Gigabyte R263-Z30-AAC1 User manual

R263-Z30-AAC1
R263-Z30-AAC2
R263-Z30-AAH2
AMD EPYC™ 9004 Server System - 2U UP 12-Bay NVMe/SATA/SAS
User Manual
Rev. 100

Copyright
© 2022 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specications and features in this manual may be made by GIGABYTE without
prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or
published in any form or by any means without GIGABYTE's prior written permission.
Documentation Classications
In order to assist in the use of this product, GIGABYTE provides the following types of documentation:
 User Manual: detailed information & steps about the installation, conguration and use of this
product (e.g. motherboard, server barebones), covering hardware and BIOS.

User Guide: detailed information about the installation & use of an add-on hardware or
software component (e.g. BMC rmware, rail-kit) compatible with this product.
Quick Installation Guide: a short guide with visual diagrams that you can reference easily for
installation purposes of this product (e.g. motherboard, server barebones).
Please see the support section of the online product page to check the current availability of these
documents.
For More Information
For related product specications, the latest rmware and software, and other information please visit our website at
http://www.gigabyte.com
For GIGABYTE distributors and resellers, additional sales & marketing materials are available from our reseller
portal: http://reseller.b2b.gigabyte.com
For further technical assistance, please contact your GIGABYTE representative or visit
https://esupport.gigabyte.com/ to create a new support ticket
For any general sales or marketing enquiries, you may also message GIGABYTE server directly by email:
server[email protected]

Conventions
The following conventions are used in this user's guide:
NOTE!
Gives bits and pieces of additional
information related to the current topic.
CAUTION!
Gives precautionary measures to
avoid possible hardware or software problems.
WARNING!
Alerts you to any damage that might
result from doing or not doing specic actions.

Server Warnings and Cautions
Before installing a server, be sure that you understand the following warnings and cautions.
WARNING!
To reduce the risk of electric shock or damage to the equipment:
• Do not disable the power cord grounding plug. The grounding plug is an important safety
feature.
• Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all
times.
• Unplug all the power cords from the power supplies to disconnect power to the equipment.
•
• Shock Hazard! Disconnect all power supply cords before servicing.
• Do not route the power cord where it can be walked on or pinched by items placed against it.
Pay particular attention to the plug, electrical outlet, and the point where the cord extends from
the server.
WARNING!
To reduce the risk of personal injury from hot surfaces, allow the drives
and the internal system components to cool before touching them.
WARNING!
This server is equipped with high speed fans. Keep away from hazardous
moving fan blades during servicing.
WARNING!
This equipment is intended to be used in Restrict Access Location. The
access can only be gained by Skilled person. Only authorized by well
trained professional person can access the restrict access location.
CAUTION!
• Do not operate the server for long periods with the access panel open or removed. Operat-
ing the server in this manner results in improper airow and improper cooling that can lead to
thermal damage.
• Danger of explosion if battery is incorrectly replaced.
• Replace only with the same or equivalent type recommended by the manufacturer.
• Dispose of used batteries according to the manufacturer’s instructions.
CAUTION!
Risk of explosion if battery is replaced incorrectly or with an incorrect type. Replace the battery
only with the same or equivalent type recommended by the manufacturer. Dispose of used bat-
teries according to the manufacturer’s instructions.

Electrostatic Discharge (ESD)
CAUTION!
ESD CAN DAMAGE DRIVES, BOARDS, AND OTHER PARTS. WE RECOMMEND THAT YOU
PERFORM ALL PROCEDURES AT AN ESD WORKSTATION. IF ONE IS NOT AVAILABLE,
PROVIDE SOME ESD PROTECTION BY WEARING AN ANTI-STATIC WRIST STRAP AT-
TACHED TO CHASSIS GROUND -- ANY UNPAINTED METAL SURFACE -- ON YOUR SERVER
WHEN HANDLING PARTS.
Always handle boards carefully. They can be extremely sensitive to ESD. Hold boards only by
their edges without any component and pin touching. After removing a board from its protective
wrapper or from the system, place the board component side up on a grounded, static free sur-
face. Use a conductive foam pad if available but not the board wrapper. Do not slide board over
any surface.
System power on/o󰀨: To remove power from system, you must remove the system from
rack. Make sure the system is removed from the rack before opening the chassis, adding, or
removing any non hot-plug components.
Hazardous conditions, devices and cables: Hazardous electrical conditions may be
present on power, telephone, and communication cables. Turn off the system and disconnect the
cables attached to the system before servicing it. Otherwise, personal injury or equipment dam-
age can result.
Electrostatic discharge (ESD) and ESD protection: ESD can damage drives,
boards, and other parts. We recommend that you perform all procedures in this chapter only at
an ESD workstation. If one is not available, provide some ESD protection by wearing an antistatic
wrist strap attached to chassis ground (any unpainted metal surface on the server) when handling
parts.
ESD and handling boards: Always handle boards carefully. They can be extremely
sensitive to electrostatic discharge (ESD). Hold boards only by their edges. After removing a
board from its protective wrapper or from the system, place the board component side up on a
grounded, static free surface. Use a conductive foam pad if available but not the board wrapper.
Do not slide board over any surface.
Installing or removing jumpers: A jumper is a small plastic encased conductor that slips
over two jumper pins. Some jumpers have a small tab on top that can be gripped with ngertips
or with a pair of ne needle nosed pliers. If the jumpers do not have such a tab, take care when
using needle nosed pliers to remove or install a jumper; grip the narrow sides of the jumper with
the pliers, never the wide sides. Gripping the wide sides can dam-age the contacts inside the
jumper, causing intermittent problems with the function con-trolled by that jumper. Take care to
grip with, but not squeeze, the pliers or other tool used to remove a jumper, or the pins on the
board may bend or break.

- 6 -
Table of Contents
Chapter 1 Hardware Installation .....................................................................................9
1-1 Installation Precautions.................................................................................... 9
1-2 Product Specications.................................................................................... 10
1-3 System Block Diagram................................................................................... 14
1-3-1 R263-Z30-AAC1.....................................................................................................14
1-3-2 R263-Z30-AAC2/ R263-Z30-AAH2 ........................................................................14
Chapter 2 System Appearance.....................................................................................15
2-1 Front View...................................................................................................... 15
2-2 Rear View....................................................................................................... 16
2-3 Front Panel LEDs and Buttons....................................................................... 17
2-3-1 RoT LEDs...............................................................................................................18
2-4 Rear System LAN LEDs................................................................................. 20
2-5 Power Supply Unit (PSU) LED....................................................................... 21
2-6 Hard Disk Drive LEDs .................................................................................... 22
Chapter 3 System Hardware Installation ......................................................................23
3-1 Removing Chassis Cover............................................................................... 24
3-2 Removing and Installing the Fan Duct ........................................................... 25
3-3 Removing and installing the Heat Sink .......................................................... 26
3-4 Installing the CPU .......................................................................................... 27
3-5 Installing the Memory..................................................................................... 29
3-5-1 Twelve Channel Memory Conguration..................................................................29
3-5-2 Installing the Memory ............................................................................................30
3-5-3 Processor and Memory Module Matrix Table .........................................................30
3-5-4 DIMM Population Table ..........................................................................................31
3-6 Installing the PCI Expansion Card ................................................................. 32
3-7 Installing the Mezzanine Card........................................................................ 33
3-7-1 OCP 3.0..................................................................................................................33
3-8 Installing the Hard Disk Drive......................................................................... 34
3-9 Installing the M.2 Device and Heat Sink ........................................................ 36
3-10 Replacing the Fan Assembly.......................................................................... 37
3-11 Replacing the Power Supply.......................................................................... 38
3-12 Cable Routing ................................................................................................ 39
3-12-1 R263-Z30-AAC1.....................................................................................................39

- 7 -
3-12-2 R263-Z30-AAC2/ R263-Z30-AAH2 ........................................................................43
Chapter 4 Motherboard Components ...........................................................................47
4-1 Motherboard Components ............................................................................. 47
4-2 Jumper Setting .............................................................................................. 49
4-3 Backplane Board Storage Connector ............................................................ 50
4-3-1 CBP20C5................................................................................................................50
Chapter 5 BIOS Setup ..................................................................................................51
5-1 The Main Menu .............................................................................................. 53
5-2 Advanced Menu ............................................................................................. 56
5-2-1 Trusted Computing .................................................................................................58
5-2-2 PSP Firmware Versions..........................................................................................59
5-2-3 Legacy Video Select...............................................................................................60
5-2-4 AST2600 Super IO Conguration...........................................................................61
5-2-5 Serial Port Console Redirection .............................................................................63
5-2-6 CPU Conguration..................................................................................................67
5-2-7 PCI Subsystem Settings.........................................................................................68
5-2-8 USB Conguration..................................................................................................71
5-2-9 Network Stack Conguration ..................................................................................73
5-2-10 NVMe Conguration ...............................................................................................74
5-2-11 SATA Conguration.................................................................................................75
5-2-12 Graphic Output Conguration.................................................................................76
5-2-13 AMD Mem Conguration Status.............................................................................77
5-2-14 Tls Auth Conguration ............................................................................................78
5-2-15 RAM Disk Conguration .........................................................................................79
5-2-16 iSCSI Conguration................................................................................................80
5-2-17 Intel(R) I210 Gigabit Network Connection ..............................................................81
5-2-18 VLAN Conguration................................................................................................83
5-2-19 MAC IPv4 Network Conguration...........................................................................84
5-2-20 MAC IPv6 Network Conguration...........................................................................85
5-3 AMD CBS Menu............................................................................................. 86
5-3-1 CPU Common Options...........................................................................................87
5-3-2 DF Common Options..............................................................................................93
5-3-3 UMC Common Options ........................................................................................100
5-3-4 NBIO Common Options........................................................................................121
5-3-5 FCH Common Options .........................................................................................131
5-3-6 NTB Common Options .........................................................................................140
5-3-7 SOC Miscellaneous Control .................................................................................141
5-3-8 Workload Tuning...................................................................................................143
5-3-9 CXL Common Options..........................................................................................144

- 8 -
5-4 AMD PBS Menu........................................................................................... 145
5-4-1 RAS ......................................................................................................................146
5-5 Chipset Setup Menu..................................................................................... 148
5-5-1 North Bridge .........................................................................................................149
5-5-2 Fabric Resource ...................................................................................................150
5-6 Server Management Menu........................................................................... 152
5-6-1 System Event Log ................................................................................................154
5-6-2 View FRU Information ..........................................................................................155
5-6-3 BMC Network Conguration .................................................................................156
5-6-4 IPv6 BMC Network Conguration.........................................................................157
5-7 Security Menu .............................................................................................. 158
5-7-1 Secure Boot .........................................................................................................159
5-8 Boot Menu.................................................................................................... 161
5-9 Save & Exit Menu......................................................................................... 163
5-10 BIOS Recovery ............................................................................................ 164
5-11 BIOS POST Beep code (AMI standard)....................................................... 165
5-11-1 PEI Beep Codes...................................................................................................165
5-11-2 DXE Beep Codes .................................................................................................165

Hardware Installation
- 9 -
1-1 Installation Precautions
The motherboard/system contain numerous delicate electronic circuits and components which
can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully
read the service guide and follow these procedures:
• Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or
warranty sticker provided by your dealer. These stickers are required for warranty validation.
• Always remove the AC power by unplugging the power cord from the power outlet before
installing or removing the motherboard or other hardware components.
• When connecting hardware components to the internal connectors on the motherboard,
make sure they are connected tightly and securely.
• When handling the motherboard, avoid touching any metal leads or connectors.
• It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic
components such as a motherboard, CPU or memory. If you do not have an ESD wrist
strap, keep your hands dry and rst touch a metal object to eliminate static electricity.
• Prior to installing the motherboard, please have it on top of an antistatic pad or within an
electrostatic shielding container.
• Before unplugging the power supply cable from the motherboard, make sure the power
supply has been turned off.
• Before turning on the power, make sure the power supply voltage has been set according to
the local voltage standard.
• Before using the product, please verify that all cables and power connectors of your
hardware components are connected.
• To prevent damage to the motherboard, do not allow screws to come in contact with the
motherboard circuit or its components.
• Make sure there are no leftover screws or metal components placed on the motherboard or
within the computer casing.
• Do not place the computer system on an uneven surface .
• Do not place the computer system in a high-temperature environment.
• Turning on the computer power during the installation process can lead to damage to
system components as well as physical harm to the user.
• If you are uncertain about any installation steps or have a problem related to the use of the
product, please consult a certied computer technician.
Chapter 1 Hardware Installation

Hardware Installation
- 10 -
1-2 Product Specications
Socket
Socket
Security
Security Server Operating Properties
Power Supply
System
Dimension
2U
438mm (W) x 87.5mm (H) x 700mm (D)
Socket
Socket
Security
Security Server Operating Properties
Power Supply
CPU AMD EPYC™ 9004 series processor family
Single processor, 5nm technology
Up to 96-core, 192 threads per processor
cTDP up to 360W
Supports CPU 400W at ambient 30°C
Socket
Socket
Security
Security Server Operating Properties
Power Supply
Socket 1 x LGA 6096
Socket SP5
Socket
Socket
Security
Security Server Operating Properties
Power Supply
Chipset System on Chip
Socket
Socket
Security
Security
Security UEFI Secure Boot
Silicon root of trust
SNMP Support: V3
Socket
Socket
Security
Security Server Operating Properties
Power Supply
Memory 12 x DIMM slots
DDR5 memory supported only
12-Channel memory architecture
RDIMM modules up to 128GB supported
3DS RDIMM modules up to 256GB supported
Memory speed: Up to 4800 MHz
Socket
Socket
Security
Security Server Operating Properties
Power Supply
LAN 1 x 1Gb/s LAN port (1 x Intel® I210-AT)
Supported NCSI function
1 x 10/100/1000 management LAN
Socket
Socket
Security
Security Server Operating Properties
Power Supply
Video Integrated in Aspeed® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
Socket
Socket
Security
Security Server Operating Properties
Power Supply
Storage R263-Z30-AAC1
12 x 3.5/ 2.5" Gen4 NVMe/ SATA/ SAS hot-swappable bays
SAS card is required for SAS devices support
R263-Z30-AAC2/ R263-Z30-AAH2
8 x 3.5/ 2.5" SATA/ SAS hot-swappable bays
4 x 3.5/ 2.5" Gen4 NVMe/ SATA/ SAS hot-swappable bays
SAS card is required for SAS devices support
NOTE:
We reserve the right to make any changes to the product specications and product-related
information without prior notice.

Hardware Installation
- 11 -
Socket
Socket
Security
Security Server Operating Properties
Power Supply
Expansion Slot R263-Z30-AAC1
Riser Card CRS201M:
- 1 x PCIe x16 slot (Gen5 x16), FHHL
Riser Card CRS201H:
- 1 x PCIe x16 slot (Gen5 x16), FHHL
2 x OCP 3.0 slot with PCIe Gen5 x16 bandwidth
- Supported NCSI function
1 x M.2 slot:
- M-key
- PCIe Gen3 x4
- Supports NGFF-2280/22110 cards
R263-Z30-AAC2/ R263-Z30-AAH2
Riser Card CRS201M:
- 1 x PCIe x16 slot (Gen5 x16), FHHL
- 2 x PCIe x16 slots (Gen4 x8), FHHL
Riser Card CRS201H:
- 1 x PCIe x16 slot (Gen5 x16), FHHL
- 1 x PCIe x16 slot (Gen4 x16), FHHL
2 x OCP 3.0 slot with PCIe Gen5 x16 bandwidth
- Supported NCSI function
1 x M.2 slot:
- M-key
- PCIe Gen3 x4
- Supports NGFF-2280/22110 cards
Socket
Socket
Security
Security Server Operating Properties
Power Supply
Internal I/O 1 x M.2 slot
1 x TPM header
2 x OCP 3.0 mezzanine slots
Socket
Socket
Security
Security Server Operating Properties
Power Supply
Front I/O 2 x USB 3.2 Gen1
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
1 x LAN activity LED
1 x HDD activity LED
1 x System status LED
Socket
Socket
Security
Security Server Operating Properties
Power Supply
Rear I/O 2 x USB 3.2 Gen1
1 x Mini-DP
1 x RJ45
1 x MLAN
1 x ID button with LED
Socket
Socket
Security
Security Server Operating Properties
Power Supply
Backplane I/O Backplane P/N: 9CBP20C5NR-00
Speed and bandwidth: PCIe Gen4 x4 or SATA 6Gb/s or SAS 12Gb/s

Hardware Installation
- 12 -
Socket
Socket
Security
Security Server Operating Properties
Power Supply
TPM 1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010
Socket
Socket
Security
Security Server Operating Properties
Power Supply
Power Supply R263-Z30-AAC1/ R263-Z30-AAC2
Dual 1300W (240V) 80 PLUS Platinum redundant power supply
AC Input:
- 100-240V~/ 12-7A, 50-60Hz
- 200-240V~/ 8A, 50-60Hz
DC Input:
- 240Vdc/ 6.5A
DC Onput:
- Max 1000W/ 100-240V~
+12V/ 80.5A
+12Vsb/ 3A
- Max 1300W/ 200-240V~ or 240Vdc Input
+12V/ 105.4A
+12Vsb/ 3A
R263-Z30-AAH2
Dual 1300W (240V) 80 PLUS Titanium redundant power supply
AC Input:
- 100-127V ~/ 12A, 50-60Hz
- 200-240V~/ 8A, 50-60Hz
DC Input:
- 240Vdc/ 7A
DC Onput:
- Max 1000W/ 100-127V~
+12.2V/ 82A
+12Vsb/ 3A
- Max 1300W/ 200-240V~ or 240Vdc Input
+12.2V/ 106A
+12Vsb/ 3A
NOTE: The default power supply is based on a basic system conguration. Please
contact with technical representatives to determine the best power supply selection
for your system conguration requirements and preferred efciency.

Hardware Installation
- 13 -
Socket
Socket
Security
Security Server Operating Properties
Power Supply
System
Management
Aspeed® AST2600 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Prole
System Firewall
Power Consumption
Power Control
LDAP / AD / RADIUS Support
Backup & Restore Conguration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings
Socket
Socket
Security
Security Server Operating Properties
Power Supply
Operating
Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

Hardware Installation
- 14 -
1-3 System Block Diagram
1-3-1 R263-Z30-AAC1
1-3-2 R263-Z30-AAC2/ R263-Z30-AAH2

System Appearance
- 15 -
Chapter 2 System Appearance
2-1 Front View
1 23
HDD0
HDD1
HDD2
HDD3
HDD4
HDD5 HDD8
HDD9
HDD6
HDD7 HDD10
HDD11
No. Description
1. Front Panel LEDs and Buttons
2. Front USB 3.2 Gen1 Ports
3. 3.5"/2.5" Drive Bays
Note! Drives with green latches support NVMe.
• Please Go to Chapter 2-3 Front Panel LED and Buttons for detail description of function
LEDs.

System Appearance
- 16 -
2-2 Rear View
83 5 7
1
2 4 6
PSU1
PSU2
SLOT3
SLOT6
Oponal
SLOT5
SLOT1
SLOT2
Reserved
SLOT7
SLOT8
No. Description
1. PCIe Slot
2. OCP 3.0 Slot (Option/SFF)
3. Mini DP Port
4. USB 3.2 Gen1 Port x 2
5. 10/100/1000 Server Management LAN Port
6. 1GbE LAN Port
7. ID Button
8. OCP 3.0 Slot (Option/SFF)

System Appearance
- 17 -
2-3 Front Panel LEDs and Buttons
(Note) If your server features RoT function, please see the following section for detail LED behavior.
L1 L2
1
3
5
7
2
4
6
8
No. Name Color Status Description
1. Reset Button Press the button to reset the system.
2. NMI button
Press the button server generates a NMI to the processor
if the multiple-bit ECC errors occur, which effectively halt
the server.
3. Power button
with LED
Green On System is powered on
Green Blink System is in ACPI S1 state (sleep mode)
N/A Off • System is not powered on or in ACPI S5 state (power off)
• System is in ACPI S4 state (hibernate mode)
4. ID Button(Note) Press the button to activate system identication
5. HDD Status
LED
Green On HDD locate
Blink HDD access
Amber On HDD fault
Green/
Amber Blink HDD rebuilding
N/A Off No HDD access or no HDD fault.
6.
System
Status
LED(Note)
Green Solid On System is operating normally.
Amber
Solid On Critical condition, may indicate:
System fan failure; System temperature
Blink
Non-critical condition, may indicate:
Redundant power module failure
Temperature and voltage issue
Chassis intrusion
N/A Off System is not ready, may indicate:
POST error; NMI error; Processor or terminator missing
7. LAN 1 Active/
Link LEDs
Green Solid On Link between system and network or no access.
Green Blink Data trasmission or receiving is occuring
N/A Off No data transmission or receiving is occuring
8. LAN 2 Active/
Link LEDs The function is disabled.

System Appearance
- 18 -
2-3-1 RoT LEDs
L1 L2
Status LE
D
ID LED
LED on Front panel(Note5)
ID LED Status LED
EC Firmware (FW) Authentication fail or not exit
EC FW is broken or not exit (Note1) OFF OFF
Authenticating/Recovering BMC/BIOS Images
Authenticating Images OFF OFF
Recovering BMC Active Flash
Blinks Blue
4 times per
second
Blinks Green
4 times per
second
Recovering BIOS Active Flash
Blinks Blue
4 times per
second
Blinks Green
4 times per
second
Authentication (AUTH) Pass
Recovering BIOS Active Flash OFF OFF
BMC : AUTH pass after doing recovery
BIOS : AUTH pass after doing recovery OFF OFF
BMC : AUTH pass after doing recovery
BIOS : AUTH pass OFF OFF
BMC : AUTH pass
BIOS : AUTH pass after doing recovery OFF OFF
Active Flash Authentication (AUTH) Fail
BMC : AUTH Fail(Note2)
Blinks Blue
1 time per
second
Blinks Green
1 time per second

System Appearance
- 19 -
BIOS : AUTH fail(Note2)
Blinks Blue
1 time per
second
Blinks Amber
1 time per second
BMC : AUTH fail after doing recovery(Note3)
Blinks Blue
2 times per
second
[ON OFF OFF]
Blinks Green
2 times per
second
[ON OFF OFF]
BIOS : AUTH fail after doing recovery(Note3)
Blinks Blue
2 times per
second
[ON OFF OFF]
Blinks Amber
2 times per
second
[ON OFF OFF]
Backup Flash Authentication Fail(Note4)
BMC : AUTH fail
Blinks Blue
2 times per
second
[ON OFF
ON OFF]
Blinks Green
2 times per
second
[ON OFF
ON OFF]
BIOS : AUTH fail
Blinks Blue
2 times per
second
[ON OFF
ON OFF]
Blinks Amber
2 times per
second
[ON OFF
ON OFF]
NOTE!
1. EC FW is broken or not exited result in Microchip CEC1702 cannot load EC FW for authentication.
2 (1) Authentication fail include below scenarios
Conguration table is missing or modied
Public key is missing or modied
Protected area or signature is modied
Flash empty
3. If active ash is still authentication failed after recovery sequence, Microchip CEC1702 stop the process
and showing LED behavior.
4. If backup flash authentication is failed cause by configuration table, public key or protected area is
broken. Microchip CEC1702 stop the process and showing LED behavior.
5. Front panel LED is controlled by BMC or Microchip CEC1702. Once Microchip CEC1702 is working(Auth
or recovery), the front panel LED is controlled by Microchip CEC1702 and vice versa.

System Appearance
- 20 -
2-4 Rear System LAN LEDs
No. Name Color Status Description
1. 1GbE
Speed LED
Yellow On 1 Gbps data rate
Green On 100 Mbps data rate
N/A Off 10 Mbps data rate
2.
1GbE
Link/
Activity
LED
Green
On Link between system and
network or no access
Blink Data transmission or receiving is occurring
N/A Off No data transmission or
receiving is occurring
21 1 2
