www.ghibliwirbel.com
Professional Cleaning Machines Since 1968
ENGLISH -
2
Contents
Technical data....................................................................................................EN-3
1.1 Introduction................................................................................................EN-5
2.1 Getting to know the machine....................................................................EN-5
3.1 Unpacking...................................................................................................EN-5
3.1.a Standard machine equipment ............................................................EN-5
4.1 Assembling the components....................................................................EN-5
4.1.a Wiper assembly..................................................................................EN-5
4.1.b Brush assembly..................................................................................EN-5
4.1.c Installing and connecting the batteries...............................................EN-6
5.1 Charging the battery..................................................................................EN-6
5.1.a Charging the battery using the on board battery charger (if present) EN-6
5.1.b Charging the battery using an external battery charge ......................EN-7
6.1 Control panel..............................................................................................EN-7
6.2 Working cycle example .............................................................................EN-8
7.1 Filling the tank ...........................................................................................EN-8
8.1 Operation....................................................................................................EN-8
8.1.a Checks before use..............................................................................EN-8
8.1.b Preparing the machine and choosing the cycle ..................................EN-8
8.1.c Using the machine ..............................................................................EN-9
8.1.d End of use and switching off...............................................................EN-9
8.1.e Maximum recovery tank water level alarm..........................................EN-9
9.1 Draining the recovery water....................................................................EN-10
10.1 Maintenance and cleaning ......................................................................EN-10
10.1.a Emptying and cleaning the clean water tank ..................................EN-10
10.1.b Cleaning the recovery water tank ...................................................EN-10
10.1.c Cleaning the squeegee ................................................................... EN-11
10.1.dCleaningthecleanwaterlter......................................................... EN-11
10.1.e Replacing the brush........................................................................ EN-11
10.1.f Replacing the squeegee rubber blades ......................................... EN-11
10.1.g Cleaning the recovery water tank ...................................................EN-12
10.1.h Replacing the fuses ........................................................................EN-12
10.1.i Wiper adjustment ............................................................................EN-12
10.1.lBatterychargeranddigitalinstrumentconguration.......................EN-13
Troubleshooting ..............................................................................................EN-14
11.1 Warranty ...................................................................................................EN-15
Wiring diagram ................................................................................................EN-16
FR 30 SM45 Touch basic..........................................................................EN-16
Man_FR30SM45TOUCH_49022000_1ed_04-2017.indd.indd 2 13/04/17 10:27
