1.00 Operating Procedures
1.01 Opening Instructions
1. Remove the console covers; visually check the consoles for any damage.
2. Turn the Power Supply on and check that the red lights are illuminated on
each playing position.
Note!
The power supply must always be turned on before the batteries are
connected to the models.
3. Check the charge meters on the battery chargers. The needle should be
between 0 & 1 when the battery is fully charged.
4. Remove the batteries from the chargers and insert the spare batteries if
they are not fully charged.
5. With the boat near to the operating area and keeping the boat propellers
clear of any obstructions, carefully slide the battery into the boat. The
propellers will rotate briefly.
6. Attach the boat top and lock it into position. Ensure it is the correct number
for the receiver.
7. Carefully place the boat on the water inside the operating area.
Caution! Place the boat on the water. Never launch or throw the boat
onto the water, as this will cause the hull to fracture around the battery
holder.
8. Repeat operations 5 to 7 for each model.
9. Coin and test each playing position in turn to ensure the console and boat
operate correctly.
The unit is now ready for use.
1.02 Closing Instructions
1. Trigger the playing position and drive the boat to the edge of the area
and remove it from the water.
2. Place the boat on the stand supplied, remove the top and slide the
battery out of the hull.
3. Inspect the propellers for damage or debris around the shaft.
4. Using polish and a cloth thoroughly clean the outside of the hull and
top.
5. Place the boat vertically with the bows up in its storage position
Caution!
It is vital that the boat is stored vertically with the bows up to ensure
that any water in the hull and water in the outer propeller shafts drains
out of the rear. Storing the boat in any other position will allow water to
enter the motors leading to their premature failure.
6. Repeat operations 1 to 4 for each model.
7. Turn off the Power Supply and check that all of the lights on the
consoles are off.
8. Open the cash doors (remove the pad locks if fitted) and remove the
cash. Note the coin counter readings.
