GIGA-BYTE TECHNOLOGY MU70-SU0 User manual

MU70-SU0
LGA2011 sockets R3 motherboard for Intel®E5-1600 V3/V4/E5-2600 V3/V4 series
processor
User's Manual
Rev. 1002

Copyright
©2016 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specifications and features in this manual may be made by GIGABYTE
without prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or
published in any form or by any means without GIGABYTE's prior written permission.
Documentation Classications
In order to assist in the use of this product, GIGABYTE provides the following types of documentations:
For detailed product information, carefully read the User's Manual.
For more information, visit our website at:
http://b2b.gigabyte.com
You are a professional?
Get an access to our complete source of sales, marketing & technical materials at:
http://reseller.b2b.gigabyte.com
https://www.facebook.com/gigabyteserver

- 3 -
Table of Contents
Box Contents...................................................................................................................5
MU70-SU0 Motherboard Layout......................................................................................6
Block Diagram .................................................................................................................9
Chapter 1 Hardware Installation ...................................................................................10
1-1 Installation Precautions.................................................................................. 10
1-2 ProductSpecications.................................................................................... 11
1-3 Installing the CPU and CPU Cooler ............................................................... 13
1-3-1 Installing the CPU...................................................................................................13
1-3-2 Installing the CPU Cooler .......................................................................................16
1-4 Installing the Memory..................................................................................... 17
1-4-1 FourChannelMemoryConguration .....................................................................17
1-4-2 Installing a Memory ...............................................................................................18
1-4-3 DIMM Population Table .........................................................................................18
1-5 Back Panel Connectors.................................................................................. 19
1-6 Internal Connectors........................................................................................ 20
1-7 Jumper Settings ............................................................................................. 33
Chapter 2 BIOS Setup ..................................................................................................39
2-1 The Main Menu .............................................................................................. 41
2-2 Advanced Menu ............................................................................................. 44
2-2-1 Serial Port Console Redirection .............................................................................45
2-2-2 PCI Subsystem Settings.........................................................................................49
2-2-2-1 PCI Express Settings..............................................................................................51
2-2-3 Network Stack ........................................................................................................53
2-2-4 CSMConguration .................................................................................................54
2-2-5 PostReportConguration ......................................................................................56
2-2-6 Trusted Computing .................................................................................................57
2-2-7 USBConguration..................................................................................................58
2-2-8 ChipsetConguration.............................................................................................59
2-9 SIOConguration...................................................................................................60
2-2-10 iSCSIConguration................................................................................................64
2-3 Intel RC Setup Menu...................................................................................... 65
2-3-1 ProcessorConguration.........................................................................................66
2-3-1-1 Pre-SocketConguration .......................................................................................69
2-3-2 AdvancedPowerManagementConguration........................................................70
2-3-2-1 CPU P State Control...............................................................................................71
2-3-2-2 CPU C State Control ..............................................................................................72

- 4 -
2-3-2-3 CPU T State Control...............................................................................................73
2-3-3 CommonRefCodeConguration ...........................................................................74
2-3-4 QPIConguration...................................................................................................75
2-3-5 MemoryConguration ............................................................................................77
2-3-5-1 Memory Topology ...................................................................................................79
2-3-5-2 Memory Thermal ....................................................................................................80
2-3-5-3 Memory Map...........................................................................................................81
2-3-5-4 MemoryRASConguration....................................................................................82
2-3-6 IIOConguration ....................................................................................................83
2-3-6-1 IOATConguration .................................................................................................84
2-3-6-2 Intel VT for Directed I/O (VT-d) ..............................................................................85
2-3-7 PCHConguration.................................................................................................86
2-3-7-1 PCH Devices ..........................................................................................................87
2-3-7-2 PCHsSATAConguration ......................................................................................88
2-3-7-2-1 SATA Mode Options..............................................................................................91
2-3-7-3 PCHSATAConguration........................................................................................93
2-3-7-3-1 SATA Mode Options..............................................................................................96
2-3-7-4 USBConguration..................................................................................................98
2-3-8 MiscellaneousConguration ..................................................................................99
2-3-9 ServerMEConguration ......................................................................................100
2-3-10 Runtime Error Logging .........................................................................................101
2-3-10-1Whea Setting ........................................................................................................102
2-3-10-2Memory Error Enabling.........................................................................................103
2-3-10-3PCI/PCI-E Error Enabling .....................................................................................104
2-4 Server Management Menu........................................................................... 105
2-4-1 System Event Log ................................................................................................107
2-4-2 View FRU Information ..........................................................................................108
2-4-3 BMCnetworkconguration ..................................................................................109
2-5 Security Menu .............................................................................................. 110
2-5-1 Secure Boot menu ............................................................................................... 111
2-5-1-1 Key Management ...............................................................................................112
2-6 Boot Menu.................................................................................................... 114
2-7 Save & Exit Menu......................................................................................... 116
2-8 BIOS POST Codes ...................................................................................... 118
2-9 BIOS POST Beep code................................................................................ 122
2-9-1 PEI Beep Codes...................................................................................................122
2-9-2 DEX Beep Codes .................................................................................................122
2-10 BIOS Recovery Instruction........................................................................... 123
Chapter 3 Appendix ....................................................................................................124
3-1 Regulatory Statements................................................................................. 124

- 5 -
Box Contents
Motherboard
Driver CD
Two SATA cables
I/O Shield
•The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
•The motherboard image is for reference only.

- 6 -
MU70-SU0 Motherboard Layout
1 2 3 4 5 6 7 8 9
11
10
13
12
14
15
16
17
18
22
23
24
25
26
27
192021282930
31
323334353638 37
39
40
41
42
44
45
4250
51
52
53
54
55
56 57
58
60
6665 67
47
46
64
63
62 61
59
48
49
43

- 7 -
Item Code Description
1 IPMB IPMB connector
2 SYS_FAN4 System fan connector#4
3 SW_ID ID switch button
4 MLAN BMC Management LAN port
5 USB3_LAN1 LAN1 port (top) / USB 3.0 ports (bottom)
6 USB3_LAN2 LAN2 port (top) / USB 3.0 ports (bottom)
7 LAN_3_4 LAN ports
8 COM1_VGA1 Serial port (top)/VGA port (buttom)
9 PS2_USB2 PS/2 connector (top)/USB 2.0 ports (buttom)
10 ATX1 24 pin main power connector
11 PMBUS PMBus connector
12 CPU_FAN CPU fan connector
13 DIMM_P0_A0 Channel 1 slot 0
14 DIMM_P0_A1 Channel 1 slot 1
15 DIMM_P0_A2 Channel 1 slot 2
16 DIMM_P0_B0 Channel 2 slot 0
17 DIMM_P0_B1 Channel 2 slot 1
18 DIMM_P0_B2 Channel 2 slot 2
19 SYS_FAN1 System fan connector#1
20 P1_CPU0 8 pin power connector
21 CPU0 Intel LGA2011 Socket R3
22 DIMM_P0_D2 Channel 4 slot 2
23 DIMM_P0_D1 Channel 4 slot 1
24 DIMM_P0_D0 Channel 4 slot 0
25 DIMM_P0_C2 Channel 3 slot 2
26 DIMM_P0_C1 Channel 3 slot 1
27 DIMM_P0_C0 Channel 3 slot 0
28 SYS_FAN2 System fan connector#2
29 SYS_FAN3 System fan connector#3
30 SATA_SGP1 SATA SGPIO header
31 MSATA1 mSATA connector
32 SATA_0_1 SATA 3 6Gb/s connectors
33 SATA_2_3 SATA 3 6Gb/s connectors
34 SSATA_0_1 SATA 3 6Gb/s connectors
35 SSATA_2_3 SATA 3 6Gb/s connectors
36 TPM TPM module connector
37 SATA_DOM SATA port 8 DOM support jumper
38 SSATA_SGP1 sSATA SGPIO header
39 SATA4 SATA 3 6Gb/s connector
40 BP_1 HDD back plane board header

- 8 -
41 CASE_OPEN Case open intrusion alert header
42 USB3_A Type A USB 3.0 connector
43 F_USB3 USB3.0 header
44 SW_RAID1 Software RAID Key jumper
45 BIOS_PWD Clearing Supervisor Password jumper
46 PMBUS_SEL PMbus select jumper
47 HSME_SEL Host select jumper
48 LAN4_ACT1 LAN port 4 active LED header
49 FUSB_2 USB 2.0 header
50 COM2 Serial port cable header
51 LAN3_ACT1 LAN port 3 active LED header
52 FP_1 Front panel header
53 S3_MASK S3 Power On Select jumper
54 BMC_FRB Force to Stop FRB Timer jumper
55 PCIE_1 PCI Express x4 slot
56 PCIE_2 PCI Express x16 slot
57 LED_BMC1 BMCrmwarereadinessLED
58 CLR_CMOS Clear CMOS jumper
59 BAT Battery socket
60 BIOS_WP BIOS write protect jumper
61 BIOS_RCVR BIOS recovery jumper
62 ME_RCVR ME recovery jumper
63 ME_UPDATE ME update jumper
64 PCIE_3 PCI Express x16 slot
65 PCIE_4 PCI Express x16 slot (Running at x8/Shared
bandwidth with MEZZ_1)
66 MEZZ_1 Mezzine slot (x4 slot/Proprietary/Running at x4)
CAUTION! If a SATA type hard drive is connected to the motherboard, please ensure the jumper is
closed and set to 2-3 pins (Default setting), in order to reduce any risk of hard disk damage. Please
refer to Page 34 for SATA_DOM jumper setting instruction.

- 9 -
Block Diagram

Hardware Installation - 10 -
1-1 Installation Precautions
The motherboard contains numerous delicate electronic circuits and components which can
become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read
the user's manual and follow these procedures:
• Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or
warranty sticker provided by your dealer. These stickers are required for warranty validation.
• Always remove the AC power by unplugging the power cord from the power outlet before
installing or removing the motherboard or other hardware components.
• When connecting hardware components to the internal connectors on the motherboard,
make sure they are connected tightly and securely.
• When handling the motherboard, avoid touching any metal leads or connectors.
• It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic
components such as a motherboard, CPU or memory. If you do not have an ESD wrist
strap,keepyourhandsdryandrsttouchametalobjecttoeliminatestaticelectricity.
• Prior to installing the motherboard, please have it on top of an antistatic pad or within an
electrostatic shielding container.
• Before unplugging the power supply cable from the motherboard, make sure the power
supply has been turned off.
• Before turning on the power, make sure the power supply voltage has been set according to
the local voltage standard.
• Before using the product, please verify that all cables and power connectors of your
hardware components are connected.
• To prevent damage to the motherboard, do not allow screws to come in contact with the
motherboard circuit or its components.
• Make sure there are no leftover screws or metal components placed on the motherboard or
within the computer casing.
• Do not place the computer system on an uneven surface
.
• Do not place the computer system in a high-temperature environment.
• Turning on the computer power during the installation process can lead to damage to
system components as well as physical harm to the user.
• If you are uncertain about any installation steps or have a problem related to the use of the
product,pleaseconsultacertiedcomputertechnician.
Chapter 1 Hardware Installation

- 11 - Hardware Installation
1-2 Product Specications
CPU Support for Intel®Xeon®E5-1600 V3/V4/E5-2600 V3/V4 series processors in
the LGA2011-3 package
L3 cache varies with CPU
Enhanced Intel SpeedStep Technology (EIST)
Support Intel Virtualization Technology (VT)
Chipset Intel®C612 Express (Wellsburg) Chipset
Memory 12 x DIMM slots
DDR4 memory supported only
Quad channel memory architecture
ECC RDIMM / LRDIMM modules supported
Single and dual rank RDIMM modules up to 32GB supported
3DS LRDIMM modules up to 128GB supported
1.2V modules: 1600/1866/2133/2400 MHz
LAN 4 x Intel®I210 supports GbE LAN ports
Realtek®RTL8211E supports 1 Management LAN 10/100/1000Mpbs LAN port
Expansion Slots 2 x PCI Express x16 slot, running at x16 (Gen3/PCIE_2/PCIE_3)
1 x PCI Express x16 slot, running at x8 (Gen3/PCIE_4/Shard bandwidth with
MEZZ_1)
1 x PCI Express x4 slot, running at x2 (GEN2/PCIE_1)
1 x Mezzine slot, running at x4 (Gen3/MEZZ_1)
Onboard
Graphics ASPEED®AST2400 supports 16MB DDR3 VRAM
Storage Interface Intel® C612 Express controller
9 x SATA3 6Gb/s connectors (SATA_0_1/SATA_2_3/SSATA_0_1/SSATA_2_3/
SATA4)
1 x mSATA3 connector (MSATA1)
Support for Intel RSTe SATA RAID 0/1/5/10
USB Up to 7 USB 3.0 ports (1 Type A connector, 4 on the back panel, 2 additional
ports via the USB brackets connected to the internal USB headers)

Hardware Installation - 12 -
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
13 x SATA3 6Gb/s connectors
1 x mSATA connector
1 x PMBus header
1 x CPU fan header
4 x System fan headers
1 x Front panel header
1 x HDD Back plane borad header
1 x USB 3.0 header
1 x USB 2.0 header
1 x USB 3.0 Type A connector
1 x TPM module connector
1 x Serial port connector
2 x SATA SPGIO headers
1 x IPMB connector
Rear Panel I/O 4 x USB 3.0 ports
2 x USB 2.0 ports
5 x RJ-45 ports (1 x 10/100/1000 dedicated management LAN port)
1 x COM port
1 x VGA port
1 x PS/2 connector
I/O Controller ASPEED®AST2400 BMC chip
Hardware
Monitor
System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU/System fan speed control
* Whether the CPU/system fan speed control function is supported will depend on
the CPU/system cooler you install.
BIOS 1x128Mbitash
AMI BIOS
Form Factor ATX Form Factor; 12 inch x 9.6 inch, 6 layers PCB
*GIGABYTEreservestherighttomakeanychangestotheproductspecicationsandproduct-relatedinformationwithout
prior notice.

- 13 - Hardware Installation
1-3 Installing the CPU and CPU Cooler
1-3-1 Installing the CPU
A. Locate the alignment keys on the motherboard CPU socket and the notches on the CPU.
Read the following guidelines before you begin to install the CPU:
• Make sure that the motherboard supports the CPU.
• Always turn off the computer and unplug the power cord from the power outlet before installing
the CPU to prevent hardware damage.
• Locate the pin one of the CPU. The CPU cannot be inserted if oriented incorrectly. (Or you may
locate the notches on both sides of the CPU and alignment keys on the CPU socket.)
• Apply an even and thin layer of thermal grease on the surface of the CPU.
• Do not turn on the computer if the CPU cooler is not installed, otherwise overheating and
damage of the CPU may occur.
• SettheCPUhostfrequencyinaccordancewiththeCPUspecications.Itisnotrecommended
thatthesystembusfrequencybesetbeyondhardwarespecicationssinceitdoesnotmeetthe
standard requirements for the peripherals. If you wish to set the frequency beyond the standard
specifications, please do so according to your hardware specifications including the CPU,
graphics card, memory, hard drive, etc.
Pin One Corner
of the CPU Socket
LGA2011 CPU
Triangle Pin One Marking on the CPU
Alignment Key
Alignment Key
Notch
Notch
Notch
Notch

Hardware Installation - 14 -
Step 1:
Push the lever closest to the "unlock" marking " "
(below referred as lever A) down and away from
the socket to release it.
Step 4:
HoldtheCPUwithyourthumbandindexngers.Align
the CPU pin one marking (triangle) with the pin one
corner of the CPU socket (or align the CPU notches with
the socket alignment keys) and carefully insert the CPU
into the socket vertically.
B. Follow the steps below to correctly install the CPU into the motherboard CPU socket.
•Before installing the CPU, make sure to turn off the computer and unplug the power cord
from the power outlet to prevent damage to the CPU.
•To protect the socket contacts, do not remove the protective plastic cover unless the CPU is
inserted into the CPU socket. Save the cover properly and replace it if the CPU is removed.
Step 2:
Push the lever closest to the "lock" marking " "
(below referred as lever B) down and away from
the socket. Then lift the lever.
Lever B
Lever A
Step 3:
Gently press lever A to allow the load plate to rise.
Open the load plate. (Note: DO NOT touch the socket
contacts after the load plate is opened.)

- 15 - Hardware Installation
Step 5:
Once the CPU is properly inserted, carefully replace the
load plate. Then secure lever B under its retention tab.
The protective plastic cover may pop off from the load
plate during the process of engaging the lever. Remove
the cover. Save the cover properly and always replace it
when the CPU is not installed.
Lever B
Lever A
Step 6:
Finally, secure lever A under its retention tab to
complete the installation of the CPU.

Hardware Installation - 16 -
1-3-2 Installing the CPU Cooler
Refer to the steps below to correctly install the CPU cooler on the motherboard. (Actual installation process
may differ depending the CPU cooler to be used. Refer to the user's manual for your CPU cooler.)
Please pay more attention when removing the CPU cooler because the thermal grease/tape
between the CPU cooler and CPU may adhere to the CPU. Inadequately removing the CPU cooler
may damage the CPU.
Step 1:
Apply an even and thin layer of thermal grease on the
surface of the installed CPU.
Step 2:
Place the cooler atop the CPU, aligning the four
mounting screws with the mounting holes on the
ILM. (If your cooler has a fan grill which may cause
interference when you tighten the screws, remove it
rstandreplaceitaftertighteningthescrews.)
Step 3:
Use one hand to hold the cooler and the other to
tighten the screws in a diagonal sequence with a
screw driver. Begin tightening a screw with a few
turns and repeat with the screw diagonally opposite
the one you just tightened. Then do the same to the
other pair. Next, fully tighten the four screws.
Step 4:
Finally, attach the power connector of the CPU
cooler to the CPU fan header (CPU_FAN) on the
motherboard.

- 17 - Hardware Installation
1-4-1 Four Channel Memory Conguration
This motherboard provides twelve DDR4 memory sockets and supports Four Channel Technology. After
thememoryisinstalled,theBIOS will automatically detect the specications and capacityofthememory.
Enabling Four Channel memory mode will be four times of the original memory bandwidth.
The four DDR4 memory sockets are divided into four channels each channel has two memory sockets as
following:
Channel 1: DIMM_P0_A0/DIMM_P0_A1/DIMM_P0_A2
Channel 2: DIMM_P0_B0/DIMM_P0_B1/DIMM_P0_B2
Channel 3: DIMM_P0_C0/DIMM_P0_C1/DIMM_P0_C2
Channel 4: DIMM_P0_D0/DIMM_P0_D1/DIMM_P0_D2
1-4 Installing the Memory
Read the following guidelines before you begin to install the memory:
•Make sure that the motherboard supports the memory. It is recommended that memory of the
same capacity, brand, speed, and chips be used.
•Always turn off the computer and unplug the power cord from the power outlet before installing
the memory to prevent hardware damage.
•Memory modules have a foolproof design. A memory module can be installed in only one
direction. If you are unable to insert the memory, switch the direction.
Due to CPU limitations, read the following guidelines before installing the memory in Four Channel mode.
1. Four Channel mode cannot be enabled if only one DDR4 memory module is installed.
2. When enabling Four Channel mode with two or four memory modules, it is recommended that
memory of the same capacity, brand, speed, and chips be used for optimum performance.
DIMM_P0_A0 DIMM_P0_A2
DIMM_P0_A1
DIMM_P0_B0
DIMM_P0_B1
DIMM_P0_B2
DIMM_P0_D2 DIMM_P0_D0
DIMM_P0_D1
DIMM_P0_C2
DIMM_P0_C1
DIMM_P0_C0
When only one DIMM is used, it must be populated in memory slot0 rst.
Memory populated sequence must be followed with slot0/slot1/slot2.
System will not boot normally with incorrect populated sequence.

Hardware Installation - 18 -
1-4-2 Installing a Memory
Before installing a memory module, make sure to turn off the computer and unplug the power
cord from the power outlet to prevent damage to the memory module.
Be sure to install DDR4 DIMMs on this motherboard.
Installation Step:
Step 1. Insert the DIMM memory module vertically into the DIMM slot, and push it down.
Step 2. Close the plastic clip at both edges of the DIMM slots to lock the DIMM module.
Note: For dual-channel operation, DIMMs must be installed in matched pairs.
Step 3. Reverse the installation steps when you wish to remove the DIMM module.
2
2
1
1-4-3 DIMM Population Table
Two/Three Slots Channel RDIMM Population Conguration Within a Channel
NOTE!
DDR4 2400MHz is only available on Intel Xeon® E5-2600 V4 processor.
Type
Ranks Per
DIMM and
Data Width
Speed (MT/s);
Slot Per Channel (SPC) and DIMM Per Channel (DPC)
RDIMM
RDIMM
RDIMM
RDIMM
LRDIMM
LRDIMM
3DS
SRx4 2133
2133
2133
2133
2133 1600
1600
1600
1600
1866
1866
2133
2133
2133
1 Slot Per Channel
1DPC
2 Slot Per Channel
1DPC 2DPC
3 Slot Per Channel
1DPC 2DPC 3DPC
SRx8
DRx8
DRx4
QRx4
2400
2400
2400
2400
2400
2400
2400
2400
2400
2400
2400
2400
2400
2400
2400
2400
2400
2400
2400
2400
2400
2400
8Rx4

- 19 - Hardware Installation
1-5 Back Panel Connectors
PS/2 Keyboard/Mouse Port
Coonnect a PS/2 keyboard or mouse to this port.
USB 2.0 Port
The USB port supports the USB 2.0 specification. Use this port for USB devices such as a USB
keyboard/mouse,USBprinter,USBashdriveandetc.
Serial Port
Connects to serial-based mouse or data processing devices.
Video Port
The video in port allows connect to video in, which can also apply to video loop thru function.
RJ-45 LAN Ports (Gigabit Ethernet LAN Ports)
The Gigabit Ethernet LAN port provides Internet connection at up to 1 Gbps data rate. The following
describes the states of the LAN port LEDs.
USB 3.0 Port
The USB port supports the USB 3.0 specification. Use this port for USB devices such as a USB
keyboard/mouse,USBprinter,USBashdriveandetc.
KVM Server Management 10/100/1000 LAN Port (Dedicated LAN Port)
The LAN port provides Internet connection with data transfer speeds of 10/100/1000Mbps. This port is
the decated LAN port for server management.
ID Switch Button
Thisbuttonprovidetheselectedunitidencationfunction.
• Whenremovingthecableconnectedtoabackpanelconnector,rstremovethecablefromyour
device and then remove it from the motherboard.
• When removing the cable, pull it straight out from the connector. Do not rock it side to side to
prevent an electrical short inside the cable connector.
Link
Activity LED
Speed LED
10/100/1000 LAN Port
Speed LED:
State Description
Yellow On 1 Gbps data rate
Yellow Blink Identify 1 Gbps data
rate
Green On 100 Mbps data rate
Green Blink Identify 100 Mbps data
rate
Off 10 Mbps data rate
Link/Activity LED:
State Description
On Link bet ween system and net work or no
access
Blinking Data transmission or receiving is occurring
Off No data transmission or receiving is occurring

Hardware Installation - 20 -
1-6 Internal Connectors
1) ATX1
2) P1_CPU0
3) PMBUS
4) CPU0_FAN (CPU Fan)
5) SYS_FAN1 (System Fan)
6) SYS_FAN2 (System Fan)
7) SYS_FAN3 (System Fan)
8) SYS_FAN4 (System Fan)
9) SATA_0_1/SATA_2_3
10) SSATA_0_1/SSATA_2_3
11) SATA4
12) SATA_SGP1
13) SATA_SGP2
14) F_USB3
15) F_USB2
16) COM2
17) FP_1
18) BP_1
19) TPM
20) IPMB
21) LED_BMC
22) SW_RAID
23) LAN4_ACT1
24) LAN3_ACT1
25) CASE_OPEN
26) BAT
1
2
3
4
5
6
7
12
13
8
9
11
10
19
18
14
4215
16
24
17
21 20
26
22
23
25
