geratech EGE-FHD-HDB-EXTL User manual

EGE-FHD-HDB-EXTL
150m, Full HD-8bit Support, HDBase-T Lite Extender


Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully before connecting,
operating or adjusting this product. Please keep this manual for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged by electrical spikes,
surges, electric shock, lightning strikes, etc. Use of surge protection systems is highly recommended
in order to protect and extend the life of your equipment.
CAUTION
The extender need to follow direct interconnection method CAT cable.
Direct interconnection method
The extender will go into protection mode automatically and no video out when using cross
interconnection method CAT cable.
Cross interconnection method
EGE-FHD-HDB-EXTL
150m, Full HD-8bit Support, HDBase-T Lite Extender

CONTENTS
1. Introduction 1
2. Features 1
3. Package Contents 1
4. Specifications 1
5. Operation Controls and Functions 2
5.1. Tansmitter 2
5.2. Receiver 3
6. Connection Diagram 5
..................................................................................
........................................................................................
........................................................................
..............................................................................
............................................
................................................................................
.................................................................................
...................................................................
EGE-FHD-HDB-EXTL
150m, Full HD-8bit Support, HDBase-T Lite Extender

1. INTRODUCTION
The HDMI Extender can extend HDMI signal over 500 feet/150 meters to an HDMI compatible
display via signal Cat5e/6 cable. It also supports bi-directional infrared control signal and RS-232
transmission together with HDMI signal, it can allow you to easily control your DVD player at TV side
or control your TV at the DVD player side when using this extender.
2. FEATURES
• HDMI 1.4, HDCP 1.4 and DVI compliant
• Video resolutions up to 1080p@60HZ (YUV4:4:4)
• HDMI High Bit Rate (HBR) audio pass through
• 150 meters transmission distance over CAT6 cable
• POC (Power over Cable), either TX or RX is powered by one 24V@1A power supply
See the description 1
• Bi-directional infrared control signal transmission
See the description 2
• Bi-directional RS-232 signal transmission
See the description 3
3. PACKAGE CONTENTS
• 1 x HDMI Extender Transmitter
• 1 x HDMI Extender Receiver
• 1 x Wideband IR emitter cable
• 1 x Wideband IR Receiver cable
• 1 x 24V/1A Power adaptor
• 1 x User Manual
4. SPECIFICATIONS
Technical
HDMI Compliance HDMI 1.4
HDCP Compliance HDCP 1.4
Video Bandwidth 148.5 MHz
Video Resolutions up to 1080P@60Hz YUV4:4:4, RGB4:4:4
Color Space RGB, YUV4:4:4, YUV4:2:2
Color Depth 8-bit
HDMI Audio Formats LPCM 2/7.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital +
(Pass-through) Dolby True HD, DTS-HD Master Audio, Dolby Atmos, DTS:X
ESD Protection Human body model — ±8kV (air-gap discharge) & ±4kV ,
(contact discharge)
1
EGE-FHD-HDB-EXTL
150m, Full HD-8bit Support, HDBase-T Lite Extender

Cennections
Inputs Transmitter: 1xHDMI Type A [19-pin female]
1xIR INPUT [3.5mm Stereo Mini-jack]
1xRS232 [Phoenix jack]
Receiver: 1xHD BaseT Out [RJ45]
1xIR INPUT [3.5mm Stereo Mini-jack]
1xRS232 [Phoenix jack]
Outputs Transmitter: 1xHD Base T Out [RJ45]
1xIR OUTPUT [3.5mm Stereo Mini-jack]
Receiver: 1xHDMI Type A (19-pin female]
1xIR OUTPUT [3.5 mm Stereo Mini-jack]
Mechanical
Housing Metal Enclosure
Color Black
Dimensions 115mm[W] x 64.7mm [D] x 17mm [H]
Weight 406g
Power Supply Input: AC100 - 240V 50/60Hz
Output: DC 24V/1A (US/EU standards, CE/FCC/UL certified)
Power Consumption 5.76W
Operating Temperature 32 - 104°F / 0 - 40°C
Storage Temperature -4 - 140°F / -20 - 60°C
Relative Humidity 20 - 90% RH (no condensation)
5. OPERATION CONTROLS AND FUNCTIONS
5.1 TRANSMITTER
Power: System power indicator.
DC 24V: Connect 24V / 1A adaptor to AC wall outlet for power supply.
HDBaseT Out: Standard HDBaseT output port. Connect HDBaseT receiver with a UTP cable
following the standard of direct interconnection method.
2
1
2
3
EGE-FHD-HDB-EXTL
150m, Full HD-8bit Support, HDBase-T Lite Extender

CONNECTING AND OPERATING
1) Connect the HDMI input source (such as HD-DVD/ PS3 /STB etc.) into transmitter over HDMI cable.
2) Connect the output of transmitter and input of receiver over CAT5E or CAT6 cable.
3) Connect the HDMI oustput (such as: HD-LCD/D-DLP) into receiver over HDMI cable.
4) Connect yhe IR TX cable into ‘‘IRTX’’ port of the transmitter; Connect the IR RX cable into IR RX
3
4
5
HDMI In: Connect to HDMI source device such as Blu-ray pr PS4 player.
IR In: Channel 2 IR Receiver. Connect to an IR receiver cable.
IR Out: Channel 1 IR Transmitter. Connect to an IR emitter cable.
RS-232: Phoenix jack provide serial port control from transmitter to receiver.
Connection Signal Indicator Lamp
• Illuminate: The transmitter and Receiver are in good connections status.
• Flashing: The transmitter and Receiver are in poor connections status.
• Dark: The Transmitter and Receiver are not connected.
Data signal Indicator Lamp
• Illuminate: HDMI signal with HDCP.
• Flashing: HDMI signal without HDCP.
• Dark: No HDMI signal.
5.2 RECEIVER
Power: System power indicator.
DC 24V: Connect 24V / 1A adaptor to AC wall outlet for power supply.
HDBaseT In: Standard HDBaseT input port. Connect HDBaseT Transmitter with a UTP cable
following the standard of direct interconnection method.
HDMI Out: Connect to the HDTV pr monitor HDMI input port.
IR In: Channel 1 IR Receiver. Connect to an IR receiver cable.
IR Out: Channel 2 IR Transmitter. Connect to an IR emitter cable.
RS-232: Phoenix jack provide serial port control signal from transmitter to receiver.
Connection Signal Indicator Lamp
• Illuminate: The transmitter and Receiver are in good connections status.
• Flashing: The transmitter and Receiver are in poor connections status.
• Dark: The Transmitter and Receiver are not connected.
Data signal Indicator Lamp
• Illuminate: HDMI signal with HDCP.
• Flashing: HDMI signal without HDCP.
• Dark: No HDMI signal.
6
7
8
9
6
7
8
9
5
4
1
2
3
EGE-FHD-HDB-EXTL
150m, Full HD-8bit Support, HDBase-T Lite Extender

DESCRIPTION 1
DESCRIPTION 2
DESCRIPTION 3
4
EGE-FHD-HDB-EXTL
150m, Full HD-8bit Support, HDBase-T Lite Extender

6. CONNECTION DIAGRAM
5
EGE-FHD-HDB-EXTL
150m, Full HD-8bit Support, HDBase-T Lite Extender

www.geratech.com.tr
www.egerate.com
www.egerate-store.com
