Gigabyte Myou S1024 User manual

Copyright © 2009
All Right Reserved - Printed in China
Myou S1024 Computer User’s Manual
Original Issue: 2009/05
This manual guides you in setting up and using your new Myou S1024 Small Notebook PC. Information in the manual
has been carefully checked for accuracy and is subject to change without notice.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means,
electronic, mechanical, photocopy, recording, or otherwise, without prior written consent.
Trademarks
Product names used herein are for identication purposes only and may be the trademarks of their respective
companies.
Microsoft®, MS-DOS, Windows®, and Windows®Sound System are trademarks of Microsoft Corporation.
Intel®, Atom™ is registered trademarks of Intel Corporation.
Sound Blaster, Sound Blaster Pro are trademarks of Creative Technology.
All other brands or product names mentioned in this manual are trademarks or registered trademarks of their
respective companies.
Once you have checked and conrmed that your Myou S1024 Computer system is complete, read through the
following pages to learn about all of your Myou S1024 Computer components.

I
ENGLISH
Safety Instructions
Use the following safety guidelines to help protect yourself and your Myou S1024 Computer.
When Using Your Myou S1024 Computer
CAUTION: Do not operate your portable computer for an extended period of time with the base
resting directly on your body. With extended operation, heat can build up in the base. Allowing
sustained contact with the skin can cause discomfort or a burn.
Do not attempt to service the Myou S1024 Computer yourself. Always follow installation
instructions closely.
Do not carry a battery in your pocket, purse, or other container where metal objects (such as car
keys) could short-circuit the battery terminals. The resulting excessive current ow can generate
extremely high temperature and may cause burns to your skin.
Be sure that nothing rests on your AC adapter’s power cable and that the cable is not located
where it can be tripped over or stepped on.
While you are using the computer or charging the battery, place the AC adapter in a ventilated
area, like on a desktop or on the oor. Do not cover the AC adapter with papers or other items that
may prevent ventilation. Also, do not use the AC adapter while it is inside a carrying case.
Do not insert objects into the air vent of your Myou S1024 Computer. Doing so can cause short-
circuiting and may result in re or electrical shock.






II
ENGLISH
Use only the AC adapter and batteries that are supplied by your Myou S1024 Computer
manufacturer. Using other types of battery or AC adapter may heighten the risk of re or explosion.
Incorrectly placed batteries may result in an explosion.
Replace only with the same or compatible battery recommended by the manufacturer.
Please discard used batteries according to the manufacturer’s instructions.
Before you connect your Myou S1024 Computer to a power source, ensure that the voltage rating
of the AC adapter matches that of the available power source.
- 115 V/60 Hz in most of North and South America and some Far Eastern countries such as
South Korea.
- 100 V/50 Hz in eastern Japan and 100 V/60Hz in western Japan.
- 230 V/50 Hz in most of Europe, the Middle East, and the Far East.
If you use an extension cord with your AC adapter, ensure that the total ampere rating of all
devices plugged into the extension cord does not exceed its total capacity.
When removing battery from your Myou S1024 Computer, rst turn off the system, disconnect the
AC adapter from the electrical outlet, then remove the battery.
To avoid risk of an electrical shock, do not connect or disconnect any cables, or perform
maintenance or reconguration of this product during a thunderstorm.
Do not throw batteries into re, doing so may cause explosion. Check with local authorities rst for
battery disposal instructions.
NOTICE: When taking your Myou S1024 Computer from a colder to a warmer environment or vice
versa, allow your Myou S1024 Computer enough time to adapt to the new environment before turning
on power.










III
ENGLISH
When unplugging the power cord, please make sure that you pull on its connector or on its strain
relief loop, and not on the power cord itself. As you pull out the connector, please ensure that it is
pulled out evenly in order not to bend its connecting pins. Also, before you connect the power cord,
make sure that both connectors are correctly oriented and aligned.
Before you clean your Myou S1024 Computer, turn it off rst, unplug it from its power source, and
remove the battery.
Handle interior components with care. When removing a component, please hold it by the edge
and not on the connecting pins (such as the memory module).
When using your telephone equipments, safety instructions should always be followed in order
to prevent re, electrical shock or injuries, these instructions include:
Do not use this product near water, for example, near a bathtub, washing basins, kitchen/
laundry sinks, wet basements or swimming pools.
Avoid using cordless phones during an electrical storm as lightening may cause electrical
shocks.
Do not use the telephone to report a gas leak within the leakage area.
WARNING: Void of Warranty
If the battery is not properly handled, there may be a risk of explosion; make sure you are using
the same or compatible battery.
Please discard used batteries according to the instructions given by the manufacturer.
Please be aware that use of cracked, severely scratched or poor quality discs may damage the
optical drive and corrupt data in the disc. Such discs may break while drive operates in high-
speed, in this case, your product warranty may be voided.






*
*
*

IV
ENGLISH
Regulatory Notices
Federal Communications Commission Notice
This equipment has been tested and found to comply with the limits for a Class B digital service,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
Any changes or modications made to this equipment may void the user’s authority to operate this
equipment. This equipment generates, uses, and can radiate radio frequency energy. If not installed
and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
All external cables connecting to this basic unit must be shielded.
For cables connecting to PCMCIA cards, see the option manual or installation
instructions.







V
ENGLISH
CE Notice (European Union)
This symbol indicates this Myou S1024 Computer complies with the EMC Directive and the
European Union’s Low Voltage Directive. This symbol also indicates that S1024 meets the following
technical standards:
EN 55022 — “Limitations and Methods of Measurement for the Radio Interferences of Information
Technology Equipment.”
EN 55024 — “Information technology equipment - Immunity characteristics - Limits and methods
of measurement.”
EN 61000-3-2 — “Electromagnetic compatibility (EMC) - Chapter 3: Limits - Section 2: Limits on
the harmonic current emissions (Equipment input current up to and including 16 A per phase).”
EN 61000-3-3 — “Electromagnetic compatibility (EMC) - Chapter 3: Limits - Section 3: Limits on
the voltage uctuations and icker in low-voltage power supply systems for equipment with rate
current up to and including 16 A.”
EN 60950 — “Safety of Information Technology Equipment.”
NOTE: EN 55022 emissions requirements provide for two classications
Class A governs commercial use
Class B is governs residential use
For CB:
Only use batteries designed for this computer. The wrong battery type may explode, leak or









VI
ENGLISH
damage the computer
Do not remove any batteries from the computer while it is powerd on
Don not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or
twisted) in any way. Even if the computer continues to work with a damaged battery in place, it
may cause circuit damage, which may possibly result in re.
Recharge the batteries using the Myou S1024 Computer’s system. Incorrect recharging may make
the battery explode.
Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service
representative or qualied service personnel.
Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries
carefully. Batteries may explode or leak if exposed to re, or improperly handled or discarded.
Keep the battery away from metal appliances.
Afx tape to the battery contacts before disposing of the battery.
Do not touch the battery contacts with your hands or metal objects.
Battery Disposal & Caution
The product that you have purchased contains a rechargeable battery. The battery is recyclable. At
the end of its useful life, under various state and local laws. It may be illegal to dispose of this battery
into the municipal waste stream. Check with your local solid waste ofcials for details in your area for
recycling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type
recommended by the manufacturer. Discard used battery according to the manufacturer’s instructions.









VII
ENGLISH
BSMI Notice (Taiwan Only)
Most Myou S1024 Computers are classied by the Bureau of Standards,
Meteorology and Inspection (BSMI) as Class B information technology equipment (ITE).
The symbol above must be attached to the product indicating compliance with the BSMI standard.
Preface
Congratulations on your purchase of a Myou S1024 Computer! Your new Myou S1024 Computer
features the most innovative features in portable computing technology. It combines state-of-the-art
ergonomics with sophisticated architecture, providing you with a personal computer that is compact,
powerful, and easy to use. Designed for a wide range of general, business, and personal productivity
applications, this Myou S1024 Computer is an ideal choice for use in the ofce, at home, and on the
road.
This Manual contains all the information you need to set up and use your Myou S1024 Computer, It
describes all of its features in a thorough yet easy-to-read manner.

CONTENTS
TAKING CARE OF YOUR Myou S1024 Small Notebook PC ...................................2
BEFORE YOU START.................................................................................................4
Make sure you have everything................................................................................4
Familiarize with the computer...................................................................................5
OPENING THE DISPLAY PANEL ........................................................................5
FRONT OVERVIEW.............................................................................................6
LEFT SIDE OVERVIEW .....................................................................................10
RIGHT SIDE OVERVIEW...................................................................................11
REAR SIDE OVERVIEW....................................................................................11
BOTTOM OVERVIEW........................................................................................15
GETTING STARTED..................................................................................................17
Power Sources .........................................................................................................17
CONNECTING THE POWER ADAPTER ..........................................................17
RECHARGING THE BATTERY..........................................................................18

Power Management..................................................................................................19
Starting Your Myou S1024 Computer.....................................................................24
POWER ON .......................................................................................................24
Status Indicators.................................................................................................26
Using Function Keys ..........................................................................................29
Using the TouchPad...........................................................................................30
BIOS SETTING ..........................................................................................................34
The Main Menu .........................................................................................................37
Advance Menu..........................................................................................................39
Security Menu...........................................................................................................40
Boot Menu.................................................................................................................41
Exit Menu ..................................................................................................................42
Cleaning & Maintenance..................................................................................................43
Appendix I: Specication.................................................................................................48
Appendix II: Recovery Update Notices...........................................................................51
Appendix III: Service Centers and Policy.......................................................................53

2
ENGLISH
ENGLISH
TAKING CARE OF YOUR Myou S1024 Small Notebook PC
To prevent possible overheating of the computer’
s processor, make sure you don’t block the
openings provided for ventilation.
DO NOT press or touch the display panel.
DO NOT place on uneven or unstable work
surfaces.
DO NOT use your Myou S1024 Computer under
harsh conditions.
DO NOT place or drop objects on the computer
and DO NOT apply heavy pressure on it.
DO NOT subject the computer to magnetic elds.
DO NOT expose to direct sunlight. DO NOT use or store in extreme temperatures.

3
BEFORE YOU START
ENGLISH
Avoid sudden changes in temperature or humidity
by keeping it away from A/C and heating vents.
DO NOT expose the computer to rain or
moisture.
DO NOT place near re or other sources of heat. DO NOT tamper with the batteries. Keep them
away from children.
DO NOT expose to dust and/or corrosive
chemicals.
DO NOT slam your Myou S1024 Computer shut
and never pick up or hold your Myou S1024
Computer by the display.
DO NOT spray water or any other cleaning uids
directly on the display.
If you are traveling with your computer, remember to
carry it as hand luggage. Do not check it in as baggage.

4
ENGLISH
BEFORE YOU START
Make sure you have everything
When you receive your Myou S1024 Small Notebook PC, unpack it carefully, and check to make
sure you have all the items listed below. For a pre-congured model you should have the follow-
ing:
Myou S1024 Computer
Lithium-Ion Battery
Expansion Port
AC adapter and Powercord
User Manual
Utility CD
Polishing cloth
Handybag (Optional)
Depending upon the conguration of your Myou S1024 Computer, you may also need following
items:
Driver and Application CD
Once you have checked and conrmed that your Myou S1024 Computer system is complete, read
through the following pages to learn about all of your Myou S1024 Computer components.










5
BEFORE YOU START
ENGLISH
Familiarize with the computer
OPENING THE DISPLAY PANEL
To open, simply lift the lid up.
When closing it, be sure not to slam it shut.

6
ENGLISH
FRONT OVERVIEW
The following is an overview of the front of the Myou S1024 Computer.
Camera
The 1.3M-pixel built-in camera allows you to have more visual features such as video recording,
visual conferencing and so on. For 1.3M-pixel camera, there is an active indicator which will be
ON when the camera working.
Microphone
The built-in digital microphone is an audio input device. It allows for reception and transmission of
voice and/or other audio data to any program capable of accepting such input.
Camera Active Indicator (for 1.3Mpixel Camera)
Camera
Microphone
Display Panel
TouchPad/Buttons
Stereo Speakers
Buttons/Status
Indicators
Keyboard

7
BEFORE YOU START
ENGLISH
Display Panel
The display panel is a color LCD panel with LED back lighting for the display of text and graphics.
Keyboard
The built-in Qwerty keyboard with dedicated Windows®and function keys.
Stereo Speakers
The built-in dual speakers allow for stereo sound.
TouchPad/Buttons
Press the left and right buttons located on the edge of the touch pad to do selection and execution
functions. These two buttons are similar to the left and right buttons on a mouse.

8
ENGLISH
Buttons/Status Indicators
The Status indicator lights correspond to specic operating mode. These modes are: Power
On/Suspend status, Battery status, Hard Disk Drive (HDD) Activity, WiFi Activity, Bluetooth Activity,
3.5G or WiMax Active, Caps Lock and Num Lock. Indicator lights are embedded in the touch type
button bar – Suspend/Resume/Power On, WiFi, Bluetooth and 3.5G or WiMax.
Suspend/Resume/Power On Button
This button turns your Myou S1024 Computer on and off as well as puts it into Sleep or Suspend
mode.Or, you can press it to resume the system from Sleep or Suspend mode. The embedded
indicator will On when system On and will blinking when system in either Sleep or Suspend mode.
WiFi
Battery/HDD/Caps Lock/Num Lock Bluetooth
Suspend/Resume/Power On Button
3.5G or WiMax

9
BEFORE YOU START
ENGLISH
WiFi
The WiFi button enables and disables Wireless LAN activity. The embedded indicator will On when
WiFi is working.
Bluetooth
The Bluetooth button enables and disables Bluetooth function. The embedded indicator will On
when Bluetooth is working.
3.5G or WiMax
The button function is depending on your system conguration. It could be use to enable or dis-
able either 3.5G or WiMax if your system equipped either one. The embedded indicator will On
when either 3.5G or WiMax is working.
Status Indicators
There four status indicators to show the activities or enable of HDD, battery charging, Caps Lock
and Num Lock.

10
ENGLISH
LEFT SIDE OVERVIEW
The following is a brief description of the left side of the Myou S1024 Computer.
Microphone Jack
The microphone jack allows you to connect an external mono microphone.
Headphone Jack
The headphone jack allows you to connect headphone, external speakers or amplier.
Memory Card Reader
The memory card reader offers the fastest and most convenient method to transfer pictures, music
and data between your Myou S1024 Computer and ash compatible devices such as digital cam-
eras, MP3 players, mobile phones, and PDAs.
Memory Card
Reader Headphone Jack
Microphone Jack
