geratech EGE-UHD-EXTIP-KVM User manual

EGE-UHD-EXTIP-KVM
HDMI / VGA over IP Extender with scaler and KVM functions

EGE-UHD-EXTIP-KVM
HDMI / VGA over IP Extender with scaler and KVM functions
DISCLAIMERS
The information in this manual has been carefully checked and is believed
to be accurate. Geratech assumes no responsibility for any infringements of
patents or other rights of third parties which may result from its use.
Geratech assumes no responsibility for any inaccuracies that may be
contained in this document. Geratech also makes no commitment to update
or to keep current the information contained in this document.
Geratech reserves the right to make improvements to this document and/or
product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed,
stored in a retrieval system, or any of its part translated into any language
or computer le, in any form or by any means—electronic, mechanical,
magnetic, optical, chemical, manual, or otherwise—without express written
permission and consent from Geratech.
© Copyright 2012 by Geratech.
All Rights Reserved.
Version 1.11 November 2017
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

EGE-UHD-EXTIP-KVM
HDMI / VGA over IP Extender with scaler and KVM functions
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate
this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain, moisture
or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any openings
or empty slots in the unit, as you may damage parts inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if it
is damaged.
• Do not allow anything to rest on the power cabling or allow any weight to
be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or openings
in the unit housing that provide ventilation and allow for sufcient space
for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE
RDV1 03/02/17 Preliminary release
RDV2 20/04/17 silkscreen and description

EGE-UHD-EXTIP-KVM
HDMI / VGA over IP Extender with scaler and KVM functions
CONTENTS
1. Introduction.........................................................................1
2. Applications ........................................................................1
3. Package Contents ..............................................................1
4. System Requirements........................................................2
5. Features...............................................................................2
6. Operation Controls and Functions ...................................4
6.1 Transmitter's Front Panel ...............................................4
6.2 Transmitter's Rear Panel ................................................6
6.3 Receiver's Front Panel ...................................................7
6.4 Receiver's Rear Panel....................................................9
6.5 WebGUI (to be updated) ..............................................10
7. Connection Diagram ........................................................17
8. Support Timing & Audio Table .......................................18
9. Specications ...................................................................22

EGE-UHD-EXTIP-KVM
HDMI / VGA over IP Extender with scaler and KVM functions
1
1. INTRODUCTION
This 4K UHD Multi-Function Extender with KVM over TCP/IP allows you to
transmit HDMI or VGA signals over CAT5e/6/7 network cable. This extender
supports the transmission of Ultra High-Denition signals (up to 4K@30Hz
YUV 4:4:4 or 4K@60Hz YUV 4:2:0) along with audio and USB up to 100m
on a single cable. The transmission distance can be further extended (up
to 100m per segment) by using gigabit network switches allowing the user
to cascade the system without signal loss or introducing delay. It is also
possible to have the Transmitter operate in multicast mode, allowing you
to send a single AV signal to a virtually multi number of Receivers within
the same local network. This system is perfect for both residential and
commercial installation environments. This system also features bi-directional
IR and RS-232 pass-through, analog line level in/out, and a microphone
input (on the Receiver), providing the user with a variety of audio options.
The USB functionality allows the system to act like a remote USB hub which,
when combined with the VGA input/output feature, provides a exible remote
KVM platform. Conguration information is provided via On Screen Display
(OSD) and control is by WebGUI and front panel controls.
2. APPLICATIONS
• HDMI, USB, Audio, RS-232 Extender
• Broadcasting system over single CAT5e/6/7
• Multimedia display on a large number of displays via multi-cast
• Hotel or convention center display multi-monitor broadcast and multi-data
sharing
• Long distance data sending with cascade
• Matrix network system
• System control over RS-232 and equipment control over IR
• Remote KVM control of a system
3. PACKAGE CONTENTS
• 1 x HDMI/USB/RS-232/IR over single CAT5e/6/7 Transmitter
• 1 x HDMI/USB/RS-232/IR over single CAT5e/6/7 Receiver
• 1 x 5V/2.6A DC Power Adaptor

EGE-UHD-EXTIP-KVM
HDMI / VGA over IP Extender with scaler and KVM functions
EGE-UHD-EXTIP-KVM
HDMI / VGA over IP Extender with scaler and KVM functions
2
• 1 x 5V/4A DC Power Adaptor
• Operation Manual
4. SYSTEM REQUIREMENTS
• HDMI or VGA source equipment such as media players, video game
consoles PCs or set-top boxes.
• HDMI or VGA receiving equipment such as HDTVs, monitors or audio
ampliers.
• Analog audio receiving equipment such as headphones, audio ampliers
or powered speakers.
• A Gigabit Ethernet network switch with jumbo frame support is required.
• A Gigabit Ethernet switch with “IGMP snooping” is required for proper
multicast support.
• 8K jumbo frames are strongly recommended.
Note: The text may displayed incompletely once uses PC as source at
resolution of 4K2K@60 YUV420.
5. FEATURES
• HDMI 2.0 and DVI 1.0 compatible, HDCP 2.2/1.4 compliant
• 1×HDMI input and output, 1×VGA input and output & 1×VGA bypass
output
• Video, audio and control transmission over TCP/IP
• HDMI input resolutions up to 4K@60Hz (YUV 4:2:0) or 4K@30Hz (YUV
4:4:4)
• HDMI output resolutions up to 4K@30Hz (YUV 4:4:4)
• 4K@50/60Hz (YUV 4:2:0) sources are automatically converted to
4K@25/30Hz (YUV 4:4:4) for output
• Supports pass-through of audio formats including LPCM 2.0/5.1/7.1,
Bitstream, and HD Bitstream
• Audio line in on Transmitter sends audio to the line out on connected
Receivers
• Microphone input on Receiver for transmission to the Transmitter
• Supports USB keyboard and mouse extension

EGE-UHD-EXTIP-KVM
HDMI / VGA over IP Extender with scaler and KVM functions
3
• Supports IR and RS-232 bypass
• Device has an info OSD and can be controlled via WebGUI and front
panel controls

EGE-UHD-EXTIP-KVM
HDMI / VGA over IP Extender with scaler and KVM functions
EGE-UHD-EXTIP-KVM
HDMI / VGA over IP Extender with scaler and KVM functions
4
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Transmitter's Front Panel
POWER
LINK
RS-232
ISP
SEL
IR
OUT
IRLINK
MODE
RESET ISP
VGA
LOOPBACK
IR
IN
POWER
RS-232
ISP
SEL
IR
OUT
RESET
IR LINK MODE ISP VGA
LOOPBACK
LINK
IR
IN
3 4 5 6 7 8 9 10 11 12
21
1POWER LED: This LED will ash BLUE while the unit is powering on
and will illuminate solid BLUE once it is ready to be used.
2LINK LED:
a. If the Transmitter has no network connection the LINK LED will not
illuminate.
b. While the Transmitter is attempting to establish a connection with
a Receiver the LINK LED will ash ORANGE.
c. When the Transmitter has established a stable connection with a
Receiver the LINK LED will illuminate in solid ORANGE.
3RS232 IN: Connect directly to your PC/laptop to send commands to RS-
232 devices connected to the Receiver. The baud rate is congurable,
but the default baud rate is 115200. When the Transmitter is in multicast
mode every connected Receiver unit can send RS-232 commands to the
Transmitter and commands sent from the Transmitter side will be sent to
all associated Receivers.
4ISP SEL: Switch this dip to entering ISP mode. (SOP to be updated)
5IR OUT: Connect to the provided IR Blaster to transmit IR signals to
devices within direct line-of-sight of the IR Blaster.
6IR IN: Connect to the provided IR Extender to extend the IR control
range of remotely located devices. Ensure that the remote being used is

EGE-UHD-EXTIP-KVM
HDMI / VGA over IP Extender with scaler and KVM functions
5
within direct line-of-sight of the IR Extender.
7IR: Accepts IR signals for control of this unit only.
8LINK:
The link status will be disabled and enable after press button.
Quick Function Keys:
1. Reset to default (auto IP & multicast) mode: Press and hold this button
when powering the unit on until both the POWER and LINK lights are
blinking. Once both lights are blinking you can power the unit off and
back on and it will be in the default auto IP and multicast modes. The
IP address will be assigned automatically within the 169.254.xxx.xxx
address range.
2. Loopback function disabled: presses the link button for three seconds,
the loopback function will be disabled.
9MODE:
Selects to video mode for streaming data. Please continue to
press this button for 3 seconds to setting Anti-Dither mode 1 bit, 2 bit,
or off for ATI Graphic card. Anti-Dithering Mode is design to provide
dithering output. Dithering output is used to make coloring looks better
than it's original color depth. This presents great difculty for Video
Compression to maintain low bandwidth even if the source display seems
static. If the source content does not generate dithering output, please
turn off this function or it will create a blocking effect. The video mode
improves live video smoothly. Normally, this extender set has capability
to automatically nal tune the live video. It is require to access to video
mode for further setting once video come with slightly latency.
10 ISP:
Press this button to entering ISP mode.(SOP to be updated)
11 RESET:
Press this recessed button to reset the unit.
12 VGA LOOPBACK: Connect to an analog VGA monitor to locally view the
connected VGA or HDMI (non-HDCP, 1080p or lower) source.
