Genie Z Series User manual

Maintenance Manual
- Booms
S®Booms
This manual includes detailed
procedures for each
maintenance inspection.
Z®Booms
For Repair procedures, Fault
Codes, Electrical and Hydraulic
Schematics, refer to the
appropriate Service and Repair
Manual for your machine.
Refer to the inside cover for a list of models
included in this manual.
Part No. 1268489GT
Rev F
1
April 2018

Maintenance Manual April 2018
Introduction
ii S®Booms • Z®Booms Part No. 1268489GT
Intr od ucti on Intr od ucti on
Important
Read, understand and obey the safety rules and
operating instructions in the appropriate Operator's
Manual on your machine before attempting any
maintenance procedure.
This manual provides detailed scheduled
maintenance information for the machine owner
and user.
Basic mechanical, hydraulic and electrical skills are
required to perform most procedures. However,
several procedures require specialized skills, tools,
lifting equipment and a suitable workshop. In these
instances, we strongly recommend that
maintenance be performed at an authorized Genie
dealer service center.
Compliance
Machine Classification
Group B/Type 3 as defined by ISO 16368
Machine Design Life
Unrestricted with proper operation, inspection and
scheduled maintenance.
Technical Publications
Genie has endeavored to deliver the highest
degree of accuracy possible. However, continuous
improvement of our products is a Genie policy.
Therefore, product specifications are subject to
change without notice.
Readers are encouraged to notify Genie of errors
and send in suggestions for improvement. All
communications will be carefully considered for
future printings of this and all other manuals.
Contact Us:
Internet: www.genielift.com
E-mail: [e-mail]
Copyright © 2015 by Terex Corporation
1268489 Rev F, December 2017
First Edition, Sixth Printing
Genie, "S" and "Z" are registered trademarks of Terex South
Dakota, Inc. in the U.S.A. and many other countries.
"TraX" and "XC" are trademarks of Terex South Dakota, Inc.

April 2018 Maintenance Manual
Introduction
Part No. 1268489GT S®Booms • Z®Booms iii
Models included in this manual
Use the following chart to identify the specific serial
number for models included in this manual.
Models
Serial number
S
-40 / S-45 from S4015-20505 to S4016H-23499
from S4515-20505 to S4516H-23499 from
S40H-23500 from S45H-23500
S
-60 / S-65
(all models)
from S6013-29296 to S6016-31260
from S6016N-31261 to S6016N-35000
from S6016H-35001 to S6016H-36399
from S6014D-101 to S6016D-639
from S6016M-101 to S6016M-399
from S60X13-26296 to S60X16H-36399
from S60XC13-26296 to S60XC16H-36399
from S60HC13-26296 to S60HC15A-29544
from S60TX13-26296 to S60TX16H-36399
from S60TX14D-101 to S60TX16D-639
from S65TX13-26296 to S65TX16H-36399
from S65TX14D-101 to S65TX16D-639
from
S60H/S60X/S60XC/S60TX/S65TXH-36400
from S60/S60TX/S60XD-640
from S60M-400
from S65TXM-101
S
-80 / S-85
from S80/85/80X15
-12264 to16H-13999
from S80/85/80X15D
-101 to 16D-339
from S80/85/80XH
-14000
from S80/85/80XD
-340
S
-80 / 85 XC
from S80/85XCH
-101
S
-100 / S-105
from S10015D
-1001 to S10016D-1549
from S10515D
-983 to S10516D-1549
S
-120 / S-125 from S12015D-1012 to S12016D-1549
from S12515D-984 to S12516D-1549
from S100/105/120/125D-1550
S
-100HD /
S
-120HD
from S100HD14D
-200 to S100HD16D-229
from
S120HD14D-201 to S120HD16D-229
from S100/S120HDD
-230
SX
-105 XC
from SX105D
-101
SX
-125 XC
from SX125D
-101
SX
-135 XC
from SX135H
-101
SX
-150
from SX15015
-100 to Sx15016H-499
from SX150H
-500
SX
-180
from SX18014
-101 to SX18016H-599
from SX180H
-600
Z
-30/20N (RJ)
from Z30N14
-15222 to Z30N16F-18899
from Z30N16D
-104 to Z30N16D-199
from Z30NF
-18900
from Z30ND
-200
Z
-33/18
from Z331815M
-101 to Z331816M-1299
from Z3318M
-1300
Z
-34/22 DC from Z3414-9686 to Z3416F-11999
Z34F-12000
Z
-34/22 N
from
Z34N14-10984 to Z34N16F-13999
from Z34N15D
-102 to Z34N16D-279
from Z34NF
-14000
from Z34ND
-280
Z
-34/22 IC
from Z3406
-4800 to Z3413-9460
from Z3413
-9461 to Z3415-10688
from Z3416F
-10689 to Z3416F-11999
from Z34F
-12000
Z
-34/22 BE
from Z3414
-9686 to Z3416F-11999
from Z34F
-12000
Z
-40/23N RJ
from Z40N13
-1902 to Z40N16N-4499
from Z40NN
-4500
Z
-45/25(J) DC
from Z452513A
-48153 to Z452516N-57199
from Z452513B
-3078 to Z452516M-6699
from Z452513D
-101 to Z452516D-939
from Z4525D
-940
from Z4525M
-6700
from Z4525N
-57200
Z
-45/25(J) IC
from Z452513A
-47001 to Z452516N-57199
from Z452514B
-3301 to Z452516M-6699
from Z452513D
-101 to Z452516D-939
from Z4525D
-940
from Z4525M
-6700
from Z4525N
-57200
Z
-45/25(J) BE
from Z452513A
-48153 to Z452516N-57199
from Z4525N
-57200
Z
-45 XC
f
rom Z4525XCM-101
Z
-51/30J
from Z513014B
-1201 to Z5130M-2000
from Z5130M
-2000
Z
-60/37 DC /
Z
-60/37 FE
from Z6016N
-101 Z6016N-599
from Z60N
-600
Z
-62/40
from Z6215A
-101 to Z6216N-2999
from Z6216D
-108 to Z6216D-149
from Z6216M
-101 to Z6216M-399
from
Z62D-150
from Z62H
-3000
from Z62M
-400
Z
-80/60
from Z8013
-4592 to Z8016H-6399
from Z80H
-6400
Z
-135/70
from Z13505
-101 to Z13513-2000
ZX
-135/70
from ZX13514
-2533 to ZX13516H-3199
(includes 2463, 2469, 2531)
from ZX135H
-3200

Maintenance Manual April 2018
Introduction
iv S®Booms • Z®Booms Part No. 1268489GT
Identifying the Correct Procedure
for your Model
Unless otherwise noted, each procedure will apply
to all models. Procedures that only apply to specific
models or options will include the information in the
procedure title.
Examples of procedures that apply to specific
models:
•Test the Engine Idle Select - Engine
Models
•Test the Turntable Level Sensor - Z-80/60
•ALC600 Models, include the following
models: S-80 XC and S-85 XC.
•ALC1000 Models, include the following
models: S-100, S-100HD, S-105, S-120,
S-120HD, S-125, SX-105 XC, SX-125 XC,
SX-135 XC, SX-150, SX-180, Z-80/60,
Z-135/70 and ZX-135/70.
Examples of procedures that apply to all models:
•Test the Drive Speed – Stowed Position
•Inspect the Tires, Wheels and Lug Nut
Torque
Find additional Manuals for your
Model
Go to http://www.genielift.com
Use the links to locate Service Manuals,
Maintenance Manuals, Service and Repair
Manuals, Parts Manuals and Operator's Manuals.

April 2018 Maintenance Manual
Introduction
Part No. 1268489GT S®Booms • Z®Booms v
Revision History
Revision Date Section Procedure / Description
A 9/2015 Initial Release
A1 10/2015 Quarterly Q-27 Test the Primary Angle Sensor
A2 11/2015 Specifications Hydraulic and Drive Hub Capacities
A3 11/2015 Introduction Updated Z-80/60 serial number for models included
A4 12/2015 Quarterly Q-17 Inspect the Calibration Decal
A5 1/2016 Specifications Performance Spec. Z62
B 3/2016 All Sections Add Z-60 DC/FE
Specifications Add Kubota D1105-E4B, GM .998L, GM 3.0L.
Update Deutz D2.9 L4 and Perkins 404F engine rpm's.
B1 4/2016 Quarterly Q-7 Check the Generator Belts, Pulleys and voltage -
Bi-Energy Models
Annual A-3 Inspect for Turntable Bearing Wear
B2 6/2016 Specifications Tires and Wheels, add Z60 DC/FE
B3 9/2016 Introduction Models Included
C 11/2016 All Sections Add SX-135 XC
C1 12/2016 Quarterly Q-26 Test the Secondary Boom Angle Sensor
D 2/2017 Quarterly Q-36 Inspect and Adjust Boom Cables
Annual A-3 Inspect Turntable Bearing Wear
A-11, A-12, A-13 Inspect Boom Cables
Programmed P12-2 Replace Boom Cables
P12-3 Remove and Inspect Boom Cables
Reference Examples:
Section – Specifications Electronic Version
Click on any content or procedure in the Table of Contents to view
the update.
Section – Maintenance, (procedure)

Maintenance Manual April 2018
Introduction
vi S®Booms • Z®Booms Part No. 1268489GT
Revision History (continued)
Revision Date Section Procedure / Description
E 3/2017 All Sections Add SX-125 XC and Z-45 XC
E1 3/2017 Programmed Remove 10 year cable inspection
F 6/2017 All Sections Add S80/85 XC, SX-105 XC
Specifications Add Deutz D436 L3i CN3 Engine
F1 4/2018 Specifications Deutz TD2011 Engine Specifications
Reference Examples:
Section – Specifications Electronic Version
Click on any content or procedure in the Table of Contents to view
the update.
Section – Maintenance, (procedure)

April 2018 Maintenance Manual
Safety Rules
Part No. 1268489GT S®Booms • Z®Booms vii
Section 1 Safet y R ul es
Danger
Failure to obey the instructions and safety rules in
this manual and the appropriate Operator's Manual
on your machine will result in death or serious
injury.
Many of the hazards identified in the operator's
manual are also safety hazards when maintenance
and repair procedures are performed.
Do Not Perform Maintenance
Unless:
You are trained and qualified to perform
maintenance on this machine.
You read, understand and obey:
•manufacturer's instructions and safety rules
•employer's safety rules and worksite
regulations
•applicable governmental regulations
You have the appropriate tools, lifting
equipment and a suitable workshop.

Maintenance Manual April 2018
Safety Rules
viii S®Booms • Z®Booms Part No. 1268489GT
Personal Safety
Any person working on or around a machine must
be aware of all known safety hazards. Personal
safety and the continued safe operation of the
machine should be your top priority.
Read each procedure thoroughly. This
manual and the decals on the machine,
use signal words to identify the following:
Safety alert symbol
—used to
alert
personnel to potential personal
injury hazards. Obey all safety
messages that follow this symbol
to avoid possible injury or death.
Indicates a imminently hazardous
situation which, if not avoided, will
result in death or serious injury.
Indica
tes a potentially hazardous
situation which, if not avoided,
could result in death or serious
injury.
Indicates a potentially hazardous
situation which, if not avoided,
may cause minor or moderate
injury.
Indicates a potentially hazardous
situation
which, if not avoided,
may result in property damage.
Be sure to wear protective eye wear and
other protective clothing if the situation
warrants it.
Be aware of potential crushing hazards
such as moving parts, free swinging or
unsecured components w
hen lifting or
placing loads. Always wear approved
steel
-toed shoes.
Workplace Safety
Any person working on or around a machine must
be aware of all known safety hazards. Personal
safety and the continued safe operation of the
machine should be your top priority.
Be sure to keep sparks, flames and
lighted tobacco away from flammable and
combustible materials like battery gases
and engine fuels. Always have an
approved fire extinguisher within easy
reach.
Be sure that all tools and working areas
are
properly maintained and ready for
use. Keep work surfaces clean and free of
debris that could get into machine
components and cause damage.
Be sure any forklift, overhead crane or
other lifting or supporting device is fully
capable of supporting and sta
bilizing the
weight to be lifted. Use only chains or
straps that are in good condition and of
ample capacity.
Be sure that fasteners intended for one
time use (i.e., cotter pins and self
-locking
nuts) are not reused. These components
may fail if they ar
e used a second time.
Be sure to properly dispose of old oil or
other fluids. Use an approved container.
Please be environmentally safe.
Be sure that your workshop or work area
is properly ventilated and well lit.

April 2018
Table of Contents
x S®Booms • Z®Booms Part No. 1268489GT
Section 3 Maintenance Procedures .................................................................................. 30
Introduction .......................................................................................................... 30
Maintenance Schedule ........................................................................................ 32
Pre-Delivery Preparation Report.......................................................................... 33
Scheduled Maintenance Inspection Report – Quarterly or Frequent .................. 34
Scheduled Maintenance Inspection Report - Annual........................................... 35
Programmed Maintenance Inspection Report - Booms....................................... 36
Commissioning Procedures ............................................................................. 37
C-1 Perform 50 Hour Service............................................................................... 37
C-2 Perform Engine Maintenance – 50 Hours..................................................... 37
C-3 Perform 150 Hour Service............................................................................. 38
Quarterly Maintenance Procedures ................................................................. 39
Q-1 Check for Open Bulletins and Owner Registration ....................................... 39
Q-2 Battery inspection ......................................................................................... 40
Q-3 Inspect the Electrical Wiring.......................................................................... 42
Q-4 Inspect the Electrical Contactor - DC / Bi-Energy Models ............................ 43
Q-5 Check the Exhaust System........................................................................... 44
Q-6 Inspect the Tires, Wheels and Lug Nut Torque ............................................ 44
Q-7 Check the Generator Belts and Pulleys, Bi-Energy Models ......................... 45
Q-8 Check the Oscillate Directional Valve Linkage (if equipped) ........................ 46
Q-9 Visual Inspection of the Hydraulic Oil ........................................................... 47
Q-10 Inspect the Hydraulic Filters........................................................................ 48
Q-11 Check and Adjust the Engine RPM ............................................................ 49
Q-12 Test the Ground Control Override .............................................................. 54
Q-13 Test the Alarm Package (if equipped) ........................................................ 55
Q-14 Test the Emergency Power System ........................................................... 56
Q-15 Test the Engine Idle Select - Engine Models.............................................. 56
Q-16 Test the Fuel Select Operation - Gasoline/LPG Models............................. 58
Q-17 Inspect the Calibration Decal - ALC1000 Models ....................................... 59
Q-18 Test the Recovery Mode System - ALC-1000 Models ............................... 60
Q-19 Test the Platform Self-leveling .................................................................... 61
Q-20 Confirm the Proper Brake Configuration..................................................... 62

April 2018
Table of Contents
Part No. 1268489GT S®Booms • Z®Booms xi
Q-21 Test the Drive Brakes..................................................................................62
Q-22 Test the Drive Speed – Stowed Position.....................................................63
Q-23 Test the Drive Speed - Raised or Extended Position..................................63
Q-24 Test the Drive Speed – Raised and Extended, ALC1000 Models ..............64
Q-25 Test the Turntable Level Sensor - Z-135/70, ZX-135/70,
SX-105 XC, SX-125 XC, SX-135 XC, SX-150 and SX-180 .........................66
Q-26 Test the Secondary Boom Angle Sensor - Z-135/70 and ZX-135/70 .........68
Q-27 Test the Primary Boom Angle Sensor - Z-135/70 and ZX-135/70 ..............70
Q-28 Test the Primary Boom Angle Sensor -
SX-105 XC, SX-125 XC, SX-135 XC, SX-150 and SX-180 .........................73
Q-29 Test the Safety Envelope Limit Switches - Z-135/70, ZX-135/70,
SX-105 XC, SX-125 XC, SX-135 XC, SX-150 and SX-180 .........................78
Q-30 Test the Primary Boom Angle Sensor - Z-80/60 .........................................82
Q-31 Test the Safety Envelope and Circuits - Z-80/60 ........................................83
Q-32 Check the Safety Envelope Limit Switches and Angle Sensor -
S-60X, S-60XC and S-80X ...........................................................................85
Q-33 Test the Safety Envelope and Circuits -
S-100, S-105, S-120 and S-125 ...................................................................87
Q-34 Test the Aircraft Protection System (if equipped)........................................93
Q-35 Test the Operator Protection Alarm (if equipped) .......................................95
Q-36 Inspect the Boom Extend/Retract Cables - All Models ...............................95
Q-37 Test the Recovery Mode System - ALC-600 Models ..................................96
Q-38 Test the Turntable Level Sensor - S-80 XC and S-85 XC ..........................97
Q-39 Test the Primary Boom Angle Sensor - S-80 XC, S-85 XC ........................99

April 2018
Table of Contents
xii S®Booms • Z®Booms Part No. 1268489GT
Annual Maintenance Procedures ................................................................... 101
A-1 Grease the Turntable Rotation Bearing and Rotate Gear........................... 101
A-2 Check the Turntable Rotation Bearing Bolts ............................................... 102
A-3 Inspect for Turntable Bearing Wear ............................................................ 103
A-4 Check the Extendable Axle - S-100, S-105, S-120 and S-125 ................... 104
A-5 Perform Maintenance-Jib Rotate Bearing ................................................. 105
A-6 Test the Bypass/Recovery Key Switch - ALC1000 Models ........................ 106
A-7 Grease the Platform Overload Mechanism (if equipped) ............................ 108
A-8 Test the Platform Overload System -
All Models, Except ALC1000 and S-60HC Models .................................... 109
A-9 Test the Platform Overload System - ALC1000 Models ............................. 111
A-10 Test the Platform Load Sense System - S-60 HC..................................... 112
A-11 Inspect the Boom Extend/Retract Cables - S-60 and S-80 Models .......... 113
A-12 Inspect the Boom Extend/Retract Cables -
S-100, S-105, S-120, S-125, SX-105 XC and SX-125 XC ........................ 115
A-13 Inspect the Boom Extend and Retract Cables -
SX-135 XC, SX-150 and SX-180 ............................................................... 117
A-14 Check the Drive Hub Oil Level and Fastener Torque ............................... 121
A-15 Test the Dual Capacity and Platform Overload System -
SX-105 XC, SX-125 XC and SX-135 XC ................................................... 123
A-16 Test the Dual Capacity and Platform Overload System -
Z-45 XC Models ......................................................................................... 125
A-17 Test the Dual Capacity and Platform Overload System -
S-80 XC and SX-85 XC.............................................................................. 126

April 2018
Table of Contents
Part No. 1268489GT S®Booms • Z®Booms xiii
Programmed Maintenance Procedures .........................................................128
P0-1 Check the Track Tension and Fastener Torque, TRAX Models -
S-60, S-65 and Z-62 Models ......................................................................128
P0-2 Check the Track Tension and Fastener Torque, TRAX Models -
S-40 and S-45 Models................................................................................129
P0-3 Grease the Extendable Axles - S-100, S-105, S-120 and S-125 ..............131
P0-4 Continental Engine Maintenance – Under 1000 Hours .............................132
P0-5 Cummins Engine Maintenance – Under 1000 Hours ................................133
P0-6 Deutz Engine Maintenance – Under 1000 Hours ......................................134
P0-7 Ford Engine Maintenance – Under 1000 Hours ........................................135
P0-8 Kubota Engine Maintenance – Under 1000 Hours ....................................136
P0-9 Perkins Engine Maintenance – Under 1000 Hours ...................................137
P0-10 GM .998L Engine Maintenance – Under 1000 Hours .............................138
P0-11 GM 3.0L Engine Maintenance – Under 1000 Hours ...............................139
P1-1 Perform Engine Maintenance – 1000 Hours .............................................140
P1-2 Replace the Drive Hub Oil .........................................................................141
P2-1 Perform Engine Maintenance – 2000 Hours .............................................144
P2-2 Test or Replace the Hydraulic Oil..............................................................146
P2-3 Replace the Hydraulic Filters.....................................................................147
P2-4 Check the Free-wheel Configuration .........................................................149
P2-5 Check the Boom Wear Pads .....................................................................151
P2-6 Check the Extendable Axle Wear Pads -
S-100, S-105, S-120, S-125, S-100HD and S-120HD ...............................154
P2-7 Check the Turntable Rotation Gear Backlash ...........................................154
P2-8 Grease the Steer Axle Wheel Bearings,
All 2WD Models, Except S-60, S-65, Z-60 DC/FE and Z-62 ......................155
P2-9 Grease the Steer Axle Wheel Bearings,
2WD Models - S-60, S-65, Z-60 DC/FE and Z-62......................................157
P3-1 Perform Engine Maintenance – 3000 Hours .............................................158
P4-1 Perform Engine Maintenance – 4000 Hours .............................................159
P5-1 Perform Engine Maintenance – 5000 Hours .............................................160
P6-1 Perform Engine Maintenance – 6000 Hours .............................................160
P12-1 Perform Engine Maintenance – 12000 Hours .........................................161
P12-2 Remove and Inspect the Boom Extend/Retract Cables ..........................161
Cable Replacement Criteria ..........................................................................164

April 2018 Maintenance Manual
Performance Specifications
Part No. 1268489GT S®Booms • Z®Booms 1
Section 2 Performance Sp eci fic ati ons
Function Speeds - S-100, S-105
and S-100HD Models
Note: Function speeds are maximum from platform
controls with maximum rated load in platform.
Primary boom up/down,
(retracted)
80 - 88 seconds
Primary boom up/down,
extended to >4 ft / >1.2 m
(time from fully stowed to the
fully raised position)
100 - 100 seconds
Primary boom up/down,
extended to >80 ft / >24.4 m
(time from 53° envelope limit to
the fully raised position)
50 - 55 seconds
Primary boom extend,
fully raised position
(0 to 100 ft / 0 to 30.5 m)
120 - 140 seconds
Primary boom retract,
fully raised position
(100 to 0 ft / 30.5 to 0 m)
120 - 140 seconds
Jib boom up/down,
(S-105 models)
28 - 32 seconds
Turntable rotate, 360°
boom horizontal and fully
retracted
170 - 190 seconds
Turntable rotate,
boom horizontal and extended
>0 ft / >0 m
63 - 70 seconds
drive enable to drive enable
Turntable rotate,
boom fully raised and extended
>80 ft / >24.4 m
109 - 120 seconds
drive enable to drive enable
Platform rotate 18 - 22 seconds
Platform level
(10° range of motion)
ANSI/CSA
AS/CE
3 - 5 seconds
20 - 22 seconds

Maintenance Manual April 2018
Performance Specifications
2 S®Booms • Z®Booms Part No. 1268489GT
Function Speeds - S-120, S-125
and S-120HD Models
Note: Function
speeds are maximum from platform
controls with maximum rated load in platform.
Primary boom up/down,
(retracted)
80 - 88 seconds
Primary boom up/down,
extended to >4 ft / >1.2 m
(time from fully stowed to the
fully raised position)
100 - 100 seconds
Primary boom up/down,
extended to >80 ft / >24.4 m
(time from 53° envelope limit to
the fully raised position)
50 - 55 seconds
Primary boom up/down,
extended to >100 ft / 30.5 m
(time from 68° envelope limit to
the fully raised position)
24 - 28 seconds
Primary boom extend,
fully raised position
(0 to 100 ft / 0 to 30.5 m)
170 - 190 seconds
Primary boom retract,
fully raised position
(100 to 0 ft / 30.5 to 0 m)
170 - 190 seconds
Jib boom up/down,
(S-125 models)
28 - 32 seconds
Turntable rotate, 360°
boom horizontal and fully
retracted
170 - 190 seconds
Turntable rotate,
boom horizontal and extended
>0 ft / >0 m
63 - 70 seconds
drive enable to drive enable
Turntable rotate,
boom fully raised and extended
>80 ft / >24.4 m
109 - 120 seconds
drive enable to drive enable
Platform rotate 18 - 22 seconds
Platform level
(10° range of motion)
ANSI/CSA
AS/CE
3 - 5 seconds
20 - 22 seconds

April 2018 Maintenance Manual
Performance Specifications
Part No. 1268489GT S®Booms • Z®Booms 3
Function Speeds - All Other Models
Note: Function speeds are maximum from platform controls with maximum rated load in platform.
Function S-40, S-45
(includes TRAX
models)
S-60, S-65, S-
60HC,
S-60X, S-60 XC
(includes TRAX
models)
S-80, S-85, S-80X
(ANSI/CSA models)
S-80, S-85
(AS/CE models)
S-80XC, S-85XC
Primary boom up 50 - 60 seconds 60 -
70 seconds
57 - 65 seconds 75 - 83 seconds 75 - 83 seconds
Primary boom down 50 - 60 seconds 60 -
70 seconds
61 - 69 seconds 75 - 83 seconds 110 - 115 seconds
Primary boom
extend
30 - 60 seconds 58 - 66 seconds 59 - 67 seconds 59 - 67 seconds 59 - 67 seconds
Primary boom
retract
15 - 35 seconds 53 - 62 seconds 57 - 65 seconds 57 - 65 seconds 57 - 65 seconds
Jib boom up 35 - 45 seconds
(S-45)
60 - 70 seconds
(S-65)
25 - 35 seconds
(S-85)
25 - 35 seconds
(S-85)
25 - 35 seconds
(S-85XC)
Jib boom down 20 - 30 seconds
(S-45)
40 - 50 seconds
(S-65)
15 - 25 seconds
(S-85)
15 - 25 seconds
(S-85)
15 -
25 seconds
(S-85XC)
Turntable rotate
stowed
70 - 100 seconds 78 - 86 seconds 90 - 103 seconds 90 - 103 seconds 95 - 103 seconds
Turntable rotate
extended
120 - 140 seconds 125 - 165 seconds 210 - 250 seconds 210 - 250 seconds 210 - 250 seconds
Raised or extended
Platform rotate 6 - 10 seconds 8 - 12 seconds 8 - 12 seconds 8 - 12 seconds 40 - 50 seconds
Platform level
(10° range of
motion)
ANSI/CSA
AS/CE
3 - 5 seconds
20 - 22 seconds
20 - 22 seconds
Function Z-30N, Z-30N RJ Z-34 BE Z-34N, Z-34
(DC models)
Z-33
Primary boom up 14 - 22 seconds 14 - 22 seconds 16 - 22 seconds 36 -
40 seconds
(retracted)
48 -
52 seconds
(extended)
Primary boom down 12 - 20 seconds 12 - 20 seconds 13 - 20 seconds 46 -
50 seconds
(retracted)
55 - 59 seconds
(extended)
Primary boom extend 15 - 19 seconds 12 -
18 seconds
11 - 15 seconds 18 - 20 seconds
Primary boom retract 10 - 14 seconds 12 - 18 seconds 13 - 17 seconds 18 -
20 seconds
Secondary boom up 11 - 18 seconds 11 - 18 seconds 15 - 22 seconds 20 - 24 seconds
Secondary boom down 7 - 15 seconds 7 - 15 seconds 11 - 18 seconds 20 - 24 seconds
Jib boom up 19 - 23 seconds 23 - 29 seconds 20 - 24 seconds X
Jib boom down 17 - 21 seconds 20 -
26 seconds
18 - 22 seconds X
Jib boom rotate 13 - 17 seconds
(Z-30N RJ)
X X X
Turntable rotate 62 - 72 seconds 62 - 72 seconds 62 - 72 seconds 62 - 65 seconds
Platform rotate 5 - 11 seconds 5 - 11 seconds 5 - 11 seconds X
Platform level
(10° range of motion)
ANSI/CSA
AS/CE
3 - 5 seconds
20 - 22 seconds
10 - 12 seconds

Maintenance Manual April 2018
Performance Specifications
4 S®Booms • Z®Booms Part No. 1268489GT
Note: Function speeds are maximum from platform controls with maximum rated load in platform.
Function Z-34 IC Z-40N, Z-40N
RJ
Z-45/25, Z-45/25J
(DC, BE models)
Z-45/25, Z-45/25J
(IC models)
Z-45 XC
Primary boom up 15 - 21 seconds 26 - 30 seconds 32 - 40 seconds 24 - 28 seconds 26 - 30 seconds
Primary boom down 13 - 19 seconds 26 - 30 seconds 26 - 30 seconds 24 - 28 seconds 26 - 30 seconds
Primary boom extend 24 - 30 seconds 18 - 22 seconds 14 - 18 seconds 18 - 22 seconds 14 - 18 seconds
Primary boom retract 14 - 20 seconds 18 - 22 seconds 17 - 21 seconds 18 - 22 seconds 14 - 18 seconds
Secondary boom up 15 - 21 seconds 32 - 36 seconds 38 - 46 seconds 24 - 28 seconds 26 - 30 seconds
Secondary boom down 11 - 17 seconds 32 - 36 seconds 38 - 46 seconds 24 - 28 seconds 26 - 30 seconds
Jib boom up 24 - 30 seconds 16 - 20 seconds 32 - 40 seconds
(Z45J)
45 - 55 seconds 40 - 44 seconds
Jib boom down 15 - 21 seconds 16 - 20 seconds 26 - 30 seconds
(Z45J)
25 - 35 seconds 24 - 28 seconds
Jib boom rotate X 16 - 20 seconds
(Z40N RJ)
X X X
Turntable rotate 62 - 72 seconds 62 - 68 seconds 95 - 125 seconds 62 - 68 seconds 67 - 73 seconds
Platform rotate 5 - 11 seconds 10 - 14 seconds 6 - 10 seconds 6 - 10 seconds 12 - 16 seconds
Platform level
(10° range of motion)
ANSI/CSA
AS/CE
3 - 5 seconds
20 - 22 seconds
Function Z-51 Z-60
(DC / FE)
Z-62
(includes TRAX
models)
Z-80
Primary boom up 36 - 40 seconds 60 - 70 seconds 60 - 65 seconds 60 - 70 seconds
(retracted)
80 - 96 seconds
(extended)
Primary boom down 36 - 40 seconds 60 - 70 seconds 65 - 70 seconds 75 - 85 seconds
(retracted)
80 - 96 seconds
(extended)
Primary boom extend 18 - 22 seconds 41 - 49 seconds 40 - 50 seconds 48 - 52 seconds
Primary boom retract 18 - 22 seconds 31 - 39 seconds 45 - 50 seconds 38 - 52 seconds
Secondary boom up 36 - 40 seconds 31 - 39 seconds 40 - 45 seconds 38 - 48 seconds
Secondary boom down 36 - 40 seconds 31 - 39 seconds 45 - 50 seconds 38 - 48 seconds
Jib boom up 45 - 55 seconds 13 - 17 seconds 68 -
73 seconds
23 - 33 seconds
Jib boom down 25 - 35 seconds 13 - 17 seconds 77 - 82 seconds 21 - 31 seconds
Turntable rotate 82 - 88 seconds 39 - 43 seconds
(stowed)
62 - 83 seconds
(extended)
120 - 125 seconds
(stowed)
240 - 245 seconds
(extended)
114 - 126 seconds
(retracted)
200 - 240 seconds
(extended)
Platform rotate 6 - 10 seconds 10 - 14 seconds 12 - 17 seconds 10 - 14 seconds
Platform level
(10° range of motion)
ANSI/CSA
AS/CE
3 - 5 seconds
20 - 22 seconds

April 2018 Maintenance Manual
Performance Specifications
Part No. 1268489GT S®Booms • Z®Booms 5
Note: Function speeds are maximum from platform controls with maximum rated load in platform.
Function Z-135 ZX-135
Primary boom up/down 88 - 105 seconds 110 - 125 seconds
Primary boom extend/retract 38 - 42 seconds 35 - 48 seconds
Secondary boom up/down 80 - 95 seconds 80 - 95 seconds
Secondary boom extend/retract 88 - 98 seconds 88 - 98 seconds
Jib boom up/down 38 - 43 seconds 38 - 43 seconds
Jib boom extend/retract 27 - 38 seconds 27 - 38 seconds
Turntable rotate stowed 88 - 92 seconds 88 - 92 seconds
Turntable rotate
(jib or primary boom extended)
160 - 180 seconds 160 - 180 seconds
Turntable rotate
(jib and primary boom extended)
280 - 350 seconds 280 - 350 seconds
Platform rotate 20 - 25 seconds 20 - 25 seconds
Platform level
(10° range of motion)
ANSI/CSA
AS/CE
3 - 5 seconds
20 - 22 seconds

Maintenance Manual April 2018
Performance Specifications
6 S®Booms • Z®Booms Part No. 1268489GT
Note: Function speeds are maximum from platform controls with maximum rated load in platform.
Function SX-105 XC SX-125 XC SX-135 XC
Primary boom
up/down, (stowed)
80 - 88 seconds / 83° 80 - 88 seconds / 83° 88 - 94 seconds / 75°
Primary boom up/down 100 - 110 seconds / 83°
string pot = 120 in / 305cm
100 - 110 seconds / 83°
string pot = 120 in / 305cm
26 - 29 seconds / 10°
string pot = 138 in / 351cm
Primary boom up/down 33 - 38 seconds / 20°
string pot = 225 in / 571cm
33 - 38 seconds / 20°
string pot = 220 in / 559cm
24 - 27 seconds / 10°
string pot = 202 in / 513cm
Primary boom up/down 40 - 45 seconds / 20°
string pot = 285 in / 724cm
40 - 45 seconds / 20°
string pot = 300 in / 762cm
34 - 37 seconds / 10°
string pot = 268 in / 681cm
Primary boom up/down 18 - 23 seconds / 5°
string pot = 345 in / 876cm
18 - 23 seconds / 5°
string pot = 345 in / 876cm
21 - 24 seconds / 5°
string pot = 357 in / 907cm
Primary boom up/down X 25 - 30 seconds / 5°
string pot= 582 in / 1478cm
X
Primary boom extend 120 - 140 seconds 170 - 190 seconds 30 - 33 seconds
0 - 100 in / 254cm
Primary boom retract 120 - 140 seconds 170 - 190 seconds 30 - 33 seconds
100 in / 254cm - 0
Jib boom up/down 28 - 32 seconds 28 - 32 seconds 60 - 65 seconds
(retracted)
122 - 130 seconds
(extended)
Jib boom
extend/retract
X X 50 - 60 seconds
Jib boom rotate X X X
Turntable rotate,
(stowed)
170 - 190 seconds 170 - 190 seconds 17 - 23 seconds
drive enable to drive enable, 30°
Turntable rotate 31 - 35 seconds
drive enable to drive enable, 30°
string pot > 80 ft / 24m
31 - 35 seconds
drive enable to drive enable, 30°
string pot = 12 in / 30.5cm
28 - 34 seconds
drive enable to drive enable. 30°
string pot = 12 in / 30.5cm
Turntable rotate 54.5 - 60 seconds
drive enable to drive enable, 30°
string pot > 256 in / 650cm
54.5 - 60 seconds
drive enable to drive enable, 30°
string pot > 256 in / 650cm
48 - 54 seconds
drive enable to drive enable, 30°
string pot = 137 in / 348cm
Platform rotate 37 - 47 seconds 37 - 47 seconds 20 - 24 seconds
Platform level
(10° range of motion)
ANSI/CSA
AS/CE
3 - 5 seconds
20 - 22 seconds

April 2018 Maintenance Manual
Performance Specifications
Part No. 1268489GT S®Booms • Z®Booms 7
Note: Function speeds are maximum from platform controls with maximum rated load in platform.
Function SX-150 SX-180
Primary boom
up/down, (stowed)
80 - 88 seconds / 82° 80 - 88 seconds / 82°
Primary boom up/down 100 - 110 seconds / 82°
string pot = 76 in / 193cm
100 - 110 seconds / 82°
string pot = 76 in / 193cm
Primary boom up/down 45 - 50 seconds / 20°
string pot = 158 in / 401cm
45 - 50 seconds / 20°
string pot = 158 in / 401cm
Primary boom up/down 71 - 80 seconds / 20°
string pot = 238 in / 605cm
71 - 80 seconds / 20°
string pot = 238 in / 605cm
Primary boom up/down 26 - 31 seconds / 5°
string pot = 370 in / 940cm
26 - 31 seconds / 5°
string pot = 370 in / 940cm
Primary boom up/down X 34 39 seconds / 5°
string pot = 596 in / 1514cm
Primary boom extend
0 - 100 in / 254cm
30 - 33 seconds 30 - 33 seconds
Primary boom retract
100 in / 254cm - 0
30 - 33 seconds 30 - 33 seconds
Jib boom up/down 58 - 62 seconds 58 - 62 seconds
Jib boom rotate 28 - 32 seconds 28 - 32 seconds
Turntable rotate
(stowed)
38 - 42 seconds
drive enable to drive enable
38 - 42 seconds
drive enable to drive enable
Turntable rotate 63 - 70 seconds
drive enable to drive enable, 80°
string pot = 36 in / 91.4cm
63 - 70 seconds
drive enable to drive enable, 80°
string pot = 36 in / 91.4
Turntable rotate 109 - 120 seconds
drive enable to drive enable, 80°
string pot = 76 in / 193cm
(above 75 ft / 22.8m)
109 - 120 seconds
drive enable to drive enable, 80°
string pot = 75 ft / 22.8m
(above 75 ft / 22.8m)
Turntable rotate 155 - 175 seconds
drive enable to drive enable, 80°
string pot = 258 in / 655cm
(above 125 ft / 38.1m)
155 - 175 seconds
drive enable to drive enable, 80°
string pot = 258 in / 655cm
(above 125 ft / 38.1m)
Platform rotate 20 - 24 seconds 20 - 24 seconds
Platform level
(10° range of motion)
ANSI/CSA
AS/CE
3 - 5 seconds
20 - 22 seconds

Maintenance Manual April 2018
Performance Specifications
8 S®Booms • Z®Booms Part No. 1268489GT
Drive Speeds
Function S-40, S-45
(includes TRAX
models)
S-60, S-65,
S-60HC, S-60X,
S-60XC
(includes TRAX
models)
S-80, S-85, S-
80X
S-80XC, S-85XC S-100, S-105,
S-120, S-125,
S-100HD, S-120HD,
SX-105 XC,
SX-125 XC
2WD models,
Stowed position
5.2 -
5.9 seconds
40 ft / 12.2 m
6.1 - 7.8 seconds
40 ft / 12.2 m
7.9 - 8.5 seconds
40 ft / 12.2 m
X X
4WD models,
Stowed position
5.2 -
5.9 seconds
40 ft / 12.2 m
8 - 10.5 sec
40 ft / 12.2 m
8 - 10.5 seconds
40 ft / 12.2 m
9 - 11 seconds
40 ft / 12.2 m
8.8 - 9.3 seconds
40 ft / 12.2 m
High flotation tires,
Stowed position
X X 11 - 13 seconds
40 ft / 12.2 m
X X
2WD or 4WD,
Raised or extended
40 - 45 seconds
40 ft / 12.2 m
40 - 45 seconds
40 ft / 12.2 m
40 - 45 seconds
40 ft / 12.2 m
55 - 60 seconds
40 ft / 12.2 m
40 - 45 seconds
40 ft / 12.2 m
2WD or 4WD,
Raised and
extended
X X X X 72.4 - 81.3 seconds
40 ft / 12.2 m
TRAX models,
Stowed position
9 - 11 seconds
40 ft / 12.2 m
10.7 - 13.6 seconds
40 ft / 12.2 m
X X X
TRAX models,
Raised or extended
40 -
45 seconds
40 ft / 12.2 m
55 -
62 seconds
40 ft / 12.2 m
X X X
Braking distance,
high range on paved
surface
3 - 4 ft
0.9 - 1.2 m
3 - 6 ft
0.9 - 1.8 m
3 -
6 ft
0.9 - 1.8 m
3 - 6 ft
0.9 - 1.8 m
4 - 6 ft
1.2 - 1.8 m
Function SX-135 XC, SX-150,
SX-180
Z-30N, Z30N RJ Z-33 Z-34N, Z34DC,
Z-34BE
2WD models,
Stowed position
X 6 - 8 seconds
40 ft / 12.2 m
8.5 - 10.5 seconds
40 ft / 12.2 m
6 - 8 seconds
40 ft / 12.2 m
4WD models,
Stowed position
SX-135XC
9 - 12seconds
SX-150, SX-180
9.8 - 11.8 seconds
40 ft / 12.2 m
X X X
2WD or 4WD,
Raised or extended
SX-135XC
67 - 70seconds
SX-150, SX-180
68 -
75.5 seconds
40 ft / 12.2 m
42 - 48 seconds
40 ft / 12.2 m
50 - 55 seconds
40 ft / 12.2 m
42 - 48 seconds
40 ft / 12.2 m
2WD or 4WD,
Raised and extended
SX-150, SX-180
275.5 - 293.3 seconds
40 ft / 12.2 m
X 190 - 195 seconds
40 ft / 12.2 m
X
Braking distance,
high range on paved surface
4 - 6 ft
1.2 - 1.8 m
2 - 4 ft
0.6 - 1.2 m
5 - 7 ft
1.5 - 2 m
2 - 4 ft
0.6 - 1.2 m
