Glacier bay GB333 User manual

THANK YOU
We appreciate the trust and condence you have placed in Glacier Bay through the purchase of this food waste
disposer. We strive to continually create quality products designed to enhance your home. Visit us online to see our
full line of products available for your home improvement needs. Thank you for choosing Glacier Bay!
IM-GB-231
USE AND CARE GUIDE
FOOD WASTE DISPOSER
Questions, problems, missing parts? Before returning to the store,
call Glacier Bay Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-GLACIER
HOMEDEPOT.COM/GLACIERBAY
Item #
1009 507 802
1009 507 805
1009 507 819
1009 507 829
Model # GB333
GB500
GB750-SL
GB1000-SL

2
Table of Contents
Safety Information.....................................................2
Warranty.....................................................................3
Pre-Installation..........................................................4
Planning Installation ..............................................4
Typical Installations ...............................................4
Tools Required .......................................................4
Package Contents ..................................................5
Installation.................................................................6
Operation..................................................................13
Continuous Feed ..................................................13
Tips For Successful Operation .............................13
Care and Cleaning ...................................................13
Troubleshooting .......................................................14
Recommended Parts and Accessories ...................15
Safety Information
INSTRUCTIONS PERTAINING TO A RISK
OF FIRE, ELECTRICSHOCK OR INJURY TO
PERSONS. SAVE THESE INSTRUCTIONS.
CAUTION: Be sure to review safety instructions
pertaining to a risk of re, electrical shock, or
injury to persons before using the disposer
When using electrical appliances, basic precautions should always be followed, including the following:
□Read all instructions before using the appliance.
□To reduce the risk of injury, close supervision
is necessary when an appliance is used near
children.
□Do not put ngers or hands into a waste disposer.
□Turn the power switch to the off position before
attempting to clear a jam or remove an object from
the disposer.
□When attempting to loosen a jam in a waste
disposer, use a long wooden object such as a
wooden spoon or the wooden handle of a broom
or mop.
□When attempting to remove objects from a waste
disposer use long-handled tongs or pliers. If the
disposer is magnetically actuated, non-magnetic
tools should be used.
□When not operating a disposer, leave the stopper in
place to reduce the risk of objects falling into the
disposer.
□DO NOT operate disposer unless splash guard is
in place.
□To reduce the risk of injury by materials that may
be expelled by a waste disposer, do not put the
following into a disposer: clam or oyster shells;
caustic drain cleaners or similar products; glass,
china or plastic; large whole bones; metal, such as
bottle caps, tin cans, aluminum foil or utensils; hot
grease or other hot liquids; whole corn husks.
□For proper grounding instructions see the electrical
connections portion of this manual.
□If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent, or
authorized person in order to avoid hazard.
□This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
□Children should be supervised to ensure that they
do not play with the appliance.

3 HOMEDEPOT.COM/GLACIERBAY
Please contact 1-855-HD-GLACIER for further assistance.
Warranty
Proof of purchase is required! Staple receipt or proof of purchase to this manual. Tracking is handled through
the serial number affixed to the bottom of the disposer and/or on the power cord label.
Conveniently record your model number and serial number on page 4 of this manual for your records. If you need
warranty service, call us toll-free at 1-833-240-6222. Have serial number and receipt available for the technician.
Warranty is non-transferable.
WARRANTY: Glacier Bay® disposers are warrantied when installed in the United States to be free from defects in
workmanship and material during the warranty period. This warranty sets forth our overall warranty commitment.
We will not assume, nor authorize any person to assume for us, any other liability in connection with the sale of our
products. Warranty only valid for product sold through authorized dealers/retailers.
LENGTH OF WARRANTY: 1/3 HP MODELS - 5 years from date of purchase. 1/2 HP MODELS - 6 years from date
of purchase. 3/4 HP MODELS - 10 years from date of purchase. 1 HP MODELS - 12 years from date of purchase.
Models that fail to operate during its warranty period, will be repaired or replaced. This Warranty includes In-Home
Warranty for Glacier Bay® models that fall into disrepair due to manufacturing defect. This warranty is limited to the
original purchaser. Original sales receipt required.
DEFECTIVE Disposer: During the warranty period, a defective or inoperative disposer will be replaced by the
company at no charge to the consumer/purchaser. Original sales receipt required. The warranty on the replacement
will be limited to the unexpired term of the warranty on the original disposer.
CHANGE OF OWNERSHIP Disposer: Warranty remains in force for warranty period from date of purchase of disposer
by the original retail customer. Warranty is non-transferable. Original sales receipt required.
MISUSE OF Disposer: This warranty does not apply to any disposer which is misused, altered, improperly installed
or used for anything other than normal residential use. Additional conditions not covered by the warranty are as
follows: Electrical connections due to improper installation; leaks at the sink ange, dishwasher inlet or discharge
elbow; damage by installer such as excessive torquing of screwed connections; incorrect operation such as
grinding nonfood waste; and jams.
HOW TO RECEIVE SERVICE: Contact our Customer Service department: Toll Free: (1-833-240-6222 ).
LIFETIME CORROSION WARRANTY: In addition to above warranty, any disposer that fails to operate because of
corrosion will be replaced. This Lifetime Corrosion warranty is limited to the original purchaser. Original sales
receipt is required.
MODEL NUMBER AND SERIAL NUMBER: The model number and serial number are located on the bottom serial
plate of your disposer and/or the power cord tag. Always reference the model number and serial number when
contacting customer service about any warranties on your disposer.
IMPLIED WARRANTIES: IMPLIED WARRANTIES, INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO WARRANTY PERIOD FROM THE DATE OF
PURCHASE. Some states do not allow limitations on how long an implied warranty lasts, so therefore the above
limitation may not apply to you.
CONSEQUENTIAL OR INCIDENTAL DAMAGES: THE COMPANY SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR
INCIDENTAL DAMAGES FOR ANY BREACH OF WARRANTY, EXPRESS OR IMPLIED. Some states do not allow the
exclusion or limitation of the consequential or incidental damages, so therefore the above exclusion may not apply
to you.
EXCLUSIVE REMEDY; CONSEQUENTIAL DAMAGES: The foregoing provisions state the exclusive remedy for any
breach of warranty, express or implied, TO THE EXTENT PERMITTED BY LAW, THE COMPANY SHALL NOT BE LIABLE
FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF WARRANTY, EXPRESS OR IMPLIED. Some states do
not allow the exclusion or limitation of consequential or incidental damages, so therefore the above exclusion may
not apply to you.

4
Pre-Installation
PLANNING INSTALLATION
CAUTION: Be sure to review safety instructions
pertaining to a risk of re, electrical shock, or injury to
persons before using the disposer.
IMPORTANT: Read all instructions carefully and
completely before starting. Keep this guide for future
reference.
NOTE: This food waste disposer has been
designed to operate on 110-120 Volt, 60 Hz
exclusively. Using any other voltage or Hz adversely
affects performance.
Record important disposer information here:
Model Number* Serial Number*
*Above information appears on the label afxed to bottom of the disposer. For your convenience, write down the
model and serial number prior to installation.
TYPICAL INSTALLATIONS
□Single bowl
□Double bowl center outlet
□Double bowl end outlet
For your specic disposer dimensions, contact
Glacier Bay customer service at 1-855-HD-GLACIER.
TOOLS REQUIRED
Flat head
screwdriver
Plumber’s
putty
SINGLE BOWL DOUBLE BOWL CENTER OUTLET DOUBLE BOWL END OUTLET

5 HOMEDEPOT.COM/GLACIERBAY
Please contact 1-855-HD-GLACIER for further assistance.
Pre-Installation (continued)
PACKAGE CONTENTS
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
Part Description
A Stopper
B Removable splash guard
C Sink ange
D Fiber gasket
E Support ange
F Upper mount ring
G Mount screws
H Retaining ring
I Cushion ring (pre-installed between upper
mount ring and lower mount ring)
J Lower mount ring* (pre-installed on the
disposer)
K Silver Guard®magnetic catch ring**
L Disposer
M Elbow ange and screw set
N Elbow
O Rubber gasket (pre-installed on elbow)
* Part not disengaged during disposer installation.
**Attachment included with 3/4 HP and 1 HP models.
NOTE: The enclosed screw set is required for
installation. Do not use previously installed screw set.
IMPORTANT: As the mounting assembly is properly
assembled at the factory, please pay close attention
to the order of the mounting system parts.

6
Installation
1 Disassembling the Disposer
Mounting Assembly
NOTE: The cushion ring and lower mount ring
will remain attached to the disposer during
installation.
IMPORTANT: Note the order of parts during
disassembly as they are arranged in the required
order.
□Disassemble the mounting assembly by
rotating the lower mount ring (J) clockwise
until the lower mount ring (J) tabs slide off
from the upper mount ring (F) ramp.
□Pull the sink ange (C) up and out of the
remaining lower mount assembly.
□Make note of the order of these parts as they
are arranged in the required order.
□Unscrew the three mount screws (G) until the
upper mount ring (F) can be moved to the top
of the support ange (E).
□Remove the retaining ring (H) with a at head
screwdriver.
□Keep the remaining parts placed together in
the order they were removed.
J
G
F
E
H
2 Preparing the Sink
IMPORTANT: This is a good time to clean out
the trap and drain lines by running a drain auger
or plumber’s snake before installing your new
disposer.
□Ensure that the sink is clean and thoroughly
dry.
□Load the underside rim of the sink ange (C)
with plumber’s putty (1).
□From the top of the sink, push the sink ange
(C) down against the sink opening to make a
good seal.
□Place a heavy object, such as the disposer, on
top of the sink ange (C) to hold it down. Place
the object on a towel to prevent scratching
the sink.
IMPORTANT: Do not move or rotate the sink
ange once it has been seated or the seal may
be broken.
C
C
1

7 HOMEDEPOT.COM/GLACIERBAY
Please contact 1-855-HD-GLACIER for further assistance.
Installation (continued)
3 Installing the Mounting
Assembly
□From under the sink, insert the ber gasket
(D), then the support ange (E), and then the
upper mount ring (F).
□Hold the three parts in place while attaching
the retaining ring (H) by pulling it apart and
having it snap within the groove of the sink
ange (C).
□Tighten the three mount screws (G) evenly and
rmly against the support ange (E). Do not
overtighten.
□Trim off any excess plumber’s putty in the sink
with a plastic knife or something similar that
will not damage your sink.
C
D
E
F
G
H
Top of
sink
Bottom
of sink
4 Preparing the Dishwasher
Connection
□Using a blunt instrument (2) (steel punch or
wooden dowel), knock out the entire plug. Do
not use a screwdriver or sharp instrument.
□When the knockout plug falls into the disposer,
you may remove it or grind it up when the
disposer is used. This will not damage the
disposer in any way, but it may take some time
to grind.
2

8
Installation (continued)
5 Attaching the Disposer
IMPORTANT: Before you connect the disposer
to the mount assembly under the sink, make sure
the lower mount ring is in place and the black
cushion ring is still engaged properly to the top of
the disposer hopper.
□Attach the disposer (L) to the upper mount
ring (F) by aligning the three mount tabs on
the lower mount ring (J) with the slide-up
ramps on the upper mount ring (F) and rotating
counterclockwise.
□The lower mounting ring (J), which is
preassembled on the disposer, has three
tabs(2) that grab the mounting ring ramp.
1. Points to the upper mount ring (F).
2. Is the tab that slides up onto the “ramp.”
3. Is the “ear” that is used to help rotate the
lower mount ring (J).
□Lift and turn the lower mount ring (J)
counterclockwise until all three mount tabs lock
over the ridges on the slide-up ramps of the
upper mount ring (F).
□As the lower mount ring (J) is turned
counterclockwise, each tab slides up onto the
upper mount ring (F) ramp (4) and locks into
position over the ridges (5).
NOTE: Use a screwdriver or hammer for leverage
if needed.
IMPORTANT: If the disposer needs to be
removed, tapping on the “ear” clockwise with a
hammer will easily loosen the lower mount ring.
4 5
1
2J
F
3
F

9 HOMEDEPOT.COM/GLACIERBAY
Please contact 1-855-HD-GLACIER for further assistance.
Installation (continued)
6 Mounting the Magnetic Catch
Ring (Included with 3/4 HP and
1 HP Models)
WARNING: This is not a toy. Keep uninstalled
magnetic catch ring away from children.
□After the disposer (L) is fully mounted to the
sink, guide the magnetic catch ring (K) through
the mount screws (G) with the at portion of the
black strap facing the metal sink ange(C).
□Place it between the support ange (E) and
upper mount ring (F).
NOTE: The ring must be placed under the ange
of the support ring.
□Once the magnetic catch ring (K) is tted, rmly
press on the snaps to secure the strap.
K
G
F
E
L
7 Attaching the Discharge Elbow
NOTE: The enclosed screw set is required for
installation. Do not use a previously installed
screw set.
□Connect the waste elbow (N) to the disposer
(L) by sliding the elbow ange (M) against the
preinstalled rubber gasket (O) on the elbow and
tightening the screws (M) into the disposer (L).
□Connect bottom of the elbow (N) by tightening
the slip nut. If using a straight pipe, it must have
a lip similar to the one on the elbow.
□Remove the gasket from the elbow (N) and
install it by ensuring the groove in the gasket
securely ts over the pipe lip.
□If you are not connecting to a dishwasher.
– Make sure all plumbing connections are
tight and in accordance with all plumbing
codes and ordinances.
– Run the water and check for leaks.
– Skip to Making the Electrical Connections
step.

10
Installation (continued)
8 Connecting the Dishwasher
Hose
□Connect the dishwasher hose (1) to the disposer
(L) using a hose clamp.
□Make sure all plumbing connections are tight
and in accordance with all plumbing codes and
ordinances.
□Run the water and check for leaks.
NOTE: An air gap (2) may not be required for all
installations. Check local plumbing codes.
2
1
L
9 Making the Electrical Connections Using Power Cord
□Connect the disposer to appropriate household
current only with the plug-in power cord.
WARNING: Improper connection of the
equipment grounding conductor can result in
a risk of electric shock. Check with a qualied
electrician or serviceman if you are in doubt as to
whether the appliance is properly grounded. Do
not modify the plug provided with the appliance
if it will not t the outlet. Have a proper outlet
installed by a qualied electrician.
IMPORTANT: The receptacle to which this
appliance is connected must be controlled by a
switch.
IMPORTANT: This appliance must be grounded.
In the event of a malfunction or breakdown,
grounding provides a path of least resistance
for electric current to reduce the risk of electric
shock. This appliance is equipped with a cord
having an equipment-grounding conductor and a
grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and
grounded in accordance with all local codes and
ordinances. If the supply cord is damaged, it must
be replaced by the manufacturer, its service agent,
or similarly qualied person in order to avoid a
hazard.

11 HOMEDEPOT.COM/GLACIERBAY
Please contact 1-855-HD-GLACIER for further assistance.
Installation (continued)
10 Removing Power Cord for Permanent Wiring
A. REMOVING THE END PLATE
□After turning off power supply,
unbolt the two nuts and remove
end plate.
B. REMOVING THE STRAIN
RELIEF CLIP
□Using a at head screwdriver
or needle nose pliers, remove
the clip from strain relief
portion of the cord.
C. CUTTING THE ELECTRIC
SUPPLY WIRES
□Using wire cutters, cut the
black (or brown) wire and
white (or blue) wire near the
connectors.
D. CUTTING THE GROUND WIRE
□Pull cord strain relief out of the
end bell. Cut the green ground
wire near the cord strain relief.
E. INSERTING STRAIN RELIEF
CONNECTOR
□Insert metal strain relief
connector (not included) into
the end bell hole and tighten
the nut securely.
F. STRIPPING THE WIRES
□Strip the green, black, and
white insulation from last
1/2in. of each wire.
G. INSERTING POWER SUPPLY
CABLE
□Insert the power supply
cable, coming from the wall
junction box, through the strain
relief connector. Tighten the
connector.
H. CONNECTING THE WIRES
□Connect disposer wire
leads (black and blue) to
corresponding wire leads of
the power supply cable. Green
always connects to green.
I. ATTACHING THE END PLATE
□Setting the wires into the end
bell, replace the end plate and
tighten the two bolts.

12
Installation (continued)
11 Making the Electrical Connections Using Permanent Wiring
WARNING: Electric shock hazard. Turn off
power before installing or servicing the disposer.
All wiring must comply with local electrical codes.
NOTE: Grounding: This disposer must be
connected to a grounded, metal, permanent wiring
system or an equipment-grounding conductor
must be run with the circuit conductors and
connected to the equipment grounding terminal or
lead on the disposer.
NOTE: An acceptable motor control switch with
a marked off position shall be provided at the time
of installation to disconnect the disposer from all
ungrounded supply conductors. The switch shall
be mounted in sight of the disposer or in sight of
the sink opening for the disposer.
NOTE: Do not connect electrical current at
main breaker panel until adequate ground is
established. Inadequate connection of the ground
wire can result in a risk of electric shock. Consult
with a certied electrician or tradesman if there
is any doubt whether the disposer is inadequately
grounded. Your disposer must be adequately
grounded.
□Turn off or disconnect all power to the wall
junction box serving the disposer.
□Open the junction box in the wall and remove the
wire nuts or electrical tape or whatever is tying
the old disposer wire to the electrical wire inside
of the junction box.
□Open the end bell plate at the bottom of the
disposer.
□If you are using exible armored (BX) cable:
– Install cable tting in the disposer end bell
hole.
– Secure the cable to the tting and install an
insulating bushing or equivalent.
– Connect white wire from the junction box to
the white (or blue) wire of the disposer.
– Connect black wire from the junction box to
the black (or brown) wire of the disposer.
– Connect bare ground wire from the junction
box to green ground screw within the
disposer end bell.
□If you are using non-metallic sheathed (ROMEX)
cable:
– Install cable tting in the end bell hole and
secure the cable to the tting.
– Connect white wire from the junction box to
the white (or blue) wire of the disposer.
– Connect black wire from the junction box to
the black (or brown) wire of the disposer.
– Connect bare ground wire from the junction
box to green ground screw within the
disposer end bell.
□If your power supply cable does not include a
grounding wire, one must be provided.
□Attach a copper wire securely to the disposer
ground screw and attach other end of ground
wire to a metal cold water pipe.
□Do not attach ground wire to a gas supply pipe.
□Use only UL Listed grounding clamp.
□If plastic pipe is used in your home, a qualied
electrician should install a proper ground.

13 HOMEDEPOT.COM/GLACIERBAY
Please contact 1-855-HD-GLACIER for further assistance.
Operation
CONTINUOUS FEED
NOTE: The anti-jam swivel impellers make a clicking
sound as they initially swing into place. This indicates
normal operation.
□Remove sink stopper. Turn on a medium ow of cold water.
□Turn switch to ON position; your motor is turning at full speed and ready to use.
□Scrape in food waste. Down the drain go table scraps, peelings, rinds, seeds, pits, small bones and coffee
grounds. To speed up food waste disposer, cut or break up large bones, rinds and cobs. Large bones and
brous waste require considerable grinding time and are more easily thrown away with other trash. Do not
be alarmed that the disposer slows down while grinding. The disposer is actually increasing torque (grinding
power) and is operating under normal conditions.
□Before turning disposer off, let water and disposer run for approximately 15 seconds after shredding or
grinding stops. This assures that all waste is thoroughly ushed through trap and drain.
□It is not recommended to use hot water while running disposer. Cold water will keep waste and fats solid so
disposer can ush away particles.
TIPS FOR SUCCESSFUL OPERATION
□Be sure disposer is empty before using your dishwasher so it may drain properly.
□You may want to leave the stopper in the sink drain when not in use to prevent utensils and foreign objects
from falling into the disposer.
□Your disposer is ruggedly built to give you many years of trouble-free service. It will handle all normal food
wastes, but it will NOT grind or dispose of such items as plastic, tin cans, bottle caps, glass, china, leather,
cloth, rubber, string, clam and oyster shells, aluminum foil, or feathers.
Care and Cleaning
IMPORTANT: Do not attempt to lubricate your disposer.
□The motor is permanently lubricated. The disposer is self-cleaning and scours its internal parts with each use.
□Never put lye or chemical drain cleaners into the disposer, as they cause serious corrosion of metal parts. If
used, resulting damage can be easily detected and all warranties are void.
□Mineral deposits from your water can form on the stainless-steel turntable, giving the appearance of rust. DO
NOT BE ALARMED, the stainless-steel turntables used will not corrode.
□Help keep your disposer free of odors by cleaning the underneath of the removable splash guard periodically.

14
Troubleshooting
Problem Possible Cause Solution
Loud noises (other than
those during grinding of
small bones and fruit pits).
These are usually caused
by accidental entry of a
spoon, bottle cap or other
foreign object.
□Turn off electrical switch and water.
□After disposer has stopped, remove splash guard,
remove object with long handled tongs, and
replace splash guard.
Unit does not start. There is a jam. □Unplug power cord or turn either the wall switch or
breaker box switch to “OFF” position, depending on
your model and wiring conguration.
□Remove stopper and/or splash guard.
□Check to see if turntable will rotate freely using a
wooden broom handle. If turntable rotates freely,
replace splash guard and check reset button to see
if it has been tripped.
The reset was tripped. □Reset button is red and located on the front of the
disposer.
□Push button in until it clicks and remains
depressed.
There is an electrical
short.
□If reset button has not been tripped, check for
shorted\or broken wire connecting to disposer.
□Check electrical power switch, fuse box or circuit
breaker. If wiring and electrical components are
intact, the unit may have internal problems that
require service or replacement.
Turntable does not rotate
freely.
There is a jam. □Turn off disposer, then check for any foreign object
lodged between the turntable and grind ring.
□Dislodge object by rotating table with a wooden
broom handle and remove object.
□If no foreign object is present, there may be
internal problems.
Unit leaks at the top. Improper seating of sink
ange (gasket centering,
putty or tightening).
□Adjust the seating of the sink ange.
Support ange not
tightened properly.
□Tighten the support ange.
Defective or improperly
installed cushion mount.
□Adjust the cushion mount installation or replace.
Unit leaks at the waste
elbow.
May be due to improper
tightening of elbow ange
screws.
□Tighten the elbow ange screws.

15 HOMEDEPOT.COM/GLACIERBAY
Please contact 1-855-HD-GLACIER for further assistance.
Recommended Parts and Accessories
Part Description
22-0003Q-00 3-Bolt Garbage Disposer Mount Fits Most Sinks
22-0002G-00 Removable Splash Guard For 3-Bolt Mount Disposers
20-MSAS-65-MW Single Outlet Air Switch For Disposers With Chrome Button
22-0003R-00 Extended Sink Flange With Extended Screws
22-MSELB-2 Outlet Elbow Kit (Elbow, Gasket, Flange, Flange Screws)
22-0001G-00 Stainless Steel Disposer Stopper
22-MSFGCM 3-Bolt Disposer Mount Ring and Fiber Gasket Kit

Questions, problems, missing parts? Before returning to the store,
call Glacier Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-GLACIER
HOMEDEPOT.COM/GLACIERBAY
Retain this manual for future use.
IM-GB-231
