Gigabyte U60 Ultra Mobile PC User manual

Ultra Mobile PC
User's Guide
Model: U60
First Edition: August 2007

IIIII
ENGLISH
IIIII
NOTICE
Specications and information found in this guide are subject to change without notice. Any changes therefore will be incorporated in future
editions. The manufacturer assumes no responsibility for errors or omissions in this document.
TRADEMARKS
• Windows™ is the trademark of Microsoft Corporation.
• Bluetooth® is the trademark owned by its proprietor.
• Other trademarks are properties of their respective owners.
Standards
The following standards are adopted throughout this guide:
• UMPC in boldface (with or without capitalization) refers to the UMPC computer that you have purchased.
• Boldface type is also used to highlight important information in this document.
• Whenever extra caution is called for, the information will be boxed in a dark frame preceded by "Note:" or "Warning:
Macrovision License of Notice
• This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this
copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless
otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

IIIII
IIIII
U60 Ultra Mobile PC User’s Guide
ENGLISH
CONTENTS
NOTICE .......................................................................................... II
TRADEMARKS ............................................................................... II
Standards ....................................................................................... II
Macrovision License of Notice ........................................................ II
Chapter 1 Before You Begin
1.1 Checking What You Received ................................................ 2
1.2 Examining Your Computer ...................................................... 2
1.3 The Five System LEDs ........................................................... 5
1.4 The Three Control Switches ................................................... 6
1.5 The Six System Buttons ......................................................... 7
1.6 The Four Communication Buttons .......................................... 7
1.7 Attention On Media Card Slot ................................................. 8
1.8 Touch Screen Calibration ....................................................... 9
1.9 Operating Temperature .......................................................... 9
Chapter 2 Battery
2.1 Battery Pack ......................................................................... 11
2.2 Recharging The Battery Pack ............................................... 11
2.3 Questions And Answers ....................................................... 11
2.4 Battery Maintenance ............................................................. 12
2.5 Power Consumption ............................................................. 12
2.6 Reducing Power Consumption ............................................. 12
2.7 Removing The Battery Pack ................................................. 13
2.8 Connecting System To AC Adapter ...................................... 13
Chapter 3 The Docking Station (Optional)
3.1 Different Views Of The Docking Station ............................... 15
3.2 Mounting The Detachable Stand .......................................... 16
3.3 Mounting The System Unit ................................................... 17
3.4 The Stylus Pen ..................................................................... 17
Chapter 4 The BAY Module Connector
4.1 Removing The Flip Stand ..................................................... 19
4.2 The BAY Modules ................................................................. 20
4.3 Installing The BAY Module ................................................... 20
4.4 The GPS Module Antenna .................................................... 21
4-5 The TV Tuner Module Antenna ............................................ 21
Chapter 5 Using the BIOS Setup Utility
Using the BIOS Setup Utility......................................................... 23
Chapter 6 Troubleshooting
6.1 Frequently Asked Question .................................................. 29
Appendix A Agency Regulatory Notices
A.1 Safety Instructions ................................................................ 32
A.2 Agency Notice ....................................................................... 35
Appendix B Recovery Update Notices
Appendix C Service Center

1IV
ENGLISH
1IV

1IV 1IV
U60 Ultra Mobile PC User’s Guide
ENGLISH
Before You Begin
Chapter 1 Before You Begin
Please read this section before you start using your Ultra Mobile
PC.

32
ENGLISH
Before You Begin
32
1.1 Checking What You Received
Your Ultra Mobile PC package should contain the following items:
• The Ultra Mobile PC.
• AC Adapter.
• AC Power Cord.
• CD Disc (Including Drivers and User's Guide).
• Battery Pack.
• TV Module with Antenna (Option).
• GPS Module with Antenna (Option).
• Docking Station (Option).
• Utility CD.
• Protection Bag.
• Warranty Card.
• Extra stylus pen.
Note: You should keep the original factory carton and packing
materials in case you need to ship the unit back for servicing.
1.2 Examining Your Computer
Before you start using your computer, you need to get acquainted
with its main features and interfaces:
Panoramic View
Slide the
display panel to
open up keyboard
before you operate.

32
32
U60 Ultra Mobile PC User’s Guide
ENGLISH
Before You Begin
Top View
1 Web Cam
2 Two Internal Microphones
3 LCD Screen
4 Touch Pad
5 Five System LEDs
6 Six System Buttons
7 Four Communication Buttons
8 Keyboard
Bottom View
1 Support Foot (also serves to lock and to disassemble the Flip
Stand)
2 Ventilation Holes
3 Speaker
4 Battery Pack
5 Flip Stand
6 Stylus Slot
Note: The stylus pen together with the system touch-screen LCD
display provides you a touch-screen operation by emulating the
industry standard mouse right click. You are advised to keep the
stylus pen in the stylus slot when not in use.

54
ENGLISH
Before You Begin
54
Front View
1 Connector for Docking Station
2 VGA Connector
3 USB Connector
Rear View
1 Kensington Lock
2 Ventilation Holes
Left View
1 Battery Lock
2 Battery Latch
3 USB Connector
4 Media Card Slot (SD/SD-IO)
5 Battery Pack

54
54
U60 Ultra Mobile PC User’s Guide
ENGLISH
Before You Begin
Right View
1 Microphone Jack
2 Power/Hold Switch
3 Volume (Increase/Decrease) Switch
4 Stylus Slot
5 Battery Pack
6 The SAS (Alt+Ctrl+Del) Switch
7 Headphone Jack
8 DC-In Jack
Two Types of Audio Jack
1.3 The Five System LEDs
The Bluetooth®LED
This LED would be lit when the Bluetooth® is powered
on. For details on how to power on and power off the
Bluetooth, please refer to Chapter 1.6.
The Wireless LAN LED
This LED would be lit when the Wireless LAN is
powered on. For details on how to power on and power
off the Wireless LAN, please refer to Chapter 1.6.
The HDD Access LED
This LED would be lit when system is accessing the
HDD drive.
The Battery Pack LED
Below is how the LED would behave in different
situations:
On Battery pack is being recharged: fast-charge or
pre-charge.
Off Battery pack is not under recharge.
Blinking Battery pack is consuming down to 10% level.
The Power On LED
Below is how the LED would behave in different
situations:
Stereo Jack: Your
headphone jack
should have this type
of connector as shown
here
Mono Jack: Your
microphone jack
should have this
type of connector as
shown here.

76
ENGLISH
Before You Begin
76
Off System is powered off, or in Hibernate mode.
On System is in full operation.
Blinking System is in Standby mode.
Note: The Five System LEDs are located near the bottom of
display panel. For exact location, please refer to the Top View
diagram in Chapter 1.2.
For more details on Standby and Hibernate, please refer to
Power Options in the Control Panel of your Microsoft Windows™
operating system.
ØFn Keys×
By pressing the Fn keys with other keys, it can simulate all
keyboard functions of a regular desktop keyboard.
[Fn]+[A]: Increase screen brightness.
[Fn]+[Z]: Decrease screen brightness.
[Fn]+[S]: Switch between LCD or external display device.
1.4 The Three Control Switches
The SAS (Alt+Ctrl+Del) Switch
Press this switch to emulate Windows' "Alt", "Ctrl" and
"Del" buttons pressed simultaneously.
The Power/Hold Switch
Slide this switch to the right ( ) to emulate standard
power button of a personal computer. The power button
is programmable by user. For details on how to program
the power button, please refer to the Power Options of
Control Panel in Windows™ System.
Slide this switch to the left (HOLD) to temporarily
suspend inputs from the keyboard, touch pad, six
system buttons on the left side of the LCD screen,
and the four communication buttons in between the
left/right keyboard. Manually slide this switch back to the
middle to resume functions of the above input devices.
The purpose of this switch is to prevent mis-triggering
of these input devices while the system unit is idle when
it is powered up. For exact locations of these input
devices, please refer to Top View diagram in Chapter 1.2.
The Volume Switch
Click this switch to the right (┿) to increase audio volume.
Click this switch to the left (━) to decrease audio volume.
Note: The Three Control Switches is located on the right side
of system unit. For exact location, please refer to the Right View
diagram in Chapter 1.2.

76
76
U60 Ultra Mobile PC User’s Guide
ENGLISH
Before You Begin
1.5 The Six System Buttons
The Mobility Center Button
Press this button to enter into the menu of optimized
mobility setting.
The Zoom-In Button
Press this button to change the screen resolution
(800x480, 1024x600, 1280x768) .
The Enter Button
Press this button to start the hand writing software
application.
The Scroll Button
Press this button to emulate the functions of these four
"f", "g", "h", and "i" keycaps.
The Left Mouse Button
Press this button to emulate the left mouse function.
The Right Mouse Button
Press this button to emulate the right mouse function.
Note: The Six System Buttons are located on the left side of
the LCD display. For exact location, please refer to the Top View
diagram in Chapter 1.2.
1.6 The Four Communication Buttons
The Bluetooth Button
Press this button to power on and power off the
Bluetooth®module. Powering on the Bluetooth® by
pressing this button does not automatically activate the
Bluetooth® function. After powering on, you need to
activate the Bluetooth® function through Windows™.
The main purpose of this button is to provide you a quick
way to turn off the power of Bluetooth® when entering
venues like airplanes, airports, and hospitals where the
usage of Bluetooth® is prohibited or not advisable.
The Wireless LAN Button
Press this button to power on and power off the Wireless
LAN module. Powering on the Wireless LAN by
pressing this button does not automatically activate the
Wireless LAN function. After powering on, you need to
activate the Wireless LAN function through Windows™.
The main purpose of this button is to provide you a quick
way to turn off the power of Wireless LAN when entering
venues like airplanes, airports, and hospitals where the
usage of Wireless LAN is prohibited or not advisable.
The Web Cam Button
Press this button to power on and power off the Web
Cam module. After powering on the Web Cam, you
need to activate its function through Windows™.

98
ENGLISH
Before You Begin
98
The BAY Button
Press this button to power on and power off the GPS
Module or TV Tuner Module. Powering on the GPS
Module or TV Tuner Module by pressing this button
does not automatically activate the respective functions.
After powering on, you need to activate the function
through Windows™. This button would work only when
the system is powered on, and either one of the GPS
or TV Tuner Module is connected into the system unit.
Note: GPS and TV Tuner Modules are optional and
need to be purchased separately. For details on how to
connect these modules to the system unit, please refer
to Chapter 4.
Note: The proper way to activate the above devices and modules
is as below:
1) Press the above buttons to power on the devices, and modules.
2) Activate the respective application programs in Windows™.
The effective range of the system Bluetooth® is 10 meters.
Note: The Four Communication Buttons are located between
the left/right keyboards. For exact location, please refer to the Top
View diagram in Chapter 1.2.
1.7 Attention On Media Card Slot
Please observe below safety measures:
• When no card (SD/SD-IO cards) is inserted into the media
slot, make sure this slot is covered by the "media slot door" as
supplied together with this Ultra Mobile PC. The purpose of this
"media slot door" is to prevent foreign matters from entering into
the system unit through this slot, when no card is inserted. When
inserting this "media slot door", please make sure the arrow is on
the topside as shown above. Inserting this door upside down may
cause damage to your Ultra Mobile PC.
Media Slot Door is
now inserted into the
system unit.
The Media Slot Door is
now taken out from the
system unit. Arrow on topside
of Media Slot
Door.

98
98
U60 Ultra Mobile PC User’s Guide
ENGLISH
Before You Begin
1.8 Touch Screen Calibration
The stylus pen together with the system touch-screen LCD display
provides you a touch-screen operation by emulating the industry
standard mouse right click. Below are the two conditions that you
need to calibrate your touch-screen.
• The rst time Windows is installed and boot up. The active cursor
is shifted; not exactly the same position where the stylus pen tip is
tapped.
• Periodically when you nd the active cursor is shifted away from
the screen position where the stylus pen tip is tapped.
To calibrate the touch-screen, go into Tablet PC Setting of
Control Panel of Windows™ XP. In the Tablet PC Setting
screen, select General and then Calibrate. Then follow instruction
to complete calibration.
Note: You need to set screen display resolution to 800x600 before
proceeding with the calibration.
1.9 Operating Temperature
Operating Temperature: 10°C to 35°C.

1110
ENGLISH
Battery
1110
Chapter 2 Battery

1110
1110
U60 Ultra Mobile PC User’s Guide
ENGLISH
Battery
2.1 Battery Pack
Your Ultra Mobile PC is equipped with a high-energy rechargeable
Lithium Ion (Li-Ion) battery pack. Battery life will vary depending
on the product conguration, product model, applications loaded
on the product, power management settings of the product, and
the product features used by the customer. As with all batteries,
the maximum capacity of this battery will decrease with time and
usage.
2.2 Recharging The Battery Pack
Your Ultra Mobile PC supports both on-line and off-line recharge.
Follow the procedure below to recharge battery:
• Make sure the battery pack is installed in the Ultra Mobile PC.
• Connect the AC adapter to the Ultra Mobile PC and to an
electrical outlet.
When a battery pack is being recharged, its battery LED (located
at the bottom of LCD display) would be lit. For details on the LEDs,
please refer to Chapter 1.3. When the Ultra Mobile PC is OFF, a
depleted Li-Ion battery will take three hours to recharge.
2.3 Questions And Answers
I can feel a mild heat next to the battery pack. Is it normal?
The battery will generate heat during recharging and
discharging. There is a protection circuit inside the Ultra
Mobile PC to prevent overheating. User needs not to worry.
My battery operation time is not as long as it should be.
Why?
The battery is heat sensitive and can only be charged to its
maximum if the battery and its environmental temperature
remain within 15-25°C (59-77°F). The more the temperature
deviates from this range during recharging, the less chance
there is for the battery to be fully charged. In order to
recharge the pack to its full capacity, users are requested
to cool down the unit by unplugging the AC Adapter. Wait
until it is cooled down. Then plug in the AC Adapter to start
recharging again.
I did not use my spare battery for a few days. Even though
it was fully recharged, there wasn’t as much power left as a
newly charged one. Why?
The batteries will self-discharge (1% per day for Li-Ion)
when they are not being recharged. To make sure a battery
pack is fully charged, recharge before use. Always keep the
battery inside the Ultra Mobile PC and have the AC adapter
connected whenever possible.

1312
ENGLISH
Battery
1312
I did not use my spare battery for months. I have problem in
recharging it.
If you happen to leave your battery pack to go through an
extended period of self-discharge, say more than three
months, the battery voltage level will become too low and
needs to be Pre-Charged (to bring the battery voltage level
high enough) before it automatically (for Li-Ion only) resumes
its normal Fast Charge. Pre-Charge may take 30 minutes.
Fast Charge usually takes 2~3 hours.
2.4 Battery Maintenance
To maintain the battery pack's maximum capacity, you should
occasionally let the Ultra Mobile PC deplete its battery power
completely before recharging.
To carry out a complete depletion of the battery, disconnect the
AC adapter and let your Ultra Mobile PC consume the remaining
battery power. To speed up the depletion, use the HDD as much as
possible. When the battery is empty, wait for the Ultra Mobile PC
to cool down (especially the battery). The temperature should be
within 15-25°C (59-77°F). Then insert the AC adapter to recharge
the battery.
2.5 Power Consumption
The Windows™ operating system has incorporated the latest
state-of-the-art ACPI (Advanced Conguration Power Interface)
power management methodology. In order to fully utilize the
power of your battery packs, it would be a good idea for you to
spend sometime to acquire a basic understanding of the power
management concept from your operating system.
In Windows™ Operating Systems, you can go through Power
Options of the Control Panel according to the version of
Windows™ Operating System the Ultra Mobile PC applies. We
shall not describe them in details.
2.6 Reducing Power Consumption
Although your Ultra Mobile PC (together with the operating
system) is capable of power conservation, there are measures you
can take to reduce the power consumption:
• Use the AC power whenever possible.
• Try to use the HDD drive to read and write les, instead of
using the external USB FDD.
• Disable unused devices, such as Web Cam, WLAN, Bluetooth®,
and etc.
• Decrease LCD panel brightness through Windows.
Note: Whenever system is powered on or powered off, make sure
the battery pack is installed in the battery pack compartment.

1312
1312
U60 Ultra Mobile PC User’s Guide
ENGLISH
Battery
2.7 Removing The Battery Pack
This battery pack can easily be removed and replaced. Make sure
that the computer is properly shutdown before changing the battery
pack. If you would like to change the battery pack while power is
on, make sure this battery pack is not the only electrical source to
the system unit. Follow the steps below to remove the battery pack.
• Make sure the system is properly shutdown.
• Flip the system upside down as shown.
• Push the battery lock to the unlock position as shown by #1.
• Push the battery latch to the unlock position as shown by #2.
• Remove the battery pack as shown by #3.
To insert the battery pack, reverse the steps above.
2.8 Connecting System To AC Adapter
• Connect AC adapter to system unit as shown by #1.
• Connect AC power cord to AC adapter as shown by #2.
• Connect other end of power cord to an electrical outlet as shown
by #3.

1514
ENGLISH
The Docking Station (Optional)
1514
Chapter 3 The Docking Station
(Optional)
Depending on model, your Ultra Mobile Personal Computer is
equipped with an optional Docking Station. This Docking Station
supports hot plug-and-play with the system unit.

1514
1514
U60 Ultra Mobile PC User’s Guide
ENGLISH
The Docking Station (Optional)
3.1 Different Views Of The Docking Station
Panoramic View
1 Power Button
2 Connector to System Unit
3 Detachable Stand
Note: This Power Button has the same function as the Power
Switch as described in Chapter 1.4. For details, please refer to
Chapter 1.4.
The Detachable Stand is shipped not mounted to the main body of
the Docking Station as shown above. For details on how to mount
this Detachable Stand, please refer to Chapter 3.2.
Front View
1 Power Button
2 Detachable Stand
Rear View
1 USB Connectors
2 RJ45 LAN Connector
3 DC-In Jack
4 VGA Connector

1716
ENGLISH
The Docking Station (Optional)
1716
Right View
1 Stylus Pen
2 Stylus Pen Tray (push to eject)
3 IEEE 1394 Connector
4 Headphone Jack
Left View
1 USB Connector
3.2 Mounting The Detachable Stand
• Align and lock the tenon from detachable stand to the mortise
from the docking station as shown by #1.
• Slide the right side of the detachable stand in the direction as
shown by #2.
• Gently press the detachable stand to the docking station as
shown.
Reverse the above steps to un-mount the detachable stand.
