geratech EGE-CMP-442 User manual

EGE-CMP-442
4x2 Component Video Matrix

CONTENTS
1. Introduction 1
2. Features 1
3. Package Contents 1
4. Operation Controls and Functions 2
4.1 Front Panel 2
4.2 Rear Panel 2
4.3 Remote Control 3
4.4 RS-232 Protocol 3
4.4.1 Pin Definition 3
4.4.2 Commands 4
5. Specifications 4
5.1. General Specification 4
5.2. Support Resolution 4
6. Connection and Installation 5
EGE-CMP-442
4x2 Component Video Matrix
.................................................................................
.......................................................................................
.......................................................................
............................................
..............................................................................
..............................................................................
.......................................................................
......................................................................
...................................................................
......................................................................
..............................................................................
..............................................................
.................................................................
.......................................................

1. Introduction
EGE-CMP-442 is a high performance Component + L/R Audio Matrix with remote control. It offers you
maximum convenience in HDTV audio/video signal distribution when you have multiple sources and
displays to connect together. Each of the four HDTV audio/video sources can be directed to any one
of the two outputs, so two displays can show 2 identical or 2 different sources at the same time.
EGE-CMP-442 provides a maximum of 8 possible connection scenarios between sources and
displays.
2. Features
1. Provides 4 by 2 matrix input/output of Component (YPbPr/YCbCr) video and L/R audio signal.
2. Buffered video and audio output.
3. Input source LED indicators on each output select.
4. Ideal for home theater integration, conference room and retail stores.
5. Supports high resolution input/output:
HDTV: 480i, 576i, 480p, 576p, 1080i, and 1080p
6. Supports analog stereo L/R audio input and output.
7. IR remote control.
8. RS-232 control.
3. Package Contents
1. EGE-CMP-442
2. 12VDC Power Supply Adaptor
3. Remote Controller
4. Operation Manual
1
EGE-CMP-442
4x2 Component Video Matrix

4. Operation Controls and Functions
4.1. Front Panel
Remote control sensor.
Power Switch & LED Indicator:
The LED will illuminate when the power is turned on.
Input Select/Indicators for Output A:
Press the "OUT A" button repeatedly to switch to your desired source. One of the four LEDs will
illuminate to indicate which input source is being selected, and routed to the display.
Input Select/Indicators for Output B:
Press the "OUT B" button repeatedly to switch to your desired source.
One of the four LEDs will illuminate to indicate which input source is being selected, and routed to
the display.
4.2. Rear Panel
RS-232 Communication Port:
Connect to the COM port of your PC for the distant control over RS-232 channel.
Component and L/R Audio OUTPUT Ports A and B:
Connect each set of Component (3 RCA) and Audio (2 RCA) to the input of your HDTV displays.
Component and L/R Audio INPUT Ports 1, 2, 3 and 4:
Connect each set of Component (3 RCA) and Audio (2 RCA) to the output of your source
equipments such as DVD player or set-top-box.
Power:
Plug the 12VDC power supply into the unit and connect the adaptor to AC wall outlet.
EGE-CMP-442
4x2 Component Video Matrix
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
2

EGE-CMP-442
4x2 Component Video Matrix
1
2
3
4
1
2
3
4


4.3 Remote Conltrol
Power:
Press the button to turn on/off the unit.
Input Select for Component/Audio OUT A:
Press 1, 2, 3 or 4 to select the desired input source for
Component/Audio OUT A.
Input Select for Component/Audio OUT B:
Press 1, 2, 3 or 4 to select the desired input source for
Component/Audio OUT B.
Void buttons (No function.)
4.4. RS-232 Protocol
4.4.1. Pin Definition
EGE-CMP-442 Remote Control Console
PIN Definition PIN Definition
1 NC 1 NC
2 Tx 2 Rx
3 Rx 3 Tx
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
* RS-232 transmission format: Baud Rate: 9600 bps
Data bit: 8 Bits
Parity: None
Stop Bit: 1 bit
3

CONNECTING AND OPERATING
1) Connect the HDMI input source (such as HD-DVD/ PS3 /STB etc.) into transmitter over HDMI cable.
2) Connect the output of transmitter and input of receiver over CAT5E or CAT6 cable.
3) Connect the HDMI oustput (such as: HD-LCD/D-DLP) into receiver over HDMI cable.
4) Connect yhe IR TX cable into ‘‘IRTX’’ port of the transmitter; Connect the IR RX cable into IR RX
4
EGE-CMP-442
4x2 Component Video Matrix
4.4.2. Commands
COMMAND ACTION
P0 Power Off (standby)
P1 Power On *
ST System Status *
VR Firmware Version
A1 Output A select Input1
A2 Output A select Input2
A3 Output A select Input3
A4 Output A select Input4
B1 Output B select Input1
B2 Output B select Input2
B3 Output B select Input3
B4 Output B select Input4
*: command "P1" and "ST" response: P? A? B?
5. Specifications
5.1. General Specification
* Input Ports:
Component (YPbPr/YCbCr) + L/R Audio x 4 sets
* Output Ports:
Component (YPbPr/YCbCr) + L/R Audio x 2 sets
* 12V DC power supply
* Dimensions: 436 (W) x 120 (D) x 44 (H)mm * Weight: 1.6 Kgs
5.2. Support Resolution
INPUT 480i / 480p / 576i / 576p / 720p / 1080i / 1080p / @50Hz/60Hz
OUTPUT 480i / 480p / 576i / 576p / 720p / 1080i / 1080p / @50Hz/60Hz

5
6. Connection and Installation
EGE-CMP-442
4x2 Component Video Matrix

Cypress Matrix Series:
Product Description
CHMX-22 2x2 HDMI Matrix
CHMX-24 2x4 HDMI Matrix
CHMX-42 4x2 HDMI Matrix
CHMX-44 4x4 HDMI Matrix
CHMX-22AS 2x2 HDMI Matrix
CCMX-42 4x2 Component Matrix w/audio
CCMX-44 4x4 Component Matrix w/audio
EGE-CMP-442
4x2 Component Video Matrix
6
