Gigatek DSP840 User manual

TM951057
USB Display
**DSP840**
Installation Manual

Required Items
The following items are used to attach the Display to the Stand.
PILLAR C
DISK
SCREW BAG WAS-1522
PILLAR B
STAND
PILLAR A
EXTENSION SUPPORT (DSP840)
ACCESSORY UNIT (DSP840)
DISPLAY
1

Assembling Steps
1. Unlock the Screw to open the Stand Plate.
2. Place the Cable from the Display through the extension
pillars to the Stand.
When extending the height of the Stand, attach the extension
pillars with different heights: Low, Mid-low, Mid-high and
High shown as below to the Stand.
2
Pill
ar
B
Pill
ar
C
Pill
ar
A
Pill
ar
C
Pill
ar
B
Pil
l
ar
A
L
ow
Mid
-
l
ow
Mid
-
hi
g
h
Hi
g
h

3. Insert the tab on the Display (or the extension Pillar) into the
hole on the Stand until you feel it clicked.
4. Connect the cable from the Display to the XH connector
inside the Stand until you feel it clicked.
Also connect the enclosed USB cable to the “ USB ”
connector .
J1
JP4
3

5. Cover the Stand Plate back and fasten the screws.
Moun
the sp
ting hole to fit
ecial screw
6. You may use the enclosed mounting screws (one Special
screw and two Wood screws) to fix the Display on the
wooden table surface.
Get the Mounting hole on the Stand Plate to fit the Special
screw first and then fix the two Wood screws.
Wooden table surface
Special screw
Wood screw
4

The Display/Pillar/Stand Dimensions
Low
5

The Display/Pillar/Stand Dimensions
Low Mid-low Mid-high High
6
