GIGA-BYTE TECHNOLOGY TO22-C20 User manual

TO22-C20
High Performance Compute Server
User Manual
Rev. 1.0

Copyright
© 2021 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specications and features in this manual may be made by GIGABYTE without
prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or
published in any form or by any means without GIGABYTE's prior written permission.
Documentation Classications
In order to assist in the use of this product, GIGABYTE provides the following types of documentation:
User Manual: detailed information & steps about the installation, conguration and use of this
product (e.g. motherboard, server barebones), covering hardware and BIOS.

User Guide: detailed information about the installation & use of an add-on hardware or
software component (e.g. BMC rmware, rail-kit) compatible with this product.
Quick Installation Guide: a short guide with visual diagrams that you can reference easily for
installation purposes of this product (e.g. motherboard, server barebones).
Please see the support section of the online product page to check the current availability of these
documents.
For More Information
For related product specications, the latest rmware and software, and other information please visit our website at
http://www.gigabyte.com
For GIGABYTE distributors and resellers, additional sales & marketing materials are available from our reseller
portal: http://reseller.b2b.gigabyte.com
For further technical assistance, please contact your GIGABYTE representative or visit
https://esupport.gigabyte.com/ to create a new support ticket
For any general sales or marketing enquiries, you may also message GIGABYTE server directly by email:
server[email protected]

Conventions
The following conventions are used in this user's guide:
NOTE!
Gives bits and pieces of additional
information related to the current topic.
CAUTION!
Gives precautionary measures to
avoid possible hardware or software problems.
WARNING!
Alerts you to any damage that might
result from doing or not doing specic actions.

Server Warnings and Cautions
Before installing a server, be sure that you understand the following warnings and cautions.
WARNING!
To reduce the risk of electric shock or damage to the equipment:
• Do not disable the power cord grounding plug. The grounding plug is an important safety
feature.
• Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all
times.
• Unplug all the power cords from the power supplies to disconnect power to the equipment.
• Shock Hazard! Disconnect all power supply cords before servicing.
• Do not route the power cord where it can be walked on or pinched by items placed against it.
Pay particular attention to the plug, electrical outlet, and the point where the cord extends from
the server.
WARNING!
To reduce the risk of personal injury from hot surfaces, allow the drives and the internal
system components to cool before touching them.
WARNING!
This server is equipped with high speed fans. Keep away from hazardous moving fan
blades during servicing.
WARNING!
This equipment is intended to be used in Restrict Access Location. The access can only
be gained by Skilled person. Only authorized by well trained professional person can ac-
cess the restrict access location.
CAUTION!
• Do not operate the server for long periods with the access panel open or removed.
Operating the server in this manner results in improper airow and improper cooling that can
lead to thermal damage.
• Danger of explosion if battery is incorrectly replaced.
• Replace only with the same or equivalent type recommended by the manufacturer.
• Dispose of used batteries according to the manufacturer’s instructions.

- 5 -
Electrostatic Discharge (ESD)
CAUTION!
ESD CAN DAMAGE DRIVES, BOARDS, AND OTHER PARTS. WE RECOMMEND THAT YOU
PERFORM ALL PROCEDURES AT AN ESD WORKSTATION. IF ONE IS NOT AVAILABLE,
PROVIDE SOME ESD PROTECTION BY WEARING AN ANTI-STATIC WRIST STRAP AT-
TACHED TO CHASSIS GROUND -- ANY UNPAINTED METAL SURFACE -- ON YOUR SERVER
WHEN HANDLING PARTS.
Always handle boards carefully. They can be extremely sensitive to ESD. Hold boards only by
their edges without any component and pin touching. After removing a board from its protective
wrapper or from the system, place the board component side up on a grounded, static free sur-
face. Use a conductive foam pad if available but not the board wrapper. Do not slide board over
any surface.
System power on/off: To remove power from system, you must remove the system from rack.
Make sure the system is removed from the rack before opening the chassis, adding, or removing
any non hot-plug components.
Hazardous conditions, devices and cables: Hazardous electrical conditions may be present
on power, telephone, and communication cables. Turn off the system and discon-nect the cables
attached to the system before servicing it. Otherwise, personal injury or equipment damage can
result.
Electrostatic discharge (ESD) and ESD protection: ESD can damage drives, boards, and
other parts. We recommend that you perform all procedures in this chapter only at an ESD work-
station. If one is not available, provide some ESD protection by wearing an antistatic wrist strap
attached to chassis ground (any unpainted metal surface on the server) when handling parts.
ESD and handling boards: Always handle boards carefully. They can be extremely sensi-tive to
electrostatic discharge (ESD). Hold boards only by their edges. After removing a board from its
protective wrapper or from the system, place the board component side up on a grounded, static
free surface. Use a conductive foam pad if available but not the board wrapper. Do not slide
board over any surface.
Installing or removing jumpers: A jumper is a small plastic encased conductor that slips over
two jumper pins. Some jumpers have a small tab on top that can be gripped with n-gertips or
with a pair of ne needle nosed pliers. If the jumpers do not have such a tab, take care when us-
ing needle nosed pliers to remove or install a jumper; grip the narrow sides of the jumper with the

- 6 -
pliers, never the wide sides. Gripping the wide sides can dam-age the contacts inside the jumper,
causing intermittent problems with the function con-trolled by that jumper. Take care to grip with,
but not squeeze, the pliers or other tool used to remove a jumper, or the pins on the board may
bend or break.
CAUTION!
Risk of explosion if battery is replaced incorrectly or with an incorrect type. Replace the battery
only with the same or equivalent type recommended by the manufacturer. Dispose of used bat-
teries according to the manufacturer’s instructions.

- 7 -
Table of Contents
Chapter 1 Hardware Installation ...................................................................................11
1-1 Installation Precautions.................................................................................. 11
1-2 Product Specications.................................................................................... 12
1-3 System Block Diagram................................................................................... 14
Chapter 2 System Appearance.....................................................................................15
2-1 Node Overview............................................................................................... 15
2-2 Front View...................................................................................................... 16
2-3 Rear View....................................................................................................... 17
2-4 System LAN LEDs ......................................................................................... 18
2-4-1 1GbE LAN LED ......................................................................................................18
2-4-2 10GbE LAN LED ....................................................................................................18
2-5 Hard Disk Drive LEDs .................................................................................... 19
Chapter 3 System Hardware Installation ......................................................................21
3-1 Installing Node into The Rack ........................................................................ 22
3-2 Removing Node Cover................................................................................... 23
3-3 Removing Hard Disk Middle Tray................................................................... 24
3-4 Installing the CPU and Heat Sink................................................................... 25
3-5 Installing the Memory..................................................................................... 27
3-5-1 Eight Channel Memory Conguration.....................................................................27
3-5-2 Installing a Memory ...............................................................................................28
3-5-3 Memory Population Table .......................................................................................28
3-5-4 Intel Optane DCPMM DIMM Population Rule ........................................................29
3-6 Installing the PCI Expansion Card ................................................................. 30
3-7 Installing the Hard Disk Drive......................................................................... 31
3-8 Cable Routing ................................................................................................ 33
Chapter 4 Motherboard Components ...........................................................................37
4-1 Motherboard Components ............................................................................. 37
4-2 Jumper Settings ............................................................................................. 39
Chapter 5 BIOS Setup ..................................................................................................41
5-1 The Main Menu .............................................................................................. 43
5-2 Advanced Menu ............................................................................................. 46
5-2-1 iSCSI Conguration ................................................................................................47
5-2-2 Intel(R) Virtual RAID on CPU .................................................................................48
5-2-3 Intel(R) Ethernet Connection X722.........................................................................49
5-2-3-1 NIC Conguration ...................................................................................................52

- 8 -
5-2-4 Trusted Computing .................................................................................................53
5-2-5 Serial Port Console Redirection .............................................................................54
5-2-5-1 COM1/COM2 Serial Over LAN/Legacy/Serial Port for Out-of-Band EMS .................
Console Redirection Settings ...............................................................................................55
5-2-6 SIO Conguration...................................................................................................58
5-2-7 PCI Subsystem Settings.........................................................................................61
5-2-8 Network Stack ........................................................................................................62
5-2-9 CSM Conguration .................................................................................................63
5-2-10 Post Report Conguration ......................................................................................65
5-2-11 NVMe Conguration ...............................................................................................66
5-2-12 USB Conguration..................................................................................................67
5-2-13 Chipset Conguration.............................................................................................68
5-3 Chipset Setup Menu....................................................................................... 69
5-3-1 Processor Conguration .........................................................................................70
5-3-1-1 Pre-Socket Conguration .......................................................................................72
5-3-2 Common RefCode Conguration ...........................................................................74
5-3-3 UPI Conguration ...................................................................................................75
5-3-4 Memory Conguration ............................................................................................77
5-3-4-1 Memory Topology ...................................................................................................79
5-3-4-2 Memory RAS Conguration....................................................................................80
5-3-5 IIO Conguration ....................................................................................................81
5-3-5-1 Intel® VT for Directed I/O (VT-d) ...........................................................................82
5-3-5-2 Inter® VMD Technology .........................................................................................83
5-3-6 Advanced Power Management Conguration ........................................................84
5-3-6-1 CPU P State Control...............................................................................................85
5-3-6-2 Hardware PM State Control....................................................................................86
5-3-6-3 CPU C State Control ..............................................................................................87
5-3-6-4 Package C State Control........................................................................................88
5-3-6-5 CPU-Advanced PM Tuning.....................................................................................89
5-3-7 PCH Conguration .................................................................................................91
5-3-7-1 PCH SATA Conguration........................................................................................92
1-3-7-2 PCH sSATA Conguration ......................................................................................94
5-3-8 Miscellaneous Conguration ..................................................................................96
5-3-9 Server ME Conguration ........................................................................................97
5-3-10 Runtime Error Logging ...........................................................................................98
5-3-10-1Whea Settings ........................................................................................................99
5-3-10-2Memory Error Enabling.........................................................................................100
5-3-10-3PCIe Error Enabling..............................................................................................101
5-4 Server Management Menu........................................................................... 102
5-4-1 System Event Log ................................................................................................104
5-4-2 View FRU Information ..........................................................................................105
5-4-3 BMC Network Conguration .................................................................................106

- 9 -
5-4-4 IPv6 BMC Network Conguration.........................................................................107
5-5 Security Menu .............................................................................................. 108
5-5-1 Secure Boot .........................................................................................................109
5-5-1-1 Key Management ...............................................................................................110
5-6 Boot Menu.................................................................................................... 112
5-6-1 UEFI NETWORK Drive BBS Priorities ................................................................114
5-6-2 UEFI Application Boot Priorities ................................................................. 115
5-7 Save & Exit Menu......................................................................................... 116
5-8 BIOS POST Codes ...................................................................................... 118
5-9 BIOS POST Beep code................................................................................ 122
5-9-1 PEI Beep Codes...................................................................................................122
5-9-2 DEX Beep Codes .................................................................................................122
5-10 BIOS Recovery Instruction........................................................................... 123

- 10 -
This page intentionally left blank

- 11 - Hardware Installation
1-1 Installation Precautions
The motherboard/system contain numerous delicate electronic circuits and components which
can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully
read the service guide and follow these procedures:
• Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or
warranty sticker provided by your dealer. These stickers are required for warranty validation.
• Always remove the AC power by unplugging the power cord from the power outlet before
installing or removing the motherboard or other hardware components.
• When connecting hardware components to the internal connectors on the motherboard,
make sure they are connected tightly and securely.
• When handling the motherboard, avoid touching any metal leads or connectors.
• It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic
components such as a motherboard, CPU or memory. If you do not have an ESD wrist
strap, keep your hands dry and rst touch a metal object to eliminate static electricity.
•
Prior to installing the motherboard, please have it on top of an antistatic pad or within an
electrostatic shielding container.
• Before unplugging the power supply cable from the motherboard, make sure the power
supply has been turned off.
• Before turning on the power, make sure the power supply voltage has been set according to
the local voltage standard.
• Before using the product, please verify that all cables and power connectors of your
hardware components are connected.
• To prevent damage to the motherboard, do not allow screws to come in contact with the
motherboard circuit or its components.
• Make sure there are no leftover screws or metal components placed on the motherboard or
within the computer casing.
• Do not place the computer system on an uneven surface
.
• Do not place the computer system in a high-temperature environment.
• Turning on the computer power during the installation process can lead to damage to
system components as well as physical harm to the user.
• If you are uncertain about any installation steps or have a problem related to the use of the
product, please consult a certied computer technician.
Chapter 1 Hardware Installation

Hardware Installation - 12 -
1-2 Product Specications
Socket
Socket
Security
Security
CPU 2nd Generation Intel® Xeon® Scalable and Intel® Xeon® Scalable Processors
Socket
Socket
Security
Security
Socket 2 x LGA 3647
Socket P
Socket
Socket
Security
Security
Chipset Intel® C621 Express Chipset
Socket
Socket
Security
Security
Memory 16 x DIMM slots
DDR4 memory supported only
6-channel memory architecture
RDIMM modules up to 64GB supported
LRDIMM modules up to 128GB supported
Supports Intel® Optane™ DC Persistent Memory (DCPMM)
1.2V modules: 2933/2666/2400/2133 MHz
Socket
Socket
Security
Security
LAN 2 x 10GbE LAN ports (Intel® X550-AT2)
1 x 10/100/1000 management LAN
Storage
Socket
Socket
Security
Security
Video Integrated in Aspeed® AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
Socket
Socket
Security
Security
Storage Front side: 2 x 2.5" hybrid NVMe/SATA/SAS + 2 x 2.5" SATA/SAS hot-swap bays
Internal: 4 x 2.5" NVMe xed bays
Socket
Socket
Security
Security
SAS Add-on card available
Socket
Socket
Security
Security
RAID Intel® SATA RAID 0/1/10/5
Socket
Socket
Security
Security
Expansion Slot 1 x PCIe x16 (Gen3 x16) slot, Low-prole half-length
1 x PCIe x8 (Gen3 x8) slot, Low-prole half-length
1 x OCP mezzanine slot (Gen3 x16)
Socket
Socket
Security
Security
Front I/O 2 x USB 3.0
1 x VGA
2 x RJ45
1 x MLAN
1 x Power button with LED
1 x ID button with LED
8 x HDD LED
1 x System status LED
Socket
Socket
Security
Security
TPM 1 x TPM header with LPC interface
Optional TPM2.0 kit: CTM000
NOTE:
We reserve the right to make any changes to the product specications and product-related
information without prior notice.

- 13 - Hardware Installation
Socket
Socket
Security
Security
System
Management
Aspeed® AST2500 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Prole
System Firewall
Power Consumption
Power Control
LDAP / AD / RADIUS Support
Backup & Restore Conguration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings
Socket
Socket
Security
Security
Environment
Ambient
Temperature
Relative
Humidity
Operating temperature: 10°C to 35°C
Non-operating temperature: -40°C to 60°C

Operating humidity: 8-80% (non-condensing)
Non-operating humidity: 20%-95% (non-condensing)
Socket
Socket
Security
Security
System
Dimension
3 Nodes/2OU
180mm (W) x 90mm (H) x 690mm (D)

- 14 - Hardware Installation
1-3 System Block Diagram
6 Channels
DDR4
6 Channels
DDR4
DMI3 x 4
UPI 10.4GT/s
UPI 10.4GT/s
2A~2D
PCIe3.0 x 16
PCIe3.0
x
16
PCIe3.0 x 1
2 x USB2.0
2 x USB3.0
LPC
Update BIOS
2 x SSATAIII
(SSATA DOM)
2 x SSATAIII
Cascade Lake SP
LGA3647 (Socket P0)
CPU0
PCIe3.0
x
16
4 x NVMe
Internal
2x NVMe / 2 x SATA
Or
4 x SATA
Cascade Lake SP
LGA3647 (Socket P0)
CPU1
BIOS Flash
32MB
SPI
6 x SATAIII
SlimLine
PCH
Intel C621
Lewisburg
MLAN
TPM 2.0
VGA
COM
ASPEED
AST2500
BMC
Rear 2 x USB 3.0
REALTEK
RTL8211E
OCP Mezzanine
2933(1DPC)/2666/2400 MHz
8 x DIMM slots
2933(1DPC)/2666/2400 MHz
8 x DIMM slots
2 x 10Gb/s BASE-T LAN
Switch
NCSI
Intel X550
PCIe3.0 x 4

- 15 - System Appearance
Chapter 2 System Appearance
2-1 Node Overview
No. Decription
1. Hard Disk Middle Tray
2. Hard Disk Cage
3. Heatsink (for CPU0)
4. DDR4 DIMM modules (for CPU0)
5. Heatsink (for CPU1)
6. DDR4 DIMM modules (for CPU1)
7. Power distribution board
8. System fan modules
1
2
3
4
6
5
8
78

System Appearance - 16 -
2-2 Front View
No. Description
1. Add-on card bay
2. USB 3.0 ports
3. ID LED
4. VGA port
5. 10 GbE LAN ports
6. 10/100/1000 server management LAN port
7. Add-on card bay
8. Front panel buttons and LEDs
Top: System status LED
Middle: Power button
Bottom: ID button
9. HDD status LED
HDD #0
(SATA)
HDD #1
(SATA)
HDD #2
(NVMe/SATA)
HDD #3
(NVMe/SATA)
1 2 345 6 7
8
99

- 17 - System Appearance
2-3 Rear View
1
No. Description
1. Bus bar connector assembly

System Appearance - 18 -
2-4 System LAN LEDs
LED Color LED State Description
Green/Yellow (A)
Off 10Mbps
Green 1Gbps
Yellow 1000Mbps
Green (B) On Active Connection
Blinking Transmit/Receive activity
AB
AB
2-4-1 1GbE LAN LED
2-4-2 10GbE LAN LED
LED Color LED State Description
Green/Yellow (A)
Off 100Mbps
Yellow 1Gbps
Green 10Gbps
Green (B) On Active Connection
Blinking Transmit/Receive activity

- 19 - System Appearance
2-5 Hard Disk Drive LEDs
NOTE:
*1: Depends on HBA/Utility Spec.
*2: Blink cycle depends on HDD's activity signal.
*3: If HDD is pulled out during rebuilding, the disk status of this HDD is regarded as faulty.
/('
/('
Disk LED
(LED on
Back Panel)
Removed HDD Slot
(LED on Back Panel)
Disk LED
Removed HDD Slot
RAID SKU
No RAID configuration
(via HBA)
RAID configuration
(via HW RAID Card or
SW RAID Card)
HDD
Access
HDD Present
(No Access)
BLINK (*2)
BLINK (*2)
OFF
OFF
OFF
OFF
OFF
--
--
--
--
--
--
--
--
OFF
(Low Speed: 2 Hz)
(*3)
(*3)
Rebuilding
HDD Fault
OFF
OFF
ON
OFF
ON
OFF
OFF
OFF
Locate
Amber
Green ON(*1)
ON
OFF
ON(*1)
OFF
Green
Amber
Green
ON(*1)Green
OFFAmber
Amber OFF
LED1
LED 2 HDD Present No HDD
Green ON OFF

System Appearance - 20 -
