GEZE GC 172 User manual

GC 172
Wireless ceiling-mounted
smoke detector
183121 -00
EN Supplementary sheet
1 Brief description of wireless kit
The wireless kit is part of the GEZE hold-open system FA GC
150 or FA GC 160.
The wireless module GC 171, ID 163051, makes wireless
communication possible between the lintel-mounted
smoke switch and the various wireless devices:
àWireless ceiling-mounted smoke detector GC 172, ID 159656
àWireless ceiling-mounted thermal detector GC 173, ID 159657
àWireless input module GC 175, ID 163068 (for the
connection of manual trigger switches or contacts for the
re detector system)
2 Wireless ceiling-mounted smoke
detector GC 172
2.1 Use
The GC 172 is a wireless ceiling-mounted smoke detector for
use in the GEZE hold-open system FA GC 150 or FA GC 160.
Signal transfer from the detector takes place wirelessly. .
A wireless module GC 171 is essential for use of the wire-
less ceiling-mounted smoke detector GC 172.
Smoke detectors detect smoke. They work using the light
scatter principle. A light transmitter and a light receiver
are arranged in the measuring chamber in such a way that
no light meets the receiver in the normal case. If there are
suspended particles (smoke) in the measuring chamber,
these scatter part of the light onto the receiver, which
2.3 Technical data
Wireless ceiling-mounted smoke ID 159656
detector GC 172 comprising: Base GC 170 B
Wireless smoke detector GC 002 F
Main battery and slave battery
Wireless smoke detector GC 002 F ID 163044
Battery set (spare) ID 163228
Main battery Type CR 123A (3 V DC)
Slave battery Type CR 2032A (3 V DC)
Colour white, RAL 9016
Dimensions (with base, dia. x H) 110 mm x 65 mm
Functional principle Scatter light, adaption of the alarm threshold, no alarm saving (self-resetting as soon as there is no
more smoke in the measuring chamber)
Insect grid prevents insects getting into the measuring chamber.
Installation position Ceiling mounting
IP rating (in accordance with EN 60529) IP20, only for dry areas
Ambient temperature -5°C to 50°C
Detector test Alarm actuation
- using test magnet near the magnetic sensor (GEZE logo)
- using test aerosol
The detector test using a test magnet tests the electrical components. The detector test which
forms part of the regular testing of the
hold-open system must be carried out using a test aerosol
Service life main battery 5 years
Signal transfer period 60 s
Antenna integrated
Frequency range 868.15 MHz to 869.85 MHz
Range 10 m (100 m in space)
Quantity Frequency channels 7
Modulation technique FSK (frequency shift keying)
Radiated power 5 dBm (3 mW)
1
2
CR2032 CR123A
8
6
7
5
3
4
60
50
9
1 Magnetic sensor for testing (behind the GEZE logo)
2 LED for displaying state
3 Set-up switch
4 Sabotage contact
5 Battery compartment
6 Main battery
7 Slave battery
8 Battery compartment cover
9 Base
2.4 Signalling
State, event LED for displaying state
Switch on
after removal of the insulation lm or after
the main battery has been inserted
ashes 1 x green, then red for approx. 1 min, then green
briey, then the LED is o
Start set-up of the wireless connection ashes 2 x green, 1 x yellow, 4 x red
Fault during set-up of the wireless connection red
Operation o
Main battery discharged ashes yellow (0.1 s on – 5 s o)
Slave battery discharged ashes green (0.1 s on – 5 s o)
Main and slave batteries discharged ashes yellow/green alternately (0.1 s on – 5 s o)
Other faults ashes yellow/green alternately (0.5 s o each)
Alarm ashes red (0.5 s on – 0.5 s o)
converts this into an electric signal.
In other words, a smoke detector not only detects smoke
but all other suspended particles and responds sensitively
to soiling.
2.2 Protection of the smoke detector from
soiling
àDo not remove the dust protection cap from the smoke
detector until commissioning is about to take place.
àAfter the smoke detector has been installed and the
dust protection removed, make sure no dust gets into
the measuring chamber. This leads to increased soiling
and can signicantly shorten the service life of the
smoke detector.
àThe measuring chamber of a smoke detector must not
be opened.
Heed the document for the hold-open system FA GC 150
or FA GC 160 - Instructions for the installation, commis-
sioning, operation and maintenance
, see www.geze.com.
