Gigabyte GS-SR147S User guide

SystemInstallation Guide
GS-SR147S
1URack MountServer
Pentium®4ProcessorServerboard
Rev.1001
P/N

2
GS-SR147SRack mountServer
TableofContent
Safety,Careand RegulatoryInformation ............................................3
Introduction ......................................................................................7
ContentsPackages..........................................................................7
WARNING!.......................................................................................7
Chapter1FeaturesSummary............................................................8
Chapter2SystemOverview............................................................10
Chapter3SystemHardwareInstallation ...........................................11
Step 3-1:ChassisRemoval.........................................................................11
Step 3-2:CPUInstallation............................................................................ 12
Step 3-3:HeatSinkInstallation ..................................................................... 13
Step 3-4:MemoryInstallation....................................................................... 13
Step 3-5:PCIExpansion CardInstallation ...................................................... 14
Step 3-6:HardDisk DriveInstallation............................................................. 15
Step 3-7:FANDuctRemovaland Installation ................................................. 16
Step 3-8:Reinstall ChassisCover................................................................ 16
Chapter4AppearanceofGS-SR147S.............................................17
4-1:FrontViewofGS-SR147S.................................................................... 17
4-2:RearViewofGS-SR147S..................................................................... 18
4-3:Switchand LEDIndicatorsDescription .................................................... 19
4-4:ConnectorIcon Description................................................................... 20
Chapter5Appendix........................................................................21
5-1:Acronyms.......................................................................................... 21

3
SafetyInformation
Safety,Careand RegulatoryInformation
LImportantsafetyinformation
Read and followall instructionsmarked on theproductand inthe documentation beforeyou operate
yoursystem.Retainall safetyand operating instructionsforfutureuse.
*The productshouldbe operated onlyfromthe type ofpowersourceindicated on the rating label.
*Ifyourcomputerhasavoltage selectorswitch,makesurethatthe switchisinthe properposition for
yourarea.The voltage selectorswitchissetatthe factorytothe correctvoltage.
*Theplug-socketcombination mustbeaccessibleatall timesbecauseitservesasthe maindisconnect-
ing device.
*Allproductshipped withathree-wireelectricalgrounding-type plugonlyfitsintoagrounding-type power
outlet. Thisisasafetyfeature.The equipmentgrounding shouldbe inaccordancewithlocaland national
electricalcodes.Theequipmentoperatessafelywhen itisused inaccordancewithitsmarked electrical
ratingsand productusage instructions
*Donotusethisproductnearwateroraheatsource.
*Setup the producton astableworksurfaceorsoastoensurestabilityofthe system.
*Openingsinthecaseareprovided forventilation.Donotblock orcovertheseopenings.Makesureyou
provide adequatespacearound thesystemforventilationwhen you setupyourworkarea.Neverinsert
objectsofanykind intothe ventilation openings.
*Toavoidelectricalshock,always unplug all powercablesand modemcablesfromthe wall outlets
beforeremoving covers.
*Allowthe producttocoolbeforeremoving coversortouching internalcomponents.
LPrecaution forProductwithLaserDevices
Observethe following precautionsforlaserdevices:
*Donotopenthe CD-ROMdrive,makeadjustments,orperformproceduresonalaserdeviceotherthan
thosespecified inthe product'sdocumentation.
*Onlyauthorized servicetechniciansshouldrepairlaserdevices.
LPrecaution forProductwithModems,Telecommunications,otLocalArea
NetworkOptions
Observethe following guidelineswhen working withoptions:
*Donotconnectoruseamodemortelephoneduring alightning storm.Theremaybeariskofelectrical
shock fromlightning.

4
GS-SR147SRack mountServer
*Toreducethe risk offire,useonlyNo.26AWGorlargertelecommunicationsline cord.
*Donotplug amodemortelephone cableintothe networkinterfacecontroller(NIC)receptacle.
*Disconnectthe modemcablebeforeopening aproductenclosure,touching orinstalling internal
components,ortouching an uninsulated modemcableorjack.
*Donotuseatelephone line toreportagasleakwhileyou areinthe vicinityofthe leak.
LFederalCommunicationsCommission (FCC)Statement
Note:Thisequipmenthasbeentested and foundtocomplywiththe limitsforaClassBdigitaldevice,
pursuanttoPart15 oftheFCC Rules.Theselimitsaredesigned toprovidereasonableprotection against
harmfulinterferencewhen the equipmentisoperated inacommercialenvironment. Thisequipment
generates,uses,and can radiateradiofrequency energyand,ifnotinstalledandused inaccordancewith
the instruction manual,maycauseharmfulinterferencetoradiocommunications.Operation ofthis
equipmentinaresidentialarea islikelytocauseharmfulinterferenceinwhichcasethe userwill be
required tocorrectthe interferenceathisownexpense.
Properlyshielded and grounded cablesand connectorsmustbe used inordertomeetFCC emission
limits.Neitherthe providernorthe manufacturerareresponsibleforanyradioortelevision interference
caused byusing otherthan recommended cablesand connectorsorbyunauthorized changesor
modificationstothisequipment.Unauthorized changesormodificationscouldvoidthe user'sauthorityto
operatethe equipment.
ThisdevicecomplieswithPart15ofthe FCC Rules.Operation issubjecttothe followingtwoconditions:
(1)thisdevicemaynotcauseharmfulinterference,and
(2)thisdevicemustacceptanyinterferencereceived,including interferencethatmaycauseundesired
operation.
LFCC part68 (applicabletoproductsfittedwithUSAmodems)
The modemcomplieswithPart68 ofthe FCC Rules.Onthisequipmentisalabelthatcontains,among
otherinformation,theFCC registration numberandRingerEquivalenceNumber(REN)forthisequipment.
You must, upon request, provide thisinformation toyourtelephone company.
If yourtelephone equipmentcausesharmtothe telephone network,the Telephone Companymay
discontinue yourservicetemporarily.Ifpossible,theywillnotifyinadvance.But,ifadvancenoticeisnot
practical,youwill be notifiedassoonaspossible.You willbeinformedofyourrighttofileacomplaintwith
the FCC.

5
SafetyInformation
Yourtelephone companymaymakechangesinitsfacilities,equipment, operations,orproceduresthat
couldaffectproperoperation ofyourequipment. Iftheydo,you willbe notified inadvancetogiveyou an
opportunitytomaintainuninterrupted telephone service.
The FCC prohibitsthisequipmenttobe connected topartylinesorcoin-telephone service.
The FCC alsorequiresthe transmitterofaFAXtransmission be properlyidentified (perFCC RulesPart
68,Sec.68.381 (c)(3)).
/forCanadian usersonly/
LCanadianDepartmentofCommunicationsCompliance Statement
Thisdigitalapparatusdoesnotexceed the Class Blimitsforradionoiseemissionsfromdigital
apparatusassetoutinthe radiointerferenceregulationsofIndustryCanada.
Le presentappareil numerique n'emetpasde bruitsradioelectriquesdepassantleslimitesapplicablesaux
appareilsnumeriquesde ClasseBprescritesdanslereglementsurlebrouillage radioelectriqueedictepar
IndustrieCanada.
LDOCnotice (forproductsfittedwithanIndustryCanada-compliantmodem)
The Canadian DepartmentofCommunicationslabelidentifiescertified equipment. Thiscertification
meansthatthe equipmentmeetscertaintelecommunicationsnetworkprotective,operationaland safety
requirements.The Departmentdoesnotguarantee the equipmentwill operatetothe usersatisfaction.
Beforeinstalling thisequipment, usersensurethatitispermissibletobe connected tothe facilitiesofthe
localTelecommunicationsCompany.The equipmentmustalsobe installedusing an acceptablemethod
ofconnection.The customershouldbe awarethatcompliancewiththeaboveconditionsmightnotprevent
degradation ofserviceinsomesituations.
Repairstocertifiedequipmentshouldbe madebyan authorizedCanadianmaintenancefacilitydesignated
bythesupplier.Anyrepairsoralterationsmade bytheusertothisequipment,orequipmentmalfunctions,
maygivethe telecommunicationscompanycausetorequestthe usertodisconnectthe equipment.
Usersshouldensurefortheirownprotection thatthe electricalground connectionsofthe powerutility,
telephone linesand internalmetallicwaterpipe system,ifresentareconnected together.Thisprecaution
maybe particularlyimportantinruralareas.
Caution:Usersshouldnotattempttomakesuchconnectionsthemselves,butshouldcontactthe
appropriateelectricinspection authority,orelectrician,asappropriate.

6
GS-SR147SRack mountServer
NOTICE:The Load Number(LN)assigned toeachterminaldevicedenotesthe percentage ofthe total
load tobe connected toatelephone loop whichisused bythe device,topreventoverloading.The
termination on aloop mayconsistofanycombination ofdevicessubjectonlytothe requirementthatthe
sumofthe Load Numbersofall the devicesdoesnotexceed 100.
/forEuropean usersonly/
CAUTION
vDangerofexplosion ifbatteryisincorrectly
replaced.
vReplaceonlywiththe sameorequivalent
type recommended bythe manufacturer.
vDisposeofused batteriesaccording tothe
manufacturer’sinstructions.

7
Introduction
þChassisþGS-8IKHXRMotherboard(Installed)
þPowerSupply(Installed)þCPUHeatSinkx1
þFANDuctx1þSlimtype CD-ROMdrive(Installed)
þStandardFloppyDrive(Installed)þGS-SR147SUser’sManual
þCables(CD-ROM,Floppy)þDriverCD formotherboarddriver&utility
þHDD Trays x2(Installed)
Introduction
WelcometoGigabyteGS-SR147SRack mountServerSystemInstallation Guide.The guide
providesinstructionsforconfiguration hardwareforthe GS-SR147Syoursystem.
Thisinstallation guidewill assisteyou ininstallingall the essentialcomponentsfortheseversystem.
Foryourprotection,pleaseread and undertand allofthe safetyand operatinginstructionsregarding your
GigabyteServerandretainforfuturereference.Theproceduresinthisguidebookassusmethatyourare
asystemornetworkadministratorexperienced ininstalling similarhardware.
ContentsPackages
When openingthe package,pleaseensurethe systemcomponentsarenotdamaged duringtheshipping.
Using the following checklisttoverifythe contents.If anycomponentismissing ordamaged inthe
system,pleasecontactyourvendorimmediately.
Computermotherboardsand expansion cardscontainverydelicateIntegrated Circuit(IC)chips.To
protectthemagainstdamage fromstaticelectricity,you shouldfollowsomeprecautionswheneveryou
workon yourcomputer.
1.Unplug yourcomputerwhen working on the inside.
2.Useagrounded wriststrap beforehandling computercomponents.Ifyou do nothave
one,touchbothofyourhandstoasafelygrounded objectortoametalobject, suchas
the powersupplycase.
3.Holdcomponentsbythe edgesand trynottouchthe ICchips,leadsorconnectors,or
othercomponents.
4.Placecomponentson agrounded antistaticpad oron the bag thatcamewiththe
componentswheneverthe componentsareseparated fromthe system.
5.EnsurethattheATXpowersupplyisswitched offbeforeyou plug inorremovetheATX
powerconnectoron the motherboard.
WARNING!

8
GS-SR147SRack mountServer
Motherboard—GA-8IKHXR
ProcessorSupported—SupportsIntel®P4processorup to3.6GHz
—Intel®P4533/800MHzFSB
—L2 cache on-dieperprocessorfrom512K
Chipset—Intel®E7210,6300ESB
SystemMemory:
MemoryCapacity—4xDDR socketup to4GB
MemoryType —Un-buffered DDR 266/333/400
DIMM Size—Support128MB,256MB,512MB,and 1GBmemory
ErrorCorrection:—Single-bitErrorsCorrection,Multiple-bitErrorsDetection
Expansion Slot—Un-buffered,EC1Butter-FlyRisercardsupportsup to2x64/66
add-on cards(3.3V):
—1xLPPCIadd-on card(Half-High/Half-Length)
—1xFull-Sizeadd-on card(Full-High/Half-Length)
ATARAIDcontroller—Intel®6300ESB
—SupportsSATARAID0,1
Cooling Fans:—5XSystemFan
IntegratedLANs:
Controller—Intel®82541GIand 82547GIGbE
Advanced SoftwareFunction —AdapterFaultTolerance
—AdaptiveLoad Balancing
IntegratedGraphics:
Controller—Integrated,ATIRage-XL
Graphics Memory—8MBSDRAM
Mass StorageSystem—2xHot-swap SATAHDD
—1xStandardType FDD
—1SlimType CD-ROM
Chapter1Features Summary

9
FeatureSummary
SuperI/O
Controller—ITE8712FSuperI/O
Built-inI/O—2xserialPort(one atrear,otheron front)
—2xUSB portson frontplane,2xUSB portsatrear
—1xVGAconnector
—2xRJ45 LANports
—P/S2Keyboardand MouseConnectors
SystemBIOS:
BIOSType —Phoenix®BIOS,Multi-bootBBS 1.0Compliant4MbFlashMemory
SpecialFeatures—BIOSHWMonitoring reporting (The valuesmonitored byHW
Monitoring chipset)
—ConsoleRedirection viaCOMports
—Intel®HyperThreading Support
—ResumeafterACBack
—WakeOnLAN
—ACPI1.0Compliant/ACPIdefined S1,S4,and S5
ServerManagementFunctions:
BMCChip—NSIPMI1.5controller
FailureDetection —IPMI1.5specification ofServermanagement
EventLogging —32KB NonvolatileMemorytoLog SystemFailureEvents
RemoteManagement—Followthe IPMI1.5specification ofServermanagement
Environment
AmbientTemperature—Operating Temperature:5oCto35oC
—Non-operating Temperature:0oCto50oC
RelativeHumidity—10-80%operating Humidityat30oC
SafetyRegulations—FCC,CE,BSMI, CB,Win2000,2003 WHQLIPMI1.5
SystemDimention:—427.5mm x521mm x42.6mm
ElectricalPowerSupply—SinglePowerSupply250W

10
GS-SR147SRack mountServer
Chapter2SystemOverview
PowerSupply
FAN x5
SlimtypeCD-ROM
FloppyDisk Drive
4xDDR DIMM socket
CPU-Socket478
1RisercardwithPCI-Xfull-height/full-length64/66MHz;and onewithPCI-Xlow-
profile64-Bit/66MHz
Hot-swapSATAHDD x2

11
HardwareInstallation Process
Pleaseobservethe safetyinformation inchapter“ImportantSafetyInformation”
Donotexposethe servertoextremeenvironmentalconditions.Protectitfromdust, humidity,
and heat.
Step3-1:ChassisRemoval
Step 1Unscrewthe thumbscrewfromthe back ofthe system.
Step 2Pushdownthetwobuttonslocated attwosidesofthe chassis,andslide towardtoremovethe
topcover.Afterremoving thechassiscover,youcan installCPUandotheressentialcomponents.
Chapter3SystemHardwareInstallation
Step1
Thumbscres
Step2
Note:BeforeinstallingCPU,you mustremovethe FANduct.ForFANductremoval,please
see Sub-section 3-7“FAN DuctRemovaland Installtion”fordetail instruction.

12
GS-SR147SRack mountServer
Step3-2:CPUInstallation
Step 1Toinstall the CPU(s),liftup the barthatlocated nexttothe socket.
Step 2The noticed cornershouldpointtowardthe end oflever.The CPUwill onlyitinthe orientation
asshownbelow.
Step 3Then,align the CPUand insertitintothe socket.Then,pushthe levertothe originalposition.
Pleasemakesurethe CPUtype and speed thataresupported bythe motherboard.
Step3
Step1Step2

13
HardwareInstallation Process
Step3-3:HeatSinkInstallation
Step 1PuttheHeatSinkon theCPU.Beforeputtingthe heatsinkon the CPU,pleasewellremember
toapplythe thermalconductivitycompound on the CPU.
Step 2Then,Seatthe heatsinkinthe retention moduleswiththe fourscrews.Installation completed.
Step3-4:MemoryInstallation
Step 1The DIMM slothasanotch,the DIMM memorymoduleonlyfitinone direction.
Step 2Align the memorynotchtothe moduleand pushthe memoryintothe DIMM socketvertically.
Step1
Notch
Step2
Step2

14
GS-SR147SRack mountServer
Step3-5:PCIExpansion CardInstallation
GS-SR147Sprovidesexpansion riserslotsforone PCI-Xfull-height/full-length64/66MHz;andone with
PCI-Xlow-profile64-Bit/66MHz.Toinstall the peripheral,pleasego through the following steps.
Note!! Beforeinstalling the PCIexpansion card,pleasecheck the cardsizelimitation.Sizelimitation
forPCI-Xfull-height/full-lengthis228.5mm x91.5mm;sizelimitation forLow-ProfileCard:167.5mm
x56 mm .
Step 1Removethe screwson the riserbracket.
Step 2Detachthe riserbracketwithbothhands.
Step 3Installing the PCIRisercard.Toinstall the risercard,justsimplypushitintothe module.
Step 4Finally,align thestableracks tothe systemmodule(see the arrowdirection mark1),and push
downvertically.
Step 5ReverseStep 1&2tosecurethe riserbracketfirmly.Installation completed.
Step1Step2
Step3Step4

15
HardwareInstallation Process
Step3-6:HardDisk Drive Installation
Step 1Pull outthe HardDisk tray.
Step 2Placeharddisk intotheharddisk tray.Secureharddisk inthe harddisk traywithscrews.For
securityreason,you shouldtighten all screwsintothe pointed position.
Step 3Pushthe harddisk trayhandletothe closed position.Connectthe cables
Step1Step2
Step3

16
GS-SR147SRack mountServer
Step3-8:Reinstall ChassisCover
Step 1Closethe coverinun-lock position.Slide ittowardtolock position.
Step 2Makesurethe thumbscrewsaretightened.
Step3-7:FAN DuctRemovaland Installation
Step 1Toremovethe FANduct, justpullup thescrew-holderand unscrewthumbscrewstoremovethe
FANduct. (Pleasesee the circlepointed tofind the screwlocation)
Step 2ForFANDuctInstallation,placethe fan ductonthetop ofheatsinks.Fastenthe screwstothe
locked position and pushdowntescrew-holders.
Step1Step2
Step1Step2

SystemAppearance
17
4-1:FrontViewofGS-SR147S
Chapter4Appearance ofGS-SR147S
u
vw
xy
u
v
w
x
y
z
z
Slim Type CD-ROM
Standard Floopy
RJ45 (For Console Redirection)
LEDs
USB connector
Hot-swap SATA HDDs

18
GS-SR147SRack mountServer
4-2:RearViewofGS-SR147S
uv
wxyz
{|
u
v
w
x
|
y
z
{
}
Power
PS/2 Keyboard and Mouse Connectors
USB Connectors
COM Port
VGA Port
LAN1/2 Ports
Expansion Slot
Expansion Slot
Locate ID LED / Button
}

19
LEDDescription
4-3:Switchand LEDIndicatorsIntroduction
Power/Sleep
IDNMILAN1/2Activities
HDD
StatusHDD Fail Warning
Name
Power
Status
HDD
LAN1/2
Activity
Identification
ColorCondition Description
Green OnPowerOn
Green BlinkSleep (S1)
-- Off PowerOff(S4)
Green OnSystemReadyOn/Alarm
AmberBlinkSystemReadybutdeqraded,CPUFailed,
DIMM Killed
AmberOnCriticalAlarm:CriticalPowerModuleFailure,
CriticalFANsFailure,Voltage (PowerSupply)
CriticalTeemperatureand Voltage
-- Off SystemNotReady/Posterror/NMIevent/CPU
orterminatormissing
Green BlinkHardDisk DriveAccess
-- Off NoAccess and NoHDD Fault
Green On LANLink/Noaccess 10M/100M
Green BlinkLANaccess
AmberOn LANLink1000M
AmberBlinkLANaccess
Blue BlinkUntiselected foridentification
-- Off Noidentification

20
GS-SR147SRack mountServer
Suggest Icon Description
Keyboard
VGA
Mouse
LAN
Serial Port
USB
4-4:ConnectorIcon Description
-ether-
