Generalscan R3520 User manual

GS-TS-000001
How to configure
Illumination Brightness &
Aim Brightness
Model R3520 and R3521
Version 1.0
Nov - 21
Page 1 of 13

GS-TS-000001
Table of Contents
Copyright.................................................................................................................................................................................. 3
Service Information ...............................................................................................................................................................3
Revision History ...................................................................................................................................................................... 3
Product model ........................................................................................................................................................................ 4
Illumination Brightness.........................................................................................................................................................4
Overview.......................................................................................................................................................................... 4
Operation......................................................................................................................................................................... 5
Example..........................................................................................................................................................................11
Aim Brightness......................................................................................................................................................................12
Overview........................................................................................................................................................................12
Operation (Continued)..............................................................................................................................................12
Example (Continued).................................................................................................................................................13
Page 2 of 13

GS-TS-000001
Copyright
GENERALSCAN reserves the right to make changes to any product to improve
reliability, function, or design.
GENERALSCAN does not assume any product liability arising out of, or in connection
with, the application or use of any product, circuit, or application described herein.
Service Information
If there is a question with the barcode scanner, you can visit website for the live chat
at: www.generalscan.com
Revision History
Version
Date
Description
1.0
Nov-21
Initial Release
Page 3 of 13

GS-TS-000001
Product model
You can confirm the product model according to the position shown in the figure
below.
R3521
Illumination Brightness
Overview
This feature sets the brightness of the illumination by altering LED power. The default
is 10, which is maximum LED brightness. For values from 1 to 10, LED brightness
varies from lowest to highest level of brightness.
NOTES:The lower the brightness, the lower the power consumption, and the
scanning performance will also be reduced. It is recommended that you use a
brightness level above level 2.
Page 4 of 13

GS-TS-000001
Operation
Step 1. Enable the Illumination Brightness.
Step 2. Scan the Numeric Barcodes.
Level 1:Scan the following Numeric Barcodes 0-1.
Page 5 of 13

GS-TS-000001
Level 2:Scan the following Numeric Barcodes 0-2.
Level 3:Scan the following Numeric Barcodes 0-3.
Page 6 of 13

GS-TS-000001
Level 4:Scan the following Numeric Barcodes 0-4.
Level 5:Scan the following Numeric Barcodes 0-5.
Page 7 of 13

GS-TS-000001
Level 6:Scan the following Numeric Barcodes 0-6.
Level 7:Scan the following Numeric Barcodes 0-7.
Page 8 of 13

GS-TS-000001
Level 8:Scan the following Numeric Barcodes 0-8.
Level 9:Scan the following Numeric Barcodes 0-9.
Page 9 of 13

GS-TS-000001
*Level 10:Scan the following Numeric Barcodes 1-0.
Page 10 of 13

GS-TS-000001
Example
To set the Illumination Brightness for level 5.
Step 1. Enable the Illumination Brightness.
Step 2. Scan the Numeric Barcodes.
Level 5:Scan the following Numeric Barcodes 0-5.
Page 11 of 13

GS-TS-000001
Aim Brightness
Overview
This feature sets the brightness, or power of the aim pattern. There are three settings:
low, medium, and high. The default is high.
NOTES:The weaker the aim brightness, the lower the power consumption. When the
aim brightness is set to low, you can hardly find the aiming light, which may affect your
use. We recommend that you set the aim brightness to medium or high mode.
Operation (Continued)
To program the Aim Brightness, scan one of the following barcodes.
Page 12 of 13

GS-TS-000001
Example (Continued)
To set the Aim Brightness for Medium, scan the following barcode.
Page 13 of 13
