Giani ValetPro VPZL9032Q User manual

VPZL9032Q 07042017
2 in 1 Supercordless
Vacuum Cleaner
Instruction Manual
Model Ref: VPZL9032Q

01
Thank you for choosing the ValetPro by Giani 2 in 1 Supercordless Vacuum
Cleaner. All products brought to you by Giani are manufactured to the highest
standards of performance and safety.
Before use, please read this manual carefully. It gives important instructions
about safety, use and maintenance of your appliance.
Remove all packaging material. You may wish to keep the packaging for future
use or storage of your appliance. Alternatively, dispose of accordingly.
Index
Important Safety Information................................02
Features............................................................... 03
Product Overview................................................. 04
Technical Information........................................... 04
Before First Use................................................... 05
Assembling Your Vacuum Cleaner....................... 05
Charging Your Vacuum Cleaner........................... 06
Using Your Upright Vacuum Cleaner.................... 06
Using your Handheld Vacuum Cleaner................ 07
Emptying The Dust Tank...................................... 08
Troubleshooting................................................... 09
After Sales Support.............................................. 10
Product Guarantee...............................................10

Important Safety Information
WARNING - To reduce the risk of re, electric shock, or injury:
• This vacuum cleaner is for domestic use only. It should not be used
for commercial purposes.
• Do not use outdoors or on wet surfaces.
• Only use the appliance for its intended use. Giani Ltd will not accept
liability if the appliance is subject to improper use or in the event of
failure to comply with these instructions.
• Do not handle the charger with wet hands.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, if they have been given
supervision or instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
• Children must not play with this appliance.
• Cleaning and user maintenance shall not be made by children unless
they are older than 8 years old and supervised.
• Keep the appliance and its cord out of reach of children less than 8
years of age.
• This product is not a toy.
• Do not use the vacuum cleaner if any parts appear to be faulty,
missing or damaged.
• Do not use the vacuum cleaner if it has been dropped or damaged in
any way.
• Ensure all parts including the dust tank are securely attached before
using or moving the vacuum cleaner.
• Do not leave the vacuum cleaner unattended when connected to the
mains supply or in use.
• Always switch off the vacuum cleaner by the power switch before
removing the plug from the mains supply before carrying out any
cleaning, performing user maintenance or changing accessories.
• Do not disconnect the charger from the mains supply by pulling on
the cord, switch it off and remove the plug by hand.
• Keep hair, loose clothing, ngers and all parts of the body away from
openings of the vacuum cleaner.
02

03
• Do not use with any of the openings blocked; keep free of
dust, lint, hair and anything that may reduce airow.
• Take extra care when vacuuming on the stairs.
• Do not use to pick up liquids.
• Do not use to pick up ammable or combustible materials.
• Do not use to pick up hot or burning objects such as a
cigarettes, matches or hot ashes.
• Do not use to pick up building materials such as plaster,
cement, brick dust etc - this will damage the motor.
• Do not use the vacuum cleaner to pick up large, hard or sharp
objects such as glass, nails, screws, coins etc - This will
damage the vacuum cleaner.
• Only use the attachments / accessories supplied with the
product or recommended by Giani.
• Do not use without the dust tank and lters in place.
• Ensure that the dust tank is emptied and the lters cleaned
regularly to maintain the performance of the vacuum cleaner.
• Do not store in direct sunlight or high humidity conditions.
• Please note the battery should not be kept in temperatures
above 40°C
Features
22.2V Rechargeable Lithium Ion Battery.
0.5L Dust Tank.
Motorised Floor Brush With LED Lighting.
Multifunctional - Upright - Hand Held.
Foldable Handle (For Easy Storage).
35 minutes operating time.

04
Product Overview
1. Upright ON/OFF Button
2. Handle
3. Button for folding Handle
4. Hand Held Cleaner Release Button
5. Hand Held Cleaner
6. Hand Held ON/OFF Button
7. Dust Tank Release Button
8. Main Body
9. Floor Brush Head
10. HEPA Filter
11. Plastic Filter
12. Dust Tank
13. Charging Base
14. Upholstery Brush
15. Crevice Tool
16. Charging Adaptor
Technical Information
Rated Power 22.2V
Suction Power 10.5W
Vacuum 5Kpa
Battery Capacity 2150mA
Dust Tank Capacity 0.5L

05
Before First Use
• Before using your vacuum cleaner for the rst time, wipe all parts
with a soft damp cloth
Assembling Your Vacuum Cleaner
DO NOT PLUG CHARGER INTO THE MAINS ELECTRICITY SUPPLY
UNTIL FULLY ASSEMBLED
1. Connect the oor brush head
into the main body (Fig 1).
2. Push the main body into the
oor brush head until correctly
connected (Fig 2).
1
2

06
1. Make sure unit is powered off before
charging it.
2. Connect the charger into the charging
stand. Then plug the charger into the
socket (Fig 3).
3. When the unit is charging, the LED
indicator will icker once every 2
seconds, when fully charged, the LED
indicator will have a solid light. If there is
fault on charge circuit, the LED indicator
will icker twice every second (Fig 4).
4. When unit is fully charged, the electric
circuit control will stop charging
automatically to protect the battery.
5. It is normal that the charger becomes a
little hot when in use
6. After every use, please charge the
vacuum to ensure it has sufcient
power. We recommend not leaving the
vacuum charging if it is not going to be
used for a long period of time.
1. Remove the unit from the charging
stand.
2. Pull the handle into position (Fig 5).
3. Press the on/off button to switch on your
vacuum (Fig 6).
Charging Your Vacuum Cleaner
THE ORIGINAL CHARGER FOR THE UNIT MUST BE USED
MAKE SURE THE POWER VOLTAGE IS THE SAME AS THE VOLTAGE
LISTED ON THE RATING LABEL
3
4
5
6
Using Your Upright Vacuum Cleaner
ON/OFF

1. Press the release button and take
out the handheld cleaner (Fig 7).
2. Attach the crevice tool or
Upholstery brush into the end of the
handheld cleaner (Fig 9 & 10).
3 . Press the on/off button to switch on
your vacuum (Fig 11).
7
07
Using Your Handheld Vacuum Cleaner
10
9
11

08
Emptying The Dust Tank
1. Press the dust tank button on the
hand-held vacuum cleaner
(Fig 12).
2. Remove the dust tank (Fig 13).
3. Take out the plastic lter and
HEPA lter, as shown (Fig 14).
4. Empty the dust tank, as shown
(Fig 15).
12
13
14
15

Troubleshooting
Issue Possible Cause Solution
The vacuum does not work The battery has not been
charged
Charge the battery
The vacuum suction power
is poor
Filters are blocked
Dust tank is full
Dust tank not tted correctly
Clear and wash lters
Empty the dust tank
Reconnect dust tank
Motorised brush head
doesn’t move
Motorised brush head is jammed
by foreign objects
Remove the motorised brush
head and clear any foreign
objects then restart the
vacuum
BEFORE CHECKING TURN OFF AND UNPLUG VACUUM CLEANER
09

After Sales Support
If you need help using your Vacuum Cleaner, please contact Giani Ltd:-
• Telephone: [phone]
• Email: [email protected]
• Website: www.gianiuk.co.uk
(Replacement instruction manuals are available to download).
Product Guarantee (UK Only)
If your appliance ceases to function within 1 year from the date of purchase,
the retailer will replace it free of charge, provided:
• You have not misused, neglected or damaged it
• It has not been modied (except by Giani Ltd)
• It was not purchased second hand
• It has not been used commercially
• You have not tted a plug incorrectly
• You can supply proof of purchase, indicating the price you paid and
where and when the appliance was purchased.
This guarantee does not affect your statutory rights.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE APPLIANCE IN
ACCORDANCE WITH EC DIRECTIVE 2002/96/EC
At the end of its working life, the appliance must NOT be disposed of as urban waste.
It must be taken to a special local authority differentiated waste collection centre or to
a dealer providing this service.
Disposing of a household appliance separately avoids possible negative
consequences for the environment and health deriving from inappropriate disposal
and enables the constituent materials to be recovered to obtain signicant savings in
energy and resources. As a reminder of the need to dispose of household appliances
separately, the product is marked with a crossed-out wheeled dustbin.
2011/65/EU
10

Giani Limited - SK2 6RH
[email protected]
Are you having problems with your cleaner?
Do you require a replacement filter?
Do you require spare parts?
Email - [email protected]
Website - www.gianiuk.co.uk
Before returning this item to your place of purchase
Please contact Giani at:
