Giani ValetPro VPH14 User manual

VPH14 07042017
Cordless Rechargeable Hand Held
Vacuum Cleaner
Instruction Manual
Model Ref: VPH14

Thank you for choosing the ValetPro by Giani Cordless Rechargeable Hand
Held Vacuum Cleaner. All products brought to you by Giani are manufactured to
the highest standards of performance and safety.
Before use, please read this manual carefully. It gives important instructions
about safety, use and maintenance of your appliance.
Remove all packaging material. You may wish to keep the packaging for future
use or storage of your appliance. Alternatively, dispose of accordingly.
Index
Important Safety Information................................02
Warning................................................................ 03
Product Overview................................................. 04
Technical Information........................................... 04
Before First Use................................................... 05
Assembling Your Vacuum Cleaner....................... 05
Using The Accessories.........................................07
Emptying The Dust Tank...................................... 07
Cleaning The Filters............................................. 08
After Sales Support.............................................. 10
Product Guarantee...............................................10
01

Important Safety Information
WARNING - To reduce the risk of re, electric shock, or
injury:
• DO NOT run the appliance over the charger cable.
• DO NOT operate the system if the appliance or any other
part of the system has been dropped or damaged.
• DO NOT disassemble or attempt to repair the vacuum
cleaner.
• DO NOT pick up any ammable or combustible liquids or
use in areas where they may be present.
• DO NOT pick up anything that is burning or smoking such
as cigarettes, matches or hot ashes.
• DO NOT use the vacuum without the dust cup lter in
place.
• DO NOT allow the appliance to be used as a toy. Close
attention is necessary when used near children, pets or
plants.
• DO NOT unplug the charger by pulling on cord.
• DO NOT handle the charger or vacuum with wet hands.
• DO NOT put any objects into openings.
• DO NOT use with any opening blocked.
• DO NOT use with mains extensions, external timer or
remote control systems
• Keep free of dust, lint, hair and anything else that may
reduce air ow.
• Keep hair, loose clothing, ngers and all parts of the body
away from opening and moving parts.
02

• Use extra care when cleaning on stairs.
• Only use the appliance for its intended use.
• Keep the charging cable away from any heated surfaces
• Store your appliance indoors, in a cool, dry area.
• Keep your work area well lit.
• Keep the end of the stick, and the attachments away
from your face and body.
• Use only on dry surfaces.
• Using improper voltage may result in damage to the
motor and possible injury to the user. Correct voltage is
listed on the rating label.
• Keep the appliance and its charger out of reach of
children.
• To protect against a risk of electric shock, do not immerse
any part of the appliance in water or other liquids.
• This appliance is intended only for household use. Follow
all user instructions in this manual.
• Use only as described in this manual. Only use the
manufacturer’s recommended accessories.
WARNING:
• DO NOT operate the vacuum cleaner too close to
heaters or radiators.
• Before inserting the charger plug into the wall outlet,
make sure that your hands are dry.
• Before you start vacuuming, make sure to remove large
or sharp objects that might damage the dust cup lter.
03

Product Overview
1. On / Off Power / Speed Button
2. Dust Tank Release Button
3. Dust Tank Lid
4. Handle
5. Dust Tank
6. Accessory Adaptor Release Button
7. Dust Tank Empty Switch
8. Telescopic Extension Tube
9. Floor Head Brush
10. Crevice Tool
11. Upholstery Brush
12. Accessory Adaptor
13. Charging Adaptor
14. Brush Head Height
Adjuster Switch
1
4
5
7
6
3
2
8
910
11 12
Technical Information
Voltage 22.2V
Battery Capacity 2000mA
Rated Power 90W
Suction Power 25W
Vacuum 8Kpa
Air Flow 0.8m3/Min
Dust Tank Capacity 0.8L
Noise 75dB
04
13
14

DO NOT PLUG CHARGER INTO THE MAINS ELECTRICITY SUPPLY
UNTIL FULLY ASSEMBLED
Your vacuum cleaner is disassembled
when unpacked (Fig 1)
1. Connect the accessory adapter (12)
into the air inlet (Fig 2)
2. Connect the telescopic extension
tube to the accessory adaptor (Fig 3)
3. Connect the oor head brush to the
other end of the telescopic extension
tube. (Fig 4)
Before First Use
Before using your vacuum cleaner for the rst time, wipe all parts with a
soft damp cloth
Assembling Your Vacuum Cleaner
1
2
3
4
05

4. Your vacuum is now fully assembled
(Fig 5).
5. Insert the DC end of the charger into
the charging socket on the main unit
body (Fig 6).
6. Plug the charger into a plug socket
and switch on the mains supply
(Fig 7). The red indicator light on the
main unit will ash when the unit is
being charged. After charging for 3
hours, the indicator light will be solid
green and on all the time, and this
means the device is fully charged.
5
6
7
06

Using The Accessories
The crevice tool and upholstery brush can be connected directly to the
accessory adaptor (Fig 8) or to the telescopic extension tube. (Fig 9)
ALWAYS ensure when changing accessories the appliance is
switched off
Emptying The Dust Tank
8 9
1. Hold the vacuum cleaner over the
dustbin, press the dust tank empty
switch. (Fig 10) The bottom of the dust
tank will open, emptying the contents
into the dustbin. Gently shake the
vacuum to remove any remaining
dust.
2. To close the dust tank, push the empty
hatch up until it clicks and locks back
into position.
3. Alternatively, you can remove the dust
tank from the main vacuum cleaner
body by holding both the main body
and the dust tank and pressing the
dust tank release button. (Fig 11)
4. The dust tank can easily be carried to
the dustbin to be emptied.
10
11
Dust Tank Empty Switch
07

5. Ret the dust tank to the main body by lining up the hook on the
main body with the slot on the dust tank, slide the dust tank down,
line up the locking catch on the dust tank lid with the slot at the top
of the main body and push together until it clicks and locks back into
position.
Cleaning The Filters
To maintain the performance of the vacuum cleaner, ensure the lters
are regularly cleaned.
Never use the vacuum cleaner without the lters in place.
Always unplug the appliance from the mains supply before performing
any cleaning or user maintenance.
1. Remove the dust tank from the main
body of the vacuum cleaner. (Fig 12)
2. Remove the dust tank lid by twisting it
anticlockwise and lifting it off. (Fig 13)
3. Lift out the HEPA lter and dust tank
central lter. (Fig 14)
08
12
13
14

4. Remove dust, dirt and debris from the
lters. This should be performed on a
regular basis. (Fig 15)
5. All lters can be cleaned under a
running tap with warm water. (Fig 16)
6. Once clean allow to dry for 24 hours
before replacing in the vacuum
cleaner. (Fig 17)
6. Do not use external heat sources to
dry the lters as they will become
damaged.
7. Never use the vacuum cleaner with
wet lters.
8. To re-t the lters reverse the
procedure performed when removing
the lters.
09
16
17
15

After Sales Support
If you need help using your Vacuum Cleaner, please contact Giani Ltd:-
• Telephone: [phone]
• Email: [email protected]
• Website: www.gianiuk.co.uk
(Replacement instruction manuals are available to download).
Product Guarantee (UK Only)
If your appliance ceases to function within 1 year from the date of purchase,
the retailer will replace it free of charge, provided:
• You have not misused, neglected or damaged it
• It has not been modied (except by Giani Ltd)
• It was not purchased second hand
• It has not been used commercially
• You have not tted a plug incorrectly
• You can supply proof of purchase, indicating the price you paid and
where and when the appliance was purchased.
This guarantee does not affect your statutory rights.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE APPLIANCE IN
ACCORDANCE WITH EC DIRECTIVE 2002/96/EC
At the end of its working life, the appliance must NOT be disposed of as urban waste.
It must be taken to a special local authority differentiated waste collection centre or to
a dealer providing this service.
Disposing of a household appliance separately avoids possible negative
consequences for the environment and health deriving from inappropriate disposal
and enables the constituent materials to be recovered to obtain signicant savings in
energy and resources. As a reminder of the need to dispose of household appliances
separately, the product is marked with a crossed-out wheeled dustbin.
2011/65/EU
10

Giani Limited - SK2 6RH
[email protected]
Are you having problems with your cleaner?
Do you require a replacement filter?
Do you require spare parts?
Email - [email protected]
Website - www.gianiuk.co.uk
Before returning this item to your place of purchase
Please contact Giani at:
