Gigaset A150 User manual

1
Lombok A150-A150A-A250-A250A / BE-NL en / A31008-M2702-M201-1-3F19 / Lombok.fm / 22.08.2016
Version 4, 16.09.2005
Gigaset A150/A150A/A250/A250A
The handset at a glance
1 Charge status of the batteries:
= e V U (flat to full)
= flashes: batteries almost flat
e V U flashes: charging
2 answer machine icon
3Displaykeys
4 End call key and On/Off key
5 Talk key/Handsfree key
6Control key (u)
7Directory key (press down on the
control key)
8Key 1
Open the answer machine /
network mailbox
9Star key
Ringers on/off (press and hold); with
an open connection: switch from
pulse
dialling to tone dialling (press briefly)
10 Key 0/recall key
Consultation call (flash): press and
hold
11 Hash key
Keypad lock on/off (press and hold);
toggles between upper/lower case
and digits; inserts a dialling pause
(press and hold)
12 Microphone
(handsfree mode A250/A250A only)
A150/A150A A250/A250A
Display keys:
Pressing a key launches the func-
tion that appears above that key
in the display.
Please
New messages in the calls list/
answer machine list/network
mailbox list (¢S. 8) are indi-
cated in the display by the mes-
sage New messages.
Display Function when
pressed
INT Call other registered
handsets ¢S. 10.
MENU Openmain/submenu
(see menu overview
¢S. 16).
“ Go back one menu
level.
UScroll up/down or
adjust volume with
u.
T Move cursor to left/
right with u.
˜Backspace deletes
one character at a
time.
OK Confirm menu func-
tion or save entry.
1±V
11.12. 11:56
INT MENU
1
2
3
4
5
6
7
8
9
10
11
12
Changing the language (display + answer machine)
Changing the display language
MENU ¤u Settings ¤OK ¤u Handset ¤OK ¤u Language ¤OK ¤u (select language) ¤OK
or:
MENU ¤521 (press the keys one after the other) ¤u(select language) ¤OK
Changing the language of the answer machine
MENU ¤u Answer Machine ¤OK ¤u Language ¤OK ¤u(select language) ¤OK

2
Lombok A150-A150A-A250-A250A / BE-NL en / A31008-M2702-M201-1-3F19 / Lombok.fm / 22.08.2016
Version 4, 16.09.2005
ECO DECT
During a call, the level of the handset's radio signal adjustsautomatically according to the distance between the hand-
set and base station: the shorter the distance, the lower the signal strength (radiation).
The handset’s radio signal is switched off when it is in standby mode. The base station, however, maintains contact
with the handset with fewer radio signals.
In addition, the base station radio signals are switched off when the No Radiation setting is enabled.
MENU ¤u Settings ¤OK ¤u Base ¤OK ¤u ECO DECT ¤OK ¤No Radiation ¤OK (‰= radiation switched off,
icon ½in the left-hand corner of the display)
Please note
◆All registered handsets must support this feature.
◆For quick connection of incoming calls the handset repeatedly switches to reception mode for short periods. This
increases energy consumption and therefore reduces the standby and talk times.
The base station at a glance
Base A150/A250
Base A150A/A250A
5
3
2
1
4
6
1
1Registration/paging key:
Search for handsets (press briefly, "Paging" ¢S. 10).
Register handsets (press and hold ¢S. 10).
2Volume keys: (–= quieter; + = louder)
During message playback: adjust the speaking volume.
While phone is ringing: adjust ringer melody volume.
3Play/Stop key:
Switch answer machine on and off (press and hold);
play back new messages from answer machine (press briefly);
during message playback: cancel playback (press briefly).
Lights up: Answer machine is activated.
Flashes: You have at least one new message or a message is played
back or being recorded.
Flashes very quickly: Full memory.
During message playback:
4 Skip to the start of the current message (press once) or go to the pre-
vious
message (press twice).
5Gotothenextmessage.
6 Delete current message.

3
Lombok A150-A150A-A250-A250A / BE-NL en / A31008-M2702-M201-1-3F19 / Lombok.fm / 22.08.2016
Version 4, 16.09.2005
Safety precautions
First steps
Check the pack contents
One Gigaset A150/A150A/A250/A250A base station, one mains adapter, one Gigaset handset, one phone cord, two bat-
teries, one battery cover, one user guide.
If you have purchased a model with multiple handsets, the package should contain two batteries, a battery cover and
acharging cradle with mains adapter for each additional handset.
Setting up the base station and charging cradle (if included)
◆Set up the base station at a central location on a flat, non-slip surface in your house or apartment. You can also
mount the base station and charging cradle on the wall.
◆Pay attention to the range of the base station. This is up to 300 m in unobstructed outdoor areas and up to 50 m
inside buildings.
◆The base station and charging cradle are designed for use in enclosed dry rooms in a temperature range of +5 °C to
+45 °C.
◆Care: Wipe down the base station and handset with a damp cloth (no solvents) or an antistatic cloth. Never use a
dry cloth. This can cause static.
◆The phone's feet do not usually leave any marks on surfaces. However, due to the multitude of different varnishes
and polishes used on today's furnishings, the risk of marks on the surfaces cannot be completely ruled out.
◆Never expose the telephone to the influence of heat sources, direct sunlight or other electrical devices.
◆Protect your Gigaset from moisture, dust, corrosive liquids and vapours.
a- Read the safety precautions and the user guide before use.
- The device cannot be used in the event of a power failure. In case of a power failure it is also not possible
to make emergency calls.
- Emergency numbers cannot be dialled if the keypad/display lock is activated!
Do not use the devices in environments with a potential explosion hazard (e.g. paint shops).
The devices are not splashproof. For this reason do not install them in a damp environment such as bathrooms
or shower rooms.
Use only the power adapter indicated on the device.
Use only rechargeable batteries that correspond to the specification (see "Specifications"). Never use a
conventional (non-rechargeable) battery or other battery types as this could result in significant health risks
and personal injury. Rechargeable batteries, which are noticeably damaged, must be replaced.
Remove faulty devices from use or have them repaired by our Service team, as these could interfere with other
wireless services.
Do not use the device if the display is cracked or broken. Broken glass or plastic can cause injury to hands and
face. Send the device to our Service department to be repaired.
Do not hold the rear of the handset to your ear when it is ringing or when speaker mode is activated. Otherwise
you risk serious and permanent damage to your hearing.
The phone may cause interference in analogue hearing aids (humming or whistling) or cause them to overload.
If you require assistance, please contact the hearing aid supplier.
Using your telephone may affect nearby medical equipment. Be aware of the technical conditions in your
particular environment, e.g. doctor's surgery. If you use a medical device (e.g. a pacemaker), please contact the
device manufacturer. They will be able to advise you regarding the susceptibility of the device to external
sources of high frequency energy (for the specifications of your Gigaset product see "Specifications").

4
Lombok A150-A150A-A250-A250A / BE-NL en / A31008-M2702-M201-1-3F19 / Lombok.fm / 22.08.2016
Version 4, 16.09.2005
Connecting the base station
Connecting the charging cradle (if included)
¤First connect the mains adapter 1.
¤Then connect the telephone jack 2and insert the cables into the
cable ducts.
Please note:
◆The mains adapter must always be connected, as the phone will not
operate without mains connection.
◆Use only the mains adapter and phone cord supplied. Pin connec-
tions on telephone cables can vary.
◆The answer machine (A150A/A250A only) is ready for use approx.
30 seconds after the base has been connected.
1
1
1
2
A150/A250
1
1
1
2
A150A/A250A
¤Connect the flat plug to the power
supply 1.
¤Plug the mains adapter into the plug
socket 2.
If you need to disconnect
the plug from the charg-
ing cradle, press the
release button 3and
disconnect the plug 4.
1
2
3
4

5
Lombok A150-A150A-A250-A250A / BE-NL en / A31008-M2702-M201-1-3F19 / Lombok.fm / 22.08.2016
Version 4, 16.09.2005
Setting up the handset for use
The display is protected by a plastic film. Please remove the protective film!
Inserting the batteries and closing the battery cover
Initial charging and discharging of the batteries
The correct charge status can only be displayed if the batteries are first fully charged and discharged.
Setting the date and time
Set the date and time so that the correct date and time can be assigned to incoming calls, and so that the alarm can be
used.
MENU ¤u Settings ¤OK ¤Date/Time ¤OK ¤Date ¤~(enter the day, month and year in 6-digit format) ¤OK
¤Time ¤~(enter hours and minutes in 4-digit format) ¤OK (display message: Saved)
¤a(press and hold to return to idle status)
When entering the time and date, you can move the position of an entry to the left or right by pressing the control key
uup or down.
Warning
Use only the rechargeable batteries recommended by Gigaset Communications GmbH (¢S. 13), i.e. never use con-
ventional (non-rechargeable) batteries as this could result in significant health risks and personal injury. For example,
the batteries could explode. The phone could also malfunction or be damaged as a result of using batteries that are
not of the recommended type.
Please note
◆The handset is pre-registered with the base. If you have purchased a model with multiple handsets, all handsets
will already be registered with the base. You do not need to register the handset again. The internal handset
number appears in the top left of the display, e.g. 1(¢S. 1).
However, if a handset is not registered with the base (Register HS or Put into base is displayed), please register
the handset manually (¢S. 10).
◆If you have purchased multiple devices, you can upgrade your Gigaset to a cordless PABX by registering all
A150/A250 handsets at the same base (¢S. 10).
◆After the first battery charge and discharge, you may place your handset in the charger after every call.
◆Always repeat the charging and discharging procedure if you remove the batteries from the handset and rein-
sert them.
◆The batteries may warm up during charging. This is not dangerous.
◆After a while, the charge capacity of the batteries will decrease for technical reasons.
¤Insert the batteries with the polarity in the cor-
rect direction.
The polarity is indicated in the battery compartment.
¤First insert the battery cover at the top a.
¤Then press the cover buntil it clicks into place.
¤To reopen the battery cover, grip into the cavity on the
casing, then pull the battery cover in an upward direction.
a
b
6.5
h
¤Charge the handset in the base for 6.5 hours.
¤After charging the handset for the first time, remove the handset from the base and only replace it
when the batteries are fully discharged.
Please note
The handset must only be placed in the designated Gigaset base or charging cradle.

6
Lombok A150-A150A-A250-A250A / BE-NL en / A31008-M2702-M201-1-3F19 / Lombok.fm / 22.08.2016
Version 4, 16.09.2005
Activating/deactivating the handset
Press and hold the akey to activate or deactivate the handset. If you place a deactivated handset in the base station or
charging cradle, it will automatically activate after approx. 30 seconds.
If you remove the handset from the base station/charging cradle, the display turns off briefly.
Making calls
Making external calls and ending calls
External calls are calls using the public telephone network.
~(Enter the phone number) ¤b.
The phone number is dialled. (Or you can first press and hold talk key b[until you your the dial tone] and then enter
the number.) During the call you can adjust the earpiece volume using tand set the volume with u.
End the call/cancel dialling: Press the end call key a.
You can automatically insert a network provider dialling code before any phone number (¢S. 6).
Accepting a call
Press the talk key bto accept the call.
When Auto Answer is activated (see menu overview ¢S. 17), simply remove the handset from the base station/charg-
ing cradle.
Calling Line Identification
When you get a call, the caller's number will be displayed on your handset; the caller's name will be displayed if it is
stored in the directory.
Prerequisites:
1 You have asked your network provider for the caller's number (CLIP) to be displayed on your handset screen.
2 The caller has asked the network provider for his/her number to be identified (CLI).
External call appears in the display if you have not requested CLIP, Withheld appears if the caller has withheld CLI, and
Unavailable appears if CLI has not been requested.
Handsfree operation (Gigaset A250/A250A only)
In handsfree mode, you activate the loudspeaker so that you can hear the caller without having to hold the handset to
your ear. During a call and when listening to the answer machine (Gigaset A250A only) you activate or deactivate hands-
free mode by pressing the handsfree key d.
For instructions on adjusting the handsfree mode volume see menu overview ¢S. 16.
Automatic network provider preselection
You can store a call-by-call number (preselection number), which is automatically placed in front of numbers when you
dial them. If, for example, you wish to make international calls via special network providers, you can save the relevant
dialling code here.
In the "With Preselect" list, specify the dialling codes or the first digits of the dialling codes that you wish to assign to the
preselection number.
Please note
If your phone receives the date and time during calling line display (e.g., via your network provider, a router or PABXs),
you can specify whether this data should be copied to your phone:
¤Press the key sequence: MENU ¤P#Q5#MI
The following is displayed;
the current setting flashes:
¤Press one of the following keys to specify, when this data should be copied to your phone:
QNever
or 1Once, in case the date/time is not set on your phone
or 2Always
Your selection is displayed (e.g. 2 for "Always"):
¤Press the display key OK.
973 SET: [0]
973 SET: [2]

7
Lombok A150-A150A-A250-A250A / BE-NL en / A31008-M2702-M201-1-3F19 / Lombok.fm / 22.08.2016
Version 4, 16.09.2005
In the "Without Presel" list, enter any exceptions to the "With Preselect" list.
Enter preselection number via menu (¢S. 17).
Permanently deactivating preselection: Delete the preselection number with ˜.
Temporarily cancelling preselection:
(press and hold) ¤MENU ¤qPreselect off ¤OK ¤~(enter number) or s(use number from directory) ¤The
number is dialled without Preselection.
Using the directory and lists
Directory
To open the directory: press control key s.
You can save up to 50 (A150/A150A) or 80 (A250/A250A) phone numbers (max. 22 digits) with corresponding names
(max. 14 characters).
Enter letters/characters ¢S. 13.
Storing the first number in the directory
s¤New Entry? ¤OK ¤~(enter number) ¤OK ¤~ (enter name) ¤OK
Storing further numbers in the directory
s¤MENU ¤New Entry ¤OK ¤~(enter number) ¤OK ¤~ (enter name) ¤OK
Selecting a directory entry
Open the directory with s.You have the following options:
◆Use uto scroll through the entries until the required name is selected.
◆Enter the first character of the name and scroll to the entry with u, if required.
Dialling with the directory
s¤u(select entry) ¤b
Using other functions
s¤u(select entry) ¤MENU
The following functions can be selected with u: New Entry/Show Number/Show Name/Edit Entry/Use Number/
Delete Entry/Send Entry/Delete List/Send List/Shortcut
Sending the directory to another handset
Prerequisites:
◆The sending and receiving handsets must both be registered to the same base station.
◆The other handset and the base station can send and receive directory entries.
s¤u(select entry) ¤MENU ¤uSend Entry/Send List ¤OK
¤~(enter the internal number of the receiving handset) ¤OK
Using shortcut keys
You can assign directory entries to the keys 2–9:
s¤u(select entry) ¤MENU ¤uShortcut ¤OK
¤u(select key) ¤OK or ~(press the key you want to assign the entry to)
To dial, press and hold the required shortcut key.
Last number redial list
This list contains the ten last dialled numbers.
Dialling from the last number redial list
b(press briefly)¤u (select entry) ¤b
Managing entries in the last number redial list
b(press briefly)¤u (select entry) ¤MENU
The following functions can be selected with u: Use Number/Copy to Dir./Delete Entry/Delete List
Example:
Presel. Number 0999
With Preselect 08
Without Presel 081
084
Phone
number
Dialled
number
07112345 ¤07112345
08912345 ¤0999 08912345
08412345 ¤08412345
All numbers that start
with 08, except for 081
and 084, are dialled
with the preselection
number 0999.
b

8
Lombok A150-A150A-A250-A250A / BE-NL en / A31008-M2702-M201-1-3F19 / Lombok.fm / 22.08.2016
Version 4, 16.09.2005
Calls list/answer machine list/network mailbox list
Press MENU ¤Messages ¤OK, to open the list overview. If you have new messages, only lists with new messages are
displayed. Scroll through the lists by pressing u.
An advisory tone sounds as soon as a new entry appears in the calls list/answer machine list/network mailbox list. New
messages appears in the display.
Calls list
Prerequisites: CLIP (¢S. 6)
Depending on the type of list set, the calls list contains (¢S. 17) answered calls, missed calls and calls recorded from the
answer machine (A150A/A250A only).
Depending on the type of list set, all numbers of the last 25 incoming calls are saved or just the missed calls are saved.
Open the calls list
MENU ¤Messages ¤OK ¤u CallsList
The calls list is displayed as follows:
Number of new entries + number of old, read entries
Press OK to open the list.
The last incoming call is displayed. If necessary, use uto select another entry.
Using other functions
u(select entry) ¤MENU
The following functions can be selected with u: Delete Entry/Copy to Dir./Date/Time/Status/Delete List
Calling back a caller from the calls list
MENU ¤Messages ¤CallsList 01+02 ¤OK ¤u(select entry) ¤b
Answer machine list (A150A/A250A only)/network mailbox list
You can use these lists to listen to messages on the answer machine (see "Playing back/deleting messages" ¢S. 8) or
network mailbox (¢S. 10).
Operating the answer machine (A150A/A250A only)
The answer machine is operated from the handset or via the keys on the base (¢S. 2). You can record your own
announcement messages using the handset. The pre-recorded announcement is used if no personal announcement is
available.
If the memory is full, Memory full! appears in the display and the answer machine switches itself off automatically. It
activates again automatically when you delete old messages.
The answer machine has already been preset at the factory. Make individual settings using the handset.
How to set a delay time (time period after which you would like the answer machine to answer a call), as well as how to
set the recording length and activate call screening during the recording, see menu overview ¢S. 16.
Activating/deactivating the answer machine
MENU ¤u Answer Machine ¤OK ¤u Answer Mach. ¤OK (‰= on)
When you switch on the answer machine, the ±icon appears in the display.
Recording your own announcement
MENU ¤u Answer Machine ¤OK ¤u Announcements ¤OK ¤Rec announce ¤OK ¤Speak after OK ¤OK
You hear the ready tone (short tone). Now say your announcement (at least 3 sec.). Press OK to confirm or press aor ”
to reject your recording. After recording, the announcement is played back for you to check.
Please note:
Recording ends automatically when the max. recording time of 170 seconds is reached or if there is a break in speaking
of more than 2 seconds.
Playing back or deleting announcements
See menu overview ¢S. 16.
Playing back/deleting messages
There are three ways to start playing back messages on the answer machine.
◆Start message playback via the Answer Machine menu:
MENU ¤u Answer Machine ¤OK ¤u Play Messages ¤OK
Please note
If calls are saved in the network mailbox, you will receive a message if the appropriate settings have been made
(depending on your network provider).
CallsList 01+02

9
Lombok A150-A150A-A250-A250A / BE-NL en / A31008-M2702-M201-1-3F19 / Lombok.fm / 22.08.2016
Version 4, 16.09.2005
If you have entered a number for the network mailbox you still need to select the answer machine: ¤uAnswer
Mach. ¤OK
◆Start message playback via the answer machine list:
MENU ¤Messages ¤OK ¤u Ans.Mach.
The list is displayed as follows:
Number of new messages + number of old, played back messages
Press OK to open the list.
◆Fast access to the answer machine:
To access the answer machine, simply press and hold the 1key. The integrated answer machine has already been
preset at the factory. However, if you have set the network mailbox for fast access, you can change this setting
(¢S. 17).
If you have new messages, playback will start with thefirst new message, otherwise with the first old message.
Gigaset A250A only: The loudspeaker on the handset switches on automatically. To switch it off, press the handsfree
key d.
Messages consist of
◆the message header (number/date/time) and
◆the message body (recorded text).
The header is played back first, then the body. The phone number or the name is displayed.
Stopping and controlling playback
Controlling playback depends on the point in time at which the corresponding key is pressed.
During message playback:
Additional functions during message playback
Press the display key MENU. Playback stops.
Select the relevant function using u: Dial Number/Continue/Handset Volume/Copy to Dir./Delete all old
Deleting an individual message
During playback: Press key Qor the display key ˜.
Deleting all old messages
During playback or pause:
MENU ¤u Delete all old ¤OK (Confirm the security prompt)
Accepting a call from the answer machine
You can accept a call while the answer machine is recording the caller's message:
MENU ¤Accept ¤OK
You can also accept the call by:
◆pressing the talk key
◆removing the handset from the base/charger (if Auto Answer is activated ¢S. 17)
Recording stops and you can speak to the caller.
Setting a different language
You can change the language for the voice prompt and default announcement.
MENU ¤u Answer Machine ¤OK ¤u Language ¤OK ¤u(select language) ¤OK
Operating when on the move (remote operation)
You can check your answer machine from any other telephone (hotel, pay phone etc.).
2Pause playback. Press 2again to resume.
tor 1 During playback of message header: Go to the start of the previous message. Skipping back from the
first message jumps to the last message.
During playback of message body: Go to the start of the current message.
sor I Go to the start of the next message. Skipping forward from the last message jumps to the first mes-
sage.
LDuring playback of message header: Skip header.
During playback of message body: Go to the body of the next message. Skipping forward from the
last message jumps to the first message.
Please note (Gigaset A250A)
When CallScreening via the handset is activated and the call can already be heard at the handset, you can only
accept the call via MENU ¤Accept ¤OK. Pressing the talk key/hands free key conly activates or deactivates the
handsfree mode.
Ans.Mach. 01+02
b

10
Lombok A150-A150A-A250-A250A / BE-NL en / A31008-M2702-M201-1-3F19 / Lombok.fm / 22.08.2016
Version 4, 16.09.2005
Prerequisites:
◆You have set a system PIN other than 0000 ¢S. 17.
◆The phone you are using for remote operation has tone dialling (DTMF) i.e., you hear different tones when you press
the keys.
Calling the answer machine and playing messages
~(Dial your own number.) ¤When you hear your announcement, press 9and enter the system PIN.
The following keys are used for operation:
Activating the answer machine
~(Enter your own number and allow the phone to ring until you hear the message: "Please enter PIN")
¤~(Enter system PIN)
Your answer machine is activated. It tells you how much memory time is left. The messages are now played back. The
answer machine cannot be deactivated remotely.
Network mailbox
The network mailbox is the answer machine in your provider's telephone network. More information is available from
your provider. You cannot use the network mailbox unless you have requested it from your provider.
In order to use the network mailbox quickly and easily via the network mailbox list (¢S. 8), the menu (¢S. 16) and to
use fast access via key 1 (¢S. 1), you will need to enter the number in your phone:
MENU ¤u Answer Machine ¤OK ¤u Netw. Mailbox/Net Mailbox ¤~(enter number) ¤OK
Locating a handset ("Paging")
You can locate your handset using the base.
¤Briefly press the registration/paging key on the base (¢S. 1)(¢S. 2).
All handsets will ring at the same time (“paging”), even if the ringers are switched off.
Ending paging: Briefly press the registration/paging key on the base (¢S. 1)(¢S. 2) or press the talk key bor the end
call key aon the handset.
Registering handsets manually
You can register up to four handsets to your base station. Each additional handset must be registered on the base sta-
tion in order for it to work properly!
Registration takes approx. 1 minute. Handsets are assigned the lowest available internal number (1-4). If the internal
numbers 1–4 are already assigned to other devices, the number 4 will be overwritten.
De-registering handsets
You can de-register all other registered handsets from each of the registered Gigaset handsets.
MENU ¤u Settings ¤OK ¤u Handset ¤OK ¤u De-register HS ¤OK ¤u Select the internal party you wish to
de-register. The handset you are currently using is indicated by <.¤OK ¤Enter the base system PIN (default setting:
0000) ¤OK
Using multiple handsets
Making internal calls
Internal calls are free calls to other handsets that are registered to the same base station.
ADuring the number/date/time announcement: Skip to the start of the previ-
ous message.
During the message playback: Skip to the start of the current message.
BStop playback. Press again to resume.
3Go to the next message.
0Delete current message.
1) On the handset
MENU ¤u Settings ¤OK ¤u Handset ¤OK ¤u Register HS ¤Enter the base system PIN (default setting: 0000)
¤OK ¤Registering is displayed.
2) On the base
Within 60 seconds, press and hold the registration/paging key on the base (¢S. 1)(¢S. 2) for approx. 3 seconds.

11
Lombok A150-A150A-A250-A250A / BE-NL en / A31008-M2702-M201-1-3F19 / Lombok.fm / 22.08.2016
Version 4, 16.09.2005
2 handsets are registered
Press the display key INT, the other handset is called.
More than 2 handsets are registered
Calling a specific handset
INT ¤~(1...4, enter internal number of the handset) or
INT ¤u(Select the internal party) ¤OK or b¤the handset is called
Calling all handsets (“group call”)
INT ¤Por INT ¤u Call all ¤OK or b¤all handsets are called
When a participant answers you can speak to them. To end the call, press a.
Internal consultation call/connecting a call
You are in conversation with an external participant. Press the INT display key and call one or all handsets. The external
participant hears the hold music. When the internal participant answers: If necessary, announce the external call.
Either press the end call key a(the call is transferred to the internal participant), or
press the display key ”. You are reconnected with the external participant.
When transferring a call you can also press the end call key abefore the internal participant answers.
Listening in to an external call
You are conducting an external call. An internal participant can listen in on this call and take part in the conversation
(conference). Prerequisite: The Listening in function must be activated.
Activating/deactivating listening in
MENU ¤u Settings ¤OK ¤u Base ¤OK ¤u Listening in ¤OK (‰= on)
Internal listening in (conference)
You want to listen in to an existing external call. Press and hold the bkey. You can listen in to the call. All participants
hear a signal tone.
To end: press the end call key a. All participants hear a signal tone.
If the first internal participant presses the end call key a, the handset that has “listened in” remains connected to the
external participant.
Setting the alarm clock
Activating/deactivating the alarm clock
MENU ¤u Alarm Clock ¤OK ¤Activation ¤OK (‰= on)
When activated: ¤~ (Set the wake-up time) ¤OK
When the alarm clock rings, press any key to switch it off for 24 hours. If the alarm clock is set, the wake-up icon lwill
appear on the screen and the wake-up time will be displayed instead of the date.
Setting the wake-up time
MENU ¤u Alarm Clock ¤OK ¤u Wake-up time ¤OK
Enter the wake-up time in hours and minutes, then press OK.
Phone settings
For details on how to make audio settings, see menu overview ¢S. 16.
For details on how to set the system PIN on the base station, see the menu overview ¢S. 17.
Changing the display language
MENU ¤u Settings ¤OK ¤u Handset ¤OK ¤u Language ¤OK ¤u (select language) ¤OK
The current language is indicated by ‰.
If you accidentally choose a language you do not understand:
MENU ¤521 (press the keys one after the other) ¤u(select language) ¤OK
Activating/deactivating music on hold
You can select that your external participant hears music in case of internal recall and during call transfer.
MENU ¤P#Q5#1M ¤The number for the current setting flashes:
0= off; 1= on ¤enter number ¤OK.
Repeater mode
With a repeater you can increase the range of your base station. You will need to activate repeater mode (¢S. 17).
Repeater mode and No Radiation mode (¢S. 17) cancel each other out.

12
Lombok A150-A150A-A250-A250A / BE-NL en / A31008-M2702-M201-1-3F19 / Lombok.fm / 22.08.2016
Version 4, 16.09.2005
Resetting the handset
You can reset individual settings and changes that you have made. Entries in the directory, the calls list and the handset's
registration to the base station will be retained.
MENU ¤u Settings ¤OK ¤u Handset ¤OK ¤u Reset Handset ¤OK ¤Reset? ¤OK
Cancel the reset with a.
Resetting the base station
When restoring factory settings the No Radiation mode is deactivated, individual settings are reset and all lists are
deleted.
The date and time are retained. The answer machine (A150A/A250A only) is ready for use approx. 15 seconds after the
base has been reset.
Resetting the base via the menu
Handsets are still registered, the system PIN is not reset.
MENU ¤u Settings ¤OK ¤u Base ¤OK ¤u Base Reset ¤OK ¤Reset? ¤OK
Resetting the base using the key on the base
All handsets are de-registered and the system PIN is reset to the original code 0000.
Carry out the following steps: Remove the mains cable from the base. Hold down the registration/paging key on the
base (¢S. 1)(¢S. 2) and reconnect the power cable to the base at the same time. Hold the key down for at least
5 seconds.
Operating the base station on the PABX/router
Operating on the router
When operating the Gigaset on an analogue port of a router you can reduce problems with echoes by activating the
Echo mode (¢S. 17). If you have no problems with echoes, this function should be deactivated.
Operating on the PABX
The following settings are only necessary when your PABX requires them; see the user guide for your PABX.
When entering the digits, enter them slowly one after the other.
Changing the dialling mode
MENU ¤P#Q5#1N¤The number for the set dialling mode flashes: 0 = touch tone dialling (DTMF); 1= dial
pulsing (DP) ¤enter number ¤OK.
Setting recall
MENU ¤P#Q5#1Q ¤The number for the current recall flashes: 0= 80 ms; 1= 100 ms; 2= 120 ms;
3= 400 ms; 4= 250 ms; 5= 300 ms; 6 = 600 ms; 7= 800 ms ¤enter number ¤OK.
Changing pause after line seizure
You can set the length of the pause inserted between pressing the talk key and sending the phone number.
MENU ¤P#Q5#1L ¤The number for the current pause length flashes: 1= 1 sec.; 2= 3 sec.; 3= 7 sec.
¤enter number ¤OK.
Changing the pause after the recall key
MENU ¤P#Q5#12 ¤The number for the current pause length flashes: 1= 800 ms; 2= 1600 ms; 3 = 3200
ms ¤enter number ¤OK.
b

13
Lombok A150-A150A-A250-A250A / BE-NL en / A31008-M2702-M201-1-3F19 / Lombok.fm / 22.08.2016
Version 4, 16.09.2005
Appendix
Entering letters/characters
Specifications
Batteries
Technology: Nickel-metal-hydride (NiMH); Size: AAA (Micro, HR03); Voltage: 1.2 V; Capacity: 400 - 1000 mAh
General specifications
Questions and answers
If you have any queries about the use of your telephone, visit our website at www.gigaset.com/service
for 24-hour support. The table below contains a list of common problems and possible solutions.
Standard
characters
Press the relevant key
the number of times
indicated.
Briefly press the hash
key #to switch from
"Abc" to "123" mode,
from "123" to "abc"
mode and from "abc"
to "Abc" mode.
DECT standard is supported
GAP standard is supported
Range up to 300 m outdoors, up to 50 m indoors
Base station power supply 230 V ~/50 Hz
Radio frequency range 1880-1900 MHz
Transmission power 10 mW average power per channel, 250 mW pulse power
Environmental conditions in operation +5 °C to +45 °C, 20% to 75% relative humidity
Base station power consumption A150/A250 A150A/A250A
In standby mode
– Handset in base station
– Handset outside base station ca. 1.0 W ca. 1.2 W ca. 0.8 W ca. 1.0 W
During a call ca. 1.0 W ca. 1.2 W
Problem Cause Solution
Nothing appears in
thedisplay. The handset is not switched on.
The batteries are flat.
Press the end call key afor approx. 5 seconds or
place the handset in the base station.
Charge or replace the batteries.
No wireless connec-
tion to the base sta-
tion, Base flashes in
the display.
The handset is outside the range of the
base station.
The handset is not registered.
The base station is not turned on.
Move the handset closer to the base station.
Register the handset ¢S. 10.
Check the mains connector on the base station
¢S. 4.
You cannot hear a
ringer/dialling tone
from the fixed line
network.
The phone cord supplied has not been
used or has been replaced by a new cord
with the wrong jack connections.
Please always use the phone cord supplied or ensure
that the pin connections are correct when purchas-
ing from a retailer: 3-4 assignment of telephone
leads/EURO CTR37.
Error tone sounds
after system PIN
prompt.
PIN forgotten.
The system PIN you have entered is
incorrect. Reset the system PIN to the default 0000 ¢S. 12.
All handsets are de-registered. All settings are
reset. All lists are deleted.
1) Space
1x 2x 3x 4x 5x 6x 7x 8x 9x 10x 11x 12x 13x 14x 15x
11£$¥¤
2abc2äáàâãç
Idef3ëéèê
4ghi4ïíìî
5jkl5
Lmno6öñóòôõ
Mpqr s7ß
Ntuv8üúùû
Owx y z 9 ÿ ýæøå
Q.,?!0+-:¿¡"’;_
P*/()<=>%
##@\ &§
1)

14
Lombok A150-A150A-A250-A250A / BE-NL en / A31008-M2702-M201-1-3F19 / Lombok.fm / 22.08.2016
Version 4, 16.09.2005
Contact with liquid
If the device comes into contact with liquid:
1 Disconnect the power supply.
2 Remove the batteries and leave the battery compartment open.
3 Allow the liquid to drain from the device.
4 Pat all parts dry.
5 Place the device in a dry, warm place for at least 72 hours (not in a microwave, oven etc.) with the battery compart-
ment open and the keypad facing down (if applicable).
6 Do not switch on the device again until it is completely dry.
When it has fully dried out, you will normaly be able to use it again.
Service (Customer Care)
Step by step towards your solution with Gigaset Customer Care
www.gigaset.com/service
Visit our Customer Care pages:
www.gigaset.com/service
Here you will find:
◆Frequently asked questions
◆Free software and user manual downloads
◆Compatibility checks
Contact our Customer Care team:
Couldn't find a solution in the FAQs section?
We are happy to help...
... by eMail: www.gigaset.com/contact
... by telephone:
Here you can get competent advice on questions regarding installation,
operation and configuration:
Here you can get competent advice on questions regarding installation,
operation and configuration:
Netherlands 0900-3333102
(1,00 € per call)
Belgium 07815 6679
(local call cost charge)
Please have your proof of purchase ready when calling.
Please note that if the Gigaset product is not sold by authorised dealers in the national territory the product may not be
fully compatible with the national telephone network. It is clearly specified on the box near the CE mark for which coun-
try/countries the equipment has been developed. If the equipment is used in a manner inconsistent with this advice or
with the instructions of the manual and on the product itself, this may have implications on the conditions for warranty
or guarantee claims (repair or exchange of product).
In order to make use of the warranty, the product purchaser is asked to submit a receipt which proves the date of
purchase (date from which the warranty period starts) and the type of goods that have been purchased.
!

15
Lombok A150-A150A-A250-A250A / BE-NL en / A31008-M2702-M201-1-3F19 / Lombok.fm / 22.08.2016
Version 4, 16.09.2005
Authorisation
This device is intended for analogue phone lines in the Belgian and Dutch network.
Country-specific requirements have been taken into consideration.
Hereby, Gigaset Communications GmbH declares that the radio equipment type Gigaset A150/A150A/A250/A250A is in
compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
www.gigaset.com/docs.
This declaration could also be available in the "International Declarations of Conformity" or “European Declarations of
Conformity” files.
Therefore please check all of these files.
Guarantee Certificate
Without prejudice to any claim the user (customer) may have in relation to the dealer or retailer, the customer shall be
granted a manufacturer's Guarantee under the conditions set out below:
◆In the case of new devices and their components exhibiting defects resulting from manufacturing and/or material
faults within 24 months of purchase, Gigaset Communications shall, at its own option and free of charge, either
replace the device with another device reflecting the current state of the art, or repair the said device. In respect of
parts subject to wear and tear (including but not limited to, batteries, keypads, casing), this warranty shall be valid
for six months from the date of purchase.
◆This Guarantee shall be invalid if the device defect is attributable to improper treatment and/or failure to comply
with information contained in the user guides.
◆This Guarantee shall not apply to or extend to services performed by the authorised dealer or the customer them-
selves (e. g. installation, configuration, software downloads). User guides and any software supplied on a separate
data medium shall be excluded from the Guarantee.
◆The purchase receipt, together with the date of purchase, shall be required as evidence for invoking the Guarantee.
Claims under the Guarantee must be submitted within two months of the Guarantee default becoming evident.
◆Ownership of devices or components replaced by and returned to Gigaset Communications shall vest in Gigaset
Communications.
◆This Guarantee shall apply to new devices purchased in the European Union. The Guarantee is issued by: Gigaset
Communications Nederland BV.
◆Any other claims resulting out of or in connection with the device shall be excluded from this Guarantee. Nothing in
this Guarantee shall attempt to limit or exclude a Customers Statutory Rights, nor the manufacturer's liability for
death or personal injury resulting from its negligence.
◆The duration of the Guarantee shall not be extended by services rendered under the terms of the Guarantee.
◆Insofar as no Guarantee default exists, Gigaset Communications reserves the right to charge the customer for
replacement or repair.
◆The above provisions does not imply a change in the burden of proof to the detriment of the customer.
To invoke this Guarantee, please contact the Gigaset Communications telephone service. The relevant number is to be
found in the accompanying user guide.
Exclusion of liability
Your handset's display consists of pixels. Each pixel consists of three sub-pixels (red, green, blue).
It may be the case that a sub-pixel is missing or has a colour deviation.
A warranty claim is only valid if the maximum number of permitted pixel errors is exceeded.
Description Maximum number of permitted pixel errors
Colour illuminated sub-pixels 1
Dark sub-pixels 1
Total number of coloured and dark sub-pixels 1
Signs of wear on the display and casing are excluded from the warranty.

16
Lombok A150-A150A-A250-A250A / BE-NL en / A31008-M2702-M201-1-3F19 / Lombok.fm / 22.08.2016
Version 4, 16.09.2005
Environment
Our environmental statement
We at Gigaset Communications GmbH are aware of our social responsibility. That is why we actively take steps to create
a better world. In all areas of our business – from product planning and production to sales and waste of disposal – fol-
lowing our environmental conscience in everything we do is of utmost importance to us.
Learn more about our earth-friendly products and processes online at www.gigaset.com.
Environmental management system
Gigaset Communications GmbH is certified pursuant to the international standards ISO 14001 and ISO 9001.
ISO 14001 (Environment): Certified since September 2007 by TÜV SÜD Management Service GmbH.
ISO 9001 (Quality): Certified since 17/02/1994 by TÜV SÜD Management Service GmbH.
Disposal
Batteries should not be disposed of in general household waste. Observe the local waste disposal regulations, details of
which can be obtained from your local authority.
All electrical and electronic products should be disposed of separately from the municipal waste stream via designated
collection facilities appointed by the government or the local authorities.
This crossed-out wheeled bin symbol on the product means the product is covered by the European Direc-
tive 2012/19/EU.
The correct disposal and separate collection of your old appliance will help prevent potential negative con-
sequences for the environment and human health. It is a precondition for reuse and recycling of used elec-
trical and electronic equipment.
For more detailed information about disposal of your old appliance, please contact your local council refuse centre or
the original supplier of the product.
Menu overview
Your phone has an extensive range of features. These are offered in the form of menus.
To select a function while the phone is in idle status, press MENU (open menu), use the control key uto scroll to the
function you require and press OK to confirm.
To return to idle status: press and hold the akey.
Not all of the functions described in this user guide are available in all countries.
Messages ¢S. 8
Alarm Clock
Activation ¢S. 11
Wake-up time ¢S. 11
Audio Settings
Handset Volume
(Gigaset A150/A150A) Can be set to one of 5 levels.
Handset Volume
(Gigaset A250/A250A) Earpiece/Speaker
Ringer Volume 5 levels + "crescendo" available.
Ringer Melody External Calls/Internal Calls/Alarm Clock
AdvisoryTones On/off
Battery Low On/off
Ring Tones On/off
Answer Machine
Play Messages Net Mailbox ** ¢S. 10
Answer Mach. ** ¢S. 8
Answer Mach. * ¢S. 8
CallScreening *Handset
(Gigaset A250A) Switch screening of a message that is being recorded on the handset (hands free mode; Prerequisite: at least 1 handset
with hands free capability is registered) or base station on/
off.
Deactivate screening for the actual recording only: press
end call key a.
Base
Announcements * Rec announce/Play announce/Del announce ¢S. 8
Message Length * Maximum/1 Minute/2 Minutes/3 Minutes

17
Lombok A150-A150A-A250-A250A / BE-NL en / A31008-M2702-M201-1-3F19 / Lombok.fm / 22.08.2016
Version 4, 16.09.2005
Ring Delay * Immediately/10 sec/18 sec/30 sec
Auto If there are no new messages, the answer machine answers
a call after 18 seconds. If new messages are present, the
answer machine answers a call after just 10 seconds.
Netw. Mailbox * ¢S. 10
Set Key 1 * Net Mailbox Assign key 1with network mailbox.
(In idle status, press and hold key 1to dial.)
¢S. 10
Answer Mach. Assign key 1with answer machine.
(In idle status, press and hold key 1to dial.)
¢S. 9
* Base station with answer machine only.
** Base station with answer machine only and if number of network mailbox is entered.
Settings
Date/Time ¢S. 5
Handset Language ¢S. 11
Auto Answer ¢S. 6
Register HS ¢S. 10
De-register HS ¢S. 10
Reset Handset ¢S. 12
Base Ringer Volume * 5 levels + „Crescendo“ + Off (level 0) selectable
Ringer Melody * 3 standard sounds and 3 melodies selectable
Call list type Missed Calls / All Calls ¢S. 8
System PIN Change System-PIN (default: 0000)
Base Reset ¢S. 12
Additional Repeater ¢S. 11
Echo mode see „Operating on the
router“¢S. 12
ECO DECT ¢S. 2 No Radiation on/off
Listening in ¢S. 11
Preselection Presel. Number/With Preselect/
Without Presel ¢S. 6
© Gigaset Communications GmbH 2016
Subject to availability. All rights reserved.
Rights of modification reserved.
www.gigaset.com
Issued by
Gigaset Communications GmbH
Frankenstr. 2a
D-46395 Bocholt
