W466 / W566 Notebook User's Manual
Original Issue: 2007/04
This manual guides you in setting up and using your new Notebook PC. Information in the manual has been carefully checked for
accuracy and is subject to change without notice.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic,
mechanical, photocopy, recording, or otherwise, without prior written consent.
Trademarks
Product names used herein are for identication purposes only and may be the trademarks of their respective companies.
Microsoft®, MS-DOS, Windows®, and Windows®Sound System are trademarks of Microsoft Corporation.
Intel®, Centrino™, Centrino Duo™, Pentium®M, Banias, Calexico are registered trademarks of Intel Corporation.
Sound Blaster, Sound Blaster Pro are trademarks of Creative Technology.
All other brands or product names mentioned in this manual are trademarks or registered trademarks of their respective companies.

English
III
III
Safety Instructions
Use the following safety guidelines to help protect yourself and
your notebook.
When Using Your W466 / W566 Notebook Computer
CAUTION: Do not operate your portable computer for an
extended period of time with the base resting directly on your
body. With extended operation, heat can build up in the base.
Allowing sustained contact with the skin can cause
discomfort or a burn.
• Do not attempt to service the notebook yourself. Always follow in-
stallation instructions closely.
• Do not carry a battery in your pocket, purse, or other container
where metal objects (such as car keys) could short-circuit the bat-
tery terminals. The resulting excessive current ow can generate
extremely high temperature and may cause burns to your skin.
• Be sure that nothing rests on your AC adapter’s power cable and
that the cable is not located where it can be tripped over or stepped
on.
• While you are using the computer or charging the battery, place
the AC adapter in a ventilated area, like on a desktop or on the
oor. Do not cover the AC adapter with papers or other items that
may prevent ventilation. Also, do not use the AC adapter while it is
inside a carrying case.
• Do not insert objects into the air vent of your notebook computer.
Doing so can cause short-circuiting and may result in re or electri-
cal shock.
• Use only the AC adapter and batteries that are supplied by your
notebook manufacturer. Using other types of battery or AC adapter
may heighten the risk of re or explosion.
• Incorrectly placed batteries may result in an explosion.
• Replace only with the same or compatible battery recommended
by the manufacturer.
• Please discard used batteries according to the manufacturer’s in-
structions.
• Before you connect your notebook to a power source, ensure that
the voltage rating of the AC adapter matches that of the available
power source.
- 115 V/60 Hz in most of North and South America and some Far
Eastern countries such as South Korea and Taiwan.
- 100 V/50 Hz in eastern Japan and 100 V/60Hz in western Japan.
- 230 V/50 Hz in most of Europe, the Middle East, and the Far East.
• If you use an extension cord with your AC adapter, ensure that the
total ampere rating of all devices plugged into the extension cord
does not exceed its total capacity.
• When removing battery from your notebook, rst turn off the sys-
tem, disconnect the AC adapter from the electrical outlet, then re-
move the battery.
• To avoid risk of an electrical shock, do not connect or disconnect
any cables, or perform maintenance or reconguration of this prod-
uct during a thunderstorm.
• Do not throw batteries into re, doing so may cause explosion.
Check with local authorities rst for battery disposal instructions.
• When setting up your notebook for work, place it on a level sur-
face.

III
English
W466 / W566 NOTEBOOK SERIES USER’S MANUAL
III
• When traveling, do not check your notebook as baggage. You can
put your notebook through an X-ray security machine, but never
put your notebook through a metal detector. If you have your note-
book checked by hand, be sure to have a charged battery ready in
case you are asked to turn on your notebook.
• When traveling with the hard drive removed from your notebook,
wrap the drive in an insulated material, such as cloth or paper. If
you have the drive checked by hand, you may be asked to install
the drive into your notebook. Your can have the hard drive checked
through an X-ray machine, but never put the drive through a metal
detector.
• When traveling, do not place your notebook in the overhead stor-
age compartment where it could shift around. Do not drop your
notebook or subject it to other mechanical shocks.
• Protect your notebook, battery, and hard drive from environmental
hazards such as dirt, dust, food, liquids, extreme temperature, and
direct exposure to sunlight.
• When you move your notebook in environments where there is a
substantial difference of temperature or humidity level, condensa-
tion may form on or within your notebook. To avoid damaging your
notebook, please allow sufcient time for the moisture to evaporate
before continue using.
NOTICE: When taking your notebook from a colder to a warmer environ-
ment or vice versa, allow your notebook enough time to adapt to the
new environment before turning on power.
•When unplugging the power cord, please make sure that you pull
on its connector or on its strain relief loop, and not on the power
cord itself. As you pull out the connector, please ensure that it is
pulled out evenly in order not to bend its connecting pins. Also, be-
fore you connect the power cord, make sure that both connectors
are correctly oriented and aligned.
• Before you clean your notebook, turn it off rst, unplug it from its
power source, and remove the battery.
• Handle interior components with care. When removing a compo-
nent, please hold it by the edge and not on the connecting pins
(such as the memory module).
When using your telephone equipments, safety instructions
should always be followed in order to prevent re, electrical
shock or injuries, these instructions include:
• Do not use this product near water, for example, near a bath-
tub, washing basins, kitchen/laundry sinks, wet basements or
swimming pools.
• Avoid using cordless phones during an electrical storm as light-
ening may cause electrical shocks.
• Do not use the telephone to report a gas leak within the leak-
age area.
WARNING: Void of Warranty
* If the battery is not properly handled, there may be a risk of
explosion; make sure you are using the same or compatible
battery.
* Please discard used batteries according to the instructions given
by the manufacturer.
* Please be aware that use of cracked, severely scratched or poor
quality discs may damage the optical drive and corrupt data in
the disc. Such discs may break while drive operates in high-
speed, in this case, your product warranty may be voided.

English
IVIII
IVIII
Regulatory Notices
Federal Communications Commission Notice
This equipment has been tested and found to comply with the limits
for a Class B digital service, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
Any changes or modications made to this equipment may void the
user’s authority to operate this equipment. This equipment gener-
ates, uses, and can radiate radio frequency energy. If not installed
and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guaran-
tee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiv-
er.
● Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
● Consult the dealer or an experienced radio/TV technician
for help.
● All external cables connecting to this basic unit must be
shielded.
For cables connecting to PCMCIA cards, see the option
manual or installation instructions.
Federal Communications Commission (FCC)
PART 68 Warning
This equipment complies with Part 68 of the FCC Rules. On the
bottom of the computer is a label that contains, among other in-
formation, the FCC Registration Number and Ringer Equivalence
Number (REN) for this equipment. You must, upon request, provide
this information to your telephone company.
FCC Part 68 Registration Number: 6CTTAI - 25876 - FB - E
REN: 0.8B
The REN is useful to determine the quantity of devices you may
connect to your telephone and still have those devices ring when
your number is called. In most, but not all areas, the sum of the
REN’s of all devices should not exceed five (5.0). To be certain of
the number of devices you may connect to your line, as determined
by the REN, you should call your local telephone company to de-
termine the maximum REN for your calling area.
If your MODEM causes harm to the telephone network, the local
Telephone Company may discontinue your service temporarily. If
possible, they will notify you in advance. However, if advanced no-
tice isn’t practical, you will be notified as soon as possible. You will
be informed of your right to file a complaint with the FCC.
Your telephone company may make changes in its facilities, equip-
ment, operations, or procedures that could affect the proper func-
tioning for your equipment. I they do, you will be notified in advance
to give you an opportunity to maintain an uninterrupted telephone
service.

IVIII
English
W466 / W566 NOTEBOOK SERIES USER’S MANUAL
IVIII
CE Notice (European Union)
This symbol indicates this W466 / W566 notebook computer
complies with the EMC Directive and the European Union’s Low
Voltage Directive. This symbol also indicates that W451U meets the
following technical standards:
• EN 55022 — “Limitations and Methods of Measurement for the
Radio Interferences of Information Technology Equipment.”
• EN 55024 — “Information technology equipment - Immunity char-
acteristics - Limits and methods of measurement.”
• EN 61000-3-2 — “Electromagnetic compatibility (EMC) - Chapter
3: Limits - Section 2: Limits on the harmonic current emissions
(Equipment input current up to and including 16 A per phase).”
• EN 61000-3-3 — “Electromagnetic compatibility (EMC) - Chapter
3: Limits - Section 3: Limits on the voltage uctuations and icker
in low-voltage power supply systems for equipment with rate cur-
rent up to and including 16 A.”
• EN 60950 — “Safety of Information Technology Equipment.”
NOTE: EN 55022 emissions requirements provide for two
classicaatios
• Class A governs commercial use
• Class B is governs residential use
BSMI Notice (Taiwan Only)
Most notebook computers are classified by the Bureau of Stan-
dards, Meteorology and Inspection (BSMI) as Class B information
technology equipment (ITE).
The symbol above must be attached to the product indicating
compliance with the BSMI standard.
CCC Notice (China Only)
• For W466 only
On Class A systems, the following warning will appear near the
regulation label:
Warning: This is a Class A product. In a domestic environment, this
product may cause radio interference, in which case users may be
required to take adequate measures.
Macrovision License of Notice
This product incorporates copyright protection technology that
is protected by methods and claims of certain U.S. patents and
other intellectual rights owned by Macrovision Corporation, and
other rights owners. Use of this copyright protection technology
must be authorized by Macrovision Corporation and is intended
for home and other limited viewing uses only unless authorized by
Macrovision Corporation. Reverse engineering of disassembly is
prohibited.

English
VIV
VIV
Preface
Congratulations on your purchase of a Notebook computer! Your
new notebook features the most innovative features in portable
computing technology. It combines state-of-the-art ergonomics with
sophisticated architecture, providing you with a personal computer
that is compact, powerful, and easy to use. Designed for a wide
range of general, business, and personal productivity applications,
this notebook is an ideal choice for use in the ofce, at home, and
on the road.
This Manual contains all the information you need to set up and
use your notebook computer, It describes all of its features in a
thorough yet easy-to-read manner.

VIV
English
W466 / W566 NOTEBOOK SERIES USER’S MANUAL
VIV
Content
Safety instructions ......................................................................... I
Regulatory Notices ........................................................................ III
Preface .......................................................................................... V
Chapter 1 Operating Basics
1.1 Using the Battery Pack .........................................................02
1.2 Connecting the AC Adapter ..................................................03
1.3 Turning Your Notebook On and Off ......................................03
1.4 Installing W466 / W566 Device Drivers ................................04
1.5 Using the Launch Keys.........................................................04
1.6 Keyboad Functions ...............................................................05
1.7 Using the Touchpad..............................................................08
1.8 Storage .................................................................................09
1.9 Inroducing the Camera .........................................................10
1.10 Graphics Display...................................................................10
1.11 Protecting Your W466 / W566 Notebook Computer .............12
Chapter 2 Connecting Peripherals
2.1 Using the USB Port...............................................................15
2.2 Connecting to an External Monitor via the VGA Port ...........15
2.3 Using the Port Replicator Connector ...................................16
2.4 Using the LAN Port ...............................................................17
2.5 Using the Modem Port ..........................................................17
2.6 Using the IEEE 1394 Port ....................................................18
2.7 PCI Express card/Newcard...................................................18
2.8 Connecting to the S-Video Port ...........................................19
2.9 SD/MMC/MS/MS Pro Cards .................................................19
2.10 Using your Bluetooth (optional) and Wireless devices. ........20
Chapter 3 Troubleshooting
3.1 Frequently Asked Questions.................................................22
Appendix A W466 Specications..................................................24
Appendix B W566 Specications..................................................26
Appendix C Service Centers ........................................................28

English
W466 / W566 NOTEBOOK SERIES USER’S MANUAL
1PB
Chapter 1 Operating Basics
This chapter will show you how to operate your W466 / W566
notebook computer, including connecting the AC adaptor, turning
the computer on/off, using touch-pad, keyboard, hot keys, battery,
and so on. If you are new to computers and to the operating
system, this chapter will guide you through some of the new
exciting features.

English
32
32
1.1 Using the Battery Pack
W466 / W566 notebook computer is designed to operate with one
of the following power sources:
• AC power
(using the AC adapter connected to an electrical outlet)
• Lithium-Ion (Li-Ion) battery pack
You should use the AC adapter whenever possible; use the battery
pack only when AC power is unavailable. The rechargeable Li-
Ion battery pack allows you to operate your notebook computer
without an external power source. When you use the AC adapter
to connect your notebook to a power outlet, the internal battery will
begin to recharge. While the battery is charging, the Battery Charge
icon on the indicator panel will be on. Once the battery is fully
charged, the Battery Charge icon will turn off. Quick charging time
is 2.5 hours for the Lithium-Ion (Li-Ion) battery when the computer
is turned off, while the normal battery charging time is 3.5 hours.
• Operating a fax modem, video, or audio equipment can increase
the use of your computer’s power.
• Decreasing monitor brightness can also save power.
• When the battery is not fully charged, allow your battery to be
charged completely before using it (i.e., before disconnecting AC
power). Calibrating the battery before use is also highly recom-
mended.
• Li-Ion Battery is vulnerable, do not charge it with other power adap-
ter, otherwise fire or explosion may occur.
►Replacing the Battery◄
The battery will gradually weaken over time. We recommend that
you replace your battery when you notice a signicant decrease of
battery capacity.
To change the battery pack, follow the steps below:
1. Turn off the computer.
2. Close the lid and ip the computer over.
3. Slide the side battery latch (1) to the left. Continue to hold it
until the battery is removed.
4. Make sure the replacement battery is properly oriented before
inserting it into the battery compartment.
Note: The battery can not be charged to 100% when remaining
battery is no less than 95%. It is based on the supplier’s advice,
and to extend charging frequency and battery life.
►Maintenance of the AC Adapter◄
• Do not connect the adapter to any other device.
•
Do not step on the power cord or place heavy objects on top of it. Ca-
refully route the power cord and keep cables away from all traffic.
• When unplugging the power cord, do not pull on the cord itself but
on the plug instead.
• If you are using an extension cord, make sure that the devices
plugged onto the cord do not exceed its total capacity. Furthermo-
re, the devices plugged into the electrical outlet shall not exceed
the fuse’s total ampere rating.
• Please verify power voltage before connecting the electrical cord
to the power outlet. If you are uncertain of its power specification,
please consult with your local vendors or power company for more
details.

32
English
W466 / W566 NOTEBOOK SERIES USER’S MANUAL
32
1.2 Connecting the AC Adapter
The AC adapter converts AC power to DC power and reduces the
voltage supplied to the computer. It can automatically adjust to any
voltage from 100 to 240 volts and outputs power at 19V, 4.74A for
W566N (19V, 3.42A for W466U / W566U), allowing you to use your
notebook computer in almost any region.
CAUTION: Use only the AC adapter and the power cord we
recommend. Using the wrong adapter may damage your computer.
We assume no responsibilities for damages arising from misuse of
AC adapters.
To properly connect the adapter, follow the steps as below:
1. Connect the power cord to the AC adapter.
2. Connect the AC adapter to the DC power port of your computer.
3. Connect the AC adapter power cord to an AC outlet.
1.3 Turning Your Notebook On and Off
►Turning on the power◄
Open the notebook lid, press and hold the power button for one or
two seconds. The power indicator will glow blue once the computer
is powered on.
►Turning off the power◄
If you are not going to use your notebook computer for a while,
it is best to turn off its power. Before turning off power, close all
programs rst and shut down the operating system.
After turning off your notebook computer, make it a habit to leave
the LCD panel open for a while after it has been used for an
extended period of time. This allows the interior of your notebook
computer to cool off. Closing the panel will force the heat up
against the LCD screen, and doing so after a while may damage
the screen. More importantly, never close the LCD panel for a long
period of time when the computer is on or when the power saving
function is disabled.
►Suspend mode◄
You can adjust default power management settings in the Power
Option/Advanced dialog box. The Power Options dialog box
provides several operating functions after your computer has been
idle for a while.

English
54
54
1.4 Installing W466 / W566 Device Drivers
If your W466 / W566 Notebook Computer already has an operating
system installed, it is best to install all necessary device drivers in
order for he hardware to properly function.
Before installing drivers, check with your vendors to see if they
have already installed all the drivers with the operating system, if
not, please follow the steps below:
1. You can nd the Utility Driver CD like the one shown below:
2. Put the CD into the CD R-W or DVD-RW (optional) Drive. An
Auto Run installation screen will appear.
1.5 Using the Launch Keys
The easy access buttons located on the top of the left side allow
you to easily access the internet and your E-Mail client (such as
Microsoft®Outlook).
There are 5 launch keys found next to the power button:
►W466 Launch Keys
►W566 Launch Keys
󲨘Internet
󲨘Opens up your Internet Explorer browser.
E-Mail
󲨘This button launches your E-Mail client (such as Microsoft®
Outlook).
󲨘Fanless
Press this button to reduce fan noise (Silent Mode).
󲨘Mute
Press this button to mute sound effects.
󲨘Wireless/Bluetooth
Press to activate wireless function.

54
English
W466 / W566 NOTEBOOK SERIES USER’S MANUAL
54
1.6 Keyboad Functions
W466 / W566 notebook computer is equipped with a standard
typewriter-layout keyboard and has extra features.
Basic Keypad
Keypad Function Desription
<Enter> key. Execute a command. Within many text
editing programs, the <Enter> key inserts a hard carriage
return, just like what an ordinary typewriter does.
<Esc> key. Press this key to cancel or escape from a
command or function.
<Ins> key. Known as the Insert key. Press this key to
change from insert to type over mode.
+
<Fn>+<PrtSc> key. Known as the Print Screen key.
Press this key to map the whole screen to share memory
for your specic usage.
<Del> key. Known as the Delete key. Press this key to
delete the character to the right of the cursor, or delete
marked texts or items.
+
<Num Lk>, <Fn>+<Home> key.
To activate/ deactivate Light Sensor. Press <Num Lk>
rst. When Num Lock light (beside Power Button) is on,
release <Num Lk> and press <Fn>+<Home>.
<Pause> key. Press this key to temporarily halt execution
of a command. Pressing any other keys to resume
execution of a command.
<Shift> key. Press this key in combination with letters
to produce uppercase letters in typing. Use this key
in combination with those two-character keys (found
on the second row of the keyboard) to produce the
upper marked keys. Also used in most programs
in combination with other keys to execute a certain
command.
<Tab> key. Press this key to move the cursor to the
next tab on the right. This key works much the same
way as on an ordinary typewriter.
<Ctrl> key. Known as the Control key. Used in most
programs in combination with other keys to execute a
command.
<Alt> key. Known as the Alternate key. Used in most
programs in combination with other keys to execute a
command.

English
76
76
<Num Lk> key. Activates the embedded 15-key numeric
keypad.
+
<Fn>+<Scr Lk> key. Used in most programs to scroll the
screen without having to move the cursor. The keys are
in color-coded blue.
<Cap Lock> key. Used in most programs to always
activate uppercase letters.
Up arrow key. Moves the cursor up one line at a time.
Down arrow key. Moves the cursor down one line at a
time.
Left arrow key. Moves the cursor to the left one space at
a time.
Right arrow key. Moves the cursor to the right one space
at a time.
<Home> key. Moves the cursor to the beginning of a
screen or line.
<PgUp> key. Moves the cursor up one screen at a time.
<PgDn> key. Moves the cursor down one screen at a
time.
<End> key. Moves the cursor to the end of a screen or a
line.
Special Function Keys
►Embedded Numeric Keypad◄
The embedded numeric keypad functions like the one on a desktop
keyboard. It is indicated by small characters located on the upper
left-hand corner of the keycaps.
Desired Access Num Lock On Num Lock Off
Number keys on
embedded keypad
Type numbers in a
normal manner
Cursor-control keys/
embedded keypad
Hold Shift while
using cursor-control
keys
Hold Fn while using
cursor-control keys
Main Keyboard keys Hold Fn while typing
letters on embedded
keypad
Type the letters in a
normal manner
Note: If an external keyboard or keypad is connected to your
notebook computer, the Numlock automatically shifts from an
internal keyboard to the external keyboard or keypad.

76
English
W466 / W566 NOTEBOOK SERIES USER’S MANUAL
76
►Windows Keys◄
Key Description
+[F1] Opens help and support
+E Explores my computer
+F Finds document
+M Minimizes all
+ Shift + M Undoes minimize all
+ R Displays run dialog box
+ Tab Activates next taskbar button
►Basic keypad◄
you can input letters, numbers, punctuation marks, and special
symbols with it.
►Fn Keys◄
By pressing the Fn key with other keys, it can simulate all keyboard
functions of a regular desktop keyboard.
[Fn]+[F1] Suspend switch
[Fn]+[F2] Activate or deactivate wireless functions
[Fn]+[F3] Switch between LCD or CRT monitor
[Fn]+[F4] Increase screen brightness
[Fn]+[F5] Decrease screen brightness
[Fn]+[F6] Audio mute
[Fn]+[F7] Decrease audio volume
[Fn]+[F8] Increase audio volume
[Fn]+[F9] Play or pause media player
[Fn]+[F10] Stop media player
[Fn]+[F11] Media player skip backward
[Fn]+[F12] Media player skip forward
[Fn]+[Esc] Enable or disable Bluetooth function

English
98
98
1.7 Using the Touchpad
The Touchpad is a pressure-sensitive pointing device that provides
all of the features of a two-button mouse; its primary function is to
move the cursor around the screen.
Since the Touchpad is a pressure-sensitive device, therefore
proper care should be attended to in order to prevent damage.
Please also note the following precautions:
• Make sure the touchpad does not come into contact with dirt,
liquid or grease.
• Do not touch the touchpad if your fingers are dirty.
• Do not place heavy objects on the touchpad or on the touchpad
buttons.
►Clicking◄
You can move the pointer over to the item with your nger on the
pad, and click once on the left button below to select it, or simply
tap once on the touchpad.
►Double Clicking◄
Move the pointer over to the item with your nger on the pad, and
click twice on the left button to select menu items, or simply tap
twice on the touchpad.
►To drag and drop◄
Move the pointer over to the item with your nger on the pad, click
once on the left button beneath the Touchpad and select the item
you want, once the item is selected, you can then drag the item by
gliding your nger on the Touchpad (clicking twice on the Touchpad
buttons equals to the speed of a double-click on a regular mouse).
►The Scroll buttons◄
If you are scrolling through the document, you may do so by gliding
your nger on the Touchpad while holding the scroll button.
You may adjust your Touchpad settings by going into Start/Control
Panel /Mouse/Buttons. You can change the Touchpad’s operating
orientations through these settings, for example changing from
right-handed to left-handed operations. You may also adjust cursor
speed as well as response time of mouse clicks.
Touchpad
Touchpad
buttons

98
English
W466 / W566 NOTEBOOK SERIES USER’S MANUAL
98
1.8 Storage
►Hard Disk◄
W466 / W566 notebook computer is equipped with a built-in large
capacity 2.5 inch IDE hard disk drive where you store or install
your computer operating system as well as software programs. The
internal hard disk is normally assigned as Drive C after formatting.
If you wish to replace your hard disk, contact your local
vendor for information about your notebook computer’s
hardware setup.
You can increase the system’s storage capacity by replacing
the standard hard disk drive with a drive of a greater capacity.
Always turn off your notebook computer before removing the
hard drive. Failure to do so will damage the computer and the
hard disk. Avoid jarring or moving your computer while the
hard disk is still being accessed.
►Optical Disc Drive (ODD)◄
W466 / W566 notebook computer is equipped with one of the DVD
Super Multi
The optical drive is normally used for installing operating system
and software programs. To insert and remove a disc from the drive:
1. Press the button on the front of the drive to eject the disc tray
and gently pull out the tray.
2. Place the disc on the tray with label side up.
3. Place the disc on the spindle and press it down gently until the
disc clicks into place.
4. Slide the tray back until it clicks shut.
Warning: When the computer is reading from the optical drive, the
indicator light for ODD will ash on. Do not attempt to remove the
disc while the indicator light is still active.
Warning: Do not insert any foreign objects into the disc tray. Do not
force the tray to open or close. When the drive is not in use, keep
the tray closed in order to prevent dust or dirt from entering the drive.
If you experience difculty when removing a disc, stick a paper clip (or
use a pin or a thin metal rod) into the emergency eject hole, the CD
disc tray should eject immediately. This procedure can also be used
to remove a CD from the drive when the notebook is powered off.
Please refer to gure below.
1
2

English
1110
1110
1.9 Inroducing the camera
Your W466U / W566U notebook computer comes with a built-in
camera.With this camera, you can conduct videoconferences
with your friends or colleagues whenever and wherever as if they
are right in front of you. It also works as a digital camera (with a
resolution up to 1.3 Megapixel) that you can use to take snapshots
instantly.
►W466 camera
►W566 camera
1.10 Graphics Display
Your computer has a high-performance graphics display system, which
can easily handle the demands of today’s multimedia computing.
►Screen Controls◄
Brightness
Function keys can increase or decrease the brightness of the monitor.
• <Fn> + <F4> decreases the LCD panel brightness.
• <Fn> + <F5> increases the LCD panel brightness.
Resolution
1. Click My Computer/Control Panel/Appearance and Themes/ Display.
Click on the Settings tab. The dialog box will display your monitor’s
current resolution.
2. Under “Screen resolution,” use the slide bar to adjust monitor’
s resolution. Normally, you should use the resolution your LCD
monitor was designed for.
Note: Using a lower resolution than the screen was designed for will
reduce the displaying area. Using the computer in DOS mode produces
the same effect, because it uses a 640 by 480 resolution by default.
►Dual Displays◄
Under Windows operating system, you may use an external monitor
and your notebook’s LCD screen simultaneously. You may also choose
to only use the external monitor with the LCD disabled or vice versa.

1110
English
W466 / W566 NOTEBOOK SERIES USER’S MANUAL
1110
1. Open Control Panel.
2. Double-click on Display. The Display Properties window will
open.
3. Click on the Settings tab.
4. Click on the Advanced button.
■ W566N
Click on GeForce Go 8400 tab. Choose nView Display Set-
tings to adjust.
■ W466U / W566U
Choose Intel Graphics Media Accelerator Driver for mobile.
Click Graphics Properties to adjust.
Single Display (for both W566N and W466U / W566U)
In Single Display mode, you can choose which device to apply as
the Primary display. The video display hot keys are available. You
can select different video outputs by pressing Fn+F3 repeatedly.
Clone (for W566N)
Extended Desktop (for W466U / W566U))
In Clone/Extended Desktop mode, the video display hot keys
are available. You can select different video outputs by pressing
Fn+F3 repeatedly. If the external monitor is connected, the display
on LCD and external monitor is the same.
Dualview (for W566N)
Dual Display Clone (for W466U / W566U)
In Dualview/Dual Display Clone mode, choose the monitor for
extended display. Dualview/Dual Display Clone mode is controlled
by the driver. You can adjust the type of video output in the Menu.
Fn+F3 has no switch function under this mode.

English
1312
1312
Tip: In order to ensure problem-free video display, when you
use an external monitor, change the output mode in the Display
properties dialog box first. After changing the output mode, you
can then use the video display hot keys.
Note: Light or dark pixels may appear on the LCD screen as a
result of LCD’s manufacturing limitations, however, this will not
effect your LCD screen’s normal functions.
1.11 Protecting Your W466 / W566 Notebook
Computer
W466 / W566 Notebook Computer provides both hardware and
software security locks to protect your computer.
Using a security lock:
A security lock notch can be found on the right side of the com-
puter. This notch allows you to connect a Kensington-compatible
security lock to it.

1312
English
W466 / W566 NOTEBOOK SERIES USER’S MANUAL
1312
Using a system protecing:
You can only enter the BIOS setup utility only when the computer
is turned on, in another word, between the time it’s turned on and
before the Windows splash screen appears. If your computer is
already turned on, reboot your computer and press the F2 key to
enter the setup utility.
►Security menu◄
• Supervisor Password
A Supervisor Password is required before you set User Password.
After selecting Change Supervisor Password, enter a new pass-
word then re-enter it to confirm. The password you enter should
contain up to 6 alphanumeric characters. If you make a mistake
while entering your password, you can always press Esc to start
over.
• User Password
You can enter into the setup utility to change or remove user pass-
words; however, you can not change or remove the Supervisor
Password, nor can you access the diskette.
• HDD Password
To input, change, or disable hard drive password. When shown as
[Locked], the hard drive password currently can not be changed
or disabled. To change or disable the function, turn off the system
and enter Setup right after turning it back on.
* Please remember the password when you decide to use HDD
Password. Your notebook service center may not be able to re-
store the HDD once the password is missing.
• Password on boot
A Supervisor Password is required before you set Password on
boot.
Main Advanced Boot
Security Exit
Supervisor Password Clear
User Password Is: Clear
HDD Password Clear
HDD Master ID 19893855
Supervisor Password [Enter]
User Password [Enter]
HDD Password [Enter]
Password on boot: [Disabled]
Item Specic Help
Supervisor Password
controls access to
the setup utility
F1 Help ↑↓ Select Item -/+ Change Values F9 Setup
Defaults
Info
BIOS SETUP UTILITY
