Genius W POINTER Operating instructions

English
1
How to use the remote:
1. Insert two AAA batteries in the RF Wireless pointer.
2. Plug the receiver unit into any USB port.
3. Your operation system will start to setup the receiver unit automatically.
And the information below will display on your computer.
4. In the Win98/Me operation system, just follow the dialog boxes on your screen.
During the installation process, Windows may ask you to put the Win98 CD into the
CD-ROM.
5. When the installation process is completed; you can use the wireless pointer.
Notice:
1. If the pointer is not working or there is interference with another pointer:
1-1 Press the M-key and Enter (wheel) together for at least 5 seconds
(The M-key green LED will flash and change to a new ID).
1-2. Use a paper clip to press the receiver ID Change button
(Wait a moment to learn the new ID).

English
2
1-3. Push any button except the laser pointer button and M-Key
(So the receiver can learn the new ID).
2. If you changed the ID before, remove the batteries or if the pointer does not work, repeat steps 1-1 to 1-2.
3. If the pointer has interference with another pointer or any other wireless frequency, just change the direction of the
receiver. Also, we recommend you do not use the pointer with another pointer within one meter of each other.
4. Any key will not function after being pressed for 40 seconds.
5. When the receiver red button is pressed for more than 5 seconds, the receiver will return to the default setting.
Then you have do steps 1-1 to 1-2 to start the pointer.
Button Functions:
Use these buttons for the different functions in Mode-1 and 2.
Mode-1
(Standard)
Mode-2
(Multimedia)
Key Function
(Multimedia)
1 Laser
ON/Off Power
2. Line Up Vo l u m e U p
3 Drag Mute
4 Line
Down Vo l u m e D o w n
5 F5
PlayQPause / Stop
(> 3 Sec)
6 BPrevious track
7 ESC Next track
F Mouse
X-Y Mouse X-Y Mouse Cursor control
A LM LM Mouse left key
B RM RM Mouse right key
M-Ke
y
Laser
p
ointer

English
3
Notice:
1) To activate the following modes, press these buttons.
M+1 Laser ON/Off Press together for more than 3 secs
(Red LED will flash)
M+3. Change ID Push together for more than 3-5 secs
(Green LED will flash)
M+4 M+4 (ALT+Tab) Push together ALT + TAB functions
M+5 Remote Power
On/Off
Press together for more than 3 secs
(Green Led will flash)
Mode change (M Key)
Mode 1: Standard
Mode 2: Multimedia
Mode-1QMode-2 (push M key >1 sec;
then green LED on)
In mode 2, push M Key once to return
to Mode 1
2) For safety, when the laser pointer button is enabled, the M-key red
LED will flash 1 time per 2 seconds. If you stop using the laser
pointer for about 30 minutes, the laser pointer
function will disable.
3) Power: DC-3V, 2 x AAA Battery
4) The last pointer is dangerous to eyes! Do not stare into the beam,
and be sure to avoid any child using the pointer.
◎Wireless Remote Hot Keys for media player
No. Hot key Key Function 98 SE ME 2000 XP Note
1 Power key N Y N Y
2 Previous track N Y N Y
3 Next track N Y N Y
4 Play/Pause N Y N Y
5 Stop N Y N Y
6 Volume up Y Y Y Y
7 Volume down Y Y Y Y
8 Mute Y Y Y Y
CD control
keys
Y = Yes, N - No
PS: In Windows 98 SE and Win 2000, you need to update the Media player AP from the Microsoft website, then items (2-5)
work fine but the Power key will not work.
