GIZZU GSPK10W User manual

SOLAR PANEL
KIT 10W
GSPK10W
USER MANUAL
Thank you for purchasing this Gizzu product.
Before operating this product, please ensure that you read the user manual
carefully in order to make sure that the best possible performance is obtained.

The Gizzu Solar Panel Kit 10W has a compact design and provides a fully off the grid capable power
solution, which can be used almost anywhere. It operates as a great lighting solution thanks to the 3
LED lamps, but it can also be used to charge your mobile devices when your power source is
interrupted or non-existent.
In the box you will get the Gizzu Solar Panel Battery Unit itself, 1x 10W Solar Panel with 8m cable,3x
2.2W LED lamp with 5m cable and a 5-in-1 USB cable.
DESCRIPTION
1x Gizzu Solar Panel Battery Unit
1x 10W Solar Panel with 8m Cable
3x 2.2W LED Lamp with 5m cable
1x 5-in-1 USB Cable
Charging
Indicator
Reset Button
Working Status
Indicator
Battery Capacity Indicator
USB 5V Output LED 12.8V Output
Solar IN Switch
PACKAGE CONTENT
INSTRUCTIONS OF THE COMPONENTS
1
2
3
4
5
6
7
8
Solar Charge
Battery Status
Load Status
LED 12.8V Output
USB 5V Output
Switch
Solar IN
Reset
No. Item Function Description
Charging Indicator (Green)
Battery Status Indicator (Yellow)
Working Status Indicator (Red)
LED 12.8V Output Interface
USB 5V Output Interface
Power Switch
Power Charging Input Interface
Reset Button
Off: Not Charging.
Flash: Currently Charging.
On: Fully Charged.
Off: Power supply is working correctly.
Flash: Overload protection is on. (not working)
On: Low battery protection is on. (not working)
The Yellow LED light indicates how much power is left in the battery,
flashing when low.
Power interface for LED lights.
The rated output of each USB charging interface is 5V/1A.
Press the button to turn the device on.
Press the button again to turn the device off.
The solar panel cable is connected to this interface and the input DC voltage is
0~24V DC.
Use this button to reset the device and bring it back to factory settings.

1. The solar panels should be installed in the position where the sunlight can directly shine on them.
The luminious surface of the solar panels should be facing the sun as much as possible to maximise
energy absorption.
2. Place the power supply in an appropriate position indoors, pay attention to any moisture and avoid
direct sunlight. Connect the Solar panel cable into the Solar charging input interface.
3. Connect the LED bulb cable to the LED output interface.
4. Press the power switch to start the device. The charging indicator, battery status indicator; and
working status indicator should all go on for 1 second to conduct a power start-up self-check.
5. After the power start-up self-check is completed, The device will deliver power to the electrical
devices.
6. Use 5-in-1 USB cable to charge mobile devices
INSTALLATION
1. Working temperature: -10°C~50°C
2. 5~95% R.H. Working humidity: 5~95% R.H
Power Supply Unit
1. The power supply unit should be used indoors, in a dry environment and avoid direct exposure to
the sun.
2. Do not exceed the maximum voltage when connecting electrical appliances to the power supply
unit otherwise you risk damaging the unit and/or battery.
3. The electrical appliances and accessories included in this home system (including light bulbs, fans,
TVs and their connecting cables) are DC powered and thus cannot be connected to AC power
without risking injury.
4. The built-in battery of the power supply unit must be handled with care.
5. The power supply unit must be kept away from dangerous environments such as fires, hot objects
and flammable gases.
6. Keep the power input/output interface clean.
7. Before plugging in appliances into the output ports, make sure the battery is fully charged.
Solar Panel
1. There must be no combustible gases in the surrounding environment.
2. Do not touch the front and rear of the solar panel with sharp objects.
3. No trampling.
USAGE REQUIREMENTS

Do not open the power housing during cleaning and maintenance. Do not allow water to seep into the
power housing and the input-output interface.
Only the maintenance personnel designated and trained by the manufacturer can maintain the system
and make maintenance records.
MAINTENANCE
Battery
1. The battery is built into the power unit and cannot be open nor replaced. Only use the battery
provided by the manufacturer of this product to avoid damaging the unit or injury.
2. Do not short circuit the battery anode and cathode.
3. Batteries must be kept away from dangerous environments such as fires, hot objects and
flammable gases.
4. When using this device for the first time, please fully charge the battery before using it.
5. If the system is not used for a long time, it should be charged every three months to ensure the
battery activity.
Tips to avoid short circuiting
1. Only use with electrical appliances outlined in the product manual.
2. Do not insert foreign metal, water and other conductive objects into the input and output ports.
Parts Requirements
Clean the solar panel surface
Solar panel connecting cables It needs to be checked every three months. Check whether the cable is well connected, whether the connector is loose, whether
the cable is damaged etc.
It is usually cleaned once every two weeks. If there is obvious dust or other foreign matter on the surface of the solar panel,
please clean it before using it.

Check for general faults, such as short circuit protection, bad cable contact, loose screws etc. before
maintenance and then check the faults according to the following table.
TROUBLESHOOTING
Cause of the Fault Solution
Indicator Status
Fault Description
Electrical appliances
do not work
Electrical appliances
do not work
The battery doesn’t charge The charging indicator is off
Working status
indicator is always on Battery low power protection
Overload or electrical short circuit
The battery has reached its
service life or the battery has low
power protection
Poor connection of solar panels
or solar panels damaged.
The working status
indicator flashes
All the indicators
are not working
The battery needs to be charged. Check the
connection line of the solar panel to make the
power supply enter the charging state.
Check whether the output interface is
short-circuited; Remove all appliances,
power off and restart
Check the connecting cable of solar panels; Or
replace the solar panel.
Connect the solar panel to the power supply.
Press the RESET button in a small hole on the
front panel with a sharp object and hold it for 1
second to make the power supply enter the
charging state.
If the battery still cannot be charged, it may be a
power failure and will require repairs.

This warranty covers a product that proves defective because of improper material or workmanship
during the warranty period. Exclusions include problems caused by environmental conditions,
malfunctions or damage due to negligence or mishandling of the equipment. For warranty claims and
repair, please contact your local authorized reseller/service center.
SPECIFICATIONS
Model
Charging Time
Protection Features
Dimensions
Weight
GSPK10W
5 hours direct sunlight
Battery Capacity
Working Hours
4Ah/12.8Vdc (51.2Wh)
8hrs for 3x 2.2W LED Lamps
USB Outputs 2x 5V/1A
PV Module Type
PV Max Power
Polycrystalline Silicon
10W
PV Voltage
Battery Charging Voltage
18V
14.6V
Battery Cycle Performance 1000
LED Indicators
Lamp Power
Solar charging, battery power and load status
2.2W
Overcharge Protection
Overdischarge Protection
Overcurrent Protection
Short circuit Protection
PV Polarity Reverse Connection Protection
360x95x260cm
2.85kg
STATEMENT OF LIMITED WARRANTY
