Gigabyte R182-340 User manual

R182-340
3rd Gen. Intel® Xeon® Scalable DP Server System - 1U 4-Bay
User Manual
Rev. 1.0

Copyright
© 2021 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specications and features in this manual may be made by GIGABYTE without
prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or
published in any form or by any means without GIGABYTE's prior written permission.
Documentation Classications
In order to assist in the use of this product, GIGABYTE provides the following types of documentation:
 User Manual: detailed information & steps about the installation, conguration and use of this
product (e.g. motherboard, server barebones), covering hardware and BIOS.

User Guide: detailed information about the installation & use of an add-on hardware or
software component (e.g. BMC rmware, rail-kit) compatible with this product.
Quick Installation Guide: a short guide with visual diagrams that you can reference easily for
installation purposes of this product (e.g. motherboard, server barebones).
Please see the support section of the online product page to check the current availability of these
documents.
For More Information
For related product specications, the latest rmware and software, and other information please visit our website at
http://www.gigabyte.com
For GIGABYTE distributors and resellers, additional sales & marketing materials are available from our reseller
portal: http://reseller.b2b.gigabyte.com
For further technical assistance, please contact your GIGABYTE representative or visit
https://esupport.gigabyte.com/ to create a new support ticket
For any general sales or marketing enquiries, you may also message GIGABYTE server directly by email:
server[email protected]

Conventions
The following conventions are used in this user's guide:
NOTE!
Gives bits and pieces of additional
information related to the current topic.
CAUTION!
Gives precautionary measures to
avoid possible hardware or software problems.
WARNING!
Alerts you to any damage that might
result from doing or not doing specic actions.

Server Warnings and Cautions
Before installing a server, be sure that you understand the following warnings and cautions.
WARNING!
To reduce the risk of electric shock or damage to the equipment:
• Do not disable the power cord grounding plug. The grounding plug is an important safety
feature.
• Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all
times.
• Unplug all the power cords from the power supplies to disconnect power to the equipment.
•
• Shock Hazard! Disconnect all power supply cords before servicing.
• Do not route the power cord where it can be walked on or pinched by items placed against it.
Pay particular attention to the plug, electrical outlet, and the point where the cord extends from
the server.
WARNING!
To reduce the risk of personal injury from hot surfaces, allow the drives
and the internal system components to cool before touching them.
WARNING!
This server is equipped with high speed fans. Keep away from hazardous
moving fan blades during servicing.
WARNING!
This equipment is intended to be used in Restrict Access Location. The
access can only be gained by Skilled person.
Only authorized by well trained professional person can access the
restrict access location.
CAUTION!
• Do not operate the server for long periods with the access panel open or removed. Operat-
ing the server in this manner results in improper airow and improper cooling that can lead to
thermal damage.
• Danger of explosion if battery is incorrectly replaced.
• Replace only with the same or equivalent type recommended by the manufacturer.
• Dispose of used batteries according to the manufacturer’s instructions.

Electrostatic Discharge (ESD)
CAUTION!
ESD CAN DAMAGE DRIVES, BOARDS, AND OTHER PARTS. WE RECOMMEND THAT YOU
PERFORM ALL PROCEDURES AT AN ESD WORKSTATION. IF ONE IS NOT AVAILABLE,
PROVIDE SOME ESD PROTECTION BY WEARING AN ANTI-STATIC WRIST STRAP AT-
TACHED TO CHASSIS GROUND -- ANY UNPAINTED METAL SURFACE -- ON YOUR SERVER
WHEN HANDLING PARTS.
Always handle boards carefully. They can be extremely sensitive to ESD. Hold boards only by
their edges without any component and pin touching. After removing a board from its protective
wrapper or from the system, place the board component side up on a grounded, static free sur-
face. Use a conductive foam pad if available but not the board wrapper. Do not slide board over
any surface.
System power on/o󰀨: To remove power from system, you must remove the system from
rack. Make sure the system is removed from the rack before opening the chassis, adding, or
removing any non hot-plug components.
Hazardous conditions, devices and cables: Hazardous electrical conditions may be
present on power, telephone, and communication cables. Turn off the system and discon-nect
the cables attached to the system before servicing it. Otherwise, personal injury or equipment
damage can result.
Electrostatic discharge (ESD) and ESD protection: ESD can damage drives,
boards, and other parts. We recommend that you perform all procedures in this chapter only at
an ESD workstation. If one is not available, provide some ESD protection by wearing an antistatic
wrist strap attached to chassis ground (any unpainted metal surface on the server) when handling
parts.
ESD and handling boards: Always handle boards carefully. They can be extremely
sensi-tive to electrostatic discharge (ESD). Hold boards only by their edges. After removing a
board from its protective wrapper or from the system, place the board component side up on a
grounded, static free surface. Use a conductive foam pad if available but not the board wrapper.
Do not slide board over any surface.
Installing or removing jumpers: A jumper is a small plastic encased conductor that slips
over two jumper pins. Some jumpers have a small tab on top that can be gripped with n-gertips
or with a pair of ne needle nosed pliers. If the jumpers do not have such a tab, take care when
using needle nosed pliers to remove or install a jumper; grip the narrow sides of the jumper with
the pliers, never the wide sides. Gripping the wide sides can dam-age the contacts inside the
jumper, causing intermittent problems with the function con-trolled by that jumper. Take care to
grip with, but not squeeze, the pliers or other tool used to remove a jumper, or the pins on the
board may bend or break.

CAUTION!
Risk of explosion if battery is replaced incorrectly or with an incorrect type. Replace the battery
only with the same or equivalent type recommended by the manufacturer. Dispose of used bat-
teries according to the manufacturer’s instructions.

- 7 -
Table of Contents
Chapter 1 Hardware Installation ...................................................................................10
1-1 Installation Precautions.................................................................................. 10
1-2 Product Specications.................................................................................... 11
1-3 System Block Diagram................................................................................... 14
Chapter 2 System Appearance.....................................................................................15
2-1 Front View...................................................................................................... 15
2-2 Rear View....................................................................................................... 16
2-3 Front Panel LED and Buttons ........................................................................ 17
2-4 Rear System LAN LEDs................................................................................. 18
2-5 Power Supply Unit (PSU) LED....................................................................... 19
2-6 Hard Disk Drive LEDs .................................................................................... 20
Chapter 3 System Hardware Installation ......................................................................21
3-1 Removing Chassis Cover............................................................................... 22
3-2 Removing and Installing the Fan Duct ........................................................... 23
3-3 Removing the Heat Sink ................................................................................ 24
3-4 Installing the CPU .......................................................................................... 25
3-5 Installing the Memory..................................................................................... 27
3-5-1 Eight Channel Memory Conguration.....................................................................27
3-5-2 Installing the Memory ............................................................................................28
3-5-3 DIMM Population Table ..........................................................................................28
3-6 Installing the PCI Expansion Card ................................................................. 29
3-7 Installing the Mezzanine Card........................................................................ 30
3-7-1 OCP 3.0..................................................................................................................30
3-7-2 OCP 2.0..................................................................................................................31
3-8 Installing the Hard Disk Drive......................................................................... 32
3-9 Installing the M.2 Device and Heat Sink ........................................................ 34
3-10 Replacing the Fan Assembly.......................................................................... 35
3-11 Replacing the Power Supply .......................................................................... 36
3-12 Cable Routing ................................................................................................ 37
Chapter 4 Motherboard Components ...........................................................................40
4-1 Motherboard Components ............................................................................. 40
4-2 Jumper Setting .............................................................................................. 42
4-3 Backplane Board Storage Connector ............................................................ 43

- 8 -
4-3-1 CBP1044 ................................................................................................................43
Chapter 5 BIOS Setup ..................................................................................................44
5-1 The Main Menu .............................................................................................. 46
5-2 Advanced Menu ............................................................................................. 49
5-2-1 Trusted Computing .................................................................................................50
5-2-2 Serial Port Console Redirection .............................................................................51
5-2-3 SIO Conguration...................................................................................................55
5-2-4 PCI Subsystem Settings.........................................................................................56
5-2-5 USB Conguration..................................................................................................57
5-2-6 Network Stack Conguration ..................................................................................58
5-2-7 Post Report Conguration ......................................................................................59
5-2-8 NVMe Conguration ...............................................................................................60
5-2-9 Chipset Conguration .............................................................................................61
5-2-10 Tls Auth Conguration ............................................................................................62
5-2-11 iSCSI Conguration................................................................................................63
5-2-12 Intel(R) i350 Gigabit Network Connection ..............................................................64
5-2-13 VLAN Conguration................................................................................................66
5-2-14 Driver Health...........................................................................................................67
5-3 Chipset Menu................................................................................................. 68
5-3-1 Processor Conguration .........................................................................................69
5-3-2 Common RefCode Conguration ...........................................................................72
5-3-3 UPI Conguration ...................................................................................................73
5-3-4 Memory Conguration ............................................................................................74
5-3-5 IIO Conguration ....................................................................................................77
5-3-6 Advanced Power Management Conguration ........................................................79
5-3-7 PCH Conguration..................................................................................................81
5-3-8 Miscellaneous Conguration ..................................................................................83
5-3-9 Server ME Conguration ........................................................................................84
5-3-10 Runtime Error Logging Settings .............................................................................85
5-3-11 Power Policy...........................................................................................................87
5-4 Server Management Menu............................................................................. 89
5-4-1 System Event Log ..................................................................................................91
5-4-2 View FRU Information ............................................................................................92
5-4-3 BMC VLAN Conguration.......................................................................................93
5-4-4 BMC Network Conguration ...................................................................................94
5-4-5 IPv6 BMC Network Conguration...........................................................................95
5-5 Security Menu ................................................................................................ 96
5-5-1 Secure Boot ...........................................................................................................97
5-6 Boot Menu.................................................................................................... 100

- 9 -
5-7 Save & Exit Menu......................................................................................... 102
5-8 BIOS POST Beep code (AMI standard)....................................................... 104
5-8-1 PEI Beep Codes...................................................................................................104
5-8-2 DXE Beep Codes .................................................................................................104

Hardware Installation - 10 -
1-1 Installation Precautions
The motherboard/system contain numerous delicate electronic circuits and components which
can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully
read the user manual and follow these procedures:
• Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or
warranty sticker provided by your dealer. These stickers are required for warranty validation.
• Always remove the AC power by unplugging the power cord from the power outlet before
installing or removing the motherboard or other hardware components.
• When connecting hardware components to the internal connectors on the motherboard,
make sure they are connected tightly and securely.
• When handling the motherboard, avoid touching any metal leads or connectors.
• It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic
components such as a motherboard, CPU or memory. If you do not have an ESD wrist
strap, keep your hands dry and rst touch a metal object to eliminate static electricity.
• Prior to installing the motherboard, please have it on top of an antistatic pad or within an
electrostatic shielding container.
• Before unplugging the power supply cable from the motherboard, make sure the power
supply has been turned off.
• Before turning on the power, make sure the power supply voltage has been set according to
the local voltage standard.
• Before using the product, please verify that all cables and power connectors of your
hardware components are connected.
• To prevent damage to the motherboard, do not allow screws to come in contact with the
motherboard circuit or its components.
• Make sure there are no leftover screws or metal components placed on the motherboard or
within the computer casing.
• Do not place the computer system on an uneven surface .
• Do not place the computer system in a high-temperature environment.
• Turning on the computer power during the installation process can lead to damage to
system components as well as physical harm to the user.
• If you are uncertain about any installation steps or have a problem related to the use of the
product, please consult a certied computer technician.
Chapter 1 Hardware Installation
