Gentner TS612 User manual

Perfect Communication through Technology, Service, and Education.
TM
Installation & Operations Manual
Multi-Line, On-Air Telephone Sy tem
TS612

TS612 Installation and Operations Manual
Gentner Part No. 800-003-000
Jul 1999 (Rev. 3.0)
© Copyright 1999 by Gentner Communications Corporation. All rights reserved. Gentner Communications
Corporation reserves specification privileges. Information in this manual is subject to change without notice.
his equipment complies with the requirements of the EU guidelines:
89/336/EEC “Electromagnetic Compatibility”
73/23/EEC “Electrical operating material for use within specific voltage limits”
Conformity of the equipment with the above guidelines is attested by the CE mark.
98/482/EC “Single terminal connection to the public switched telephone network (PS N)”

TECHNICAL SUPPORT: 1.800.283.5936 (USA) OR 1.801.974.3760
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
What’s In This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Sales and Customer Service . . . . . . . . . . . . . . . . . . . . . . . . . .4
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Warranty Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
bout the TS612 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Off- ir Telephone Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
On- ir Telephone Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Dedicated Screening Station . . . . . . . . . . . . . . . . . . . . . . . . . .7
bout Version 2.5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Operational Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Telephone Line Requirements . . . . . . . . . . . . . . . . . . . . . . . .9
Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Equipment Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Telephone Line Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Telephone Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Line Expansion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Configuring the TS612 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Single-Studio Mixed Caller . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Single-Studio Split Caller . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Single-Studio Split-Hybrid . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Dual-Studio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Equipment Interconnections . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
udio Hookup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Record Control Hookup . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
ux I/O Hookup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Control Surface Hookup . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Calibration of Send udio . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Calibration of Caller udio . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Calibration of Hold udio . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Calibration of GC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
able of Content
T

TECHNICAL SUPPORT: 1.800.283.5936 (USA) OR 1.801.974.3760
2
Setup and Operation . . . . . . . . . . . . . . . . . . .31
Operational Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Networking Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
RS232 Standard Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Loop-Override mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Setup Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
dditional Operational Modes . . . . . . . . . . . . . . . . . . . . . . .34
Using the Control Surface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Studio Control Surface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Screener Control Surface . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Control Surface Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Screener Control Surface Buttons . . . . . . . . . . . . . . . . . . . .43
Call Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
On the Handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
On- ir . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Glossar . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Appendices . . . . . . . . . . . . . . . . . . . . . . . . . . .51
ppendix : Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
ppendix B: Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
ppendix C: Serial Communications Protocol . . . . . . . . . . . . .57
Hex Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Status Bytes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Peek/Poke, Reset, and Other Commands . . . . . . . . . . . . .65
ppendix D: Schematics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
ppendix E: Bill of Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
ppendix F: Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94
ppendix G: Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .95
FCC Part 15 Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . .95
FCC Part 68 Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . .95
IC Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
Information for CTR21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
Network Compatibility Declaration . . . . . . . . . . . . . . . . . . .97
Alphabetical Index . . . . . . . . . . . . . . . . . . . . .99

TECHNICAL SUPPORT: 1.800.283.5936 (USA) OR 1.801.974.3760
1
Congratulations on purchasing the S612 multi-line telephone system.
he S612 interfaces telephone calls to your audio equipment,
providing superior analog telephone integration into broadcast
applications. Ease of use, quick installation, and versatility have made
the S612 one of the most popular telephone interface systems in the
broadcast industry today.
he S612 features two internal digital hybrids, providing high-quality
interface to six telephone lines (expandable to 12). he dual hybrids
allow the S612 to operate as a single-studio telephone system able to
conference up to four callers simultaneously, or a two-studio system
able to conference two callers to each studio.
his manual gives instructions on installation, set up, and operation of
the S612. It also helps you resolve technical problems, should any arise.
For more information, please contact Gentner Communications. We
welcome and encourage your comments so we can continue to
improve our products and serve your needs.
Introduction
INTRODUCTION 3

TECHNICAL SUPPORT: 1.800.283.5936 (USA) OR 1.801.974.3760
INTRODUCTION • WHA ’S IN HIS MANUAL
4
he manual is divided into the following sections:
“Overview” is a basic introduction to the S612.
“Installation” explains how to install the S612 in a professional
setting. Detailed diagrams and descriptions will help you decide on
the best configuration settings for the needs of your environment.
“Setup and Operation” describes how to use the S612 on a
day-to-day basis. It also contains information on how to set up the
control surfaces.
“Glossar ” defines some of the industry-standard terminology as
well as other terms that you will find throughout this manual.
“Appendices” include additional information such as schematics,
connector pinouts, and serial communications protocol.
For additional help on how to install, set up, or operate the S612
system, please contact Gentner:
Sales and Customer Service
Telephone: [phone] (USA) or 1.801.975.7200
Fax: [phone] (USA) or 1.801.977.0087
e-mail: [e-mail]
Technical Support
Telephone: [phone] (USA) or 1.801.974.3760
Fax: [phone]
e-mail: [e-mail]
Gentner Communications Corporation
www.gentner.com
1825 Research Way, Salt Lake City, U 84119
What’s In This
Manual

TECHNICAL SUPPORT: 1.800.283.5936 (USA) OR 1.801.974.3760
INTRODUCTION • UNPACKING 5
Unpacking
Please check that the following was received with your shipment:
Gentner Communications
is not responsible for prod-
uct damage incurred during
shipment. You must make claims
directly with the carrier. Inspect
your shipment carefully for obvious
signs of damage. If the shipment
appears to be damaged, retain the
original boxes and packing material
for inspection by the carrier.
Contact your carrier immediately.
!
Direct Plug-In Power
Transformer
Part 830-003-203
25-foot Control
Surface Cable
Part 830-003-025
TS612 Control
Surface
Part 860-003-200
9
12 3
4 5 6
78
0#
AB C DE F
GH I
PR S TU V WX Y
Op er
JK L MN O
MODE AUX FLSH
REC
CONF VIP
SCRN MUTE
HOLD AIR
OFF NEXT
123456
7 8 9 10 11 12
*
TS612 Mainframe
Part 850-003-006
25-foot Telephone
Cable
Part 830-000-025
TS612 Installation and
Operations Manual
Part 800-003-000
AC Power Cord
Part 699-150-006 XLRs
One male, One female
Parts 664-600-003
and 664-500-003
TS612 Operations
Quick Reference Card
Part 800-003-003
(domestic)
International power cord provided
with international TS612
Warrant
Instructions
Please register your S612 online by visiting Gentner echnical Support
on the World Wide Web at www.gentner.com. When your product is
properly registered, Gentner Communications will be able to serve you
better should you require technical assistance. Warranty information will
also be used to notify you of upgrades, new product information, etc.

TECHNICAL SUPPORT: 1.800.283.5936 (USA) OR 1.801.974.3760
6

TECHNICAL SUPPORT: 1.800.283.5936 (USA) OR 1.801.974.3760
2
he S612 is a multi-line telephone system with a separate mainframe
and control surface. he mainframe contains two internal digital hybrids
which provide high-quality interface to six telephone lines (expandable
to 12). he dual hybrids allow the S612 to operate as a single-studio
telephone system able to conference up to four callers simultaneously,
or a two-studio system able to conference two callers to each studio.
Off-Air Telephone Use
he S612 operates off-air like a standard multi-line telephone system.
Using the control surface, outgoing and incoming calls can be placed
and answered in complete privacy, even while other calls are on hold
and on-air.
On-Air Telephone Use
Once connected, any call can be placed on-air at the touch of a button.
Special features such as Screen, Next, and VIP, enable you to make
sure that the right call goes on-air at the right time.
Dedicated Screening Station
he S612 supports a dedicated call-screening control surface. An off-
air screener takes incoming calls and places them in a screened-hold
queue. he on-air talent or producer may press any line to put it on-air.
o automatically place a call on-air from the top of the screened hold
queue the on-air talent simply presses the Next button.
Overview
About the TS612
OVERVIEW • ABOU HE S612 7

TECHNICAL SUPPORT: 1.800.283.5936 (USA) OR 1.801.974.3760
OVERVIEW • ABOU VERSION 2.5
8
Firmware version 2.5.3 introduces user-selectable capabilities including
split-caller mode, split-hybrid mode, previous-hold, two-button hold, and
two-button off, and screener air control. hese and others features will
be discussed in detail later on in the manual.
Split-Caller Mode
You can use the S612 as a single studio system and bring each of the
hybrid outputs independently to the audio console with a single feed for
both hybrids.
Split-H brid Mode
Like Split-Caller Mode, you can bring each hybrid out to the console
independently. However, you can return independent feeds for each
hybrid in Split-Hybrid Mode.
Previous-Hold
his mode places calls on hold automatically when you select another
line. You can switch between previous-hold mode and traditional line
switching (with automatic disconnect) via the control surface.
Two-Button Hold
With wo-Button Hold you can place a single call on hold when two or
more lines are conferenced together.
Two-Button Off
his mode allows you to disconnect any line by pressing the Off button
followed by the line button you wish to disconnect.
Screener Air Control
When enabled, this mode allows the screening control surface to place
calls to and from air.
About Version 2.5.3

TECHNICAL SUPPORT: 1.800.283.5936 (USA) OR 1.801.974.3760
OVERVIEW • OPERA IONAL REQUIREMEN S 9
Operational
Requirements
Telephone Line Requirements
he S612 requires analog (PO S) telephone lines or analog extension
lines from a PBX that fully emulates analog lines (loop-start plus
battery).
For the best performance, Gentner Communications recommends that
you connect directly to telephone-company provided PO S lines, rather
than PBX extensions.
o simplify S612 installation with PO S lines, request that your
telephone company provide lines with an RJ21X connector (wired
according to the pinout table on page 11). If your telephone company
provides only individual lines with RJ11C connectors, an RJ11 interface
panel may be ordered from Gentner (part number 676-550-001). If you
plan to loop through the S612 to your business-telephone system,
make sure you have the loop-extension cable prewired to prevent dis-
ruption to your business telephone service.
If you use analog extensions of your business PBX, use a separate
extension for each telephone-line input at the S612. Remember that
these lines cannot contain digitized audio or telephone-set control
signals. he S612 (handset) can transfer calls to another PBX
extension provided the PBX extension supports hook flash commands.
If you are uncertain whether the your PBX extensions are analog, a
good (although not infallible) test is to connect to an external modem or
fax machine. If the modem or fax operates correctly, the line will
probably work with the S612. o set up analog loop-start extensions for
the S612, contact your PBX system provider.
Power Requirements
he S612 mainframe will accommodate 85–240 Vac, 50–60 Hz and
uses 30 watts of power maximum, in accordance with the supplied
power module. International customers should request that the dealer
provide a molded power cord (grounded) with the appropriate plug.
he S612 control surface will accommodate 12 Vdc 500 mA, in
accordance with the supplied power module. he supplied wall adapter
operates on 117 Vac unless your dealer ordered the 220 Vac version.
Equipment Placement
he S612 mainframe fits a standard 19-inch equipment rack. Do not block ventilation
holes when installing the
mainframe in a19-inch
equipment rack.
!

TECHNICAL SUPPORT: 1.800.283.5936 (USA) OR 1.801.974.3760
10

TECHNICAL SUPPORT: 1.800.283.5936 (USA) OR 1.801.974.3760
3
In tallation
Telephone Line
Setup
INSTALLATION • ELEPHONE LINE SE UP 11
he S612 connects to six or 12 telephone lines, depending on your
hardware configuration. he basic configuration supports six lines. For
instructions on installing the expansion cards to increase S612
capacity to 12 lines, see page 12.
Telephone Connections
Six or 12 telephone lines may be connected to the each of the main-
frame’s two 50-pin Centronix connectors (RJ21X). Phone Lines In is a
male connector. Phone Lines Out is a female connector.
Connecting six or 12 telephone lines to the Phone Lines Out connector
on the mainframe enables the loop-out function of the S612. Lines not
in use by the S612 are then available for use on a separate telephone
system.
Phone Line Pin Wire Color* Pin Wire Color*
1
2
3
4
5
6
7
8
9
10
11
12
*Wire colors are presented in the following format: base/stripe
1TIP blue/white 26 RING white/blue
2TIP orange/white 27 RING white/orange
3TIP green/white 28 RING white/green
4TIP brown/white 2 RING white/brown
5TIP silver/white 30 RING white/silver
6TIP blue/red 31 RING red/blue
7TIP orange/red 32 RING red/orange
8TIP green/red 33 RING red/green
TIP brown/red 34 RING red/brown
10 TIP silver/red 35 RING red/silver
11 TIP blue/black 36 RING black/blue
12 TIP orange/black 37 RING black/orange

TECHNICAL SUPPORT: 1.800.283.5936 (USA) OR 1.801.974.3760
INSTALLATION • ELEPHONE LINE SE UP
12
Line Expansion
A six line S612 is shipped from the factory configured for six telephone
lines. You may expand a six line system to 12 lines by adding two
additional telco cards. Cards must be installed in sets of two in order for
the system to function properly. Once line expansion is completed, lines
7–12 are active on your control surface.
Follow the step-by-step instructions below to ensure proper installation
of additional elco cards:
1) Remove the top cover of the mainframe chassis by loosening four
screws; two on each of the mainframe side panels. Lift the top off
carefully.
2) Find the two empty PCB card slots. hey are located on the left-hand
side of the mainframe when it is viewed from the front.
3) Carefully insert the two expansion cards into the two expansion
slots. Either card can be placed in either slot. Be careful that the cards
are inserted correctly. he component side of the PCB must be toward
the left side of the chassis, the same as previously installed cards.
Press down gently to make certain the cards are seated completely.
4) Place the top chassis cover back onto the mainframe and tighten
the four screws.
5) Reconnect the mainframe to your power source.
FRONT
TOP VIEW
TS612 Mainframe Assy
(Top Cover Removed)
Expansion
Card Slots
Card Guide
(Telco Channel
Extender)
To prevent electrical shock
or possible equipment
damage, disconnect the
unit from all electrical power before
proceeding.
!

TECHNICAL SUPPORT: 1.800.283.5936 (USA) OR 1.801.974.3760
INSTALLATION • CONFIGURING HE S612 13
Configuring the
TS612
o best suit your requirements, the S612 may be configured in several
ways. he type of configuration is determined by the positions of the
DIP switches located behind the access panel on the front of the main-
frame. Unscrew the two large screws on the front of the main frame and
remove the access panel to change DIP switch settings.
he table below indicates the configuration mode associated with each
DIP switch. DIP switches 1, 3, 6, and 7 affect S612 configuration
directly and are discussed below in relation to the possible
configurations. Other DIP switches are discussed later in the manual.
ENHANCE
SEND
HOLD
CALLER SEND
HYBRID 1 HYBRID 2
CALLER SEND CALLER
1012 456789 UP DOWN 3
Dip Switch Description Up Position Down Position
1
2
3
4
5
6
7
8
9
10
Mainframe Operation Single Split Studio
Open Collector Outputs Momentary Latching
Mix-Minus Internal External
COM Port Operation Standard Control Network Interface
Not Active
Split Caller Off On
Split Hybrid Off On
Loop Override Off On
Aux Inputs Momentary Latching
Operating Mode Operational Setup

TECHNICAL SUPPORT: 1.800.283.5936 (USA) OR 1.801.974.3760
INSTALLATION • CONFIGURING HE S612
14
he S612 may be used as a single-studio or dual-studio system. In a
single-studio setting, the S612 operates as a dual-hybrid telephone
system, with up to 12 lines and three control surfaces: main/studio 1,
aux/studio 2, and screener. he main/studio 1, aux/studio 2 control
surfaces have parallel control of all on-air functions.
In a dual-studio setting, the S612 operates as two single-hybrid
telephone systems. A dual-studio system must have the 12-line
expansion installed or switch #4 activated to operate. As a split-studio
configuration, lines 1–6 and hybrid 1 are dedicated to studio 1, and
lines 7–12 and hybrid 2 are dedicated to studio 2 unless switch 4 is acti-
vated in which case lines 1–12 are shared by both studios. he studio
control surfaces operate independently of each other, while the
screener control surface can screen lines for either studio. he
configurations for single-studio and dual-studio systems are discussed
in detail on the following pages.
S612
Mainframe
Screener
Optional
OFF
OFF
NEX7 8 9 10 11 12
OFF NEX
NEX
7 8 9 10 11 12
9
123
45 6
78
0#
AB C
AB C
DE F
DE F
GH I
GH I
PR S
PR S
UV
UV
WX Y
WX Y
Op er
Op er
JK L
JK L
MN O
MN O
MODE
MODE
AUX FLSH
REC
CONF
ONF
VIP
SCRN
SCRN
MU E
MU E
HOLD AIR
OFF NEX
1 2 3 4 5 6
7 8 9 10 11 12
*
Main/Studio One Studio Console
Aux/Studio wo
S612
Mainframe
Studio Console
Common
Screener
Main/Studio One Aux/Studio wo
Studio Console
9
123
4 5 6
78
0#
AB C
AB C
DE F
DE F
GH I
GH I
PR S
PR S
UV
U V
WX Y
WX Y
Op er
Op er
JK L
JK L
MN O
MN O
MODE
MODE
AUX
UX
FLSH
FLSH
REC
REC
CONF
ONF
VIP
VIP
SCRN
SCRN
MU E
MU E
HOLD
HOLD
AIR
AIR
OFF
OFF
NEX
NEX
1 2 3 4 5 6
7 8 9 10 11 12
*
9
123
4 5 6
78
0#
AB C
AB C
DE F
DE F
GH I
GH I
PR S
PR S
UV
U V
WX Y
WX Y
Op er
Op er
JK L
JK L
MN O
MN O
MODE
MODE
AUX
UX
FLSH
FLSH
REC
REC
CONF
ONF
VIP
VIP
SCRN
SCRN
MU E
MU E
HOLD
HOLD
AIR
AIR
OFF
OFF
NEX
NEX
1 2 3 4 5 6
7 8 9 10 11 12
*
9
12 3
456
78
0#
AB C
AB C
DE F
DE F
GH I
GH I
PR S
PR S
UV
U V
WX Y
WX Y
Op er
Op er
JK L
JK L
MN O
MN O
MODE
MODE
AUX
UX
FLSH
FLSH
REC
REC
CONF
ONF
VIP
VIP
SCRN
SCRN
MU E
MU E
HOLD
HOLD
AIR
AIR
OFF
OFF
NEX
NEX
1 2 3 4 5 6
7 8 9 10 11 12
*

TECHNICAL SUPPORT: 1.800.283.5936 (USA) OR 1.801.974.3760
INSTALLATION • CONFIGURING HE S612 15
Single-Studio Mixed Caller
In mixed-caller mode, all calls placed to air are routed to the audio
console through the Main Caller output regardless of which hybrid a
call is routed through. Each of the S612’s two hybrids has two call slots.
his allows up to four calls to be placed to air simultaneously by
conferencing them together.
DIP Switch Settings. For mixed-caller mode, DIP switch 1 should be
up. DIP switch 3 determines the mix-minus setup for the configuration. If
DIP switch 3 is in the up position, the S612’s internal mix-minus feature
is active. Full program audio (including the caller audio) may be routed
to the Main Send input. Caller audio will be removed by the S612
before transmitting the signal back to the caller.
If DIP switch 3 is in the down position, external mix-minus must be
provided. Caller audio must be removed from the program mix before
routing the signal to the Send input.
Studio Console
AUX / STUDIO # 2 MAIN / STUDIO # 1
RECORD
CONTROL RECORD CONTROL
COM PORT
CONTROL
SUR ACE
CONTROL
SUR ACE
CALLER CALLER
SEND SEND
HOLD HOLD
REC
MIX REC
MIX
SCREENER
CONTROL
SUR ACE
AUX I / O
PHONE LINES
IN
OUT
85 - 240VAC; 2A
50Hz/60Hz
MADE IN U.S.A.
1012 4567893
1012 4567893
Main Caller Output
(callers 1–4)
Mix Minus or
Program audio

TECHNICAL SUPPORT: 1.800.283.5936 (USA) OR 1.801.974.3760
INSTALLATION • CONFIGURING HE S612
16
Single-Studio Split Caller
In split-caller mode when conference mode is enabled, caller audio is
routed to the audio console through both Caller outputs (Main and Aux)
as shown in the diagram below. he advantage of split-caller mode is
that caller audio is separated into two audio signals that may be
connected to separate inputs on your audio console. Calls are routed to
the hybrids (placed on-air) in the order they are added to the
conference. See the table on the right for more information. Hybrid 1
audio is routed to the Main Caller output. Hybrid 2 audio is routed to the
Aux Caller Output.
DIP Switch Settings. For split-caller mode, DIP switch 6 should be
down. DIP switch 3 determines the mix-minus setup for the
configuration. If DIP switch 3 is in the up position, the S612’s internal
mix-minus feature is active. Full program audio (including the caller
audio) may be routed to the Main Send input. Caller audio will be
removed by the S612 before transmitting the signal back to the caller.
If DIP switch 3 is in the down position, external mix-minus must be
provided. Caller audio from both Caller outputs (Main and Aux) must be
removed from the program mix before routing the signal to the Main
Send input.
Order Calls are
Placed into H brid / Slot Caller Output
1
2
3
4
H1 / S1 Main
H2 / S1 Aux
H2 / S2 Aux
H1 / S2 Main
Conference
Studio Console
AUX / S UDIO # 2 MAIN / S UDIO # 1
RECORD
CON ROL
RECORD
CON ROL
COM POR
CON ROL
SURFACE
CON ROL
SURFACE
CALLER CALLER
SEND SEND
HOLD HOLD
REC
MIX REC
MIX
SCREENER
CON ROL
SURFACE
AUX I / O
PHONE LINES
IN
OU
85 - 240VAC; 2A
50Hz/60Hz
MADE IN U.S.A.
Main Caller
Output
Callers 1 and 4
Mix Minus
or
Program
Aux Caller
Output
Callers 2 and 3
1012 4567893
1012 4567893

TECHNICAL SUPPORT: 1.800.283.5936 (USA) OR 1.801.974.3760
INSTALLATION • CONFIGURING HE S612 17
Single-Studio Split-H brid
In split-hybrid mode, the two hybrids operate independently. Caller
audio is routed to the audio console through both Caller outputs (Main
and Aux) in the same manner as split-caller mode. he primary
difference is that the hybrids receive program audio through two
separate Send inputs (Main and Aux). As in split-caller mode, Hybrid 1
audio is routed to the Main Caller output and Hybrid 2 audio is routed to
the Aux Caller output.
DIP Switch Settings. For split-hybrid mode, DIP switch 7 should be
down. he recommended mix-minus setting for split hybrid mode is DIP
switch 3 down. his setting requires external mix-minus. he audio mix
routed to the Main Send input should not have callers two and three
mixed in. Likewise, the Aux Send audio input should not have callers
one and four mixed in. his allows the studio console operator to adjust
the caller to caller level between the two S612 hybrids.
For configurations
requiring internal mix-
minus, we recommend that
you use Split-Caller Mode. You will
only have to provide one program
mix from the studio console to the
TS612.
✍
Studio Console
AUX/STUDIO # 2 MAIN / STUDIO # 1
RECORD
CONTROL RECORD CONTROL
COM PORT
CONTROL
SURFACE CONTROL
SURFACE
CALLER CALLER
SEND SEND
HOLD HOLD
REC
MIX REC
MIX
SCREENER
CONTROL
SURFACE
AUXI/O
PHONE LINES
IN
OUT
85 - 240VAC; 2A
50Hz/60Hz
MADE IN U.S.A.
Main Caller
Output
Callers 1 and 4
Mix Minus
Callers 2 and 3
Mix Minus
Callers 1 and 4
Aux Caller
Output
Callers 2 and 3
1012 4567893

TECHNICAL SUPPORT: 1.800.283.5936 (USA) OR 1.801.974.3760
INSTALLATION • CONFIGURING HE S612
18
Dual-Studio
In this configuration, the S612 operates as two single-hybrid telephone
systems in either split or shared mode.
Split Mode. In split mode, the two talent control surfaces operate
independently. Studio 1 controls lines 1–6 and studio 2 controls lines
7–12. he screener accesses all 12 lines to screen calls for either talent.
All calls placed to air by studio 1 are routed to the audio console
through the Main Caller output. All calls placed to air by studio 2 are
routed to the audio console through the Aux Caller output. Because
each of the S612’s two hybrids has two call slots, each studio can
conference a maximum of two calls together.
DIP Switch Settings. For dual-studio mode, DIP switch 1 should be
down. DIP switch 3 determines the mix-minus setup. If DIP switch 3 is
up, the S612’s internal mix-minus feature is active. Studio 1 program
audio (including the caller audio) may be routed to the Main Send input
and Studio 2 program audio may be routed to the Aux Send input.
Caller audio is removed by the S612 before returning to the caller.
If DIP switch 3 is down, external mix-minus must be provided. Caller
audio must be removed from the program mix by each studio console
before routing the signal to a Send input.
Shared Mode. In shared mode, both studios have control of all 12
lines and can see when a line is in use by the other studio.
If DIP switch 4 is down (shared mode), Studio 1 and Studio 2 have
access to all 12 lines.
Studio1
AUX / STUDIO # 2 MAIN / STUDIO # 1
RECORD
CONTROL RECORD CONTROL
COM PORT
CONTROL
SUR ACE
CONTROL
SUR ACE
CALLER CALLER
SEND SEND
HOLD HOLD
REC
MIX REC
MIX
SCREENER
CONTROL
SUR ACE
AUX I / O
PHONE LINES
IN
OUT
85 - 240VAC; 2A
50Hz/60Hz
MADE IN U.S.A.
Studio 2
1012 4567893
1012 4567893
1012 4567893
