GenTran Silent Generator User manual

1
INSTALLATION and OPERATING MANUAL
The Silent Generator™ Power System is a battery-powered backup system for
use when backup power is required and a traditional combustion-engine
generator power source is not practical or possible due to noise, regulation,
reliability, space or fuel storage/availability issues. The Silent Generator™
Power System provides an uninterruptible power output, ideal for office
computers and servers, refrigeration, medical equipment, aquariums and
other reliability-demanding power applications. When connected to AC
power, the Silent Generator™ Power System is constantly recharging, ready
for the next power disruption.
Additionally, the Silent Generator™ Power System can be recharged with
most any renewable DC power source such as solar, wind or hydro and
qualifies for up to a 30% Federal Section 1122 tax credit1or a Section 1603
grant in lieu of Renewable Energy Tax Credits2, significantly reducing the
initial investment required.
This Installation and Operating Guide provides information required for
proper installation, operation, environmental consideration, and battery
maintenance recommendations.
This manual is published for informational purposes and should not be considered all inclusive. If further information is required, you should
consult Gen/Tran Corporation. Sale of product shown in this document is subject to terms and conditions outlined in appropriate Gen/Tran
selling policies or other contractual agreement between the parties. This document is not intended to and does not enlarge or add to any
such contract. Every effort has been made to ensure the accuracy and completeness of the information in this manual. Gen/Tran reserves the
right to change and update the manual and product at any time without prior notice.
No warranties, expressed or implied, including warranties of fitness for a particular purpose or merchantability, or warranties arising from
course of dealing or usage of trade, are made regarding the information, recommendations and descriptions contained herein. In no event
will Gen/Tran Corporation be responsible to the purchaser or user in contract, in tort (including negligence), strict liability or otherwise for
any special, indirect, incidental or consequential damage or loss whatsoever, including but not limited to damage or loss of use of
equipment, plant or power system, cost of capital, loss of power, additional expenses in the use of existing power facilities, or claims against
the purchaser or user by its customers resulting from the use of the information, recommendations and description contained herein.
NOTE TO INSTALLER: Please leave this manual with the customer for future reference.
Una versión en español de este manual está disponible para descargar en nuestra página web www.gen-tran.com/support/installation
MODEL NUMBER ___________________________________SERIAL NUMBER ________________________________________________________
DATE OF INSTALLATION ______________________________DEALER NAME/PHONE ___________________________________________________
Please note Model number and Serial Number here for future reference. Serial Number may be found on back of the unit.
1
To be eligible for a S1122 Tax Credit, the qualified property must be used in a residential property. Please consult your tax advisor for complete
information.
2
To be eligible for a S1603 Grant, the qualified property must be used in a trade or business or held for the production of income. Residential or nonbusiness
properties are not eligible. Please consult your tax advisor for complete information.

2
IMPORTANT SAFETY PRECAUTIONS:
This symbol indicates the presence of a hazard or unsafe practice that can result in personal injury or product/property damage.
This symbol refers to a hazard or unsafe practice that can result in severe personal injury or death if this hazard is not avoided.
This symbol warns of immediate hazards that will result in severe personal injury, death or property damage.
PLEASE READ THIS MANUAL IN ITS ENTIRETY BEFORE ATTEMPTING TO UNPACK, ASSEMBLE, INSTALL,
OPERATE OR MAINTAIN THIS EQUIPMENT. HAZARDOUS VOLTAGES ARE PRESENT INSIDE THE SILENT GENERATOR™
POWER SYSTEM ENCLOSURE THAT CAN CAUSE DEATH OR SEVERE PERSONAL INJURY. FOLLOW PROPER INSTALLATION,
OPERATION AND MAINTENANCE PROCEDURES TO AVOID THESE VOLTAGES.
THE SILENT GENERATOR™ POWER SYSTEM IS NOT INTENDED FOR USE AS AN EMERGENCY SYSTEM (SEE
NEC ARTICLES 517 AND 700), NOR AS A LEGALLY REQUIRED SYSTEM (SEE NEC ARTICLE 701), NOR FOR
PRIMARY POWER IN PLACE OF THE ELECTRIC UTILITY OR IN LIFE SUPPORT OR CRITICAL MEDICAL APPLICATIONS.
DO NOT connect any AC load whose neutral conductor is connected (bonded) to ground to the System.
Power equipment covered by this document is designed and tested to operate within its nameplate ratings. Operation
outside of these ratings may cause the equipment to fail resulting in death, serious bodily injury and/or property damage. All responsible
personnel should locate the equipment nameplate and be familiar with the information provided therein.
Installation of this system must be done by a Licensed electrician in compliance with all applicable electrical codes and ordinances.
The Silent Generator™ Power System is intended for indoor use only. Do not expose the unit to rain, snow, or moisture. To reduce risk of
fire hazard, do not cover or obstruct the ventilation openings. Do not install the Silent Generator Power System in a zero-clearance
compartment as overheating may result.
The Silent Generator™ Power System may connect to one source of DC Power and one source of AC Power. To reduce the risk of electrical
shock, disconnect all sources of AC and DC power from the Silent Generator™ Power System before attempting any maintenance or
cleaning or working on any circuits connected to the unit. Turning off controls/switches will not eliminate this risk.
Do not operate the Silent Generator™ Power System with damaged or substandard wiring, if it has received a sharp blow, been dropped, or
otherwise damaged in any way.
Do not disassemble the Silent Generator™ Power System, there are no user-serviceable parts inside. Contact Gen/Tran to obtain service.
Attempting to service the unit yourself may result in a risk of electrical shock or fire, and will void your warranty. Internal capacitors remain
charged after all power is disconnected.
Do not insert any foreign objects into the Silent Generator™ Power System’s AC outlets, DC Power input socket, or the
ventilation holes. Keep the Silent Generator™ Power System cabinet closed. Make sure only authorized personnel have access to the
cabinet. Due to the serious shock hazard from high voltages within the cabinet, all service and adjustments to the unit must be performed by
an electrician or authorized service personnel. All possible contingencies which may arise during installation, operation or maintenance, and
all details and variations of this equipment do not purport to be covered by these instructions. If further information is desired by purchaser
regarding his particular installation, operation or maintenance of particular equipment, contact Gen/Tran.
BATTERY SAFETY PRECAUTIONS:
1. Use only sealed VRLA AGM type batteries specified by Gen/Tran in the Silent Generator™ Power System. Use of any other batteries
could create a hazardous situation and will void the warranty.
2. To reduce the risk of battery explosion, follow these instructions and those published by the battery manufacturer.
3. Working in the vicinity of batteries may be dangerous. Unsealed batteries can generate explosive gases during normal operation.
Therefore, you must read this guide and follow the instructions exactly before installing or using the Silent Generator™ System.
4. This equipment contains components which tend to produce arcs or sparks. To prevent fire or explosion, do not install in locations that
require ignition-protected equipment. This includes any space containing gasoline-powered machinery, fuel tanks, fuel lines as well as
joints, fittings, or other connections between components of the fuel system.
5. Never smoke or allow a spark or flame near the batteries.
6. Use caution to reduce the risk of dropping a metal tool on the batteries. It could spark or short circuit the battery or other electrical parts
and could cause an explosion.

3
7. Remove all personal metal items, like rings, bracelets, and watches when working with batteries. Batteries can produce a short circuit
current high enough to weld metal, causing a severe burn.
8. Have someone within range of your voice or close enough to come to your aid when you work near a battery.
9. Wear complete eye protection and clothing protection. Avoid touching your eyes while working near batteries.
10. Have plenty of fresh water and soap nearby in case battery acid contacts skin, clothing, or eyes.
11. If battery acid contacts skin or clothing, wash immediately with soap and water. If acid enters your eye, immediately flood it with
running cold water for at least twenty minutes and get medical attention immediately.
12. Operating in temperatures above 77°F (25°C) will reduce battery life. The external battery cabinet environment must be free of
conductive contaminants and excessive moisture (condensation, flammable vapors, chemical fumes, or corrosive gases and liquids).
SYSTEM SPECIFICATIONS:
Max Output/Available Power 4000 Watts @ 25°C
Nominal Battery Voltage 48 Volts DC
DC Input Operating Range 42-64 VDC
Nominal AC Output 120/240 VAC ±5% at 50Hz or 60 Hz
Max Output Current 17 Amps @ 240 VAC
33 Amps @120 VAC
Max Output Surge @ 25° C 200% 7 Sec.
150% 30 Sec.
115% 30 Min.
Internal Battery Type Sealed Lead Acid, AGM, 2 types
- Deep Cycle (repetitive discharge + charge apps)
- Float (used occasionally, for backup power)
Available Battery Capacity 800 Amp Hours (standard)
1000 Amp Hours (optional)
Continuous Charging Current 10 Amps @ 25°C
At 56 VDC Out with 240 VAC Input
Receptacles Provided 4 x 15 amp 120 V (NEMA 5-15)
1 x 20 amp 120/240 V (NEMA L14-20)
AC Input Voltage Range 80 to 150 VAC per Leg
AC Input Frequency Range 45 to 65 Hz
Max AC Input Current 40 Amps AC
DC Output Range 42 to 70 VDC
Power Factor >.92
Unit Weight 930 lbs with 800 AH batteries
1010 lbs with 1000 AH batteries
Unit Dimensions 19.2”W x 28.3”D x 48.3”H
Suitable for use with 90° C Copper conductors
Torque DC Input Terminals to: 5 ft-lbs / 6.78 N-m
Normal Operating Temperature: -20°C to +45°C
SYSTEM CONFIGURATIONS:
MODEL Output Watts@125VAC AC-Input/Output (VAC) Storage (Amp Hours) Battery Type
SG (Silent Generator) 4000 A = 125 VAC only
B = 125/250 VAC*
1 = 800*
2 = 1000
1 = Float*
2 = Deep Cycle
*= Standard configuration Example: SG4000-B-1-1

4
SECTION 1 – PREPARING for INSTALLATION
1.1 ITEMS INCLUDED WITH SYSTEM
•Silent Generator™ Power System
•2- shipping/ramp brackets and hardware
•Silent Generator™ Power System Installation and Operating Manual
•Apollo Solar TSW™ Inverter/Charger User’s Manual
•TriStar™ Controller Installation and Operation Manual
•10 foot 20A 120/240 with L14-20 connector and plug (Model RJB12410)
•Anderson SB50 Gray Connector with (2) #6 wire lugs
1.2 TOOLS and HARDWARE REQUIRED FOR INSTALLATION
•Pallet Jack capable of moving 1200 lbs.
•7/16” and 1/2”socket wrench
•Flathead screwdriver
•#2 Phillips head screwdriver
•Scissors or knife to remove packaging
1.3 OPTIONAL ITEMS FOR INSTALLATION
•Power Outlet Box with L14-20 receptacle, PN: 14212
•20 Amp 2-Pole circuit breaker for load center
1.4 SITE PREPARATION
When deciding where to locate your Silent Generator™ Power System, consider the size and weight of the unit, complying with
the minimum site preparation requirements below. Ensure the structural integrity of the floor can withstand the weight of the
cabinet.
Minimum site preparation requirements:
•Clearance: 6” (15.2 cm) minimum on sides and top to any obstruction at all times
•Temperature: Ambient temperature not to exceed 104°F (40°C)
•Ventilation: Minimum room size of 6’ x 6’ x 8’
•Power: 20A, 2 Pole 125/250VAC dedicated power circuit
Cabinet physical specifications:
•Height: 48.31” (122.7 cm)
•Width: 19.16” (48.7 cm)
•Depth: 28.3” (71.9 cm)
•Weight: Model SG-4000-X-1-X, 800AH storage, approximately 930 lbs. (422 kg)
Model SG-4000-X-2-X, 1000AH storage, approximately 1010 lbs. (458 kg)
1.5 UNLOADING THE SILENT GENERATOR™ POWER SYSTEM
The Silent Generator™ Power System is shipped bolted to a pallet via two support brackets which can be used as ramps
to allow the cabinet to roll off the pallet (Fig. #1). It is recommended that a pallet jack be used to move the unit to a
location where the unit can then be removed from the pallet and in close proximity to its final location.
At least two people should be present to unload the cabinet off of the pallet.
1. Move the Silent Generator™ Power System cabinet as close as possible to the desired operating location with a pallet jack,
remove the packaging protecting the outer cabinet surfaces.
2. Verify that the locking casters are locked and are not able to spin freely.
3. Using a 7/16”socket wrench, remove and save the four hex lag screws that secure the cabinet to the pallet.
4. Using a ½” socket wrench, remove the four bolts that attach shipping brackets to Silent Generator™ System cabinet.

5
5. Position the shipping brackets as indicated in Figure #2, using the four lag screws from Step 3, attached shipping brackets
to lip of pallet, spacing per Figure 3 spacing. The shipping brackets are now to be used as ramps to roll the unit off the
pallet.
6. Verify there is ample space at the end of the ramps for the cabinet to rest on level ground, unlock the cabinet casters.
7. Using two people, slowly move the Silent Generator™ Power System down the ramp until the unit is on level ground.
Remove shipping brackets from pallet. If the Silent Generator™ Power System is to be permanently mounted, re-attach the
shipping brackets in reverse order mentioned above, and anchor to floor.
8. In case the cabinet will need to be moved to another location, retain the shipping brackets/ramps to move the Silent
Generator™ Power System again. They can also be useful to cross uneven ground and doorway thresholds.
9. Discard pallet and other shipping materials.
10. Roll to installation location, ensuring Section 1.4 site preparation has been completed.
FIGURE 1 FIGURE 2
FIGURE 3

6
SECTION 2 - CONNECTING POWER
The Silent Generator™ Power System can be cord-connected or hard-wired to AC/DC power. The Silent Generator™ Power
System must be connected to a properly sized AC and/or DC power source to ensure the batteries are charged and ready for the
next power disruption.
2.1 CONNECTING TO AC UTILITY POWER
2.1.1 CORD CONNECTING
The Silent Generator™ Power System has a NEMA L14-20 (125/250VAC @ 20A) male power inlet, commonly found on
generator equipment, to allow users to cord-connect to AC power. Consult with a licensed electrician to install a 20A
125/250VAC Power Outlet Box (PN 14212) near the location the Silent Generator™ Power System will be installed. Connect
the provided RJB12410 cordset between the Power Outlet Box and power inlet on the Silent Generator™ Power System.
2.1.2 HARDWIRING CONNECTING
A more permanent installation solution is to hardwire the Silent Generator™ Power System directly to a dedicated 20A
125/250VAC 2-Pole circuit breaker in your load center. Cut the male plug off of the RJB12410 cordset and connect to the 20A
125/250VAC 2-pole circuit breaker in your load center following all local electrical code and permitting requirements.
2.2 CONNECTING TO DC POWER
The Silent Generator™ Power System can be connected solar PV panels, wind generating or hydro power sources via an
Anderson SB50 receptacle. An Anderson SB50 connector is provided. See Figure 4. The TriStar™ Model T-60 DC charge
controller is factory set for 48 VDC/48A nominal inputs. Use minimum 6 AWG 90C wire for the DC connection. Please refer to
the enclosed TriStar™ Controller Installation and Operation Manual for complete DC connection instructions.
FIGURE 4

7
2.3 THE USER INTERFACE/LCD SCREEN
OVER-LOAD !
System overload, system shuts off,
loads will not be powered,
disconnect loads, will
AUTO-START after 6 second delay
SYSTEM OVERLOAD

8
SECTION 3 - START-UP PROCEDURE
1. Confirm all wiring is correct and connections are tight.
2. Check that all input/output voltages and polarities are correct.
3. Turn ON the DC BATTERY circuit breaker.
4. Turn ON the DC SOLAR INPUT circuit breaker (if a DC input power source is attached).
5. The Silent Generator™ Power System will start in the inverter mode within 6 seconds.
6. Turn ON the 20A 125/250VAC circuit breaker providing AC power to the Silent Generator™ Power System. The system
should switch to charge mode. Please refer to the Apollo Inverter/Charger User’s Manual Section 5.2 for LCD screen
descriptions.
7. Connect and turn on an appliance, such as a hair dryer or toaster, to the Silent Generator™ Power System, verify load
wattage on LCD screen.
8. Disconnect the AC and DC power inputs to the Silent Generator™ Power System. The System will switch to back-up
mode and continue to provide power to your appliance. Disconnect appliances from Silent Generator™ Power System
and reconnect the AC and DC power inputs.
SECTION 4 - CONNECTING LOADS
Loads may be connected to the Silent Generator™ Power System thru the 2-15A VAC GFCI receptacles and/or thru the 20Amp
125/250 VAC L14-20 receptacle. Gradually add load, monitoring the Silent Generator™ Power System LCD to ensure the total
loads do not exceed 4000w in total. If the Silent Generator™ Power System is overloaded, it will shut off and not restart until
loads are removed and then restart after 6 second delay. All loads connected to the Silent Generator™ Power System will be
provided power without interruption as along as the batteries are properly charged.
SECTION 5 - BATTERY MAINTENANCE and REPLACEMENT
The Silent Generator™ Power System uses VRLA AGM sealed batteries, full charged and ready to use from the factory. The
Silent Generator™ Power System should be installed and connected to an AC or DC power source within 90 days of purchase.
While the batteries have a design life of 10 years, long periods between charging (self-discharging), more frequent
charge/discharge cycles and extreme ambient temperatures can reduce actual battery life to 5 years or less. While the batteries
are maintenance-free, avoid frequent (daily) discharging of batteries to more than 50% of their capacity. Under extreme
conditions, occasionally discharging to an 80% level is acceptable. Total discharging will reduce battery life and permanently
damage the batteries. Gen/Tran recommends setting up a bi-annual maintenance schedule to check the condition of the
batteries. If batteries need to be replaced, ONLY use a Gen/Tran approved battery, call Gen/Tran for pricing and availability. Use
of unauthorized batteries will void the warranty and could potentially damage the system.
SECTION 6 – TROUBLESHOOTING
Use the following troubleshooting guide to help diagnose problems. Thoroughly inspect the Silent Generator™ Power System
wiring and cable connections. Correct any wiring problems before performing any tests or replacing any components.
6.1 BASIC TROUBLESHOOTING
In case of a Silent Generator™ Power System failure, check the following BEFORE calling your installer:
1. Check that all power cord and cable connections are tight.
2. Check that the dedicated 20A 125/250VAC 2-Pole circuit breaker in your load center is ON.
STANDBY
BAT 48.4V 0.0 A
System is in STAND-BY, no loads
will be powered
SYSTEM STANDB
Y
To enter STAND-BY mode,
press STANDBYbutton once
To exit STAND-BY mode,
press STANDBYbutton once

9
3. Check that the DC BATTERY circuit breaker and the DC SOLAR INPUT circuit breaker (if a DC input power source is attached)
are ON.
4. Turn OFF the DC BATTERY circuit breaker for 30 seconds, then turn ON. If the Power System still does not function, please
continue with Troubleshooting Guide, if problems persists, call Gen/Tran for technical support
6.2 TROUBLESHOOTING GUIDE
PROBLEM POSSIBLE CAUSE(S) SOLUTION SECTION
A. Dedicated 20A
circuit breaker in
load center is
tripping*
1. Circuit breaker is smaller than 20A/2P
2. Circuit breaker is not dedicated to unit
3. Circuit breaker is defective
* Some installation may require a
dedicate 30A/2P circuit breaker, call
Gen/Tran for additional information.
1. Change to 20A/2P circuit breaker
2. Remove all other loads on circuit breaker
3. Replace circuit breaker
2.1
B. Power System
shuts off during use
in utility and/or
backup mode.
1. Connected loads exceed 4000W
2. Batteries are over 80% discharged
3. Inverter is defective
1. Reduce connect loads to 4000W or less, system will
restart in 6 seconds after loads are reduced
2. Recharge batteries with AC and/or DC power
3. Refer to Apollo User’s Manual
4
C. Power system
runs shorter than
expected in backup
mode
1. Batteries are not fully charged
2. Batteries have been damaged due to
overuse or deep discharging
3. Loads are larger than planned
1. Ensure AC and/or DC power is connect to system
and charge for 24 hours
2. Test batteries and replace if damaged
3. Turn off some loads
5
SECTION 7 – FILING for TAX CREDITS
When properly installed and used in conjunction with certain “qualified” properties, such as solar electric PV panels and
windmills, the Silent Generator™ Power System may qualify for Federal, State and/or local tax credits and/or incentive grants,
significantly reducing the initial investment required.
Included in this Installation Manual is a Manufacturer’s Certification Statement, certifying that The Silent Generator™ Power
System qualifies for the Federal Tax Credit allowed under S1122 of the American Recovery and Reinvestment Act of 2009.
Since Gen/Tran is not a tax or legal advisor, please consult with your tax and legal professional for more complete information.
SECTION 7 - AVAILABLE ACCESSORIES
•Model 14212 Power Outlet Box
•RJB12425 Cordset

10
Manufacturer’s Certification Statement
Pertaining to the Tax Relief For the American Recovery and Reinvestment Act of 2009
Gen/Tran Corporation
This Manufacturer’s Certification Statement can be relied upon by you, the taxpayer, for verification that Gen/Tran Corporation
certifies that the following products are “Residential Energy Efficient Properties” that qualify for the Federal Tax Credit for
residential dwellings allowed under section 1122 of the American Recovery and Reinvestment Act of 2009.
Name and Address of Manufacture:
Gen/Tran Corporation, 1335 Ridgeland Parkway, Suite 150, Alpharetta, GA 30004
Property Identification:
Solar Electric Property
Product Description:
Model SG4000, Silent Generator™ Power System
The IRS does not require the taxpayer to attach this certification statement to their tax return. However, the taxpayer should
retain this certification statement as part of their tax records. As in all tax matters, the taxpayer is advised to consult their tax
professional.
Under penalties of perjury, I declare that I have examined this certification statement, and to the best of my knowledge and belief,
the facts are true, correct, and complete.
Jack Mandula, President, Gen/Tran Corporation, August 16, 2011
Disclaimer:*This certification statement is made as of August 16, 2011 and Gen/Tran Corporation makes no warranty as to the
qualification of the products for federal tax credits if there are changes in requirements or applicable law after such date. Gen/Tran
Corporation is not a tax advisor. Taxpayers claiming a tax credit should consult a tax professional with any questions. Gen/Tran
Corporation is not responsible or liable for the taxpayer’s ability to receive tax credits. This document is not intended to constitute
legal or tax advice. More comprehensive information is available from the IRS.
The user maintains the full and complete responsibility to comply with all codes, laws and regulations applicable to the safe and
proper use, handling and installation of the product and should consult with a professional for all construction and design related
questions.
Homeowner’s Certification: The following products (s) have been installed in the primary
residence of the following Taxpayer:
Homeowner’s Name:_______________________________________________________
Primary Residence
Address:_________________________________________________________________
Product(s)
Installed:__________________________________________________________________
Price Paid for Products:__________ Date Purchased: __________Date Installed_________
