Genie GHD102 User manual

Quick Start Guide
Please read these instructions carefully before operating the unit
and keep for further reference. All the examples and pictures used
here are for reference only. The contents of this manual are subject
to change without notice.
2 Channel AHD / CVI / TVI /
CVBS Signal Video Multiplexer
Over One Coax
GHD102

Quick Start Guide 2 Channel AHD / CVI / TVI / CVBS Signal Video Multiplexer Over One Coax
2
The Genie GHD102 uses FDM compression modulation technology on the
transmitter and allows 2 channels of CVI / AHD / TVI / CVBS camera signals to be
compressed and converted into a digital signal which is then transmitted using a
single coaxial cable.The receiver then decompresses and re-converts the signal
back into 2 separate video channels allowing you to connect to a compatible
DVR (CVI / TVI / AHD / CVBS) or video matrix. This product automatically adjusts
for transmission distances from 0–200 m. The maximum transmission distance
supported depends greatly on the quality of the coax cable being used. It supports
2 separate video signals down one coaxial cable by way of Frequency Division
Multiplexing (FMD), all data transmission are real-time and all images supported are
high definition with minimum delay.
Features
• Designed with minimum installation requirement
• 2x separate video channels down 1 coaxial cable
• Real-time images
• Simple Plug and Play operation
• Built-in static protection circuit
• Ideal for utilising existing cables already installed
• Supports coaxial video line 75–3, 75–5, RG59 etc.
• FDM technology is easy for multi-channel signal transmission in 1 coaxial cable
with minimum delay and interference
Specifications
Compatible Mode AHD / CVI / TVI / CVBS
Supported Pixels
TVI : 720p / 1080p / 3MP
AHD : 720p / 960p / 1080p
CVI : 720p / 960p / 1080p
CVBS
Interface BNC Port
Power Supply Input DC12V x2 (Not Supplied)
Transmission Distance 0–200m (Adaptive)
Operating Temperature -30°C – 50°C
Material High quality Aluminium Alloy
Dimensions 64 × 43 × 23 mm
Weight 67.5g (Each)

Quick Start Guide 2 Channel AHD / CVI / TVI / CVBS Signal Video Multiplexer Over One Coax
3
Installation Steps
Please check the following items before installation.
If anything is missing, please contact dealer.
• Install in accordance with any local regulations
• Please note that this equipment isn’t waterproof and is designed for indoor use
only
• Please use a regulated power supply voltage DC12V only
• No user serviceable parts inside
• Not suitable for up the coax pan tilt control
Dimensions
Application
64mm
43mm
Warning : Need to use a single core coax cable to ensure the transmission distance.
