Gigabyte R133-C11-AAB1 User manual

R133-C11-AAB1
R133-C11-AAG1
AMD Ryzen™ 7000 Server System - 1U UP 8-Bay SATA
Dual 550W (240V) 80 PLUS Platinum redundant power supply (AAB1)
Dual 800W (240V) 80 PLUS Titanium redundant power supply (AAG1)
User Manual
Rev. 1.0

Copyright
© 2023 Giga Computing Technology CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of Giga Computing.
Changes to the specications and features in this manual may be made by Giga Computing
without prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or
published in any form or by any means without Giga Computing's prior written permission.
Documentation Classications
In order to assist in the use of this product, Giga Computing provides the following types of documen-
tation:
 User Manual: detailed information & steps about the installation, conguration and use of this
product (e.g. motherboard, server barebones), covering hardware and BIOS.

User Guide: detailed information about the installation & use of an add-on hardware or
software component (e.g. BMC rmware, rail-kit) compatible with this product.
Quick Installation Guide: a short guide with visual diagrams that you can reference easily for
installation purposes of this product (e.g. motherboard, server barebones).
Please see the support section of the online product page to check the current availability of these
documents.
For More Information
For related product specications, the latest rmware and software, and other information please visit our website at
http://www.gigabyte.com/Enterprise
For GIGABYTE distributors and resellers, additional sales & marketing materials are available from our reseller
portal: http://reseller.b2b.gigabyte.com
For further technical assistance, please contact your GIGABYTE representative or visit
https://esupport.gigabyte.com/ to create a new support ticket
For any general sales or marketing enquiries, you may also message GIGABYTE server directly by email:
server[email protected]

Conventions
The following conventions are used in this user's guide:
NOTE!
Pieces of additional
information related to the current topic.
CAUTION!
Precautionary measures to
avoid possible hardware or software problems.
WARNING!
Alerts to any damage that might
result from doing or not doing specic actions.

Server Warnings and Cautions
Before installing a server, be sure that you understand the following warnings and cautions.
WARNING!
To reduce the risk of electric shock or damage to the equipment:
• Do not disable the power cord grounding plug. The grounding plug is an important safety
feature.
• Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all
times.
• Unplug the power cord from the power supply to disconnect power to the equipment.
• Do not route the power cord where it can be walked on or pinched by items placed against it.
Pay particular attention to the plug, electrical outlet, and the point where the cord extends from
the server.
WARNING!
To reduce the risk of personal injury from hot surfaces, allow the drives and the internal
system components to cool before touching them.
WARNING!
This server is equipped with high speed fans. Keep away from hazardous moving fan
blades during servicing.
CAUTION!
• Do not operate the server for long periods with the access panel open or removed. Operat-
ing the server in this manner results in improper airow and improper cooling that can lead to
thermal damage.
• Danger of explosion if battery is incorrectly replaced.
• Replace battery with the same or equivalent type recommended by the manufacturer.
• Dispose of used batteries according to the manufacturer’s instructions.
CAUTION!
Risk of explosion if battery is replaced incorrectly or with an incorrect type. Replace the battery
only with the same or equivalent type recommended by the manufacturer. Dispose of used bat-
teries according to the manufacturer’s instructions.

Electrostatic Discharge (ESD)
CAUTION!
ESD CAN DAMAGE DRIVES, BOARDS, AND OTHER PARTS. WE RECOMMEND THAT YOU
PERFORM ALL PROCEDURES AT AN ESD WORKSTATION. IF ONE IS NOT AVAILABLE,
PROVIDE SOME ESD PROTECTION BY WEARING AN ANTI-STATIC WRIST STRAP AT-
TACHED TO CHASSIS GROUND -- ANY UNPAINTED METAL SURFACE -- ON YOUR SERVER
WHEN HANDLING PARTS.
Always handle boards carefully, they can be extremely sensitive to ESD. Hold boards only by
their edges without touching any components or connectors. After removing a board from its
protective ESD bag or from the system, place the board component side up on a grounded, static
free surface. Use a conductive foam pad if available but not the ESD bag. Do not slide the board
over any surface.
System power on/off: To service components within the server, please ensure the power has
been disconnected.
e.g. Remove the node from the server chassis (to disconnect power) or disconnect the power
from the server chassis.
Make sure the system is removed from the rack before opening the chassis, adding, or removing
any non hot-plug components.
Hazardous conditions, devices and cables: Hazardous electrical conditions may be present
on power, telephone, and communication cables. Turn off the system chassis and disconnect the
cables attached to the system before servicing the chassis. Otherwise, personal injury or equip-
ment damage can result.
Electrostatic discharge (ESD) and ESD protection: ESD can damage drives, boards, and
other parts. We recommend that you perform all procedures in this chapter only at an ESD work-
station. If one is not available, provide some ESD protection by wearing an antistatic wrist strap
attached to chassis ground (any unpainted metal surface on the server) when handling parts.
ESD and handling boards: Always handle boards carefully. They can be extremely sensi-tive to
electrostatic discharge (ESD). Hold boards only by their edges. After removing a board from its
protective wrapper or from the system, place the board component side up on a grounded, static
free surface. Use a conductive foam pad if available but not the board wrapper. Do not slide
board over any surface.

Installing or removing jumpers: A jumper is a small plastic encased conductor that slips over
two jumper pins. Some jumpers have a small tab on top that can be gripped with n-gertips or
with a pair of ne needle nosed pliers. If the jumpers do not have such a tab, take care when us-
ing needle nosed pliers to remove or install a jumper; grip the narrow sides of the jumper with the
pliers, never the wide sides. Gripping the wide sides can dam-age the contacts inside the jumper,
causing intermittent problems with the function con-trolled by that jumper. Take care to grip with,
but not squeeze, the pliers or other tool used to remove a jumper, or the pins on the board may
bend or break.

- 7 -
Table of Contents
Chapter 1 Hardware Installation ................................................................................... 11
1-1 Installation Precautions.................................................................................. 11
1-2 Product Specications.................................................................................... 12
1-3 System Block Diagram................................................................................... 16
Chapter 2 System Appearance.....................................................................................17
2-1 Front View...................................................................................................... 17
2-2 Rear View....................................................................................................... 18
2-3 Front Panel LED and Buttons ........................................................................ 19
2-4 Rear System LAN LEDs................................................................................. 20
2-5 Power Supply Unit LED.................................................................................. 21
2-6 Hard Disk Drive LEDs .................................................................................... 22
Chapter 3 System Hardware Installation ......................................................................23
3-1 Removing and Installing the Chassis Cover .................................................. 24
3-2 Removing and Installing the Hard Disk Drive................................................. 25
3-3 Removing and Installing the Fan Duct ........................................................... 28
3-4 Removing and Installing the Heat Sink .......................................................... 29
3-5 Removing and Installing the CPU .................................................................. 30
3-6 Removing and Installing Memory................................................................... 32
3-6-1 Dual Channel Memory Conguration .....................................................................32
3-6-2 Removing and Installing a Memory Module ...........................................................33
3-6-3 Memory Module Population Table ..........................................................................33
3-7 Removing and Installing the PCIe Card......................................................... 34
3-8 Installing the GPU Card (Optional)................................................................. 35
3-9 Installing the M.2 Device and Heat Sink ........................................................ 36
3-10 Removing and Installing the Power Supply.................................................... 37
3-11 Cable Routing ................................................................................................ 38
Chapter 4 Motherboard Components ...........................................................................44
4-1 Motherboard Components ............................................................................. 44
4-2 Jumper Settings ............................................................................................. 46
4-3 Backplane Board Storage Connector............................................................. 47
4-3-1 CBP1047 ................................................................................................................47
4-3-2 CBP1045 ................................................................................................................47

- 8 -
Chapter 5 BIOS Setup ..................................................................................................48
5-1 The Main Menu .............................................................................................. 50
5-2 Advanced Menu ............................................................................................. 52
5-2-1 Trusted Computing .................................................................................................53
5-2-2 AMD fTPM Conguration........................................................................................55
5-2-3 AST2600 Super IO Conguration...........................................................................56
5-2-4 S5 RTC Wake Settings...........................................................................................58
5-2-5 Serial Port Console Redirection .............................................................................59
5-2-6 CPU Conguration..................................................................................................63
5-2-7 PCI Subsystem Settings.........................................................................................64
5-2-8 USB Conguration..................................................................................................66
5-2-9 Network Stack Conguration ..................................................................................68
5-2-10 CSM Conguration .................................................................................................69
5-2-11 Post Report Conguration ......................................................................................70
5-2-12 NVMe Conguration ...............................................................................................71
5-2-13 SATA Conguration.................................................................................................72
5-2-14 Chipset Conguration.............................................................................................73
5-2-15 RAM Disk Conguration .........................................................................................74
5-2-16 Tls Auth Conguration ............................................................................................75
5-2-17 iSCSI Conguration................................................................................................76
5-2-18 Broadcom BCM7416 NetXtreme-E 10GBASE-T Network Connection .................77
5-2-19 VLAN Conguration................................................................................................80
5-2-20 MAC IPv4 Network Conguration...........................................................................81
5-2-21 MAC IPv6 Network Conguration...........................................................................82
5-2-22 Broadcom NetXtreme Gigabit Ethernet Network Connection.................................83
5-2-23 VLAN Conguration................................................................................................85
5-2-24 MAC IPv4 Network Conguration...........................................................................86
5-2-25 MAC IPv6 Network Conguration...........................................................................87
5-2-26 Driver Health...........................................................................................................88
5-3 Chipset Setup Menu....................................................................................... 89
5-3-1 North Bridge ...........................................................................................................90
5-4 Server Management Menu............................................................................. 91
5-4-1 System Event Log ..................................................................................................93
5-4-2 View FRU Information ............................................................................................94
5-4-3 BMC VLAN Conguration.......................................................................................95
5-4-4 BMC Network Conguration ...................................................................................96
5-4-5 IPv6 BMC Network Conguration...........................................................................97
5-5 Security Menu ................................................................................................ 98
5-5-1 Secure Boot ...........................................................................................................99
5-6 Boot Menu.................................................................................................... 101
5-7 Save & Exit Menu......................................................................................... 102

- 9 -
5-8 BIOS Recovery ............................................................................................ 104
5-9 BIOS POST Beep code (AMI standard)....................................................... 105
5-9-1 PEI Beep Codes...................................................................................................105
5-9-2 DXE Beep Codes .................................................................................................105

- 10 -
This page intentionally left blank

- 11 -
Hardware Installation
1-1 Installation Precautions
The motherboard/system contain numerous delicate electronic circuits and components which
can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully
read the service guide and follow these procedures:
• Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or
warranty sticker provided by your dealer. These stickers are required for warranty validation.
• Always remove the AC power by unplugging the power cord from the power outlet before
installing or removing the motherboard or other hardware components.
• When connecting hardware components to the internal connectors on the motherboard,
make sure they are connected tightly and securely.
• When handling the motherboard, avoid touching any metal leads or connectors.
• It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic
components such as a motherboard, CPU or memory. If you do not have an ESD wrist
strap, keep your hands dry and rst touch a metal object to eliminate static electricity.
•
Prior to installing the motherboard, please have it on top of an antistatic pad or within an
electrostatic shielding container.
• Before unplugging the power supply cable from the motherboard, make sure the power
supply has been turned off.
• Before turning on the power, make sure the power supply voltage has been set according to
the local voltage standard.
• Before using the product, please verify that all cables and power connectors of your
hardware components are connected.
• To prevent damage to the motherboard, do not allow screws to come in contact with the
motherboard circuit or its components.
• Make sure there are no leftover screws or metal components placed on the motherboard or
within the computer casing.
• Do not place the computer system on an uneven surface
.
• Do not place the computer system in a high-temperature environment.
• Turning on the computer power during the installation process can lead to damage to
system components as well as physical harm to the user.
• If you are uncertain about any installation steps or have a problem related to the use of the
product, please consult a certied computer technician.
Chapter 1 Hardware Installation

Hardware Installation
- 12 -
1-2 Product Specications
Socket
Socket
Security
Security Server Operating Properties
Power SupplySystem fan
System
Dimension
1U
438 (W) x 43.5 (H) x 710 (D) mm
Socket
Socket
Security
Security Server Operating Properties
Power SupplySystem fan
CPU AMD® Ryzen™ 7000 Series Processors
Single processor, 5nm technology
TDP up to 170W
Socket
Socket
Security
Security Server Operating Properties
Power SupplySystem fan
Socket AM5
Socket
Socket
Security
Security Server Operating Properties
Power SupplySystem fan
Chipset AMD® B650E
Memory 4 x DIMM slots
DDR5 memory supported only
Dual Channel memory architecture
DIMM modules up to 32GB supported
ECC Unbuffered DIMM 1Rx8/2Rx8 modules supported
Non-ECC Unbuffered DIMM 1Rx8/2Rx8/1Rx16 modules supported
Memory speed: up to 5200 MHz
LAN 2 x 10Gb/s LAN ports (1 x Broadcom® BCM57416)
2 x 1Gb/s LAN ports (1 x Broadcom® BCM5720)
NCSI function supported on Broadcom® BCM5720 and BCM57416 (by
switch)
1 x 10/100/1000 management LAN
Video Integrated in Aspeed® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
Storage Front side:
4 x 3.5"/2.5" SATA hot-swappable bays, from FCH
4 x 2.5" 9.5mm SATA hot-swappable bays, from FCH
SATA supported only
NOTE:
We reserve the right to make any changes to the product specications and product-related
information without prior notice.

- 13 -
Hardware Installation
Expansion Slot PCIe Cable:
1 x PCIe x16 (Gen5 x16) FHFL slot, from CPU, for GPUs*
*Max 300W for GPUs
Riser Card CRSE016:
1 x PCIe x4 (Gen4 x4) FHHL slot, from CPU
1 x M.2 slot:
M-key
PCIe Gen4 x4, from FCH
Supports 2280/22110 cards
Internal I/O 2 x USB 3.2 Gen1
2 x USB 2.0
1 x Front panel header
1 x Back panel header
2 x Fan headers (4 pin)
1 x M.2 slot
1 x TPM header
1 x PMBus header
Front I/O 1 x USB 3.2 Gen1
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
2 x LAN activity LEDs
1 x HDD activity LED
1 x System status LED
Rear Panel I/O 2 x USB 3.2 Gen2
1 x Mini-DP
4 x RJ45
1 x MLAN
1 x ID button with LED
Backplane I/O Backplane P/N: 9CBP1045NR-00 and 9CBP1047NR-00
Speed and bandwidth:
SATA 6Gb/s
TPM 1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010

Hardware Installation
- 14 -
Socket
Socket
Security
Security Server Operating Properties
Power SupplySystem fan
Power Supply
(AAB1)
Dual 800W (240V) 80 PLUS Platinum redundant PSU
AC Input:
100-240V~/ 10-5A, 50-60Hz
DC Input:
240Vdc/ 4A
DC Output:
Max 800W/ 100-240V~ or 240Vdc Input
+ 12V/ 65A
+ 12Vsb/ 2.1A
Socket
Socket
Security
Security Server Operating Properties
Power SupplySystem fan
Power Supply
(AAG1)
Dual 800W (240V) 80 PLUS Titanium redundant PSU
AC Input:
100-127V~/ 10A, 50-60Hz
200-240V~/ 5A, 50-60Hz
DC Input:
240Vdc/ 5A
DC Output:
Max 800W
+ 12.2V/ 65A
+ 12Vsb/ 3A

Hardware Installation
- 15 -
System
Management
Aspeed® AST2600 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Prole
System Firewall
Power Consumption
Power Control
LDAP / AD / RADIUS Support
Backup & Restore Conguration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings
Socket
Socket
Security
Security Server Operating Properties
Power SupplySystem fan
Operating
Properties
Operating temperature: 10°C to 30°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

Hardware Installation
- 16 -
1-3 System Block Diagram
mini-DP
2-Channel DDR5, 4 x DIMM slots
Speed up to 5200MHz (2DPC)
PCIe 4.0 x4
PCIe 2.0 x1
USB 2.0
SATA x4
SATA x4
PCIe 3.0 x4
2 x 10GbE LAN
PCIe 2.0 x1
PCIe 4.0 x4
PCIe 3.0 x2
BCM57416
2 x USB3.2 Gen1
USB 3.2 Gen1 x2
SPI
eSPI
BCM5720
ASM1164
2 x 1GbE LAN
AMD B650E
Chipset
ASPEED
AST2600
BMC
MLAN
RTL8211FD
RGMII
TPM
BIOS
Switch
NCSI
Switch
SPI Flash
128 MB
NCSI
NCSI
NCSI
PCIe 5.0 x16 PCIe x16
(for GPU)
PCIe 4.0 x4 PCIe x4
Riser CRSE016
USB3.2 Gen1 x1
1 x USB3.2 Gen1
(front)
AMD Socket AM5
Ryzen 7000 Series
Processors
M.2
4-bay 3.5"/2.5" SATA + 4-bay 2.5" 9.5mm SATA
SL_SATA2
SL_SATA1

- 17 -
System Appearance
Chapter 2 System Appearance
2-1 Front View
No. Description
1. Front USB 3.2 Gen1 Port x 2
2. Front Panel LEDs and Buttons
3. 2.5" 9.5mm Drive Bays
4. 3.5"/2.5" Drive Bays
• Refer to section 2-3 Front Panel LEDs and Buttons for a detailed description of the
function of the LEDs.
1 2
HDD0 HDD1 HDD2 HDD3
HDD4 HDD5 HDD6 HDD7
4
3

System Appearance
- 18 -
2-2 Rear View
23
4
56
7 8
1
PSU1PSU2 SLOT2SLOT3
SLOT1
No. Description
1. ID Button with LED
2. 10 GbE LAN Port x 2
3. 1 GbE LAN Port x 2
4. Server Management LAN Port
5. USB 3.2 Gen1 Port x 2
6. Mini DP Port
7. PCIe Card Slot
8. GPU Card Slot

- 19 -
System Appearance
2-3 Front Panel LED and Buttons
No. Name Color Status Description
1. NMI button
Press the button server generates a NMI to the processor
if the multiple-bit ECC errors occur, which effectively halt
the server.
2. Reset Button Press the button to reset the system.
3. ID Button Press the button to activate system identication
4. Power button
with LED
Green On System is powered on
Green Blink System is in ACPI S1 state (sleep mode)
N/A Off
• System is not powered on or in ACPI S5 state
(power off)
• System is in ACPI S4 state (hibernate mode)
4. ID Button Press the button to activate system identication
5/6 LAN 1/2 Active/
Link LEDs
Green Solid On Link between system and network or no access.
Green Blink Data trasmission or receiving is occuring
N/A Off No data transmission or receiving is occuring
7. HDD Status
LED
Green On HDD locate
Blink HDD access
Amber On HDD fault
Green/
Amber Blink HDD rebuilding
N/A Off No HDD access or no HDD fault.
8. System
Status LED
Green Solid On System is operating normally.
Amber
Solid On
Critical condition, may indicate:
System fan failure
System temperature
Blink
Non-critical condition, may indicate:
Redundant power module failure
Temperature and voltage issue
Chassis intrusion
N/A Off
System is not ready, may indicate:
POST error
NMI error
Processor or terminator missing
ID
SYS
RST
NMI L2L1
2
14 3
7 8
56

System Appearance
- 20 -
2-4 Rear System LAN LEDs
43 43 32 2 41
No. Name Color Status Description
1. 10GbE
Speed LED
Green On 10 Gbps data rate
Yellow On 1Gbps data rate
N/A Off 100 Mbps data rate
2. 10GbE Link /
Activity LED
Green On Link between system and network or no access
Blink Data transmission or reception is occurring.
N/A Off No data transmission or reception is occurring.
3. 1GbE Speed
LED
Yellow On 1 Gbps data rate
Green On 100 Mbps data rate
N/A Off 10 Mbps data rate
4. 1GbE Link /
Activity LED
Green On Link between system and network or no access
Blink Data transmission or reception is occurring.
N/A Off No data transmission or reception is occurring.
