 - 15 kW 60 Hz
RD020 - 20 kW 60 Hz
RD030 - 30 kW 60 Hz
RD048 - 48 kW 60 Hz (Single Phase Only)
RD050 - 50 kW 60 Hz (Three Phase Only)
0066781 - 30 kW 60 Hz

ii Owner’s Manual for Stationary Diesel Generators
Use this page to record important information about
the generator set.
For quick and easy reference, copy the information
printed on the Unit Identification Label onto the sample
label printed here. The Unit Identification Label is
located at the rear of the alternator on 15/20 kW (2.3L)
units, and on the front engine mount on 30 kW (2.4L)
and 50 kW (3.4L) models. The label provides the follow-
ing information:
•Model Number
•Serial Number
•Rated KW
•Voltage Rating
•Maximum Current Rating (AMPS)
When contacting an Authorized Service Dealer about
parts and/or service, always provide the complete model
number and serial number.
Operation and Maintenance: Proper maintenance and
care of the generator ensures safe operation and longer
service life while also keeping operating expenses to a
minimum. It is the operator’s responsibility to perform all
safety checks, to make sure that all maintenance is per-
formed promptly, and to have the equipment checked
periodically by an Authorized Service Dealer.
Normal maintenance, service and replacement of parts
are the responsibility of the owner/operator, and are not
considered defects in materials or workmanship within
the terms of the warranty. Individual operating habits
and usage may contribute to the need for additional
maintenance or service.
When the generator requires servicing or repairs, con-
tact an Authorized Service Dealer for assistance. Autho-
rized service technicians are factory-trained and are
capable of handling all service needs.
AUTHORIZED
SERVICE DEALER LOCATION
To locate the nearest
AUTHORIZED SERVICE DEALER,
please call this number:
1-800-333-1322
or visit the dealer locator at:
www.generac.com/Service/DealerLocator/
SAMPLE LABEL

Table of Contents
Owner’s Manual for Stationary Diesel Generators iii
Section 1 Safety
1.1 Introduction .......................................................................................................................... 1
1.2 Safety Information ................................................................................................................ 2
1.3 General Hazards ................................................................................................................... 2
1.4 Exhaust Hazards .................................................................................................................. 3
1.5 Electrical Hazards ................................................................................................................ 3
1.6 Fire Hazards .......................................................................................................................... 3
1.7 Explosion Hazards ............................................................................................................... 3
Section 2 Specifications
2.1 Emission Information .......................................................................................................... 5
2.1.1 Emissions Data Plate ....................................................................................................................5
2.2 Specifications ....................................................................................................................... 6
2.2.1 Engine ...........................................................................................................................................6
2.3 Engine Oil Recommendations ............................................................................................ 7
2.4 Coolant Water Treatment ....................................................................................................7
2.5 Fuel Requirements ............................................................................................................... 7
2.5.1 Fuel Maintenance .........................................................................................................................8
2.5.2 Fuel Maintenance .........................................................................................................................8
2.6 Battery Requirements .......................................................................................................... 8
2.6.1 Battery Charger ............................................................................................................................8
2.7 Corrosion Protection ........................................................................................................... 8
2.8 Accessories .......................................................................................................................... 8
Section 3 Activation and Startup
3.1 Orientation .......................................................................................................................... 11
3.2 Remove Side Access Panels ............................................................................................ 11
3.3 Prime Fuel System ............................................................................................................. 12
3.4 Install Battery ..................................................................................................................... 12
3.5 Open Viewing Window ....................................................................................................... 13
3.6 Start and Run Engine ......................................................................................................... 13
3.7 Activate Unit ...................................................................................................................... 14
3.8 Operational Checks ........................................................................................................... 15
3.8.1 Self Test ......................................................................................................................................15
3.8.2 Check Manual Transfer Switch Operation ..................................................................................15
Table of Contents

Table of Contents
iv Owner’s Manual for Stationary Diesel Generators
3.8.3 Electrical Checks ........................................................................................................................ 16
3.8.4 Test Generator Under Load ........................................................................................................ 16
3.8.5 Check Automatic Operation ........................................................................................................ 17
3.9 Final Instructions ................................................................................................................17
Section 4 Operation
4.1 Control Panel ......................................................................................................................19
4.2 Auto/Manual/Off ..................................................................................................................19
4.3 Menu Navigation .................................................................................................................20
4.4 Alarm/Warning Conditions ................................................................................................22
4.5 Change Time and Date .......................................................................................................22
4.6 Programmable Timers ........................................................................................................22
4.6.1 Dealer Programmable ................................................................................................................ 22
4.6.1.1 Exercise Time ..................................................................................................................... 22
4.6.2 User Programmable ................................................................................................................... 23
4.6.2.1 Start-Up Delay Timer .......................................................................................................... 23
4.6.2.2 Warm-Up Delay Timer ........................................................................................................ 23
4.7 USB Port for Firmware Updates ........................................................................................23
4.8 Battery Charger ..................................................................................................................23
4.9 Transfer Switch Automatic Operation ..............................................................................23
4.9.1 Automatic Sequence of Operation .............................................................................................. 24
4.9.1.1 Utility Failure ....................................................................................................................... 24
4.9.1.2 Cranking.............................................................................................................................. 24
4.9.1.3 Load Transfer...................................................................................................................... 24
4.10 Transfer Switch Manual Operation .................................................................................24
4.10.1 Transfer to Generator Power .................................................................................................... 25
4.10.2 Transfer Back to Utility Power .................................................................................................. 25
Section 5 Maintenance
5.1 Component Locations ........................................................................................................27
5.2 Access Panels ....................................................................................................................29
5.2.1 Removal ..................................................................................................................................... 29
5.2.2 Installation .................................................................................................................................. 29
5.3 Service Maintenance Intervals ..........................................................................................30
5.4 Remove From Service ........................................................................................................31
5.5 30 Hour Break-In .................................................................................................................31

Table of Contents
Owner’s Manual for Stationary Diesel Generators v
5.6 Daily Maintenance (If Running Continuously) ................................................................. 31
5.7 Schedule A Maintenance ................................................................................................... 32
5.7.1 Preliminary Instructions ..............................................................................................................32
5.7.2 Check Fuel Level and Fill ...........................................................................................................32
5.7.3 Drain Fuel Filter and Check Fuel Lines/Hoses ...........................................................................32
5.7.4 Check Coolant Level and Hoses ................................................................................................33
5.7.5 Check Radiator for Clogging .......................................................................................................34
5.7.6 Check Lubricating Oil Level ........................................................................................................34
5.7.7 Check Battery Condition/Fluid Level ...........................................................................................35
5.7.7.1 Check Condition and Clean ................................................................................................ 35
5.7.7.2 Check Fluid Level ............................................................................................................... 35
5.7.7.3 Check State of Charge........................................................................................................ 35
5.7.7.4 Battery Replacement .......................................................................................................... 35
5.7.8 Check and Adjust V-Belt .............................................................................................................37
5.7.8.1 Check.................................................................................................................................. 37
5.7.8.2 Adjust .................................................................................................................................. 38
5.7.9 Replace Air Filter Element ..........................................................................................................38
5.7.10 Drain Breather Canister and Replace Filter ..............................................................................38
5.7.11 Lubricate Governor Rod Linkage ..............................................................................................39
5.7.12 Final Instructions .......................................................................................................................39
5.8 Schedule B Maintenance ................................................................................................... 40
5.8.1 Replace Lubricating Oil and Oil Filter .........................................................................................40
5.8.2 Replace Fuel Filter ......................................................................................................................41
5.8.2.1 Prime Fuel System.............................................................................................................. 41
5.8.3 Drain/Flush Coolant System .......................................................................................................41
5.8.4 Final Instructions .........................................................................................................................42
5.9 Schedule C Maintenance ................................................................................................... 43
5.10 Return To Service ............................................................................................................ 43
Section 6 Troubleshooting
6.1 Engine Troubleshooting .................................................................................................... 45
6.2 Controller Troubleshooting ............................................................................................... 46
6.3 Removal From Service During Utility Outages ............................................................... 47
6.4 Storage ................................................................................................................................ 47
6.4.1 Prepare For Storage ...................................................................................................................47
6.4.2 Return From Storage ..................................................................................................................48
6.5 Attention After Submersion .............................................................................................. 49
6.6 Attention After Fuel Spillage ............................................................................................. 49
6.7 Contaminated Fuel Disposal ............................................................................................. 49

Table of Contents
vi Owner’s Manual for Stationary Diesel Generators
(000005)
WARNING
California Proposition 65. This product contains or
emits chemicals known to the state of California to
cause cancer, birth defects, and other reproductive
harm.
(000004)
WARNING
California Proposition 65. Engine exhaust and some of
its constituents are known to the state of California to
cause cancer, birth defects, and other reproductive
harm.

Owner’s Manual for Stationary Diesel Generators 1
Section 1 Safety
1.1 — Introduction
Thank you for purchasing this stationary automatic standby generator set. Every effort was made to ensure that the
information in this manual was both accurate and complete at the time it was released. However, the manufacturer
reserves the right to change, alter or otherwise improve this product at any time without prior notice.
This generator is designed to automatically supply electrical power to operate critical loads during a utility power failure.
The unit is factory installed in an all-weather metal enclosure and is intended exclusively for outdoor installation
using only diesel fuel.
When properly sized, the generator is suitable for supplying typical residential/commercial loads, such as induction
motors (sump pumps, refrigerators, freezers, air conditioners, furnaces, etc.), electronic components (computers, mon-
itors, televisions, etc.), lighting, microwaves, and other residential and business loads.
READ THIS MANUAL THOROUGHLY: The operator is responsible for proper and safe use of this equipment. Read
and thoroughly understand the contents of this manual before attempting to use the equipment. If any portion of this
manual is not fully understood, contact the nearest Authorized Service Dealer for assistance.
SAVE THESE INSTRUCTIONS: The manufacturer suggests that this manual and the rules for safe operation be cop-
ied and posted near the generator installation site. Safety should be stressed to all operators and potential operators of
this equipment.
SAFETY: Throughout this manual, and on tags and decals affixed to the unit, DANGER, WARNING, CAUTION and
NOTE blocks are used to alert personnel to special instructions about a particular operation, function or service that
may be hazardous if performed incorrectly or carelessly. Observe them carefully. Their definitions are as follows:
INDICATES A HAZARDOUS SITUATION OR ACTION WHICH, IF NOT AVOIDED, WILL RESULT IN DEATH OR SERIOUS
INJURY.
Indicates a hazardous situation or action which, if not avoided, could result in death or serious injury.
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
NOTE: Notes contain additional information important to an operation or procedure.
Four commonly used safety symbols accompany the DANGER, WARNING and CAUTION blocks. The type of informa-
tion each indicates is as follows:
This symbol points out important Safety Information that, if not followed, could endanger personal safety and/or
property of others.
This symbol points out a potential Explosion Hazard.
This symbol points out a potential Fire Hazard.
This symbol points out a potential Electrical Shock Hazard.
These “Safety Alerts” cannot eliminate the hazards that they signal. Strict compliance with these special instructions,
plus common sense, are major accident prevention measures.
*
!
+
$

Safety
2Owner’s Manual for Stationary Diesel Generators
1.2 — Safety Information
Study these safety rules carefully before operating or servicing this equipment. Become familiar with this Owner’s Man-
ual and with the unit. The generator can operate safely, efficiently and reliably only if it is properly installed, operated
and maintained. Many accidents are caused by failing to follow simple rules or precautions.
The manufacturer cannot anticipate every possible circumstance that might involve a hazard. The warnings in this
manual, and on tags and decals affixed to the unit are not all-inclusive. If using a procedure, work method or operating
technique the manufacturer does not specifically recommend, ensure that it is safe for personnel. Also make sure the
procedure, work method or operating technique used does not render the generator unsafe.
Despite the safe design of this generator, operating this equipment imprudently, neglecting its mainte-
nance or being careless can cause possible injury or death. Permit only responsible and capable per-
sons to install, operate and maintain this equipment.
Potentially lethal voltages are generated by these machines. Ensure steps are taken to make the
machine safe before attempting to work on the generator.
Parts of the generator are rotating and/or hot during operation. Exercise care near a running generator.
The installation of this generator must always comply with applicable codes, standards, laws and regu-
lations.
A running generator gives off DEADLY carbon monoxide, an odorless, colorless, poisonous gas.
Breathing carbon monoxide can cause dizziness, throbbing temples, nausea, muscular twitching, head-
ache, vomiting, weakness, sleepiness, inability to think clearly, fainting, unconsciousness or even
death.
The control panel for this unit is intended to be operated by qualified service personnel only.
1.3 — General Hazards
•For safety reasons, this equipment should only be installed, serviced and repaired by a Service Dealer or other
competent, qualified electrician or installation technician who is familiar with applicable codes, standards, regula-
tions and product Installation Manual guidelines. The operator also must comply with all such codes, standards,
regulations and product Installation Manual guidelines.
•The engine exhaust fumes contain carbon monoxide, which can be DEADLY. This dangerous gas, if breathed in
sufficient concentrations, can cause unconsciousness or even death. DO NOT alter or add to the exhaust system
or do anything that might render the system unsafe or in noncompliance with applicable codes and standards.
•Install a carbon monoxide alarm indoors, according to manufacturer’s instructions/recommendations.
•Adequate, unobstructed flow of cooling and ventilating air is critical for correct generator operation. Do not alter
the installation or permit even partial blockage of ventilation provisions, as this can seriously affect safe operation
of the generator. The generator MUST be installed and operated outdoors only.
•Keep hands, feet, clothing, etc. away from drive belts, fans, and other moving or hot parts. Never remove any
drive belt or fan guard while the unit is operating.
•When working on this equipment, remain alert at all times. Never work on the equipment when physically or men-
tally fatigued.
•Inspect the generator regularly, and contact the nearest Dealer for parts needing repair or replacement.
•Before performing any maintenance on the generator, remove the control panel fuse and disconnect the Nega-
tive (-) battery cable to prevent accidental startup. When disconnecting battery cables always remove the NEGA-
TIVE (-) cable first. When reconnecting the cables, connect the POSITIVE (+) cable first.
•Never use the generator or any of its parts as a step. Stepping on the unit can stress and break parts, and may
result in dangerous operating conditions from leaking exhaust gases, fuel leakage, oil leakage, etc.
*
*
*
*
*
*

Safety
Owner’s Manual for Stationary Diesel Generators 3
1.4 — Exhaust Hazards
•Generator engine exhaust contains DEADLY carbon monoxide, an odorless, colorless, poisonous gas. Breathing
carbon monoxide can cause dizziness, throbbing temples, nausea, muscular twitching, headache, vomiting,
weakness, sleepiness, inability to think clearly, fainting, unconsciousness or even death. If any carbon monoxide
poisoning symptom is experienced, move into fresh air and immediately seek medical attention.
•This generator is designed for OUTDOOR installation ONLY. Never operate the generator inside any garage or
other enclosed space.
1.5 — Electrical Hazards
•All generators covered by this manual produce dangerous electrical voltages that can cause fatal electrical
shock. Utility power delivers extremely high and dangerous voltages to the transfer switch, as does the standby
generator when it is in operation. Avoid contact with bare wires, terminals, connections, etc. while the unit is run-
ning. Ensure all appropriate covers, guards and barriers are in place, secured and/or locked before operating the
generator. If work must be done around an operating unit, stand on an insulated, dry surface to reduce potential
shock hazard.
•Do not handle any kind of electrical device while standing in water, while barefoot, or while hands or feet are wet.
DANGEROUS ELECTRICAL SHOCK MAY RESULT.
•The generator may crank and start at any time when utility power is lost. When this occurs, load circuits are
transferred to the STANDBY (generator) power source. Before working on the generator, always move the Main
Circuit Breaker switch on the control panel down to the OFF (Open) position, press the OFF key on the control
panel keypad, remove the 7.5 amp fuse, and disconnect the battery negative cable (black) from the battery neg-
ative (-) terminal.
•In case of accident caused by electric shock, immediately shut down the source of electrical power. If this is not
possible, attempt to free the victim from the live conductor. AVOID DIRECT CONTACT WITH THE VICTIM. Use
a nonconducting implement, such as a dry rope or board, to free the victim from the live conductor. If the victim is
unconscious, apply first aid and get immediate medical help.
•Never wear jewelry when working on this equipment. Jewelry can conduct electricity resulting in electric shock,
or may get caught in moving parts resulting in injury.
1.6 — Fire Hazards
•For fire safety, the generator must be installed and maintained properly. Installation MUST always comply with
applicable codes, standards, laws, regulations and product Installation Manual guidelines. Adhere strictly to
local, state, and national electrical and building codes. Comply with regulations of the Occupational Safety and
Health Administration (OSHA). Also, ensure that the generator is installed in accordance with the manufacturer’s
instructions and recommendations. Following proper installation, do nothing that might alter a safe installation
and render the unit in noncompliance with the aforementioned codes, standards, laws and regulations.
•Keep a fire extinguisher near the generator at all times. Extinguishers rated “ABC” by the National Fire Protection
Association are appropriate for use on the standby generator. Keep the extinguisher properly charged and be
familiar with its use. Consult the local fire department with any questions pertaining to fire extinguishers.
1.7 — Explosion Hazards
•Do not smoke around the generator. Wipe up any fuel or oil spills immediately. Ensure that no combustible mate-
rials are left in the generator compartment, or on or near the generator as FIRE or EXPLOSION may result. Keep
the area surrounding the generator clean and free from debris.
If this generator is used to power electrical load circuits normally powered by a utility power source,
it is required by code to install a transfer switch. The transfer switch must effectively isolate the elec-
trical system from the utility distribution system when the generator is operating (NEC 702). Failure to
isolate an electrical system by such means will result in damage to the generator and also may result
in injury or death to utility power workers due to backfeed of electrical energy.
+

Safety
4Owner’s Manual for Stationary Diesel Generators
This page intentionally left blank.

Owner’s Manual for Stationary Diesel Generators 5
Section 2 Specifications
2.1 — Emission Information
The U.S. Environmental Protection Agency (EPA) requires that the generator comply with exhaust emission standards.
The generator is certified to meet the applicable EPA emission levels, and is certified for use as a stationary engine for
standby power generation. Any other use may be a violation of federal and/or local laws. To ensure that the engine
complies with the applicable emission standards for the duration of the engine’s life, it is important to follow the mainte-
nance specifications in Section 5. This generator is certified to operate on Diesel Fuel No. 2 (KSM2610).
2.1.1— Emissions Data Plate
A data plate is riveted to the cylinder head cover to verify compliance with EPA emissions regulations.
Figure 2-1. Emissions Data Plate (Sample)
Cylinder Head Cover

Specifications
6Owner’s Manual for Stationary Diesel Generators
2.2 — Specifications
2.2.1— Engine
A complete specification sheet is included in the documentation provided with the unit at the time of purchase. For
additional copies, consult your local Authorized Service Dealer.
General 2.3L Engine 2.4L-49 Engine 3.4L Engine
Engine System
Type 4 cylinder, in-line, 4 cycle 4 cylinder, in-line, 4 cycle 4 cylinder, in-line, 4 cycle
Fuel Type Ultra Low Sulfur Diesel Ultra Low Sulfur Diesel Ultra Low Sulfur Diesel
Fuel Filtering 5 Microns 5 Microns 10 Microns
Bore and Stroke 3.46 in x 3.70 in
(88 mm x 94 mm)
3.54 in x 3.70 in
(90 mm x 94 mm)
3.86 in x 4.45 in
(98 mm x 113 mm)
Displacement 139.5 cubic inches (2.286 liter) 146 cubic inches (2.392 liter) 208.3 cubic inches (3.41 liter)
Firing Order 1-3-4-2 1-3-4-2 1-3-4-2
Direction or Rotation CCW - As Viewed From Flywheel CCW - As Viewed From Flywheel CCW - As Viewed From Flywheel
Dimensions L x W x H 685 x 491 x 636 mm
(26.97 in x 19.33 in x 25.04 in)
677.1 x 497.8 x 721.3 mm
(26.66 in x 19.60 in x 28.40 in)
742 x 587 x 721 mm
(29.21 in x 23.11 in x 28.39 in)
Dry Weight 441 lbs (200 kgs) 573 lbs (260 kgs) 551 lbs (250 kgs)
Compression Ratio 21.3 : 1 21.3 : 1 18.5 : 1
Cooling System
Water Pump Pre-Lubed, Self-Sealing Pre-Lubed, Self-Sealing Pre-Lubed, Self-Sealing
Drive Belt Belt Belt
Thermostat Full Open Temperature:
185° F (85° C)
Full Open Temperature:
185° F (85° C)
Full Open Temperature:
185° F (85° C)
System Coolant Capacity 2.8 gal (10.6 liter) 2.8 gal (10.6 liter) 2.8 gal (10.6 liter)
Coolant Flow Rate 10 gal (38 liter)/min at 1800 RPM 10 gal (38 liter)/min at 1800 RPM 12.2 gal (46 liter)/min at 1800 RPM
Lubricating System
Oil Pump Type Gear Gear Gear
Oil Filter Type Full Flow Spin-On Canister Full Flow Spin-On Canister Full Flow Spin-On Canister
Oil Cooler Not Applicable Installed Installed
Crankcase Capacity 6.87 qt. (6.5 liter) 6.8 qt. (6.4 liter) 7.4 qt. (7.0 liter)
Lubricating Oil 15W-40 15W-40 15W-40
Oil Fill Location Filler Cap on Valve Cover and/or
Front Engine Cover
Filler Cap on Valve Cover and/or
Front Engine Cover
Filler Cap on Valve Cover and/or
Front Engine Cover
Oil Drain Location Oil Pan, Bottom Side Oil Pan, Bottom Side Oil Pan, Front
Intake and Exhaust System
Intake Air System Naturally Aspirated Turbocharged Turbocharged/Aftercooled
Maximum Allowable
Intake Restriction 25 in. of Water (6.23 kPa) 25 in. of Water (6.23 kPa) 25 in. of Water (6.23 kPa)
Maximum Allowable
Exhaust Back Pressure 23.6 in. of Water (5.88 kPa) 23.6 in. of Water (5.88 kPa) 24 in of Water (5.98 kPa)
Breather Closed Crankcase System Open Crankcase System Open Crankcase System
Other Specifications
Operating Temperature Range -20° F to 120° F (-29° C to 49° C) -20° F to 120° F (-29° C to 49° C) -20° F to 120° F (-29° C to 49° C)
POWER ADJUSTMENT FOR AMBIENT CONDITIONS
Temperature Deration........................................................................................3% for every 5 °C above 25 °C or 1.7% for every 5 °F above 77 °F
Altitude Deration (15, 30, 48 & 50 kW) ...................................................... 1% for every 100 m above 915 m or 3% for every 1000 ft above 3000 ft
Altitude Deration (20 kW) ......................................................................... 1% for every 100 m above 305 m or 3% for every 1000 ft above 1000 ft

Specifications
Owner’s Manual for Stationary Diesel Generators 7
2.3 — Engine Oil Recommendations
To maintain the product warranty, use only genuine Generac replacement parts. Generac maintenance kits include
both the oil filter and air filter, and can be obtained through any Authorized Dealer.
All Generac maintenance kits meet minimum American Petroleum Institute (API) Service Class CD or better. Select the
appropriate viscosity oil grade according to the expected operating temperature. After break-in, synthetic oil also can
be used in the appropriate weight as standard. Once synthetic oil is used, it should be used for the life of the generator.
It is not recommended to go back to a mineral oil. Do not use special additives.
Figure 2-2. Lubricating Oil Recommendations
2.4 — Coolant Water Treatment
Use of improper coolants can damage the engine cooling system. Use demineralized water or distilled water for best
results. Hard water causes scale deposits, which reduces cooling efficiency and raises internal temperatures, possibly
leading to engine damage. Use an anti-corrosive to prevent rot in summer and anti-freeze to prevent freezing in winter.
Dilute the anti-freeze based on a theoretical temperature that is 9-18°F (5-10°C) below the lowest temperature
expected in the area. A ratio of 40-60% is most common range.
NOTE: Use only Peak Fleet-Charge® 50/50 ethylene glycol type coolant (available from any authorized
dealer).
Do not use propylene glycol type coolant. Using the wrong coolant, mixing different types of coolant,
or even mixing different brands of the correct type of coolant, can produce unsatisfactory results, pos-
sibly leading to engine damage.
2.5 — Fuel Requirements
IMPORTANT! DO NOT use Home Heating Oil or Bio-Diesel Fuel.
Use No. 2D diesel fuel when temperatures are above freezing. When temperatures are below freezing, blend No.1D
diesel fuel and No. 2D diesel fuel together for a climate adjusted fuel ratio.
Starting October 1, 2010, diesel fuel must also meet the following requirements:
•Sulfur content of 15 parts per million (ppm) maximum.
•Minimum Cetane index of 40.
Freezing Point °F (°C) -13 (-25) -31 (-35) -58 (-50)
Coolant (% Volume) 40 50 60
Water (% Volume) 60 50 40
- 20
- 4
15W-40
10W-30
5W-30
- 40
- 40
- 30
- 22 - 10 14 0 32 10
50 20 68 30 86 40 104 50 122
- 20
- 4
- 40
- 40
- 30
- 22 - 10 14 0 32 10 50 20 68 30 86 40 104 50 122
All Seasons
Winter Conditions
Arctic Conditions
º C
º F
º C
º F
*

Specifications
8Owner’s Manual for Stationary Diesel Generators
NOTE: Low ambient temperatures as well as engine operation at high altitudes may require the use of fuels
with higher Cetane ratings.
Allow at least 5 percent of the tank capacity for fuel expansion. DO NOT OVERFILL!
2.5.1— Fuel Maintenance
Always treat diesel fuel for long term storage. Use the approved fuel additive and water abatement material. Test
stored fuel every 90 days and provide additional treatment if required. Periodically check and dry abatement material
as necessary.
2.5.2— Fuel Maintenance
Always treat diesel fuel for long term storage. Use the approved fuel additive and water abatement material. Test
stored fuel every 90 days and provide additional treatment if required. Periodically check and dry abatement material
as necessary.
2.6 — Battery Requirements
2.6.1— Battery Charger
The battery charger is integrated into the control panel module. It operates as a “Smart Charger” which ensures output
charging levels are safe and continuously optimized to promote maximum battery life.
2.7 — Corrosion Protection
Periodically wash and wax the enclosure using automotive type products. Frequent washing is recommended in salt
water/coastal areas.
2.8 — Accessories
The following product accessories are available. Contact a Dealer for additional information.
Group 27F, 12 Volt 2.3L Engine: For areas where temperatures regularly drop below 32° F (0° C).
NOTE: Battery dimensions (L x W x H) for Group 27F battery must not exceed 12-1/2" x 6-13/16" x 8-15/16"
(318 mm x 173 mm x 227 mm).
Group 31, 12 Volt 2.4L-49 Engine: For areas where temperatures regularly drop below 32° F (0° C).
NOTE: Battery dimensions (L x W x H) for Group 31 battery must not exceed 13" x 6-13/16" x 9-7/16"
(330 mm x 173 mm x 240 mm).
1. Scheduled Maintenance Kit (Part No. 006572-0; 15/20 kW) 8. Emergency Stop Switch (Part No. 006510-0)
2. Scheduled Maintenance Kit (Part No. 006571-0; 30 kW) 9. Touch-Up Paint Kit (Part No. 005704-0)
3. Scheduled Maintenance Kit (Part No. 006570-0; 50 kW) 10. Five Gallon Spill Box (Part No. 006502-0)
4. Cold Weather Kit (Part No. 006560-0: 15/20 kW; Part No.
006559-0: 30 kW; Part No. 006558-0: 50 kW)
11. Fuel Tank Risers (Part No. 006505-0: 15/20 kW; Part
No. 006506-0: 30/50 kW)
5. Vent Extension Support Kit (Part No. 006588-1) 12. 90% Fuel Fill Level Alarm (Part No. 006504-0)
6. Fuel Fill Drop Tube (Part No. 006507-0) 13. Spill Box Drain Back (Part No. 006511-0)
7. Lockable Fuel Fill Cap (Part No. 006512-0) 14. Stainless Steel Fuel Lines (Part No. 006513-0:15/20 kW;
Part No. 006517-0: 30 kW; Part No. 006516-0:
50 kW)

Specifications
Owner’s Manual for Stationary Diesel Generators 9
Figure 2-3. Product Accessories
1. 2.
6.
7. 8.
3.
4.
5.
9. 10.
12. 13. 14.
11.

Specifications
10 Owner’s Manual for Stationary Diesel Generators
This page intentionally left blank.

Owner’s Manual for Stationary Diesel Generators 11
Section 3 Activation and Startup
IMPORTANT NOTE: The unit fuel tank has been inspected by AHJ (authority having local jurisdiction) or fire
marshal and meets all requirements. Unit is fueled and the fuel is treated as per additive directions.
3.1 — Orientation
NOTE: The 3.4L engine is depicted in the artwork used in this manual. The location and appearance of some
components may vary between engine models.
The side of the enclosure with the viewing window is identified as the rear of the generator set. The right and left sides
are identified by standing at the rear and looking towards the front of the unit.
Figure 3-1. Enclosure (Rear Left View)
3.2 — Remove Side Access Panels
NOTE: Access panels are located at both the front and sides of the enclosure.
1. Insert key into latch and rotate counterclockwise 1/2 turn. See Figure 3-2.
2. Raise panel using thumb latch.
Figure 3-2. Access Panel Key
Viewing
Window
Fuel Priming
Pump
Battery
Key
Thumb Latch

Activation and Startup
12 Owner’s Manual for Stationary Diesel Generators
3.3 — Prime Fuel System
1. See Figure 3-3. Loosen the air bleed screw and work priming pump until bubbles are observed. Place a shop rag
around the air bleed screw to catch any loss of fuel.
2. When all bubbles are purged and replaced by a solid stream of fuel, tighten the air bleed screw.
3. Check for leaks.
Figure 3-3. Prime Fuel System
3.4 — Install Battery
CAUTION: Always connect the positive battery
cable first. If the positive cable should contact
ground with the negative cable installed, the result-
ing sparks may cause a battery explosion which
could result in serious injury.
2.4L/3.4L Models
NOTE: On 2.3L models, remove ten screws to release lou-
vered air intake panel on left side of enclosure.
1. Loosen two screws with nylon washers to release hold-
down clamp from battery tray.
2. Install battery onto tray.
3. Install two screws with nylon washers to secure hold-
down clamp to battery tray.
4. Install battery positive cable (red) to battery positive (+)
terminal.
5. Install battery negative cable (black) to battery negative
(-) terminal.
NOTE: On 2.3L models, start ten screws to install louvered
air intake panel. Alternately tighten screws to 90 in-lbs (10
N-m) using a crosswise pattern.
Priming
Pump
Air Bleed
Screw
$
Figure 3-4. Battery Cable Connections
Battery
Red Lead
From Starter
Black Lead
To Frame

Activation and Startup
Owner’s Manual for Stationary Diesel Generators 13
3.5 — Open Viewing Window
1. Rotate viewing window upward to access control panel.
2. To hold viewing window in the open position, remove rod
from clip at back of window and insert into hole in frame.
See Figure 3-5.
3.6 — Start and Run Engine
1. Pull up rubber flap covering fuse holder and verify installation of 7.5 amp fuse. See A of Figure 3-6.
2. Move the Main Circuit Breaker switch down to the OFF (Open) position. See B of Figure 3-6.
3. Press MANUAL on the control pad to start the engine. A blue LED illuminates to confirm that the system is in the
MANUAL mode. See C of Figure 3-6.
4. Allow the engine to run until it reaches normal operating temperature.
5. Press OFF on the control pad to stop the engine. A red LED illuminates to confirm that the system is in the OFF
mode.
Figure 3-6. Generator Control Panel
Figure 3-5. Viewing Window
o
OFF
PUSH TO TRIP
7.5 Amp Fuse
and USB Port
Main Circuit Breaker
C
BA
LCD Screen
Control Pad

Activation and Startup
14 Owner’s Manual for Stationary Diesel Generators
3.7 — Activate Unit
Display Reads: Generator Active is displayed on the
LCD screen when the unit is first
powered up. After displaying firmware
and hardware version codes, as well as
other system information, the Installation
Wizard is launched, and the Language
screen is displayed.
Use UP ARROW or DOWN ARROW to
scroll to desired language.
Press ENTER.
If the wrong language is selected, it may be changed
later using the Edit menu.
Display Reads: Press ENTER. Press ESCAPE to abort the activation sequence. NOT
ACTIVATED is displayed and the generator will run in
manual mode only. Disconnect and reconnect the
negative battery cable to restart the activation routine.
If power is removed after a successful activation, no
data is lost, but the time and date must be updated.
Display Reads: Go to www.activategen.com or call 1-
888-9ACTIVATE (922-8482, US & CA
only) if activation passcode is not avail-
able.
If activation pass code is available, wait a
few seconds for the next display.
Display Reads: Use UP ARROW or DOWN ARROW to
increment or decrement the digit to
correspond to the first number of the
pass code.
Press ENTER.
Repeat step to enter remaining digits.
Press ESCAPE to return to preceding digits if a
correction becomes necessary.
If attempts to enter the activation code are
unsuccessful, check the number against the code
given on activategen.com. If it is correct, contact 1-888-
9ACTIVATE (922-8482, US & CA only).
Display Reads: Use UP ARROW or DOWN ARROW to
increment or decrement the hour. Press
ENTER.
Use UP ARROW or DOWN ARROW to
increment or decrement the minute.
Press ENTER.
Use UP ARROW or DOWN ARROW to
select the month. Press ENTER.
Use UP ARROW or DOWN ARROW to
increment or decrement the date. Press
ENTER.
Use UP ARROW or DOWN ARROW to
increment or decrement the year. Press
ENTER.
Language
- English +
Up Arrow = (+)
Down Arrow = (-)
Activate me (ENT) or
ESC to run in manual
To Activate go to
www.activategen.com
SN 1234567890
PASS CODE XXXXX
Select Hour (0-23)
- 6 +
