GIGA-BYTE TECHNOLOGY R282-3C2 User manual

R282-3C2
3rd Gen. Intel® Xeon® Scalable DP Server System - 2U 12-Bay Gen4 NVMe
User Manual
Rev. 1.0

Copyright
© 2021 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specications and features in this manual may be made by GIGABYTE without
prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or
published in any form or by any means without GIGABYTE's prior written permission.
Documentation Classications
In order to assist in the use of this product, GIGABYTE provides the following types of documentations:
For detailed product information, carefully read the User's Manual.
For More Information
For related product specications, the latest rmware and software, and related information, please visit
our website at:
http://www.gigabyte.com
For GIGABYTE distributors and resellers, additional sales & marketing materials are available from our
reseller portal:
http://reseller.b2b.gigabyte.com
For further information & technical assistance, please contact your GIGABYTE sales representative.
You may also message GIGABYTE server directly by email, Facebook or twitter
Email: server[email protected]
Facebook: https://www.facebook.com/gigabyteserver
Twitter: https://twitter.com/GIGABYTEServer

- 3 -
Conventions
The following conventions are used in this user's guide:
NOTE!
Gives bits and pieces of additional
information related to the current topic.
CAUTION!
Gives precautionary measures to
avoid possible hardware or software problems.
WARNING!
Alerts you to any damage that might
result from doing or not doing specic actions.

- 4 -
Server Warnings and Cautions
Before installing a server, be sure that you understand the following warnings and cautions.
WARNING!
To reduce the risk of electric shock or damage to the equipment:
• Do not disable the power cord grounding plug. The grounding plug is an important safety
feature.
• Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all
times.
• Unplug the power cord from the power supply to disconnect power to the equipment.
• Do not route the power cord where it can be walked on or pinched by items placed against it.
Pay particular attention to the plug, electrical outlet, and the point where the cord extends from
the server.
WARNING!
To reduce the risk of personal injury from hot surfaces, allow the drives and the internal
system components to cool before touching them.
WARNING!
This server is equipped with high speed fans. Keep away from hazardous moving fan
blades during servicing.
CAUTION!
• Do not operate the server for long periods with the access panel open or removed. Operating
the server in this manner results in improper airow and improper cooling that can lead to
thermal damage.
• Danger of explosion if battery is incorrectly replaced.
• Replace only with the same or equivalent type recommended by the manufacturer.
• Dispose of used batteries according to the manufacturer’s instructions.

- 5 -
Electrostatic Discharge (ESD)
CAUTION!
ESD CAN DAMAGE DRIVES, BOARDS, AND OTHER PARTS. WE RECOMMEND THAT YOU
PERFORM ALL PROCEDURES AT AN ESD WORKSTATION. IF ONE IS NOT AVAILABLE,
PROVIDE SOME ESD PROTECTION BY WEARING AN ANTI-STATIC WRIST STRAP
ATTACHED TO CHASSIS GROUND -- ANY UNPAINTED METAL SURFACE -- ON YOUR
SERVER WHEN HANDLING PARTS.
Always handle boards carefully. They can be extremely sensitive to ESD. Hold boards only by
their edges without any component and pin touching. After removing a board from its protective
wrapper or from the system, place the board component side up on a grounded, static free
surface. Use a conductive foam pad if available but not the board wrapper. Do not slide board
over any surface.
System power on/off: To remove power from system, you must remove the system from rack.
Make sure the system is removed from the rack before opening the chassis, adding, or removing
any non hot-plug components.
Hazardous conditions, devices and cables: Hazardous electrical conditions may be present
on power, telephone, and communication cables. Turn off the system and discon-nect the cables
attached to the system before servicing it. Otherwise, personal injury or equipment damage can
result.
Electrostatic discharge (ESD) and ESD protection: ESD can damage drives, boards, and
other parts. We recommend that you perform all procedures in this chapter only at an ESD
workstation. If one is not available, provide some ESD protection by wearing an antistatic wrist
strap attached to chassis ground (any unpainted metal surface on the server) when handling
parts.
ESD and handling boards: Always handle boards carefully. They can be extremely sensi-tive to
electrostatic discharge (ESD). Hold boards only by their edges. After removing a board from its
protective wrapper or from the system, place the board component side up on a grounded, static
free surface. Use a conductive foam pad if available but not the board wrapper. Do not slide
board over any surface.
Installing or removing jumpers: A jumper is a small plastic encased conductor that slips over
two jumper pins. Some jumpers have a small tab on top that can be gripped with n-gertips or
with a pair of ne needle nosed pliers. If the jumpers do not have such a tab, take care when
using needle nosed pliers to remove or install a jumper; grip the narrow sides of the jumper with
the

- 6 -
pliers, never the wide sides. Gripping the wide sides can dam-age the contacts inside the jumper,
causing intermittent problems with the function con-trolled by that jumper. Take care to grip with,
but not squeeze, the pliers or other tool used to remove a jumper, or the pins on the board may
bend or break.
CAUTION!
Risk of explosion if battery is replaced incorrectly or with an incorrect type. Replace the battery
only with the same or equivalent type recommended by the manufacturer. Dispose of used
batteries according to the manufacturer’s instructions.

- 7 -
Table of Contents
Chapter 1 Hardware Installation................................................................................. 11
1-1 Installation Precautions.................................................................................. 11
1-2 Product Specications.................................................................................... 12
1-3 System Block Diagram................................................................................... 16
Chapter 2 System Appearance...................................................................................17
2-1 Front View...................................................................................................... 17
2-2 Rear View....................................................................................................... 18
2-3 Front Panel LED and Buttons ........................................................................ 19
2-4 Rear System LAN LEDs................................................................................. 21
2-5 Hard Disk Drive LEDs .................................................................................... 22
2-6 Power Supply Unit LED.................................................................................. 23
Chapter 3 System Hardware Installation...................................................................25
3-1 Removing Chassis Cover............................................................................... 26
3-2 Removing and Installing the Fan Duct ........................................................... 27
3-3 Installing the CPU and Heat Sink................................................................... 28
3-3-1 Follow these instructions to install the CPU: ..........................................................28
3-4 Installing the Memory..................................................................................... 30
3-4-1 Eight Channel Memory Conguration.....................................................................30
3-4-2 Installing a Memory ...............................................................................................31
3-4-3 DIMM Population Table ..........................................................................................31
3-4-4 Processor and Memory Module Matrix Table .........................................................32
3-4-5 Intel Optane DCPMM DIMM Population Rule ........................................................33
3-5 Installing the PCI Expansion Card ................................................................. 34
3-6 Installing the Hard Disk Drive......................................................................... 35
3-7 Replacing the FAN Assemblly ........................................................................ 37
3-8 Replacing the Power Supply.......................................................................... 38
3-9 Cable Routing ................................................................................................ 39
Chapter 4 Motherboard Components ........................................................................45
4-1 Motherboard Components ............................................................................. 45
4-2 Jumper Setting .............................................................................................. 47
4-3 Backplane Board Storage Connector ............................................................ 48
4-3-1 CBP20O7 ...............................................................................................................48
4-3-2 CBP2022 ................................................................................................................49
Chapter 5 BIOS Setup .................................................................................................51

- 8 -
5-1 The Main Menu .............................................................................................. 53
5-2 Advanced Menu ............................................................................................. 56
5-2-1 Trusted Computing .................................................................................................57
5-2-2 Serial Port Console Redirection .............................................................................58
5-2-3 SIO Conguration...................................................................................................62
5-2-4 PCI Subsystem Settings.........................................................................................63
5-2-5 USB Conguration..................................................................................................64
5-2-6 Network Stack Conguration..................................................................................65
5-2-7 Post Report Conguration ......................................................................................66
5-2-8 NVMe Conguration ...............................................................................................67
5-2-9 Chipset Conguration.............................................................................................68
5-2-10 Tls Auth Conguration ............................................................................................69
5-2-11 iSCSI Conguration................................................................................................70
5-2-12 Intel(R) i350 Gigabit Network Connection ..............................................................71
5-2-13 VLAN Conguration................................................................................................73
5-2-14 Driver Health...........................................................................................................74
5-3 Chipset Menu................................................................................................. 75
5-3-1 Processor Conguration.........................................................................................76
5-3-2 Common RefCode Conguration ...........................................................................79
5-3-3 UPI Conguration ...................................................................................................80
5-3-4 Memory Conguration ............................................................................................81
5-3-5 IIO Conguration ....................................................................................................84
5-3-6 Advanced Power Management Conguration........................................................86
5-3-7 PCH Conguration..................................................................................................88
5-3-8 Miscellaneous Conguration ..................................................................................90
5-3-9 Server ME Conguration ........................................................................................91
5-3-10 Runtime Error Logging Settings .............................................................................92
5-3-11 Power Policy...........................................................................................................94
5-4 Server Management Menu............................................................................. 96
5-4-1 System Event Log ..................................................................................................98
5-4-2 View FRU Information ............................................................................................99
5-4-3 BMC VLAN Conguration.....................................................................................100
5-4-4 BMC Network Conguration.................................................................................101
5-4-5 IPv6 BMC Network Conguration.........................................................................102
5-5 Security Menu .............................................................................................. 103
5-5-1 Secure Boot .........................................................................................................104
5-6 Boot Menu.................................................................................................... 107
5-7 Save & Exit Menu......................................................................................... 109
5-8 BIOS POST Beep code (AMI standard)........................................................111

- 9 -
5-8-1 PEI Beep Codes................................................................................................... 111
5-8-2 DXE Beep Codes ................................................................................................. 111

- 10 -
This page intentionally left blank

- 11 - Hardware Installation
1-1 Installation Precautions
The motherboard/system contain numerous delicate electronic circuits and components which
can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully
read the service guide and follow these procedures:
• Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or
warranty sticker provided by your dealer. These stickers are required for warranty validation.
• Always remove the AC power by unplugging the power cord from the power outlet before
installing or removing the motherboard or other hardware components.
• When connecting hardware components to the internal connectors on the motherboard,
make sure they are connected tightly and securely.
• When handling the motherboard, avoid touching any metal leads or connectors.
• It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic
components such as a motherboard, CPU or memory. If you do not have an ESD wrist
strap, keep your hands dry and rst touch a metal object to eliminate static electricity.
• Prior to installing the motherboard, please have it on top of an antistatic pad or within an
electrostatic shielding container.
• Before unplugging the power supply cable from the motherboard, make sure the power
supply has been turned off.
• Before turning on the power, make sure the power supply voltage has been set according to
the local voltage standard.
• Before using the product, please verify that all cables and power connectors of your
hardware components are connected.
• To prevent damage to the motherboard, do not allow screws to come in contact with the
motherboard circuit or its components.
• Make sure there are no leftover screws or metal components placed on the motherboard or
within the computer casing.
• Do not place the computer system on an uneven surface .
• Do not place the computer system in a high-temperature environment.
• Turning on the computer power during the installation process can lead to damage to
system components as well as physical harm to the user.
• If you are uncertain about any installation steps or have a problem related to the use of the
product, please consult a certied computer technician.
Chapter 1 Hardware Installation

Hardware Installation - 12 -
1-2 Product Specications
CPU 3rd Generation Intel® Xeon® Scalable Processors
Intel® Xeon® Platinum Processor, Intel® Xeon® Gold Processor, Intel® Xeon®
Silver Processor
10nm technology, CPU TDP up to 270W
NOTE: If only 1 CPU is installed, some PCIe or memory functions might be
unavailable.
Socket 2 x LGA 4189
Socket P+
Chipset Intel® C621A Express Chipset
Memory 32 x DIMM slots
DDR4 memory supported only
8-channel memory architecture per processor
RDIMM modules up to 128GB supported
LRDIMM modules up to 128GB supported
3DS RDIMM/LRDIMM modules up to 256GB supported
1.2V modules: 3200/2933/2666 MHz
LAN 2 x 1Gb/s LAN ports (Intel® I350-AM2)
1 x 10/100/1000 management LAN
Expansion Slot Riser Card CRS2033:
1 x PCIe x16 slot (Gen4 x16), Full height half-length
2 x PCIe x8 slots (Gen4 x8), Full height half-length
Riser Card CRS2137:
1 x PCIe x16 slot (Gen4 x16 o x8), Full height half-length
1 x PCIe x8 slots (Gen4 x0 or x8), Full height half-length
1 x PCIe x16 slot (Gen4 x16 or x8), shared with OCP 2.0, Full height half-length
Riser Card CRS2027:
2 x PCIe x8 slots (Gen4 x8), Low prole half-length
1 x OCP 3.0 mezzanine slot with PCIe Gen4 x16 bandwidth from CPU_0
Supported NCSI function
1 x OCP 2.0 mezzanine slot with PCIe Gen3 x8 bandwidth from CPU_1
Supported NCSI function
Video Integrated in Aspeed® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM

- 13 - Hardware Installation
Storage
8 x 3.5" or 2.5" SATA/SAS hot-swappable HDD/SSD bays
4 x 3.5" or 2.5" SATA/SAS/Gen4 NVMe hot-swappable HDD/SSD bays
2 x 2.5" SATA/SAS hot-swappable HDD/SSD bays in rear side
SAS card is required for SAS devices support
SAS N/A
RAID Intel® SATA RAID 0, 1, 10, 5
Internal
Connectors
2 x CPU fan headers
1 x USB 3.0 header
1 x TPM header
1 x VROC connector
1 x Front panel header
1 x HDD back plane board header
1 x IPMB connector
1 x Clear CMOS jumper
1 x BIOS recovery switch
Front Panel
LED/Buttons
2 x USB 3.0
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x NMI button
1 x System status LED
1 x HDD activity LED
2 x LAN activity LEDs
Rear Panel I/O 2 x USB 3.0
1 x VGA
2 x RJ45
1 x MLAN
1 x ID button with LED
Backplane I/O Front side_CBP20C5: 8 x SATA/SAS and 4 x SATA/SAS/NVMe ports
Rear side_CBP2022: 2 x SATA ports
Bandwidth: PCIe Gen4 x4 or SATA 6Gb/s or SAS 12Gb/s per port
TPM 1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010

Hardware Installation - 14 -
Power Supply 2 x 1600W redundant PSUs
80 PLUS Platinum
AC Input:
- 100-120V~/ 12A, 50-60Hz
- 200-240V~/ 10.0A, 50-60Hz
DC Input:
240Vdc, 10A
DC Output:
- Max 1000W/ 100-120V~
+12V/ 81.5A
+12Vsb/ 2.5A
- Max 1600W at 200-240V or 240Vdc Input
+12V/ 133A
+12Vsb/ 2.5A
Environment
Ambient
Temperature
Relative
Humidity
Operating temperature: 10°C to 35°C
Non-operating temperature: -40°C to 60°C
Operating humidity: 8-80% (non-condensing)
Non-operating humidity: 20%-95% (non-condensing)
OS Compatibility Windows Server 2016
Windows Server 2019
Windows Server 2022
Red Hat Enterprise Linux 8.2 ( x64) or later
Red Hat Enterprise Linux 8.3 ( x64) or later
SUSE Linux Enterprise Server 12 SP5 ( x64) or later
SUSE Linux Enterprise Server 15 SP2 ( x64) or later
Ubuntu 20.04 LTS (x64) or later
Ubuntu 20.04.1 LTS (x64) or later
VMware ESXi 6.7 Update3 P03
VMware ESXi 7.0 Update2
Citrix Hypervisor 8.2.0
System Fans 4 x 80x80x38mm (16,300rpm)

- 15 - Hardware Installation
System
Management
Aspeed® AST2600 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface:
Dashboard
JAVA Based Serial Over LAN
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Prole
System Firewall
Power Consumption
Power Control
LDAP / AD / RADIUS Support
Backup & Restore Conguration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings
System
Dimension
2U
438mm (W) x 87.5mm (H) x 730mm (D)
* We reserves the right to make any changes to the product specications and product-related information without prior
notice.

Hardware Installation - 16 -
1-3 System Block Diagram
8-Channel DDR4, 16 x DIMMs
Speed up to 3200 MHz
8-Channel DDR4, 16 x DIMMs
Speed up to 3200 MHz
DMI3 x 4
PCIe3.0 x 1
PCIe3.0 x 1
eSPI
SPI
2 x USB 2.0
SPI Flash
64 MB
SPI Flash
64 MB
3 x SlimSAS 4i
2 x SSATAIII
4 x SSATAIII
2 x SATA DOM
8 x SATAIII
2 x USB 3.0
(Internal)
2 x USB 3.0
(rear)
USB 3.0 x2
USB 3.0 x2
TPM
VGA
COM
ASPEED
AST2600
BMC
MLAN
MAC
PCIe4.0 x 16
PCIe4.0
x
32
2 x PCIe 4.0 x8 slots
PCIe 4.0 x16 slot
PCIe 4.0 x8 slot
PCIe 4.0 x8 slot
PCIe 4.0 x0 or x8 slot
PCIe 4.0 x16 or x8 slot
PCIe 4.0 x16 or x8 slot
PCIe4.0
x
16
PCIe4.0
x
24
PCIe4.0
x
8
SPI Flash
64 MB
SPI Flash
64 MB
Dual ROM
(ROT Option)
Dual ROM
(ROT Option)
3 x UPI 11.2GT/s (ICX)
PCIe4.0 x 16
Switch
NCSI
NCSI
OCP 3.0 mezzanine
OCP 2.0 mezzanine
PCH
Lewisburg-R
Intel C621A
2 x SlimSAS 8i
PCIe4.0 x 16
2 x SlimSAS 8i
Switch
Intel
i350-AM2
10/100/1G
PHY
Ice Lake-SP
LGA4189 (Socket P+)
CPU0
Ice Lake-SP
LGA4189 (Socket P+)
CPU1
2 x 1GbE LAN
Riser CRS2033
Riser CRS2137
Riser CRS2027
Switch

- 17 - Hardware Installation
Chapter 2 System Appearance
2-1 Front View
No. Decription
1. Front Panel LEDs and buttons
2. Front USB 3.0 ports
NOTE! The Green Latch Supports NVMe
• Please Go to Chapter 2-3 Front Panel LED and Buttons for detail description of function LEDs.
1 2

Hardware Installation - 18 -
2-2 Rear View
No. Decription
1. Mezzanine Slot (Option/OCP 3.0 Card/SFF Type)
2. ID Button with LED
3. Server management LAN port
4. 1GbE LAN port x 2
5. USB 3.0 port x 2
6. Mezzanine Slot (Option/OCP 2.0 Card)
7. VGA port
8. Low-Prole PCIe Card Slot
9. Full height
10. Full height
7
8910
2
31456

- 19 - Hardware Installation
2-3 Front Panel LED and Buttons
L1 L2
1
3
5
7
2
4
6
8
No. Name Color Status Description
1. Reset Button Press the button to reset the system.
2. NMI button
Press the button server generates a NMI to the processor
if the multiple-bit ECC errors occur, which effectively halt
the server.
3. Power button
with LED
Green On System is powered on
N/A Off • System is not powered on or in ACPI S5 state (power
off)
4. ID Button
with LED
Blue On System identication is active.
N/A Off System identication is disabled.
5. HDD Status
LED
Green On HDD locate
Blink HDD access
Amber On HDD fault
Green/
Amber Blink HDD rebuilding
N/A Off No HDD access or no HDD fault.
6. System
Status LED
Green On System is operating normally.
Amber
On
Critical condition, may indicates:
System fan failure
System temperature
Blink
Non-critical condition, may indicates:
Redundant power module failure
Temperature and voltage issue
Chassis intrusion
N/A Off
Non-critical condition, may indicates:
Redundant power module failure
Temperature and voltage issue
Chassis intrusion

Hardware Installation - 20 -
No. Name Color Status Description
7. LAN1 Active/
Link LED
Green On Link between system and network
or no access
Green Blink Data transmission or receiving is occurring
N/A Off No data transmission or receiving is occurring
8. LAN2 Active/
Link LED
Green On Link between system and network
or no access
Green Blink Data transmission or receiving is occurring
N/A Off No data transmission or receiving is occurring
